MALFUNCTION INDICATOR
The IC regulator warning function activates to illuminate "CHARGE" warning lamp, if excessive voltage is produced or no voltage is produced while generator is operating.
BELT DEFLECTION
For belt deflection specifications, see GENERATOR BELT DEFLECTION SPECIFICATIONS table.
| Application | In. (mm) | ||
|---|---|---|---|
| 2.4L | |||
| New Belt Deflection | |||
| A/C Compressor | 0.31-0.39 (8-10) | ||
| Alternator | 0.31-0.39 (8-10) | ||
| Power Steering | 0.31-0.39 (8-10) | ||
| Used Belt Deflection | |||
| A/C Compressor | 0.39-0.47 (10-12) | ||
| Alternator | 0.39-0.47 (10-12) | ||
| Power Steering | 0.39-0.51 (10-13) | ||
| 3.3L | |||
| New Belt Deflection | |||
| A/C Compressor | 0.413-0.453 (10.5-11.5) | ||
| A/C Compressor w/ Supercharger | 0.33-0.37 (8.5-9.5) | ||
| Alternator | 0.24-0.28 (6-7) | ||
| Power Steering | 0.31-0.35 (8-9) | ||
| Used Belt Deflection | |||
| A/C Compressor | 0.47-0.51 (12-13) | ||
| A/C Compressor w/ Supercharger | 0.374-0.413 (9.5-10.5) | ||
| Alternator | 0.24-0.31 (7-8) | ||
| Power Steering | 0.374-0.413 (9.5-10.5) | ||
GENERATOR BELT DEFLECTION SPECIFICATIONS
WORK FLOW
Note. For diagnostic procedure 1, see DIAGNOSTIC PROCEDURE 1, CHECK "L" TERMINAL CIRCUIT . For diagnostic procedure 2, see DIAGNOSTIC PROCEDURE 2, CHECK "B" TERMINAL CIRCUIT . For diagnostic procedure 3, see DIAGNOSTIC PROCEDURE 3, CHECK "S" TERMINAL CIRCUIT .
Scheme 7
ALTERNATOR
For overhaul (Scheme 8)
