Automatic Transaxle: Removal & Installation Nissan Maxima A34

Precautions for A/T Assembly or TCM Replacement

1. When replacing A/T assembly or TCM, refer to the pattern table below and initialize TCM if necessary.

Scheme 247

Note. "Old one" is the TCM or A/T assembly that has been used on other vehicles.

REMOVAL

1. Drain ATF. Refer to «CHANGING A/T FLUID»(ref-233644-S09092123082006052600000) .
2. Drain engine coolant, refer to «CHANGING ENGINE COOLANT»(ref-233644-S16252982522006052600000) .
3. Remove hose clamps and hoses from ATF cooler.
4. Remove bolt from ATF cooler and remove ATF cooler.

INSTALLATION

Installation is the reverse order of removal.

Note. Do not reuse sealing parts.

Installation is the reverse order of removal. Refer to COMPONENTS

Scheme 248

1. Remove side cover. Refer to «SIDE COVER»(ref-233658-S21415321042006052600000) .
2. Disconnect solenoid valve connectors.
3. Disconnect control valve assembly bolts and remove control valve assembly.

Installation is the reverse order of removal.

Scheme 249

1. Install bolts in sequence as shown. Refer to «COMPONENTS»(ref-233658-S15431245132006052600000) for specified torque. BOLT SPECIFICATION Bolt Symbol Length mm (in) Number of bolts A 55 (2.17) 2 B 50 (1.97) 2 C 16 (0.63) 2

Scheme 250

1. Remove PNP switch. Refer to «COMPONENTS»(ref-233658-S15431245132006052600000) .
2. Remove side cover. Refer to «REMOVAL»(ref-233658-S35535387112006052600000) .
3. Disconnect solenoid valve connectors.
4. Remove terminal cord assembly.

Installation is the reverse order of removal.

Scheme 251

1. Drain engine coolant. Refer to «CHANGING ENGINE COOLANT»(ref-233644-S16252982522006052600000) .
2. Remove battery and bracket. Refer to «REMOVAL»(ref-233654-S08818943502006052600000) .
3. Remove air cleaner assembly. Refer to «REMOVAL AND INSTALLATION»(ref-233643-S23956234542006052600000) .
4. Disconnect terminal cord assembly harness connector and park/neutral position (PNP) switch harness connectors.
5. Disconnect harness connectors of revolution sensor, ground, mass air flow sensor, and turbine revolution sensor.
6. Remove ATF cooler valve assembly bracket bolts.
7. Disconnect ATF cooler hose clips.
8. Disconnect ATF cooler hoses from ATF cooler valve assembly.
9. Disconnect control cable at transaxle side.
10. Drain ATF. Refer to «CHANGING A/T FLUID»(ref-233644-S09092123082006052600000) .
11. Remove engine undercover.
12. Remove upper transaxle to engine bolts.
13. Support engine. Refer to «ENGINE ASSEMBLY»(ref-233643-S00166700062006052600000) .
14. Remove drive shafts. Refer to «REMOVAL AND INSTALLATION»(ref-233652-S33721208742006052600000) ".
15. Remove crankshaft position sensor from transaxle.
16. Support transaxle with a jack.
17. Remove starter motor from transaxle. Refer to «REMOVAL AND INSTALLATION»(ref-233654-S08607087732006052600000) .
18. Remove front suspension member. Refer to «REMOVAL AND INSTALLATION»(ref-233650-S01688699322006052600000) .
19. Remove rear cover plate and bolts securing torque converter to drive plate. Rotate crankshaft for access to securing bolts.
20. Remove lower transaxle to engine bolts.
21. Lower transaxle while supporting it with a jack.
22. If replacing the transaxle as a unit, remove the LH transaxle mount from the transaxle case.

Scheme 252

1. Drive plate runout CAUTION: Do not allow any magnetic materials to contact the ring gear teeth. Maximum allowable runout: Refer to «DRIVE PLATE RUNOUT (A/T)»(ref-233643-S40332161282006052600000) .
2. If this runout is out of allowance, replace drive plate and ring gear.

Scheme 253

Scheme 254

Scheme 255

Scheme 256

1. When connecting torque converter to transaxle, measure distance "A" to be certain that they are correctly assembled. Distance "A": 14.0 mm (0.551 in) or more
2. Install bolts converter to drive plate. Converter bolt: 49 - 58 N.m (5.0 - 5.9 kg-m, 37 - 42 ft-lb) NOTE: With converter installed, rotate crankshaft several turns to check that transaxle rotates freely without binding.
3. Tighten bolts securing transaxle. TIGHTENING TORQUE Bolt No. Tightening torque N.m (kg-m, ft-lb) 1 mm (in) 1 70 - 79 (7.2 - 8.0, 52 - 58) 55 (2.17) 2 41.2 - 52.0 (4.2 - 5.3, 31 - 38) 40 (1.57) 3 70 - 79 (7.2 - 8.0, 52 - 58) 55 (2.17)
4. Tighten LH mounting bracket bolts to the specified torque. Refer to «REMOVAL AND INSTALLATION»(ref-233643-S15386963742006052600000) .
5. Tighten front suspension member bolts to the specified torque. Refer to «REMOVAL AND INSTALLATION»(ref-233650-S01688699322006052600000) .
6. Tighten rear plate cover bolts to the specified torque. Refer to «REMOVAL AND INSTALLATION»(ref-233643-S42259334642006052600000) .
7. Installation of the remaining components is in the reverse order of removal. Check fluid level in transaxle. Move selector lever through all positions to be sure that transaxle operates correctly. With parking brake applied, rotate engine at idling. Move selector lever through N to D and to R position. A slight shock should be felt by hand gripping selector each time transaxle is shifted. When replacing the A/T assembly, initialize TCM. Refer to «PRECAUTIONS FOR A/T ASSEMBLY OR TCM REPLACEMENT»(ref-233658-S03733069252006052600000) . Perform road test. Refer to «ROAD TEST»(ref-233658-S04061879022006052600000) .

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

1. Drain ATF through drain plug.
2. Remove torque converter by transaxle case it firmly and turning while pulling straight out.
3. Remove A/T fluid level gauge.
4. Remove A/T fluid charging pipe.
5. Remove O-ring from A/T fluid charging pipe.
6. Remove air breather hose.
7. Remove A/T fluid cooler tube.
8. Remove turbine revolution sensor. CAUTION: Be careful not to damage the turbine revolution sensor and transaxle case.
9. Remove revolution sensor. CAUTION: Be careful not to damage the revolution sensor and transaxle case.
10. Remove nut and range lever.
11. Using a flat-bladed screwdriver, pry off the lock washer.
12. Loosen nut and remove lock washer.
13. Remove washer plate.
14. Remove PNP switch from transaxle case. BOLT SYMBOL SPECIFICATION Bolt symbol Length mm (in) Number of bolts A 20 (0.79) 1 B 33 (1.30) 1
15. Remove hexagon bolt.
16. Remove ATF cooler assembly, washer and spring washer.
17. Remove O-rings from the ATF cooler assembly. NOTE: Do not reuse spring washer or O-rings.
18. Remove side cover. CAUTION: Be careful not to damage side cover and transaxle case. NOTE: Do not reuse seal bolts
19. Disconnect solenoid connectors. CAUTION: Be careful not to damage connector.
20. Remove sensor clamp bolt.
21. Remove sensor clamp and A/T fluid temperature sensor. CAUTION: Be careful not to damage A/T fluid temperature sensor.
22. Remove suction cover bolts.
23. Remove suction cover and suction cover gasket.
24. Remove control valve assembly bolts from transaxle case. BOLT SYMBOL SPECIFICATION Bolt symbol Length mm (in) Number of bolts A 55 (2.17) 2 B 50 (1.97) 2 C 16 (0.63) 2
25. While holding control valve assembly, disconnect parking lock rod sub assembly from manual valve lever sub assembly and remove control valve assembly. NOTE: Shift position is "N".
26. Remove governor apply gaskets.
27. Remove terminal cord assembly. CAUTION: Be careful not to damage solenoid connectors and A/T fluid temperature sensor.
28. Remove oil pump assembly bolts from transaxle case.
29. Remove oil pump assembly using Tool. Tool number ST33290001 (J-34286)
30. Remove oil seal from oil pump assembly using suitable tool. CAUTION: Be careful not to scratch oil pump assembly.
31. Remove one-way clutch outer race sub assembly.
32. Remove thrust washer.
33. Remove transaxle housing bolts from transaxle case. BOLT SYMBOL SPECIFICATION Bolt symbol Length mm (in) Number of bolts A 30 (1.18) 13 B 35 (1.38) 2 C 45 (1.77) 1 D (1) - 1 (1) Torx bolt
34. Remove transaxle housing with a soft hammer.
35. Remove governor apply gasket.
36. Remove seal ring.
37. Remove tube clamp bolt and clamp.
38. Remove differential gear lube apply tube using a suitable tool. CAUTION: Be careful not to bend or damage differential gear lube apply tube. Be careful not to damage transaxle housing.
39. Remove oil reservoir plate.
40. Remove oil cleaner magnets from oil reservoir plate.
41. Remove differential gear assembly.
42. Remove oil strainer sub assembly.
43. Remove oil reservoir plate.
44. Remove tube clamp.
45. Remove U/D brake apply tube sub assembly using suitable tool. CAUTION: Be careful not to bend or damage U/D brake apply tube sub assembly. Be careful not to damage transaxle case.
46. Disconnect manual detent spring sub assembly from manual valve lever sub assembly using a flat-bladed screwdriver or suitable tool.
47. Remove manual valve lever sub assembly from parking lock rod sub assembly.
48. Remove parking lock rod sub assembly.
49. Remove bolts for manual detent spring sub assembly. BOLT SYMBOL SPECIFICATION Bolt symbol Length mm (in) Number of bolts A 16.7 (0.657) 1 B 14.0 (0.551) 1
50. Remove manual detent spring sub assembly.
51. Remove parking lock pawl shaft and torsion spring No.1.
52. Remove parking lock pawl bracket and parking lock pawl.
53. Remove parking lockpin sub assembly.
54. Remove spring guide sleeve and torsion spring No.2.
55. Remove manual valve oil seal using a flat-bladed screwdriver. CAUTION: Be careful not to damage transaxle case.
56. Remove thrust needle roller bearing and thrust bearing race from U/D gear assembly.
57. Remove U/D gear assembly.
58. Remove seal rings from U/D gear assembly.
59. Remove U/D clutch assembly.
60. Remove anchor bolt.
61. Remove U/D brake band assembly. CAUTION: Be careful not to damage transaxle case.
62. Remove U/D RR planetary carrier assembly and thrust bearing races.
63. Remove U/D RR planetary ring gear sub assembly.
64. Remove thrust needle roller bearing adjusting shim and thrust bearing race from U/D RR planetary ring gear sub assembly.
65. Remove snap ring using a snap ring pliers
66. Remove U/D brake damper assembly.
67. Remove O-rings from U/D brake damper assembly.
68. Remove U/D brake piston assembly and compression spring.
69. Remove O-ring from U/D brake piston assembly.
70. Remove transaxle case cover bolts from transaxle case. BOLT SYMBOL SPECIFICATION Bolt symbol Length mm (in) Number of bolts A 30 (1.18) 8 B 45 (1.77) 2 C 48 (1.89) 2 D (1) - 1 (1) Stud bolt
71. Tap transaxle case cover with a soft hammer. CAUTION: Be careful not to damage transaxle case cover.
72. Remove transaxle case cover.
73. Remove governor apply gaskets from transaxle case. NOTE: Do not reuse gaskets
74. Remove tube clamp bolt.
75. Remove transaxle lube apply tube, using a flat-bladed screwdriver. CAUTION: Be careful not to bend or damage transaxle lube apply tube. Be careful not to damage transaxle case.
76. Remove forward and direct clutch assembly.
77. Remove thrust bearing race, thrust needle roller bearing and seal ring from forward and direct clutch assembly. NOTE: Do not reuse seal ring.
78. Remove planetary sun gear sub assembly and thrust needle roller bearings.
79. Measure the inner diameter of planetary sun gear sub assembly bushing, using suitable bore gauge. CAUTION: Measure at different places and take an average. If it is greater than the maximum, replace it with a new planetary sun gear sub assembly. Standard: 22.200 - 22.226 mm (0.8740 - 0.8750 in) Allowable limit: 22.276 (0.8770 in)
80. Remove RR planetary ring gear assembly.
81. Remove thrust needle roller bearing and thrust bearing race from RR planetary ring gear assembly.
82. Remove planetary gear assembly.
83. Remove thrust bearing race from planetary gear assembly.
84. Measure the inner diameter of planetary gear assembly bushing, using suitable bore gauge. CAUTION: Measure at different places and take an average. If it is greater than the maximum, replace it with a new planetary gear assembly. Standard :30.056 - 30.082 mm (1.1833 - 1.1843 in) Allowable limit: 30.132 (1.1863 in)
85. Remove thrust bearing.
86. Remove snap ring using a flat-bladed screwdriver.
87. Remove 1st and reverse brake flanges, 1st and reverse brake discs and 1st and reverse brake plates. INSPECTION Check that the sliding surface of discs are not worn and burnt. If necessary, replace them. CAUTION: Replace new discs by soaking them at least 2 hours in A/T fluid.
88. Remove FR planetary ring gear assembly with one-way clutch No.2.
89. Make sure that the FR planetary ring gear assembly should turn freely counterclockwise and should lock clockwise.
90. Remove snap ring using a flat-bladed screwdriver.
91. Remove return spring.
92. While pushing the piston by hand, apply compressed air (4 Kg/cm 2 ) into the oil passage of transaxle case as shown in the figure and remove 1st and reverse brake piston.
93. Remove O-rings from 1st and reverse brake piston. NOTE: Do not reuse O-Rings.
94. Remove thrust bearing and thrust bearing race from counter drive gear sub assembly.
95. Remove snap ring using a suitable snap ring pliers.
96. Remove counter drive gear sub assembly.
97. Remove differential side oil seal from transaxle case and transaxle housing using suitable tool. CAUTION: Be careful not to scratch transaxle case and transaxle housing. NOTE: Do not reuse oil seals
98. Remove outer race and adjust shim from transaxle case, using Tool Tool number: ST30612000 (J-25745-2)
99. Remove thrust roller bearing from transaxle housing, using Tool. Tool number: ST333290001 (J-34286)

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

1. Remove oil seal from oil pump assembly, using suitable tool. CAUTION: Be careful not to scratch oil pump assembly. NOTE: Do not reuse old seal.
2. Remove thrust washer from oil pump assembly.
3. Remove snap ring, using a flat-bladed screwdriver.
4. Remove 2nd coast brake flange, 2nd coast brake disc and 2nd coast brake plate.
5. Compress return spring with a press, using Tool. Tool number: KV31102400 (J-34285 and J-34285-87)
6. Remove snap ring, using suitable snap ring pliers.
7. Remove return spring.
8. While pushing the 2nd coast brake piston by hand, apply compressed air (4 kg/cm 2 ) into the oil passage as shown and remove 2nd coast brake piston. CAUTION: Be careful not to damage the O-ring and 2nd coast brake piston.
9. Remove O-rings from 2nd coast brake piston. NOTE: Do not reuse O-rings.
10. Remove snap ring, using suitable tool.
11. Remove 2nd brake flange, 2nd brake discs and 2nd brake plates.
12. Remove return spring.
13. Remove snap ring, using suitable tool. CAUTION: Be careful not to damage oil pump assembly and 2nd brake piston.
14. While pushing the 2nd brake piston by hand, apply compressed air (4 kg/cm 2 ) into the oil passage as shown and remove 2nd brake piston (With 2nd brake sleeve). CAUTION: Be careful not to damage 2nd brake piston and 2nd brake sleeve.
15. Remove O-rings from 2nd brake piston and 2nd brake sleeve. NOTE: Do no reuse O-rings.
