Maintenance: Adjustments Nissan Juke I

DRIVE BELT: Adjustment

Refer to : " DRIVE BELT ".

Scheme 1

1. Check that the reservoir tank engine coolant level is within the "MIN" to "MAX" when the engine is cool.
2. Adjust the engine coolant level if necessary. CAUTION: Refill Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent in its quality mixed with water (distilled or demineralized). Refer to " «FLUIDS AND LUBRICANTS»(ref-516397-S21810730752012120600000) ".

Scheme 2

1. To check for leakage, apply pressure to the cooling system with the radiator cap tester (commercial service tool) (A) and the radiator cap tester adapter (commercial service tool) (B). Testing pressure: Refer to " «RADIATOR»(ref-516398-S23670404892012120600000) ". WARNING: Never remove radiator cap when engine is hot. Serious burns may occur from high-pressure engine coolant escaping from engine cooling system. CAUTION: Higher test pressure than specified may cause radiator damage. NOTE: In a case that engine coolant decreases, replenish radiator with engine coolant.
2. If anything is found, repair or replace damaged parts.

PREPARATION BEFORE ADJUSTMENT

Using releasing agent, remove double-faced adhesive tape from the road wheel.

ADJUSTMENT

1. The details of the adjustment procedure are different for each model of wheel balancer. Therefore, refer to each instruction manual.
2. If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for aluminum wheels.

Scheme 3

Scheme 4

Scheme 5

1. Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
2. When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install to the designated outer position of, or at the designated angle in relation to the road wheel. CAUTION: Never install the inner balance weight before installing the outer balance weight. Before installing the balance weight, always to clean the mating surface of the road wheel. Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz) x 5/3 = 38.33 g (1.35 oz) ==> 40 g (1.41 oz) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 37.4 ==> 35 g (1.23 oz) 37.5 ==> 40 g (1.41 oz) Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN balance weights. Balance weights are non-reusable; always replace with new ones. Never install three or more sheets of balance weight. If calculated balance weight value exceeds 50 g (1.76 oz), install two balance weight sheets in line with each other as shown in the figure. CAUTION: Never install one balance weight sheet on top of another.
3. Start the tire balance machine again.
4. Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Never install three or more balance weight.
5. Start the tire balance machine. Check that the inner and outer residual unbalance value is within the allowable unbalance value. CAUTION: If either residual unbalance value exceeds limit, repeat installation procedures. Allowable unbalance value Dynamic (At flange): Refer to " «ROAD WHEEL»(ref-516434-S35696986952012120600000) ". Static (At flange): Refer to " «ROAD WHEEL»(ref-516434-S35696986952012120600000) ".

Scheme 6

1. Follow the maintenance schedule for tire rotation service intervals. Refer to " «EXPLANATION OF GENERAL MAINTENANCE»(ref-516397-S06576289682012120600000) ".
2. When installing the wheel, tighten wheel nuts to the specified torque. Refer to " «EXPLODED VIEW»(ref-516434-S02069449892012120600000) ". CAUTION: Never include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria. Use NISSAN genuine wheel nut.
3. Perform the ID registration, after tire rotation. Refer to " «WORK PROCEDURE»(ref-516434-S20319290252012120600000) ".

Scheme 7

1. If fluid level is extremely low, check brake system for leaks.

Scheme 8

1. Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.

Scheme 9

1. Drain brake fluid from each bleed valve.
2. Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BLEEDING BRAKE SYSTEM»(ref-516399-S21439092472012120600000) ". Refill with recommended brake fluid. Refer to " «FLUIDS AND LUBRICANTS»(ref-516397-S21810730752012120600000) ". Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.
