DETAILED FLOW
- GET INFORMATION FOR SYMPTOM Get the detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurred). GO TO 2
- CHECK DTC WITH AUTOMATIC DRIVE POSITIONER SYSTEM Check "Self Diagnostic Result" with CONSULT-III. Refer to " «DTC INDEX»(ref-388077-S29513721372011022800000) ". Is any symptom described and any DTC displayed? Symptom is described, DTC is displayed. >> GO TO 3 Symptom is not described, DTC is displayed. >> GO TO 7 Symptom is described, DTC is not displayed. >> GO TO 4
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. GO TO 7
- CONFIRM THE SYMPTOM Try to confirm the symptom described by the customer. GO TO 5
- CHECK NORMAL OPERATING CONDITION Check normal operating condition. Refer to " «DESCRIPTION»(ref-388077-S26416799452011022800000) ". Is the incident normal operation? YES >> Inspection End. NO >> GO TO 6
- PERFORM BASIC INSPECTION Isolate the malfunctioning part with the basic inspection. Refer to " «PRELIMINARY CHECK»(ref-388077-S39438205812011022800000) ". GO TO 8
- PERFORM DTC CONFIRMATION PROCEDURE Perform the confirmation procedure for the detected DTC. Is the DTC displayed? YES >> GO TO 9 NO >> Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-388039-S29430263232011022800000) ".
- PERFORM COMPONENT FUNCTION CHECK Perform the component function check for the isolated malfunctioning part. GO TO 9
- DETECT MALFUNCTIONING PART BY DIAGNOSTIC PROCEDURE Isolate the malfunctioning part by performing the diagnosis procedure relevant to the symptom during the component diagnosis. GO TO 10
- REPAIR OR REPLACE Repair or replace the malfunctioning part. GO TO 11
- FINAL CHECK Perform the DTC confirmation procedure (if DTC is detected) or component function check (if no DTC is detected) again, and then check that the malfunction can be repaired securely. Are all malfunctions corrected? YES >> Inspection End. Symptom is detected. >> GO TO 4 DTC is detected. >> GO TO 7
Preliminary Check
- FOREIGN OBJECTS Check the following: objects on or behind the seats that could cause binding objects under the seats that may be interfering with the seat's moving parts objects under pedals that may interfere with movement Are there any foreign objects that could be causing interference? YES >> Remove objects. NO >> GO TO 2
- WIRING CONNECTIONS Disconnect harness connectors. Check terminals for damage or loose connections. Reconnect harness connectors. Are any connectors damaged or loose? YES >> Repair or replace damaged parts. NO >> GO TO 3
- POWER AND GROUND Check power supply and ground circuits for control unit. Refer to " «DRIVER SEAT CONTROL UNIT : DIAGNOSIS PROCEDURE»(ref-388077-S12269009592011022800000) ". Is the inspection result normal? YES >> Refer to " «DTC INDEX»(ref-388077-S29513721372011022800000) ". NO >> Repair or replace as necessary.
Special Repair Requirement
Refer to Owner's Information for Automatic Drive Positioner system operating instructions.
Scheme 220
OUTLINE
The system automatically moves the driver seat, steering column and door mirror position by the driver seat control unit and the automatic drive positioner control unit. The driver seat control unit corresponds with the automatic drive positioner control unit by UART communication.
| Function | Description | |
|---|---|---|
| Manual function | The driving position (seat, steering column and door mirror position) can be adjusted by using the power seat switch, ADP steering switch or door mirror remote control switch. | |
| Memory function | The seat, steering column and door mirror move to the stored driving position by pressing seat memory switch (1 or 2). | |
| Entry/Exit assist function | Exit | On exit, the seat moves backward and the steering column moves upward. |
| Entry | On entry, the seat and steering column returns from exiting position to the previous driving position. | |
| Intelligent Key interlock function | Perform memory operation, exiting operation and entry operation by Intelligent Key unlock operation or driver side door request switch unlock operation. | |
SYSTEM DESCRIPTION CHART
Note. The lumbar support system is controlled independently with no link to the automatic drive positioner system.
Scheme 221
CONTROL UNITS
| Item | Function |
|---|---|
| Driver seat control unit | Main unit of automatic drive positioner system It is connected to the CAN. It communicates with the automatic drive positioner control unit via UART communication. |
| Automatic drive positioner control unit | It communicates with the driver seat control unit via UART communication. Perform various controls with the instructions of driver seat control unit. Perform the controls of the pedal adjusting, door mirror and the seat memory switch. |
| BCM | Transmits the following status to the driver seat control unit via CAN communication. Front door LH: OPEN/CLOSE Ignition switch position: ACC/ON Door lock: UNLOCK (with Intelligent Key or remote keyless entry request switch operation) Key ID Key switch: Insert/Pull out Intelligent Key Starter: CRANKING/OTHER |
| Combination meter | Transmits the vehicle speed signal to the driver seat control unit via CAN communication. |
| AV control unit | The setting change of auto drive positioner system can be performed on the display. |
| TCM | Transmits the shift position signal (P range) to the driver seat control unit via CAN communication. |
COMPONENT DESCRIPTION CHART
INPUT PARTS
Switches
| Item | Function |
|---|---|
| Key slot | The key switch is installed to detect the key inserted/removed status. |
| Front door switch LH | Detect front door (driver side) open/close status. |
| Transmission range switch (built into CVT control valve assembly) | Detect the P range position of CVT selector lever. |
| Set switch | The registration and system setting can be performed with its operation. |
| Seat memory switch 1/2 | The registration and operation can be performed with its operation. |
| Power seat switch | The following switch is installed. Reclining switch Lifting switch (front) Lifting switch (rear) Sliding switch The specific parts can be operated with the operation of each switch. |
| ADP steering switch | The following switch is installed. Tilt switch Telescopic switch The specific parts can be operated with the operation of each switch. |
| Door mirror remote control switch | The following switch is installed. Mirror switch Changeover switch The specific parts can be operated with the operation of each switch. |
COMPONENT DESCRIPTION CHART
Sensors
| Item | Function |
|---|---|
| Door mirror sensor (LH/RH) | Detect the up/down and left/right position of outside mirror face. |
| Tilt and telescopic sensors | Detect the up/down and front/rear position of steering column. |
| Lifting sensor (front) | Detect the up/down position of seat lifting (front). |
| Lifting sensor (rear) | Detect the up/down position of seat lifting (rear). |
| Reclining sensor | Detect the tilt of seatback. |
| Sliding sensor | Detect the front/rear position of seat. |
COMPONENT DESCRIPTION CHART
OUTPUT PARTS
| Item | Function |
|---|---|
| Door mirror motor (LH/RH) | Move the outside mirror face up/down and left/right. |
| Tilt and telescopic motors | Move the steering column up/down and front/rear. |
| Lifting motor (front) | Move the seat lifting (front) up/down. |
| Lifting motor (rear) | Move the seat lifting (rear) up/down. |
| Reclining motor | Tilt and raise up the seatback. |
| Sliding motor | Slide the seat forward/backward. |
| Seat memory indicator | Illuminates or flashes according to the registration/operation status. |
COMPONENT DESCRIPTION CHART
Scheme 222
The driving position (seat, steering column and door mirror position) can be adjusted manually with power seat switch, ADP steering switch and door mirror remote control switch.
DETAIL FLOW
Seat
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Power seat switch (sliding, lifting, reclining) | The power seat switch signal is inputted to the driver seat control unit when the power seat switch is operated. | |
| 2 | Motors (sliding, lifting, reclining) | The driver seat control unit outputs signals to each motor according to the power seat switch input signal. |
COMPONENT DESCRIPTION CHART
Tilt and Telescopic
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | ADP steering switch | The ADP steering switch signal is input to the automatic drive positioner control unit when the ADP steering switch is operated. | |
| 2 | Motors (tilt, telescopic) | The automatic drive positioner control unit actuates the motors according to the operation of the ADP steering switch signal. | |
| 3 | Sensors (tilt, telescopic) | The automatic drive positioner control unit recognizes any operation limit of each actuator via each sensor and will not operate the motors anymore at that time. |
COMPONENT DESCRIPTION CHART
Door Mirror
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Door mirror remote control switch | The door mirror remote control switch signal is inputted to the automatic drive positioner control unit when the door mirror remote control switch is operated. | |
| 2 | Motors (Door mirror motor) | The automatic drive positioner control unit actuates each motor according to the operation of the door mirror remote control switch. |
COMPONENT DESCRIPTION CHART
Note. The door mirrors can be operated manually when ignition switch is in either ACC or ON position. The ignition switch signal (ACC/ON) is transmitted from BCM to the driver seat control unit via CAN communication and from the driver seat control unit to the automatic drive positioner control unit via UART communication.
Scheme 223
| Item | Function |
|---|---|
| Driver seat control unit | Operates the specific seat motor with the signal from the power seat switch. Transmits the ignition switch signal (ACC/ON) via UART communication to the automatic drive positioner control unit. |
| Automatic drive positioner control unit | Operates the specific motor with the signal from ADP steering switch or door mirror remote control switch. |
| BCM | Recognizes the following status and transmits it to the driver seat control unit via CAN communication. Ignition position: ACC/ON |
COMPONENT DESCRIPTION CHART
Switches
| Item | Function |
|---|---|
| Power seat switch | The following switch is installed. Reclining switch Lifting switch (front) Lifting switch (rear) Sliding switch The specific parts can be operated with the operation of each switch. |
| ADP steering switch | The following switch is installed. Tilt switch Telescopic switch The specific parts can be operated with the operation of each switch. |
| Door mirror remote control switch | The following switch is installed. Mirror switch Changeover switch The specific parts can be operated with the operation of each switch. |
COMPONENT DESCRIPTION CHART
Sensors
| Item | Function |
|---|---|
| Tilt and telescopic sensors | Detect the up/down and front/back position of steering column. |
COMPONENT DESCRIPTION CHART
| Item | Function |
|---|---|
| Door mirror motor (LH/RH) | Move the outside mirror face up/down and left/right. |
| Tilt and telescopic motors | Move the steering column up/down and front/back. |
| Lifting motor (front) | Move the seat lifter (front) up/down. |
| Lifting motor (rear) | Move the seat lifter (rear) up/down. |
| Reclining motor | Tilt and raise up the seatback. |
| Sliding motor | Slide the seat forward/backward. |
COMPONENT DESCRIPTION CHART
Scheme 224
The driver seat control unit can store the optimum driving positions (seat, steering column and door mirror position) for 2 people. If the front seat position is changed, one-touch (pressing desired memory switch) operation allows changing to the other driving position.
Note. Further information for the memory storage procedure. Refer to Owner's Information.
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Memory switch | The memory switch signal is inputted to the automatic drive positioner control unit when memory switch 1 or 2 is operated. Memory switch signal is input to driver seat control unit via UART communication. | |
| 2 | Motors (seat, steering, door mirror) | Driver seat control unit operates each motor of seat when it recognizes the memory switch pressed and requests each motor operation to automatic drive positioner control unit via UART communication. The automatic drive positioner control unit operates each motor. | |
| Memory switch Indicator | Driver seat control unit requests the flashing of memory indicator to automatic drive positioner control unit via UART communication while either of the motors is operating. The automatic drive positioner control unit illuminates the memory indicator. | ||
| 3 | Sensors (seat, steering column, door mirrors) | Driver seat control unit judges the operating seat position with each seat sensor input. The positions of the steering column and outside mirrors are monitored with each sensor signal that is input from auto drive positioner control unit via UART communication. Driver seat control unit stops the operation of each motor when each part reaches the recorded address. | |
| 4 | Memory switch Indicator | Driver seat control unit requests the illumination of memory indicator to auto drive positioner control unit via UART communication after all motors stop. The auto driving positioner control unit illuminates the memory indicator for 5 seconds. |
COMPONENT DESCRIPTION CHART
Scheme 225
| Item | Function |
|---|---|
| Driver seat control unit | The address of each part is recorded. Operates each motor of seat to the registered position. Requests the operations of steering column and door mirrors to automatic drive positioner control unit |
| Automatic drive positioner control unit | Operates the steering column and door mirrors with the instructions from the driver seat control unit. |
COMPONENT DESCRIPTION CHART
Switches
| Item | Function |
|---|---|
| Memory switch 1/2 | The registration and memory function can be performed with its operation. |
COMPONENT DESCRIPTION CHART
Sensors
| Item | Function |
|---|---|
| Door mirror sensor (LH/RH) | Detect the up/down and left/right position of outside mirror face. |
| Tilt and telescopic sensors | Detect the up/down and front/rear position of steering column. |
| Lifting sensor (front) | Detect the up/down position of seat lifting (front). |
| Lifting sensor (rear) | Detect the up/down position of seat lifting (rear). |
| Reclining sensor | Detect the tilt of seatback. |
| Sliding sensor | Detect the front/rear position of seat. |
COMPONENT DESCRIPTION CHART
| Item | Function |
|---|---|
| Door mirror motor (LH/RH) | Move the outside mirror face upward/downward and leftward/rightward. |
| Tilt and telescopic motors | Move the steering column up/down and front/rear. |
| Lifting motor (front) | Move the seat lifter (front) upward/downward. |
| Lifting motor (rear) | Move the seat lifter (rear) upward/downward. |
| Reclining motor | Tilt and raise up the seatback. |
| Sliding motor | Slide the seat forward/backward. |
| Memory indicator | Illuminates or blinks according to the registration/operation status. |
COMPONENT DESCRIPTION CHART
Scheme 226
When exiting, if the conditions are satisfied, the seat is moved backward from normal sitting position and the steering column is moved up.
The seat slide amount at entry/exit operation can be changed.
Note. This function is set to ON before delivery (initial setting). Further information for the system setting procedure. Refer to Owner's Information.
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Front door switch LH | Driver seat control unit receives front door switch LH signal (open) from BCM via CAN communication. | |
| 2 | Motors (seat sliding, tilt) | Driver seat control unit operates the seat sliding motor, which recognizes that the driver side door is opened with ignition switch OFF. Driver seat control unit then requests the operations of tilt motor to auto drive positioner control unit via UART communication. The automatic drive positioner control unit operates each motor for a constant amount. |
COMPONENT DESCRIPTION CHART
Scheme 227
| Item | Function |
|---|---|
| Driver seat control unit | Operates the seat sliding motor for a constant amount. Requests operation of the tilt motor from the automatic drive positioner control unit. |
| Automatic drive positioner control unit | Operates the tilt motor with the request from the driver seat control unit. |
| BCM | Recognizes the following status and transmits it to the driver seat control unit via CAN communication. Front door LH: OPEN/CLOSE Key switch signal Ignition switch signal |
COMPONENT DESCRIPTION CHART
Switches
| Item | Function |
|---|---|
| Front door switch LH | Detect front door LH open/close status. |
COMPONENT DESCRIPTION CHART
Sensors
| Item | Function |
|---|---|
| Tilt sensor | Detect the up/down position of steering column. |
| Sliding sensor | Detect the front/rear position of seat. |
COMPONENT DESCRIPTION CHART
| Item | Function |
|---|---|
| Tilt motor | Move the steering column up/down. |
| Sliding motor | Slide the seat forward/backward. |
COMPONENT DESCRIPTION CHART
Scheme 228
The seat is in the exiting position when either following condition is satisfied, the seat returns from exiting position to the previous driving position.
Note. This function is set to OFF before delivery (initial setting). Further information for the system setting procedure. Refer to Owner's Information.
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Door switch/Ignition switch | Driver seat control unit receives the signals of ignition switch signal and front door switch from BCM via CAN communication. | |
| 2 | Motors (sliding, tilt) | Driver seat control unit operates the sliding motor when the operating conditions are satisfied and requests the operation of tilt motor to automatic drive positioner control unit via UART communication. The automatic drive positioner control unit operates the tilt motor. | |
| Sensors (sliding, tilt) | Each sensor monitors the operating positions of seat and steering column, then stops the operation of motor when each part reaches the recorded address. |
COMPONENT DESCRIPTION CHART
Scheme 229
| Item | Function |
|---|---|
| Driver seat control unit | According to the ignition signal and front door switch LH signal from BCM, Operates the seat sliding motor for a constant amount. Requests the operation of tilt motor to automatic drive positioner control unit. |
| Automatic drive positioner control unit | Operates the tilt motor with the instructions from the driver seat control unit. |
| BCM | Recognizes the following status and transmits it to the driver seat control unit via CAN communication. Front door LH: OPEN/CLOSE Ignition switch position: ACC/ON |
COMPONENT DESCRIPTION CHART
Switches
| Item | Function |
|---|---|
| Front door switch LH | Detect front door LH open/close status. |
COMPONENT DESCRIPTION CHART
Sensors
| Item | Function |
|---|---|
| Tilt sensor | Detect the up/down position of steering column. |
| Sliding sensor | Detect the front/rear position of seat. |
COMPONENT DESCRIPTION CHART
| Item | Function |
|---|---|
| Tilt motor | Move the steering column up/down. |
| Sliding motor | Slide the seat forward/backward. |
COMPONENT DESCRIPTION CHART
Scheme 230
When unlocking doors by using Intelligent Key or door request switch (driver side), seat slide and steering tilt move directly to the exit assist function.
Other loads move to the exit assist function after performing memory function.
Then performs the entry assist function.
| Order | Input | Output | Control unit condition |
|---|---|---|---|
| 1 | Door unlock signal (CAN) Key ID signal (CAN) | Driver seat control unit receives the door unlock signal and the key ID signal from BCM when unlocking the door with Intelligent Key or driver side door request switch. | |
| 2 | Driver seat control unit performs the seat slide and steering tilt move directly to the exit assist function. Other loads move to the exit assist function after performing memory function. | ||
| 3 | Driver seat control unit performs the entry assist function. |
COMPONENT DESCRIPTION CHART
Scheme 231
| Item | Function |
|---|---|
| Driver seat control unit | It performs memory function and entry/exit assist function after receiving the door unlock signal from BCM. |
| Automatic drive positioner control unit | Operates the steering column and door mirrors with the instructions from the driver seat control unit. |
| BCM | Recognizes the following status and transmits it to the driver seat control unit via CAN communication. Door lock: UNLOCK (with Intelligent Key or driver side door request switch) Key ID signal Ignition switch signal |
COMPONENT DESCRIPTION CHART
DATA MONITOR
| Monitor Item | Unit | Main Signals | Selection From Menu | Contents |
|---|---|---|---|---|
| SET SW | "ON/OFF" | X | X | ON/OFF status judged from the setting switch signal. |
| MEMORY SW1 | "ON/OFF" | X | X | ON/OFF status judged from the seat memory switch 1 signal. |
| MEMORY SW2 | "ON/OFF" | X | X | ON/OFF status judged from the seat memory switch 2 signal. |
| SLIDE SW-FR | "ON/OFF" | X | X | ON/OFF status judged from the sliding switch (forward) signal. |
| SLIDE SW-RR | "ON/OFF" | X | X | ON/OFF status judged from the sliding switch (backward) signal. |
| RECLN SW-FR | "ON/OFF" | X | X | ON/OFF status judged from the reclining switch (forward) signal. |
| RECLN SW-RR | "ON/OFF" | X | X | ON/OFF status judged from the reclining switch (backward) signal. |
| LIFT FR SW-UP | "ON/OFF" | X | X | ON/OFF status judged from the lifting switch front (up) signal. |
| LIFT FR SW-DN | "ON/OFF" | X | X | ON/OFF status judged from the lifting switch front (down) signal. |
| LIFT RR SW-UP | "ON/OFF" | X | X | ON/OFF status judged from the lifting switch rear (up) signal. |
| LIFT RR SW-DN | "ON/OFF" | X | X | ON/OFF status judged from the lifting switch rear (down) signal. |
| MIR CON SW-UP | "ON/OFF" | X | X | ON/OFF status judged from the mirror switch (up) signal. |
| MIR CON SW-DN | "ON/OFF" | X | X | ON/OFF status judged from the mirror switch (down) signal. |
| MIR CON SW-RH | "ON/OFF" | X | X | ON/OFF status judged from the door mirror remote control switch (passenger side) signal. |
| MIR CON SW-LH | "ON/OFF" | X | X | ON/OFF status judged from the door mirror remote control switch (driver side) signal. |
| MIR CHNG SW-R | "ON/OFF" | X | X | ON/OFF status judged from the door mirror remote control switch (switching to right) signal. |
| MIR CHNG SW-L | "ON/OFF" | X | X | ON/OFF status judged from the door mirror remote control switch (switching to left) signal. |
| TILT SW-UP | "ON/OFF" | X | X | ON/OFF status judged from the ADP steering switch (up) signal. |
| TILT SW-DOWN | "ON/OFF" | X | X | ON/OFF status judged from the ADP steering switch (down) signal. |
| TELESCO SW-FR | "ON/OFF" | X | X | ON/OFF status judged from the ADP steering switch (forward) signal. |
| TELESCO SW-RR | "ON/OFF" | X | X | ON/OFF status judged from the ADP steering switch (backward) signal. |
| DETENT SW | "ON/OFF" | X | X | The selector lever position "OFF (P position) / ON (other than P position)" judged from the detention switch signal. |
| STARTER SW | "ON/OFF" | X | X | Ignition key switch ON (START, ON) /OFF (ACC, OFF) status judged from the ignition switch signal. |
| SLIDE PULSE | X | Value (32768) when battery connections are standard. If it moves backward, the value increases. If it moves forward, the value decreases. | ||
| RECLN PULSE | X | Value (32768) when battery connections are standard. If it moves backward, the value increases. If it moves forward, the value decreases. | ||
| LIFT FR PULSE | X | Value (32768) when battery connections are standard. If it moves DOWN, the value increases. If it moves UP, the value decreases. | ||
| LIFT RR PULSE | X | Value (32768) when battery connections are standard. If it moves DOWN, the value increases. If it moves UP, the value decreases. | ||
| MIR/SEN RH U-D | "V" | X | Voltage input from door mirror sensor (passenger side) up/down is displayed. | |
| MIR/SEN RH R-L | "V" | X | Voltage input from door mirror sensor (passenger side) left/right is displayed. | |
| MIR/SEN LH U-D | "V" | X | Voltage input from door mirror sensor (driver side) up/down is displayed. | |
| MIR/SEN LH R-L | "V" | X | Voltage input from door mirror sensor (driver side) left/right is displayed. | |
| TILT PULSE | X | Value (32768) when battery connections are standard. If it moves DOWN, the value increases. If it moves UP, the value decreases. | ||
| TELESCO PULSE | X | Value (32768) when battery connections are standard. If it moves backward, the value increases. If it moves forward, the value decreases. | ||
| VEHICLE SPEED | X | X | Display the vehicle speed signal received from combination meter by numerical value [km/h]. | |
| P RANG SW CAN | "ON/OFF" | X | X | ON/OFF status judged from the P range switch signal. |
| R RANGE (CAN) | "ON/OFF" | X | X | ON/OFF status judged from the R range switch signal. |
| DOOR SW-FL "OPEN/ | CLOSED" | X | X | ON/OFF status judged from the door switch (front driver side) signal. |
| DOOR SW-FR "OPEN/ | CLOSED" | X | X | ON/OFF status judged from the door switch (front passenger side) signal. |
| IGN ON SW | "ON/OFF" | X | X | ON/OFF status judged from the ignition switch signal. |
| ACC ON SW | "ON/OFF" | X | X | ON/OFF status judged from the ACC switch signal. |
| KEY ON SW | "ON/OFF" | X | X | ON/OFF status judged from the key on switch signal. |
| KEYLESS ID | X | X | Key ID status judged from the key ID signal. | |
| KYLS DR UNLK | "ON/OFF" | X | X | ON/OFF status judged from the driver side door unlock actuator output switch signal. |
| VHCL SPEED (ABS) | "RCV" | X | X | Vehicle speed status judged from vehicle speed signal. |
| HANDLE | "RHD/LHD" | X | X | RHD/LHD status judged from handle position signal. |
| TRANSMISSION | "A/T" | X | X | CVT status judged from transmission. |
DATA MONITOR CHART
WORK SUPPORT
| Work item | Content | Item |
|---|---|---|
| SEAT SLIDE VOLUME SET | The amount of seat sliding for entry/exit assist can be selected from 3 items. | 40 mm (1.6 in) |
| 80 mm (3.1 in) | ||
| 150 mm (6 in) | ||
| EXIT TILT SETTING | Entry/exit assist (steering column) can be selected: ON (operated) - OFF (not operated) | ON |
| OFF | ||
| EXIT SEAT SLIDE SETTING | Entry/exit assist (seat) can be selected: ON (operated) - OFF (not operated) | ON |
| OFF |
WORK SUPPORT CHART
Refer to Owner's Information.
DRIVER SEAT CONTROL UNIT : Special Repair Requirement
- PERFORM ADDITIONAL SERVICE Perform additional service when removing battery negative terminal. Refer to Owner's Information.
Note. Do not disconnect the battery negative terminal and the driver seat control unit connector until DTC is confirmed with CONSULT-III.
Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".
Scheme 232
Scheme 233
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect automatic drive positioner control unit. Check voltage between automatic drive positioner control unit harness connector and ground. CONNECTOR TERMINAL REFERENCE CHART Terminals Voltage (V) (Approx.) (+) (-) Automatic drive positioner control unit connector Terminal M67 25 Ground Battery voltage Is the inspection result normal? YES >> GO TO 2 NO >> Repair or replace harness.
- CHECK GROUND CIRCUIT Check continuity between the automatic drive positioner control unit harness connector and ground. CONNECTOR TERMINAL REFERENCE CHART Automatic drive positioner control unit connector Terminal Ground Continuity M67 30 Yes Is the inspection result normal? YES >> Automatic drive positioner control unit power supply and ground circuit are OK. NO >> Repair or replace harness.
- PERFORM ADDITIONAL SERVICE Perform additional service when removing battery negative terminal. Refer to Owner's Information.
Component Function Check
- CHECK FUNCTION Select "SLIDE SW-FR", "SLIDE SW-RR" in "Data monitor" mode with CONSULT-III. Check sliding switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status SLIDE SW-FR Sliding switch (forward) Operate ON Release OFF SLIDE SW-RR Sliding switch (backward) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S20236797122011022800000) ".
- CHECK FUNCTION Select "RECLN SW-FR", "RECLN SW-RR" in "Data monitor" mode with CONSULT-III. Check reclining switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status RECLN SW-FR Reclining switch (forward) Operate ON Release OFF RECLN SW-RR Reclining switch (backward) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S19312555412011022800000) ".
- CHECK FUNCTION Select "LIFT FR SW-UP", "LIFT FR SW-DN" in "DATA MONITOR" mode with CONSULT-III. Check lifting switch (front) signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status LIFT FR SW-UP Lifting switch front (up) Operate ON Release OFF LIFT FR SW-DN Lifting switch front (down) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S00212274992011022800000) ".
- CHECK FUNCTION Select "LIFT RR SW-UP", "LIFT RR SW-DN" in "Data monitor" mode with CONSULT-III. Check lifting switch (rear) signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status LIFT RR SW-UP Lifting switch rear (up) Operate ON Release OFF LIFT RR SW-DN Lifting switch rear (down) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S18934859192011022800000) ".
- CHECK FUNCTION Select "TILT SW-UP", "TILT SW-DOWN" in "Data monitor" mode with CONSULT-III. Check tilt switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status TILT SW-UP Tilt switch (up) Operate ON Release OFF TILT SW-DOWN Tilt switch (down) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S33050668662011022800000) ".
- CHECK FUNCTION Select "TELESCO SW-FR", "TELESCO SW-RR" in "Data monitor" mode with CONSULT-III. Check telescopic switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status TELESCO SW-FR Telescopic switch (forward) Operate ON Release OFF TELESCO SW-RR Telescopic switch (backward) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S33124860172011022800000) ".
- CHECK FUNCTION Select "MEMORY SW 1", "MEMORY SW 2", "SET SW" in "Data monitor" mode with CONSULT-III. Check seat memory switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status MEMORY SW 1 Memory switch 1 Push ON Release OFF MEMORY SW 2 Memory switch 2 Push ON Release OFF SET SW Set switch Push ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S26118339002011022800000) ".
CHANGEOVER SWITCH : Component Function Check
- CHECK FUNCTION Select "MIR CHNG SW-R", "MIR CHNG SW-L" in "Data monitor" mode with CONSULT-III. Check tilt switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status MIR CHNG SW-R Mirror switch (right) Operate ON Release OFF MIR CHNG SW-L Mirror switch (left) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «CHANGEOVER SWITCH : DIAGNOSIS PROCEDURE»(ref-388077-S15730793132011022800000) ".
MIRROR SWITCH : Component Function Check
- CHECK FUNCTION Select "MIR CON SW-UP/DN", "MIR CON SW-RH/LH" in "Data monitor" mode with CONSULT-III. Check tilt switch signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status MIR CON SW-UP/DN Mirror switch (up/down) Operate ON Release OFF MIR CON SW-RH/LH Mirror switch (right/left) Operate ON Release OFF Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «MIRROR SWITCH : DIAGNOSIS PROCEDURE»(ref-388077-S06722706492011022800000) ".
- CHECK FUNCTION Select "DOOR SW-FL" in "Data monitor" mode with CONSULT-III. Check the front door switch LH signal under the following conditions. DATA MONITOR CHART Monitor item Condition Status DOOR SW-FL Front door switch LH Open ON Close OFF Is the inspection result normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S13766954012011022800000) ".
- CHECK FUNCTION Select "SLIDE PULSE" in "Data monitor" mode with CONSULT-III. Check sliding sensor signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value SLIDE PULSE Seat sliding Operate (forward) Change (decrease) Operate (backward) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S29573164902011022800000) ".
- CHECK FUNCTION Select "RECLN PULSE" in "Data monitor" mode with CONSULT-III. Check reclining sensor signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value RECLN PULSE Seat reclining Operate (forward) Change (decrease) Operate (backward) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S26133432372011022800000) ".
- CHECK FUNCTION Select "LIFT FR PULSE" in "Data monitor" mode with CONSULT-III. Check the lifting sensor (front) signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value LIFT FR PULSE Seat lifting (front) Operate (up) Change (decrease) Operate (down) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S35800608432011022800000) ".
- CHECK FUNCTION Select "LIFT RR PULSE" in "Data monitor" mode with CONSULT-III. Check lifting sensor (rear) signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value LIFT RR PULSE Seat lifting (rear) Operate (up) Change (decrease) Operate (down) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S41859810052011022800000) ".
- CHECK FUNCTION Select "TILT PULSE" in "Data monitor" mode with CONSULT-III. Check tilt sensor signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value TILT PULSE Steering column Operate (UP-WARD) Change (decrease) Operate (DOWN-WARD) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S33050668662011022800000) ".
- CHECK FUNCTION Select "TELESCO PULSE" in "Data monitor" mode with CONSULT-III. Check telescopic sensor signal under the following conditions. DATA MONITOR CHART Monitor item Condition Valve TELESCO PULSE Steering column Operate (forward) Change (decrease) Operate (backward) Change (increase) Release No change Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S41607815422011022800000) ".
DRIVER SIDE : Component Function Check
- CHECK FUNCTION Select "MIR/SEN LH U-D", "MIR/SEN LH R-L" in "Data monitor" with CONSULT-III. Check mirror sensor (driver side) signal under the following condition. DATA MONITOR CHART Monitor item Condition Value MIR/SEN LH U-D Door mirror LH Close to peak 3.4V Close to valley 0.6V MIR/SEN LH R-L Close to right edge 3.4V Close to left edge 0.6V Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-388077-S37215972422011022800000) ".
PASSENGER SIDE : Component Function Check
- CHECK FUNCTION Select "MIR/SEN RH U-D", "MIR/SEN RH R-L" in "Data monitor" with CONSULT-III. Check the mirror sensor RH signal under the following conditions. DATA MONITOR CHART Monitor item Condition Value MIR/SEN RH U-D Door mirror RH Close to peak 3.4V Close to valley 0.6V MIR/SEN RH R-L Close to right edge 3.4V Close to left edge 0.6V Is the indication normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-388077-S27500492612011022800000) ".
- CHECK FUNCTION Select "SEAT SLIDE" in "Active test" mode with CONSULT-III. Check the sliding motor LH operation. DATA MONITOR CHART Test Item Description SEAT SLIDE OFF Seat sliding Stop FR Forward RR Backward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S23384526172011022800000) ".
- CHECK FUNCTION Select "SEAT RECLINING" in "Active test" mode with CONSULT-III. Check the reclining motor LH operation. DATA MONITOR CHART Test Item Description SEAT RECLINING OFF Seat reclining Stop FR Forward RR Backward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S00721147562011022800000) ".
- CHECK FUNCTION Select "SEAT LIFTER FR" in "Active test" mode with CONSULT-III. Check the lifting motor (front) operation. DATA MONITOR CHART Test Item Description SEAT LIFTER FR OFF Seat lifting (front) Stop UP Upward DWN Downward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S24413930762011022800000) ".
- CHECK FUNCTION Select "SEAT LIFTER RR" in "Active test" mode with CONSULT-III. Check the lifting motor (rear) operation. DATA MONITOR CHART Test Item Description SEAT LIFTER RR OFF Seat lifting (rear) Stop UP Upward DWN Downward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S29873508902011022800000) ".
- CHECK FUNCTION Select "TILT MOTOR" in "Active test" mode with CONSULT-III. Check the tilt motor operation. DATA MONITOR CHART Test item Description TILT MOTOR OFF Steering tilt Stop UP Upward DWN Downward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S10331437652011022800000) ".
- CHECK FUNCTION Select "TELESCO MOTOR" in "Active test" mode with CONSULT-III. Check the telescopic motor operation. DATA MONITOR CHART Test item Description TELESCO MOTOR OFF Steering telescopic Stop FR Forward RR Backward Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S04569475562011022800000) ".
- CHECK DOOR MIRROR MOTOR FUNCTION Check the operation with "MIRROR MOTOR RH" and "MIRROR MOTOR LH" in "ACTIVE TEST" mode with CONSULT-III Refer to " «CONSULT-III FUNCTION (AUTO DRIVE POS.)»(ref-388077-S27170190612011022800000) ". Is the inspection result normal? YES >> Door mirror motor function is OK. NO >> Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S03189396342011022800000) ".
- CHECK FUNCTION Select "MEMORY SW INDCTR" in "Active test" mode with CONSULT-III. Check the memory indicator operation. COMPONENT DESCRIPTION CHART Test item Description MEMORY SW INDCTR OFF Memory switch indicator OFF ON-1 Indicator 1: ON ON-2 Indicator 2: ON Is the operation of relevant parts normal? YES >> Inspection End. NO >> Perform diagnosis procedure. Refer to " «DIAGNOSIS PROCEDURE»(ref-388077-S14240753322011022800000) ".
PHYSICAL VALUES
ECU DIAGNOSIS INFORMATION CHART Terminal No. (wire color) Description Condition Voltage (V) (Approx) + - Signal name Input/Output 5 (R/L) Ground Sensor power supply Output - Battery voltage 6 (B) Ground Lifting switch (rear) down signal Input Lifting switch (rear) Operate (down) 0 Release Battery voltage 7 (L/B) Ground Lifting switch (front) down signal Input Lifting switch (front) Operate (down) 0 Release Battery voltage 8 (W) Ground Reclining switch backward signal Input Reclining switch Operate (backward) 0 Release Battery voltage 9 (V) Ground Sliding switch backward signal Input Sliding switch Operate (backward) 0 Release Battery voltage 10 (LG) Ground Memory indicator 2 signal Output Memory indicator 2 Illuminate 1 Other than above Battery voltage 11 (O/B) Ground Memory switch 2 signal Input Memory switch 2 Press 0 Other than above 5 12 (P/Y) Ground Telescopic sensor signal Input Telescopic Operate Other than above 0 or 5 13 (W/B) Ground Reclining sensor signal Input Seat reclining Operate Stop 0 or 5 15 (Y/B) Ground UART communication (TX/RX) Input Ignition switch ON 16 (O/V) - CAN-H - - - 21 (P/B) Ground Set switch signal Input Set switch Press 0 Other than above 5 22 (R) Ground Lifting switch (rear) up signal Input Seat lifting switch (rear) Operate (up) 0 Release Battery voltage 23 (O/Y) Ground Lifting switch (front) up signal Input Seat lifting switch (front) Operate (up) 0 Release Battery voltage 24 (GR) Ground Reclining switch forward signal Input Reclining switch Operate (forward) 0 Release Battery voltage 25 (Y) Ground Sliding switch forward signal Input Sliding switch Operate (forward) 0 Release Battery voltage 26 (W/Y) Ground Memory indicator 1 signal Output Memory indicator 1 Illuminate 1 Other than above Battery voltage 27 (V/W) Ground Memory switch 1 signal Input Memory switch 1 Press 0 Other than above 5 28 (L/R) Ground Tilt sensor signal Input Tilt Operate Other than above 0 or 5 29 (G) Ground Lifting sensor (rear) signal Input Seat lifting (rear) Operate Stop 0 or 5 30 (W/R) Ground Lifting sensor (front) signal Input Seat lifting (front) Operate Stop 0 or 5 31 (O) Ground Sliding sensor signal Input Seat sliding Operate Stop 0 or 5 32 (GR/B) - CAN-L - - - 34 (L/G) Ground Lifting motor (front) down output signal Output Seat lifting (front) Operate (down) Battery voltage Stop 0 35 (GR) Ground Reclining motor forward output signal Output Seat reclining Operate (forward) Battery voltage Release 0 36 (V) Ground Sliding motor backward output signal Output Seat sliding Operate (backward) Battery voltage Stop 0 37 (R/Y) Ground Power source Input - Battery voltage 39 (B) Ground Ground (power) - - 0 40 (B/R) Ground Lifting motor (rear) down output signal Output Seat lifting (rear) Operate (down) Battery voltage Stop 0 41 (R) Ground Lifting motor (rear) up output signal Output Seat lifting (rear) Operate (up) Battery voltage Stop 0 42 (O) Ground Lifting motor (front) up output signal Output Seat lifting (front) Operate (up) Battery voltage Stop 0 43 (W) Ground Reclining motor backward output signal Output Seat reclining Operate (backward) Battery voltage Stop 0 44 (Y) Ground Sliding motor forward output signal Output Seat sliding Operate (forward) Battery voltage Release 0
Scheme 234
Scheme 235
Scheme 236
Fail Safe
The fail-safe mode may be activated if the following symptoms are observed.
| Operating in fail-safe mode | Malfunction Item | Related DTC | Diagnosis |
|---|---|---|---|
| Only manual functions operate normally. | CAN communication | U1000 | U1000 CAN COMM CIRCUIT |
| CONTROL UNIT | U1010 | U1010 CONTROL UNIT (CAN) | |
| EEPROM | B2130 | B2130 EEPROM | |
| Only manual functions, except door mirror, operate normally. | UART communication | B2128 | B2128 UART COMMUNICATION LINE |
| Only manual functions, except seat sliding, operate normally. | Seat sliding output | B2112 | B2112 SLIDING MOTOR |
| Only manual functions, except seat reclining, operate normally. | Seat reclining output | B2113 | B2113 RECLINING MOTOR |
| Only manual functions, except steering tilt, operate normally. | Steering column tilt output | B2116 | B2116 TILT MOTOR |
FAIL SAFE REFERENCE CHART
ECU DIAGNOSIS INFORMATION CHART Terminal No. (wire color) Description Condition Voltage (V) (Approx.) + - Signal name Input/Output 1 (Y) Ground Tilt switch up signal Input Tilt switch Operate (up) 0 Other than above 5 2 (V/W) Ground Changeover switch RH signal Input Changeover switch position RH 0 Neutral or LH 5 3 (Y/B) Ground Mirror switch up signal Input Mirror switch Operated (up) 0 Other than above 5 4 (V/W) Ground Mirror switch left signal Input Mirror switch Operated (left) 0 Other than above 5 5 (GR) Ground Door mirror sensor (passenger side) up/down signal Input Door mirror RH position Change between 3.4 (close to peak) 0.6 (close to valley) 6 (W) Ground Door mirror sensor (driver side) up/down signal Input Door mirror LH position Change between 3.4 (close to peak) 0.6 (close to valley) 7 (P) Ground Telescopic switch forward signal Input Telescopic switch Operate (forward) 0 Other than above 5 8 (R) Ground UART communication (TX/RX) Output Ignition switch ON 10 (G) Ground Door mirror motor (passenger side) up output signal Output Door mirror RH Operate (up) Battery voltage Other than above 0 11 (V) Ground Door mirror motor (passenger side) left output signal Output Door mirror RH Operate (left) Battery voltage Other than above 0 12 (Y) Ground Door mirror motor (driver side) down output signal Output Door mirror (LH) Operate (down) Battery voltage Other than above 0 Door mirror motor (driver side) right output signal Operate (right) Battery voltage Other than above 0 13 (LG) Ground Tilt switch down signal Input Tilt switch Operate (down) 0 Other than above 5 14 (O) Ground Changeover switch LH signal Input Changeover switch position LH 0 Neutral or RH 5 15 (L/B) Ground Mirror switch down signal Input Mirror switch Operate (down) 0 Other than above 5 16 (V) Ground Mirror switch right signal Input Mirror switch Operate (right) 0 Other than above 5 17 (L) Ground Door mirror sensor (passenger side) left/right signal Input Door mirror RH position Change between 3.4 (close to left edge) 0.6 (close to right edge) 18 (L) Ground Door mirror sensor (driver side) left/right signal Input Door mirror LH position Change between 0.6 (close to left edge) 3.4 (close to right edge) 19 (G) Ground Telescopic switch backward signal Input Telescopic switch Operate (backward) 0 Other than above 5 20 (P) Ground Ground - - 0 21 (BR) Ground Door mirror motor sensor power supply Input - 5 22 (Y) Ground Door mirror motor (passenger side) down output signal Output Door mirror (RH) Operate (down) Battery voltage Other than above 0 Door mirror motor (passenger side) right output signal Operate (right) Battery voltage Other than above 0 23 (GR) Ground Door mirror motor (driver side) up output signal Output Door mirror (LH) Operate (up) Battery voltage Other than above 0 24 (V) Ground Door mirror motor (driver side) left output signal Output Door mirror (LH) Operate (left) Battery voltage Other than above 0 25 (R/Y) Ground Power source Input - Battery voltage 26 (V) Ground Telescopic motor backward output signal Output Steering telescopic Operate (backward) Battery voltage Other than above 0 27 (L) Ground Tilt and telescopic motor power source - Battery voltage 28 (G) Ground Tilt motor down output signal Output Steering tilt Operate (down) Battery voltage Other than above 0 29 (W/B) Ground Tilt motor up output signal Output Steering tilt Operate (up) Battery voltage Other than above 0 Telescopic motor forward output signal Steering telescopic Operate (forward) Battery voltage Other than above 0 30 (B) Ground Ground - - 0
Scheme 237
ECU DIAGNOSIS INFORMATION CHART Terminal No. (Wire color) Description Condition Value (Approx.) (+) (-) Signal name Input/Output 1 (W/B) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (R/Y) Ground Battery power supply output Output Ignition switch OFF Battery voltage 3 (L/W) Ground Ignition power supply output Output Ignition switch ON Battery voltage 4 (P/W) Ground Interior room lamp power supply Output After passing the interior room lamp battery saver operation time 0V Any other time after passing the interior room lamp battery saver operation time Battery voltage 5 (G) Ground Front door RH UNLOCK Output Front door RH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 7 (R/W) Ground Step lamp Output Step lamp ON 0V OFF Battery voltage 8 (V) Ground All doors LOCK Output All doors LOCK (actuator is activated) Battery voltage Other than LOCK (actuator is not activated) 0V 9 (L) Ground Front door LH UNLOCK Output Front door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 10 (G) Ground Rear door RH and rear door LH UNLOCK Output Rear door RH and rear door LH UNLOCK (actuator is activated) Battery voltage Other than UNLOCK (actuator is not activated) 0V 11 (Y/R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0V 14 (GR/W) Ground Engine switch (push switch) illumination ground Input Tail lamp OFF 0V ON NOTE: When the illumination brightening/dimming level is in the neutral position 15 (Y/L) Ground ACC indicator lamp Output Ignition switch OFF Battery voltage ACC or ON 0V 17 (G/B) Ground Turn signal (RH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch RH 18 (G/Y) Ground Turn signal (LH) Output Ignition switch ON Turn signal switch OFF 0V Turn signal switch LH 19 (Y) Ground Room lamp timer control Output Interior room lamp OFF Battery voltage ON 0V 21 (P/B) Ground Optical sensor signal Input Ignition switch ON When outside of the vehicle is bright Close to 5V When outside of the vehicle is dark Close to 0V 24 (R/W) Ground Stop lamp switch 1 Input - Battery voltage 26 (O/L) Ground Stop lamp switch 2 Input Stop lamp switch OFF (brake pedal is released) 0V ON (brake pedal is depressed) Battery voltage 27 (O) Ground Front door lock assembly LH (unlock sensor) Input Front door LH LOCK status UNLOCK status 0V 29 (Y) Ground Key slot switch Input When Intelligent Key is inserted into key slot Battery voltage When Intelligent Key is not inserted into key slot 0V 31 (G) Ground Rear window defogger feedback signal Input Rear window defogger switch OFF 0V ON Battery voltage 32 (R/B) Ground Front door RH switch Input Front door RH switch OFF (when front door RH closes) ON (when front door RH opens) 0V 37 (O) Ground Trunk lid opener cancel switch Input Trunk lid opener cancel switch CANCEL ON 0V 38 (GR/W) Ground Rear window defogger ON signal Input Rear window defogger switch OFF 5V ON 0V 40 (Y/G) Ground Power window serial link Input/Output Ignition switch ON Ignition switch OFF or ACC 0V 41 (W) Ground Engine switch (push switch) illumination Output Engine switch (push switch) illumination ON 5.5V OFF 0V 42 (R) Ground LOCK indicator lamp Output LOCK indicator lamp ON 0V OFF Battery voltage 45 (P) Ground Receiver & sensor ground Input Ignition switch ON 0V 46 (V/W) Ground Receiver & sensor power supply output Output Ignition switch OFF 0V ACC or ON 5.0V 47 (1) (G/O) Ground Tire pressure receiver signal Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 48 (R/G) Ground Selector lever transmission range switch signal Input Selector lever P or N position 12.0V Except P and N positions 0V 49 (L/O) Ground Security indicator signal Output Security indicator ON 0V Blinking OFF Battery voltage 50 (LG/B) Ground Combination switch INPUT 5 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Lighting switch 1ST Lighting switch high-beam Lighting switch 2ND Turn signal switch RH 51 (L/W) Ground Combination switch INPUT 1 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front wiper switch HI (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 52 (G/B) Ground Combination switch INPUT 2 Output Combination switch All switch OFF (Wiper intermittent dial 4) 0V Front washer switch ON (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 53 (LG/R) Ground Combination switch INPUT 3 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front wiper switch INT Front wiper switch LO Lighting switch AUTO 54 (G/Y) Ground Combination switch INPUT 4 Output Combination switch (Wiper intermittent dial 4) All switch OFF 0V Front fog lamp switch ON Lighting switch 2ND Lighting switch flash-to-pass Turn signal switch LH 57 (1) (W) Ground Tire pressure warning check switch Input - 5V 58 (SB) Ground Front door LH switch Input Front door LH switch OFF (front door LH CLOSE) ON (front door LH OPEN) 0V 59 (G/R) Ground Rear window defogger relay Output Rear window defogger Active Battery voltage Not activated 0V 60 (B/R) Ground Front console antenna 2 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 61 (W/R) Ground Center console antenna 2 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 62 (V) Ground Front outside handle RH antenna (-) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 63 (P) Ground Front outside handle RH antenna (+) Output When the front door RH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 64 (V) Ground Front outside handle LH antenna (-) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 65 (P) Ground Front outside handle LH antenna (+) Output When the front door LH request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 68 (G/O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 69 (O) Ground NATS antenna amp (built in key slot) Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 70 (R/B) Ground Ignition relay-2 control Output Ignition switch OFF or ACC 0V ON Battery voltage 71 (L/O) Ground Remote keyless entry receiver signal Input/Output During waiting When operating either button on Intelligent Key 75 (R/Y) Ground Combination switch OUTPUT 5 Input Combination switch All switch OFF (Wiper intermittent dial 4) Front fog lamp switch ON (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 76 (R/G) Ground Combination switch OUTPUT 3 Input Combination switch All switch OFF (Wiper intermittent dial 4) Lighting switch high-beam (Wiper intermittent dial 4) Lighting switch 2ND (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 78 (P) Ground CAN-L Input/Output - - 79 (L) Ground CAN-H Input/Output - - 80 (R/L) Ground Key slot illumination Output Key slot illumination OFF 0V Blinking ON Battery voltage 81 (LG) Ground ON indicator lamp Output Ignition switch OFF or ACC 0V ON Battery voltage 83 (L) Ground ACC relay control Output Ignition switch OFF 0V ACC or ON Battery voltage 84 (Y/R) Ground CVT shift selector Output - Battery voltage 87 (G/B) Ground Selector lever P position switch Input Selector lever P position 0V Any position other than P Battery voltage 88 (R) Ground Front door RH request switch Input Front door RH request switch ON (pressed) 0V OFF (not pressed) 89 (R) Ground Front door LH request switch Input Front door LH request switch ON (pressed) 0V OFF (not pressed) 90 (Y) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0V ON Battery voltage 91 (L/R) Ground Remote keyless entry receiver power supply Output Ignition switch OFF Battery voltage 95 (R/W) Ground Combination switch OUTPUT 1 Input Combination switch (Wiper intermittent dial 4) All switch OFF Turn signal switch LH Turn signal switch RH Front wiper switch LO Front washer switch ON 96 (P/B) Ground Combination switch OUTPUT 4 Input Combination switch All switch OFF (Wiper intermittent dial 4) Lighting switch AUTO (Wiper intermittent dial 4) Lighting switch 1ST (Wiper intermittent dial 4) Any of the conditions below with all switch OFF Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 97 (R/B) Ground Combination switch OUTPUT 2 Input Combination switch (Wiper intermittent dial 4) All switch OFF Lighting switch flash-to-pass Lighting switch 2ND Front wiper switch INT Front wiper switch HI 98 (G/O) Ground Hazard switch Input Hazard switch Pressed 0 V Not pressed 103 (V) Ground Trunk lid opening. Output Trunk lid Open (trunk lid opener actuator is activated) Battery voltage Close (trunk lid opener actuator is not activated) 0V 110 (V/W) Ground Trunk room lamp Output Trunk room lamp ON 0V OFF Battery voltage 114 (B) Ground Trunk room antenna 1 (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 115 (W) Ground Trunk room antenna 1 (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 118 (L/O) Ground Rear bumper antenna (-) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 119 (BR/W) Ground Rear bumper antenna (+) Output When the trunk lid request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 127 (BR/W) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC Battery voltage ON 0V 130 (W) Ground Trunk room lamp switch Input Trunk room lamp switch OFF (trunk is closed) ON (trunk is open) 0V 132 (R) Ground Starter motor relay control Output Ignition switch ON When selector lever is in P or N position and the brake is depressed Battery voltage When selector lever is in P or N position and the brake is not depressed 0V 140 (BR) Ground Engine switch (push switch) Input Engine switch (push switch) Pressed 0V Not pressed Battery voltage 141 (BR) Ground Trunk request switch Input Trunk request switch ON (pressed) 0V OFF (not pressed) 144 (GR) Ground Request switch buzzer Output Request switch buzzer Sounding 0V Not sounding Battery voltage 147 (L/R) Ground Trunk lid opener switch Input Trunk lid opener switch Pressed 0V Not pressed Battery voltage 148 (R/W) Ground Rear door RH switch Input Rear door RH switch OFF (when rear door RH closes) ON (when rear door RH opens) 0V 149 (R/B) Ground Rear door LH switch Input Rear door LH switch OFF (when rear door LH closes) ON (when rear door LH opens) 0V (1) With low tire pressure monitoring system
Scheme 238
Scheme 239
Scheme 240
Scheme 241
Scheme 242
Scheme 243
Scheme 244
Scheme 245
Scheme 246
Scheme 247
Scheme 248
Scheme 249
Scheme 250
Scheme 251
Scheme 252
Scheme 253
Scheme 254
Scheme 255
Scheme 256
Scheme 257
Scheme 258
Scheme 259
Scheme 260
Scheme 261
Scheme 262
Scheme 263
Scheme 264
Scheme 265
Scheme 266
Scheme 267
Scheme 268
Scheme 269
Scheme 270
Scheme 271
Scheme 272
Scheme 273
Scheme 274
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| B2190: NATS ANTENNA AMP | Inhibit engine cranking | Erase DTC |
| B2191: DIFFERENCE OF KEY | Inhibit engine cranking | Erase DTC |
| B2192: ID DISCORD BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2193: CHAIN OF BCM-ECM | Inhibit engine cranking | Erase DTC |
| B2195: ANTI-SCANNING | Inhibit engine cranking | Erase DTC |
| B2560: STARTER CONT RELAY | Inhibit engine cranking | 500 ms after the following CAN signal communication status has become consistent Starter control relay signal Starter relay status signal |
| B2562: LO VOLTAGE | Inhibit engine cranking | 100 ms after the power supply voltage increases to more than 8.8 V |
| B2608: STARTER RELAY | Inhibit engine cranking | 500 ms after the following signal communication status becomes consistent Starter motor relay control signal Starter relay status signal (CAN) |
| B260A: IGNITION RELAY | Inhibit engine cranking | 500 ms after the following conditions are fulfilled IGN relay (IPDM E/R) control signal: OFF (Battery voltage) Ignition ON signal (CAN to IPDM E/R): OFF (Request signal) Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal) |
| B260F: ENG STATE SIG LOST | Maintains the power supply position attained at the time of DTC detection | When any of the following conditions is fulfilled Power position changes to ACC Receives engine status signal (CAN) |
| B2617: STARTER RELAY CIRC | Inhibit engine cranking | 1 second after the starter motor relay control inside BCM becomes normal |
| B2618: BCM | Inhibit engine cranking | 1 second after the ignition relay (IPDM E/R) control inside BCM becomes normal |
| B26E1: ENG STATE NO RECIV | Inhibit engine cranking | When any of the following conditions are fulfilled Power position changes to ACC Receives engine status signal (CAN) |
FAIL SAFE REFERENCE CHART
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS AIRBAG -- MAXIMA " and SEAT BELTS -- MAXIMA " articles.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG article. Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service. |
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components. Water soluble dirt: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the dirty area. Then rub with a soft and dry cloth. Oily dirt: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the dirty area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
- Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
- For genuine leather seats, use a genuine leather seat cleaner.
