Engine Brake Adjustment
"ENGINE BRAKE LEVEL"
0: Initial set value (Engine brake level control is activated)
OFF: Engine brake level control is deactivated.
| CAUTION | Mode of "+1" "0" "-1" "-2" "OFF" can be selected by pressing the "UP" "DOWN" on CONSULT screen. However, do not select mode other than "0" and "OFF". If the "+1" or "-1" or "-2" is selected, that might cause the irregular driveability. |
Check CVT Fluid Deterioration Date
"CVTF DETERIORATION DATE"
210000 or more
It is necessary to change CVT fluid.
Less than 210000: It is not necessary to change CVT fluid.
| CAUTION | Touch "CLEAR" after changing CVT fluid, and then erase "CVTF DETERIORATION DATE". |
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT positions after installing the CVT shift selector. Refer to " INSPECTION AND ADJUSTMENT ".
Perform " ADDITIONAL SERVICE WHEN REPLACING TCM ". Refer to " DESCRIPTION ".
Scheme 19
- Remove air cleaner case. Refer to " «REMOVAL AND INSTALLATION»(ref-621377-S23069609932014061000000) ".
- Remove clip (A) from bracket.
- Remove air breather hose (1) from transaxle assembly.
Perform " ADDITIONAL SERVICE WHEN REPLACING CONTROL VALVE OR TRANSAXLE ASSEMBLY ". Refer to " DESCRIPTION ".
Scheme 20
Perform "ADDITIONAL SERVICE WHEN REPLACE CONTROL VALVE OR TRANSAXLE ASSEMBLY". Refer to " DESCRIPTION ".
Scheme 21
Perform "ADDITIONAL SERVICE WHEN REPLACE CONTROL VALVE OR TRANSAXLE ASSEMBLY". Refer to " DESCRIPTION ".
