Glass & Window System: Diagnosis Nissan Maxima A35

Windows 10 illustrations ~635 words

DUPLICATE THE NOISE AND TEST DRIVE

If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to duplicate the same conditions when you confirm the repair.

If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to duplicate the noise with the vehicle stopped by doing one or all of the following

  1. Close a door.
  2. Tap or push/pull around the area where the noise appears to be coming from.
  3. Rev the engine.
  4. Use a floor jack to recreate vehicle "twist".
  5. At idle, apply engine load (electrical load, half-clutch on M/T models, drive position on CVT and A/T models).
  6. Raise the vehicle on a hoist and hit a tire with a rubber hammer.
  1. Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
  2. If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the vehicle body.

Generic Squeak and Rattle Trouble Shooting

Refer to appropriate component for specific component removal and installation information.

INSPECT THE FUNCTION OF THE ANTI-PINCH SYSTEM

To inspect the anti-pinch system, refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : SPECIAL REPAIR REQUIREMENT ".

Scheme 266

Scheme 266: Exploded View

Scheme 267

Scheme 267

Scheme 268

Scheme 268

Scheme 269

Scheme 269
  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S42436787412011022800000) ".
  2. Remove the adhesive bolt hole covers.
  3. Reconnect the window switch to raise/lower the door glass until the door glass bolts (A) can be seen.
  4. Remove the door glass bolts (A).
  5. Raise the door glass and hold with a suction lifter (A).
  6. Disconnect the window motor connector (A).
  7. Remove the door module assembly mounting bolts.
  8. Remove the door module assembly.

INSPECTION AFTER REMOVAL

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

  1. Wire wear
  2. Regulator deformation
  3. Grease condition for each sliding part

Apply multi-purpose grease at the locations shown.

Scheme 270

Scheme 270

To inspect the anti-pinch system, refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : SPECIAL REPAIR REQUIREMENT ".

Scheme 271

Scheme 271: Exploded View

Scheme 272

Scheme 272: REMOVAL

Scheme 273

Scheme 273
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S39866662632011022800000) ".
  2. Position the vapor barrier aside.
  3. Temporarily reconnect the power window switch and raise/lower the door window until the glass bolts can be seen.
  4. Remove the glass bolts, and place the glass on the inner bottom of the panel.
  5. Remove the partition sash from the glass run.
  6. Remove the partition sash bolt (lower) and screw (upper) to remove the sash.
  7. Remove the partition glass and door glass from the inside of the panel.

FITTING INSPECTION

  1. Check that the glass is securely fit into the glass run groove.
  2. Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)], and check that the clearance to the sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts, guide rail bolts, and glass and carrier plate bolts to correct the glass position.

Scheme 274

Scheme 274

Scheme 275

Scheme 275
  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-388080-S39866662632011022800000) ".
  2. Position aside the vapor barrier.
  3. Temporarily reconnect the power window switch and raise/lower the door window until the glass bolts can be seen.
  4. Remove the glass bolts.
  5. Raise the door glass and hold with a suction lifter.
  6. Remove the bolts and the regulator and guide channel from the panel.
  7. Disconnect the connector from the regulator assembly.
  8. Remove the regulator assembly.

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

  1. Gear wear
  2. Regulator deformation
  3. Spring damage
  4. Grease contact areas for each sliding part
