Seat: Removal & Installation Nissan Maxima A35

Removal and Installation

REMOVAL

Note. Confirm the position of connector before starting work.

Scheme 34

Scheme 35

Scheme 36

1. Slide the seat to the front most position.
2. Remove the rear slide covers side fixing points (A). Release the pawls (A). Remove the rear slide covers
3. Remove the rear mount bolts.
4. Slide the seat to the rear most position.
5. Remove the front slide covers.
6. Remove the front mount bolts.
7. Disconnect battery negative and positive terminals. CAUTION: Disconnect battery negative and positive terminals then wait for at least 3 minutes.
8. Disconnect harness connector under the seat and remove harness clamps.
9. Remove seat from the vehicle.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 37

Scheme 38

1. When installing the front seats tighten the driver seat bolts in the specified order as shown in the figure.
2. When installing the front seats tighten the passenger seat bolts in the specified order as shown in the figure.

Scheme 39

Scheme 40

1. Pull the lock lever (1) at the front bottom of the seat cushion forward (one for each side), and pull the seat cushion upward to release the wire (2) from the seat cushion hook. Then pull the seat cushion forward to remove.
2. Remove the seat cushion from the vehicle.

Installation is in the reverse order of removal.

Scheme 41

Scheme 42

1. Remove the seat cushion.
2. Remove the headrest assemblies.
3. Remove the seatback frame bolts and nut.
4. Disconnect the harness connectors.
5. Lift the seatback to disengage seat hook wires from the hangers.

Installation is in the reverse order of removal.

Note. Confirm the position of connector before starting work.

Scheme 43

Scheme 44

Scheme 45

1. Slide the seat to the front most position.
2. Remove the rear side covers. Release the pawls (A). Move the cover backward and remove the rear slide covers.
3. Remove the rear mount bolts.
4. Slide the seat to the rear most position.
5. Remove the front slide covers.
6. Remove the front mount bolts.
7. Disconnect battery negative and positive terminals. CAUTION: Disconnect battery negative and positive terminals then wait for at least 3 minutes.
8. Disconnect harness connector under the seat and remove harness clamps.
9. Remove seat from the vehicle.

Installation is in the reverse order of removal.

Scheme 46

Scheme 47

1. When installing the front seats tighten the driver seat bolts in the specified order as shown figure.
2. When installing the front seats tighten the passenger seat bolts in the specified order as shown figure.

Scheme 48

Scheme 49

1. Pull the lock lever (1) at the front bottom of the seat cushion forward (one for each side), and pull the seat cushion upward to release the wire (2) from the seat cushion hook. Then pull the seat cushion forward to remove.
2. Remove the seat cushion from the vehicle.

Installation is in the reverse order of removal.

Scheme 50

1. Remove the seat cushion.
2. Remove the headrest assemblies.
3. Remove the seatback frame bolts and nut.
4. Lift the seatback to disengage seat hook wires from the hangers.

Installation is in the reverse order of removal.

Scheme 51

Removal

Scheme 52

1. Pull the lock lever (1) at the front bottom of the seat cushion forward (one for each side), and pull the seat cushion upward to release the wire (2) from the seat cushion hook. Then pull the seat cushion forward to remove.
2. Remove the seat cushion from the vehicle.

Installation

Installation is in the reverse order of removal.

Removal

Scheme 53

Scheme 54

1. Lock seatbacks in upright position.
2. Remove the lower frame halo anchor bolts and nut.
3. Fold seatbacks forward.
4. Remove latch covers (A).
5. Remove upper frame halo bolts (B).
6. Remove the seatback assembly.

Installation

Installation is in the reverse order of removal.

Scheme 55

Disassembly

Scheme 56

1. Remove the seat from the vehicle. Refer to " «REMOVAL AND INSTALLATION»(ref-388069-S39263206372011022800000) "
2. Release the clips (D) from the seat cushion springs.
3. Pull the bottom of the seatback board upward enough to release the inner clips (C).
4. Pull the seatback board to unsnap the outboard side hook and pawl (B).
5. Push the seatback board downward to disengage the hooks (A).
6. Pull the top of the seatback board on the outboard side away enough to reach inside and unsnap the inboard side hook (B) and remove the seatback board.

Assembly

Assembly is in the reverse order of disassembly.
