Maintenance: Other — Nissan Juke I (2010-2014)

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description KV10115801 (J 38956) Oil filter wrench Removing and installing oil filter 64.3 mm (2.531 in)

Commercial Service Tool

Tool name Description Power tool Loosening nuts and bolts Spark plug wrench Removing and installing spark plug 14 mm (0.55 in)

Scheme 40

Scheme 40: Commercial Service Tool

General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

Item		Reference page
Tires	Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the specified pressure. Check carefully for damage, cuts or excessive wear.	SERVICE DATA AND SPECIFICATIONS (SDS)
Wheel nuts	When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary.
Tire rotation	Tires should be rotated every 7, 500 miles (12, 000 km).	TIRE ROTATION
Tire Pressure Monitor System (TPMS) transmitter components	Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age.	SYSTEM
Wheel alignment and balance	If the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. For additional information regarding tires, refer to "Important Tire Safety Information" (US) or "Tire Safety Information" (Canada) in the NISSAN Warranty Information Booklet.	WHEEL ALIGNMENT WHEEL ALIGNMENT (2WD), WHEEL ALIGNMENT (AWD)
Windshield	Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary.
Windshield wiper blades	Check for cracks or wear if they do not wipe properly.
Doors and engine hood	Check that all doors and the engine hood operate smoothly as well as the trunk lid and back hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently.	BODY MAINTENANCE
Lamps	Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis.

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.

Item		Reference page
Warning lamps and chimes	Make sure that all warning lamps and chimes are operating properly.
Windshield wiper and washer	Check that the wipers and washer operate properly and that the wipers do not streak.
Windshield defroster	Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioning.
Steering wheel	Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in)
Seats	Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restraints move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks.
Seat belts	Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly and are installed securely. Check the belt webbing for cuts, fraying, wear or damage.	SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS
Accelerator pedal	Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal.
Brakes	Check that the brake does not pull the vehicle to one side when applied.
Brake pedal and booster	Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep floor mats away from the pedal.	PERIODIC MAINTENANCE BRAKE BOOSTER
Clutch pedal	Make sure the pedal operates smoothly and check that it has the proper free play.	PERIODIC MAINTENANCE
Parking brake	Check that the lever has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied.	PERIODIC MAINTENANCE
CVT P (Park) position mechanism	On a fairly steep hill check that the vehicle is held securely with the selector lever in the "P" position without applying any brakes.

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Item		Reference page
Windshield washer fluid	Check that there is adequate fluid in the tank.
Engine coolant level	Check the coolant level when the engine is cold.	LEVEL
Radiator and hoses	Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the radiator hoses have no cracks, deformation, deterioration or loose connections.	RADIATOR
Brake and clutch fluid levels	Make sure that the brake and clutch fluid levels are between the "MAX" and "MIN" lines on the reservoirs.	FLUID LEVEL BRAKE FLUID LEVEL AND LEAKS
Battery	Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level.	BASIC INSPECTION
Engine drive belts	Make sure that no belt is frayed, worn, cracked or oily.	DRIVE BELT
Engine oil level	Check the level on the dipstick after parking the vehicle on a level spot and turning off the engine.	PERIODIC MAINTENANCE
Exhaust system	Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it.	EXHAUST SYSTEM
Underbody	The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate.
Fluid leaks	Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately.

Two different maintenance schedules are provided, and should be used, depending upon the conditions in which the vehicle is mainly operated. After 60, 000 miles (96, 000 km) or 48 months, continue the periodic maintenance at the same mileage/time intervals.

Schedule 1	Follow Periodic Maintenance Schedule 1 if the driving habits frequently includes one or more of the following driving conditions: Repeated short trips of less than 5 miles (8 km). Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing. Operating in hot weather in stop-and-go "rush hour" traffic. Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use. Driving in dusty conditions. Driving on rough, muddy, or salt spread roads. Towing a trailer, using a camper or a car-top carrier.	Emission Control System Maintenance	EMISSION CONTROL SYSTEM MAINTENANCE
Schedule 1		Chassis and Body Maintenance	CHASSIS AND BODY MAINTENANCE
Schedule 2	Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown in Schedule 1 apply to the driving habits.	Emission Control System Maintenance	EMISSION CONTROL SYSTEM MAINTENANCE
Schedule 2		Chassis and Body Maintenance	CHASSIS AND BODY MAINTENANCE

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference Section - Page or - Content Title
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1, 000 (km x 1, 000) Months	3.75 (6) 3	7.5 (12) 6	11.25 (18) 9	15 (24) 12	18.75 (30) 15	22.5 (36) 18	26.25 (42) 21	30 (48) 24	Reference Section - Page or - Content Title
Drive belt	NOTE (1)									DRIVE BELT
Air cleaner filter	NOTE (2)								[R]	AIR CLEANER FILTER
EVAP vapor lines									I (7)	EVAP VAPOR LINES: INSPECTION
Fuel lines									I (7)	FUEL LINES
Fuel filter	NOTE (3)
Engine coolant (7)	NOTE (4)									ENGINE COOLANT: INSPECTION
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL
Engine oil filter (Use genuine oil filter or equivalent)		R	R	R	R	R	R	R	R	OIL FILTER
Spark plugs (Iridium/platinum - tipped type)	NOTE (5)	Replace every 105, 000 miles (168, 000 km)								SPARK PLUG
Intake and exhaust valve clearance (7)	NOTE (6)									BASIC INSPECTION
(1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FL section. (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (5) Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	If operating mainly in dusty conditions, more frequent maintenance may be required.

(3)	Maintenance-free item. For service procedures, refer to the FL section.

(4)

First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant.

(5)	Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage.

(6)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

(7)	Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference Section - Page or - Content Title
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1, 000 (km x 1, 000) Months	33.75 (54) 27	37.5 (60) 30	41.25 (66) 33	45 (72) 36	48.75 (78) 39	52.5 (84) 42	56.25 (90) 45	60 (96) 48	Reference Section - Page or - Content Title
Drive belt	NOTE (1)								I (7)	DRIVE BELT
Air cleaner filter	NOTE (2)								[R]	AIR CLEANER FILTER
EVAP vapor lines									I (7)	EVAP VAPOR LINES: INSPECTION
Fuel lines									I (7)	FUEL LINES
Fuel filter	NOTE (3)
Engine coolant (7)	NOTE (4)									ENGINE COOLANT: INSPECTION
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL
Engine oil filter (Use genuine oil filter or equivalent)		R	R	R	R	R	R	R	R	OIL FILTER
Spark plugs (Iridium/platinum - tipped type)	NOTE (5)	Replace every 105, 000 miles (168, 000 km)								SPARK PLUG
Intake and exhaust valve clearance (7)	NOTE (6)									BASIC INSPECTION
(1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FL section. (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (5) Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage. (6) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (7) Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belts if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	If operating mainly in dusty conditions, more frequent maintenance may be required.

(3)	Maintenance-free item. For service procedures, refer to the FL section.

(4)

(5)	Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage.

(6)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

(7)	Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference Section - Page or - Content Title
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1, 000 (km x 1, 000) Months	3.75 (6) 3	7.5 (12) 6	11.25 (18) 9	15 (24) 12	18.75 (30) 15	22.5 (36) 18	26.25 (42) 21	30 (48) 24	Reference Section - Page or - Content Title
Brake lines & cables					I				I	BRAKE LINES AND CABLES
Brake pads & rotors			I		I		I		I	BRAKE FLUID LEVEL AND LEAKS FRONT DISC BRAKE REAR DISC BRAKE
Brake fluid					R				R	BRAKE FLUID
CVT fluid	NOTE (1)				I				I	CVT FLUID
Manual transaxle oil					I				I	OIL LEVEL
Transfer fluid and differential gear oil	NOTE (2)				I				I	TRANSFER FLUID REAR DIFFERENTIAL GEAR OIL
Steering gear & linkage, axle & suspension parts			I		I		I		I	STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (3)									OUTSIDE THE VEHICLE TIRE ROTATION
Propeller shaft & drive shaft boots			I		I		I		I	REAR PROPELLER SHAFT DRIVE SHAFT
Exhaust system			I		I		I		I	EXHAUST SYSTEM
In-cabine microfilter					R				R	IN-CABIN MICROFILTER
Brake lines & cables					I				I	BRAKE LINES AND CABLES
Brake pads & rotors			I		I		I		I	BRAKE FLUID FRONT DISC BRAKE REAR DISC BRAKE
Brake fluid					R				R	BRAKE FLUID
CVT fluid	NOTE (1)				I				I	CVT FLUID
Manual transaxle oil					I				I	OIL LEVEL
Transfer fluid and differential gear oil	NOTE (2)				I				I	TRANSFER FLUID REAR DIFFERENTIAL GEAR OIL
Steering gear & linkage, axle & suspension parts			I		I		I		I	STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (3)									OUTSIDE THE VEHICLE TIRE ROTATION
Propeller shaft & drive shaft boots			I		I		I		I	REAR PROPELLER SHAFT DRIVE SHAFT
Exhaust system			I		I		I		I	EXHAUST SYSTEM
In-cabine microfilter					R				R	IN-CABIN MICROFILTER
(1) Use only Genuine NISSAN CVT fluid (NS-2). If towing a trailer, using a camper or a car-top carrier or driving on rough or muddy roads, inspect CVT fluid deterioration at NISSAN dealers every 100, 000 km (60, 000 miles), then change CVT fluid NS-2 if necessary. And if the inspection is not be performed, change (not just inspect) CVT fluid NS-2 every 100, 000 km (60, 000 miles). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the warranty. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30, 000 miles (48, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section.

(1)

Use only Genuine NISSAN CVT fluid (NS-2). If towing a trailer, using a camper or a car-top carrier or driving on rough or muddy roads, inspect CVT fluid deterioration at NISSAN dealers every 100, 000 km (60, 000 miles), then change CVT fluid NS-2 if necessary. And if the inspection is not be performed, change (not just inspect) CVT fluid NS-2 every 100, 000 km (60, 000 miles). Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the warranty.

(2)	If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30, 000 miles (48, 000 km) or 24 months.

(3)	Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section.

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. []: At the mileage intervals only
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference Section - Page or - Content Title
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1, 000 (km x 1, 000) Months	7.5 (12) 6	15 (24) 12	22.5 (36) 18	30 (48) 24	37.5 (60) 30	45 (72) 36	52.5 (84) 42	60 (96) 48	Reference Section - Page or - Content Title
Drive belt	NOTE (1)								I*	DRIVE BELT
Air cleaner filter					[R]				[R]	AIR CLEANER FILTER
EVAP vapor lines					I*				I*	EVAP VAPOR LINES: INSPECTION
Fuel lines					I*				I*	FUEL LINES
Fuel filter	NOTE (2)
Engine coolant*	NOTE (3)									ENGINE COOLANT: INSPECTION
Engine oil		R	R	R	R	R	R	R	R	ENGINE OIL
Engine oil filter (Use genuine oil filter or equivalent.)		R	R	R	R	R	R	R	R	OIL FILTER
Spark plugs (Iridium/platinum - tipped type)	NOTE (4)	Replace every 105, 000 miles (168, 000 km)								SPARK PLUG
Intake and exhaust valve clearance*	NOTE (5)									BASIC INSPECTION
(1) After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit. (2) Maintenance-free item. For service procedures, refer to the FL section. (3) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% antifreeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (4) Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage. (5) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required.

(1)	After 60, 000 miles (96, 000 km) or 48 months, inspect every 15, 000 miles (24, 000 km) or 12 months. Replace the drive belt if found damaged or if the auto belt tensioner reading reaches the maximum limit.

(2)	Maintenance-free item. For service procedures, refer to the FL section.

(3)

(4)	Replace spark plug when the plug gap exceeds 1.1 mm (0.043 in) even if within specified periodic replacement mileage.

(5)	Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance.

Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary.
MAINTENANCE OPERATION		MAINTENANCE INTERVAL								Reference Section - Page or - Content Title
Perform at number of miles, kilometers or months, whichever comes first.	Miles x 1, 000 (km x 1, 000) Months	7.5 (12) 6	15 (24) 12	22.5 (36) 18	30 (48) 24	37.5 (60) 30	45 (72) 36	52.5 (84) 42	60 (96) 48	Reference Section - Page or - Content Title
Brake lines & cables			I		I		I		I	BRAKE LINES AND CABLES
Brake pads & rotors			I		I		I		I	BRAKE FLUID LEVEL AND LEAKS FRONT DISC BRAKE REAR DISC BRAKE
Brake Fluid					R				R	BRAKE FLUID
CVT fluid	NOTE (1)		I		I		I		I	CVT FLUID
Manual transaxle oil			I		I		I		I	OIL LEVEL
Transfer fluid and differential gear oil			I		I		I		I	TRANSFER FLUID REAR DIFFERENTIAL GEAR OIL
Steering gear & linkage, axle & suspension parts					I				I	STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS
Tire rotation	NOTE (2)									OUTSIDE THE VEHICLE TIRE ROTATION
Propeller shaft & drive shaft boots			I		I		I		I	REAR PROPELLER SHAFT DRIVE SHAFT
Exhaust system					I				I	EXHAUST SYSTEM
In-cabine microfilter			R		R		R		R	IN-CABIN MICROFILTER
(1) Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty. (2) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section.

(1)	Using transmission fluid other than Genuine NISSAN CVT Fluid NS-2 will damage the CVT, which is not covered by the NISSAN new vehicle limited warranty.

(2)	Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this section.

SAE Viscosity Number

NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.

Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubrication Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.

Scheme 41

Scheme 41: SAE Viscosity Number

Anti-Freeze Coolant Mixture Ratio

The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.

WARNING

Never remove the radiator or coolant reservoir cap when the engine is hot. Wait until the engine and radiator cool down. Serious burns could be caused by high pressure fluid escaping from the radiator. See precautions in "If your vehicle overheats" found in the "In case of emergency' section of this manual. The radiator is equipped with a pressure type radiator cap. To prevent engine damage, use only a genuine NISSAN radiator cap.

CAUTION

When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufacture's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system. The life expectancy of the factory-fill coolant is 105, 000 miles (168, 000 km) or 7 years. Mixing any other type of coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue), including Genuine NISSAN Long Life Antifreeze/Coolant (green), or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. Refer to the Nissan Service and Maintenance Guide for more details.

Scheme 42

Scheme 42: DRIVE BELT: Exploded View

Scheme 43

Scheme 43: DRIVE BELT: Inspection

WARNING

Perform this step when engine is stopped.

Check that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A) in the figure. NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (B) in the figure.
Visually check entire drive belt for wear, damage or cracks.
If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.

OIL LEAKAGE

Make sure that gear oil is not leaking from transaxle or around it.

Scheme 44

Scheme 44: OIL LEVEL

Remove filler plug (1) and gasket from transaxle case.
Check the oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
Set a gasket on filler plug and then install it to transaxle case. CAUTION: Never reuse gasket.
Tighten filler plug to the specified torque. Refer to " «EXPLODED VIEW»(ref-516408-S42282830212012120600000) ".

Scheme 45

Scheme 45: GEAR OIL: Draining

Start engine and let it run to warm up transaxle.
Stop engine. Remove drain plug (1) and gasket, using a socket [Commercial service tool] and then drain gear oil.
Set a gasket on drain plug and install it to clutch housing, using a socket [Commercial service tool]. CAUTION: Never reuse gasket.
Tighten drain plug to the specified torque. Refer to " «EXPLODED VIEW»(ref-516408-S42282830212012120600000) ".

Check transfer surrounding area (oil seal, drain plug, filler plug, and transfer case etc.) for oil leakage.

Scheme 46

Scheme 46: OIL LEVEL

Remove filler plug (1) and gasket. Then check that oil is filled up from mounting hole for the filler plug. CAUTION: Never start engine while checking oil level.
Before installing filler plug, set a new gasket. Install filler plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-516403-S08011437982012120600000) ". CAUTION: Never reuse gasket.

Scheme 47

Scheme 47: TRANSFER FLUID: Draining

Run the vehicle to warm up the transfer unit sufficiently.
Stop the engine and remove the drain plug (1) and gasket to drain the transfer oil.
Before installing drain plug, set a new gasket. Install drain plug on the transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-516403-S08011437982012120600000) ". CAUTION: Never reuse gasket.

Scheme 48

Scheme 48: TRANSFER FLUID: Refilling

Remove filler plug (1) and gasket. Then fill oil up to mounting hole for the filler plug. Oil and viscosity: Refer to " «FLUIDS AND LUBRICANTS»(ref-516397-S21810730752012120600000) ". Oil capacity: Refer to " «GENERAL SPECIFICATIONS»(ref-516403-S14387979652012120600000) ". CAUTION: Carefully fill the oil. (Fill up for approximately 3 minutes.)
Leave the vehicle for 3 minutes, and check the oil level again.
Before installing filler plug, set a new gasket. Install filler plug on transfer and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-516403-S08011437982012120600000) ". CAUTION: Never reuse gasket.

Check rear final drive surrounding area (oil seal, drain plug, filler plug, and gear carrier, etc.) for oil leakage.

Scheme 49

Scheme 49: OIL LEVEL

Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure. CAUTION: Never start engine while checking oil level.
Set a new gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-516430-S36936740722012120600000) ". CAUTION: Never reuse gasket.

Scheme 50

Scheme 50: REAR DIFFERENTIAL GEAR OIL: Draining

Stop engine.
Remove drain plug (1) and drain gear oil.
Set a new gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-516430-S36936740722012120600000) ". CAUTION: Never reuse gasket.

DISC ROTOR

Check condition, wear, and damage.

Scheme 51

Scheme 51: CALIPER

Check for leakage.

Scheme 52

Scheme 52: BRAKE PAD

Check for wear or damage.

DISC BRAKE: Front Disc Brake

Unit: mm (in)
Item		Limit
Brake pad	Wear thickness	2.0 (0.079)
Disc rotor	Wear thickness	24.0 (0.945)
	Thickness variation (measured at 8 positions)	0.008 (0.0003)
	Runout (with it attached to the vehicle)	0.035 (0.0014)

DISC BRAKE: Rear Disc Brake

Unit: mm (in)
Item		Limit
Brake pad	Wear thickness	2.0 (0.079)
Disc rotor	Wear thickness	8.0 (0.315)
	Thickness variation (measured at 8 positions)	0.016 (0.0006)
	Runout (with it attached to the vehicle)	0.1 (0.004)

Scheme 53

Scheme 53: STEERING GEAR

Check gear housing and boots for looseness, damage and grease leakage.
Check connection with steering column for looseness.

STEERING LINKAGE

Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.

DRIVE BELT

Tension of drive belt

Belt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner.

SPARK PLUG

Unit: mm (in)
Make		NTK
Standard type		DILKAR7C9H
Gap (Nominal)	Standard	0.9 (0.035)
Gap (Nominal)	Limit	1.1 (0.043)

CONVENTIONAL

Item		Limit
Runout	Axial runout	Less than 0.3 mm (0.012 in)
Runout	Radial runout	Less than 0.3 mm (0.012 in)
Allowable unbalance	Dynamic (At flange)	Less than 5 g (0.17 oz) (one side)
Allowable unbalance	Static (At flange)	Less than 10 g (0.35 oz)

EMERGENCY

Item		Limit
Runout	Axial runout (Average)	Less than 1.2 mm (0.047 in)
Runout	Radial runout (Average)	Less than 1.0 mm (0.039 in)

Maintenance: Other Nissan Juke I
