DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred) as much as possible when the customer brings the vehicle in. GO TO 2
- REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. GO TO 3
- IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. GO TO 4
- IDENTIFY THE MALFUNCTIONING PARTS WITH "COMPONENT DIAGNOSIS" Perform the diagnosis with "Component diagnosis" of the applicable system. GO TO 5
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. GO TO 6
- FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Are the malfunctions corrected? YES: Inspection End. NO: Refer to " «INTERMITTENT INCIDENT»(ref-382152-S05830002852011011400000) ".
Scheme 62
INPUT/OUTPUT SIGNAL CHART
| Item | Input signal to main power window and door lock/unlock switch | Main power window and door lock/unlock switch function | Actuator |
|---|---|---|---|
| Key cylinder switch | LOCK/UNLOCK signal (more than 1.5 seconds over) | Power window control | Front power window motor |
| Encoder | Encoder pulse signal | ||
| Main power window and door lock/unlock switch | Front power window motor LH UP/DOWN signal | ||
| Power window and door lock/unlock switch RH | Front power window motor RH UP/DOWN signal | ||
| BCM | RAP signal | ||
| Rear power window switch | Rear power window motor UP/DOWN signal | Rear power window motor |
INPUT/OUTPUT SIGNAL CHART
| Item | Input signal to front power window switch | Front power window switch function | Actuator |
|---|---|---|---|
| Power window and door lock/unlock switch RH | Front power window motor RH UP/DOWN signal | Power window control | Front power window motor RH |
| Encoder | Encoder pulse signal | ||
| BCM | RAP signal |
INPUT/OUTPUT SIGNAL CHART
POWER WINDOW LOCK
Ground circuit inside main power window and door lock/unlock switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the main power window and door lock/unlock switch.
FRONT WINDOW ANTI-PINCH SYSTEM
| Component | Function |
|---|---|
| BCM | Supplies power supply to power window switch. Controls retained power. |
| Main power window and door lock/unlock switch | Directly controls all power window motor of all doors. Controls anti-pinch operation of front power window LH. |
| Power window and door lock/unlock switch RH | Controls front power window motor RH. Controls anti-pinch operation of front power window RH. |
| Rear power window switch | Controls rear power window motors LH and RH. |
| Front power window motor LH | Integrates the ENCODER and POWER WINDOW MOTOR. Starts operating with signals from main power window and door lock/unlock switch. Transmits power window motor rotation as a pulse signal to main power window and door lock/unlock switch. |
| Front power window motor RH | Starts operating with signals from main power window and door lock/unlock switch & power window and door lock/unlock switch RH. |
| Rear power window motor | Starts operating with signals from main power window and door lock/unlock switch & rear power window switch. |
| Front door lock assembly LH (key cylinder switch) | Transmits operation condition of key cylinder switch to power window main switch. |
| Front door switch LH or RH | Detects door open/close condition and transmits to BCM. |
COMPONENT DESCRIPTION CHART
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch. |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
CONSULT-III FUNCTION CHART
WORK SUPPORT
| Work item | Description |
|---|---|
| RETAINED PWR SET | RAP signal's power supply period can be changed by mode setting. Selects RAP signal's power supply period between three steps MODE1 (45 sec.)/MODE2 (OFF)/MODE 3 (2 min.). |
WORK ITEM DESCRIPTION CHART
Main Power Window And Door Lock/Unlock Switch
- CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Does power window motor operate with main power window and door lock/unlock switch operation? Is the inspection result normal? YES: Main power window and door lock/unlock switch power supply and ground circuit are OK. NO: Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-382206-S37155514632011011400000) ".
Power Window And Door Lock/Unlock Switch RH
- CHECK FRONT POWER WINDOW MOTOR RH FUNCTION Does front power window motor RH operate with power window and door lock/unlock switch RH operation? Is the inspection result normal? YES: Power window and door lock/unlock switch RH power supply and ground circuit are OK. NO: Refer to " «FRONT POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-382206-S02338826782011011400000) ".
Rear Power Window Switch
- CHECK REAR POWER WINDOW MOTOR FUNCTION Does rear power window motor operate with rear power window switch operation? Is the inspection result normal? YES: Rear power window switch power supply and ground circuit are OK. NO: Refer to " «REAR POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-382206-S27332587912011011400000) ".
DRIVER SIDE : Component Function Check
- CHECK POWER WINDOW MOTOR CIRCUIT Does front power window motor LH operate with operating main power window and door lock/unlock switch? Is the inspection result normal? YES: Front power window motor LH is OK. NO: Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-382206-S34849028642011011400000) ".
PASSENGER SIDE : Component Function Check
- CHECK POWER WINDOW MOTOR CIRCUIT Does power window motor operate with operating main power window and door lock/unlock switch or power window and door lock/unlock switch RH? Is the inspection result normal? YES: Front power window motor RH is OK. NO: Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-382206-S37433833922011011400000) ".
REAR LH : Component Function Check
- CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Does rear power window motor LH operate with main power window and door lock/unlock switch or rear power window switch LH? Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH : DIAGNOSIS PROCEDURE»(ref-382206-S03809448682011011400000) "
REAR RH : Component Function Check
- CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Does rear power window motor RH operate with operating main power window and door lock/unlock switch or rear power window switch RH? Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Refer to " «REAR RH : DIAGNOSIS PROCEDURE»(ref-382206-S07446152082011011400000) ".
- CHECK ENCODER OPERATION Does front door glass LH perform AUTO open/close operation normally when operating main power window and door lock/unlock switch? Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «DRIVER SIDE : DIAGNOSIS PROCEDURE»(ref-382206-S05038702772011011400000) "
- CHECK ENCODER OPERATION Does front door glass RH perform AUTO open/close operation normally when operating power window and door lock/unlock switch RH? Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «PASSENGER SIDE : DIAGNOSIS PROCEDURE»(ref-382206-S29579504252011011400000) ".
Component Function Check
- CHECK FRONT DOOR SWITCH INPUT SIGNAL Check ("DOOR SW-DR" and "DOOR SW-AS") in "DATA MONITOR" mode with CONSULT-III. Refer to " «RETAINED PWR : CONSULT-III FUNCTION (BCM - RETAINED PWR)»(ref-382181-S16331084272011011400000) ". MONITOR ITEM CONDITION CHART Monitor item Condition DOOR SW-DR OPEN : ON CLOSE : OFF DOOR SW-AS OPEN : ON CLOSE : OFF Is the inspection result normal? YES: Front door switch circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-382206-S12967478522011011400000) ".
- CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check ("KEY CYL LK-SW", "KEY CYL UN-SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM : CONSULT-III FUNCTION (BCM - COMMON ITEM)»(ref-382181-S08372301292011011400000) ". MONITOR ITEM CONDITION CHART Monitor item Condition KEY CYL LK-SW Lock : ON Neutral/Unlock : OFF KEY CYL UN-SW Unlock : ON Neutral/Lock : OFF Is the inspection result normal? YES: Key cylinder switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-382206-S35946876702011011400000) ".
POWER WINDOW MAIN SWITCH : Component Function Check
- CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM : CONSULT-III FUNCTION (BCM - COMMON ITEM)»(ref-382181-S08372301292011011400000) ". MONITOR ITEM CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «POWER WINDOW MAIN SWITCH : DIAGNOSIS PROCEDURE»(ref-382206-S23327978442011011400000) ".
FRONT POWER WINDOW SWITCH : Component Function Check
- CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH OUTPUT SIGNAL Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT-III. Refer to " «COMMON ITEM : CONSULT-III FUNCTION (BCM - COMMON ITEM)»(ref-382181-S08372301292011011400000) ". MONITOR ITEM CONDITION CHART Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «FRONT POWER WINDOW SWITCH : DIAGNOSIS PROCEDURE»(ref-382206-S24427405032011011400000) ".
- CHECK POWER WINDOW LOCK SIGNAL Exchanges for a normal main power window and door lock/unlock switch, and operation is checked. Does power window lock operate? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-382206-S25960238492011011400000) ". NO: Check condition of harness and connector.
TERMINAL REFERENCE CHART Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (R/Y) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is operated UP. Battery voltage 2 (W/B) Ground Encoder ground - - 0 3 (R/B) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is operated DOWN. Battery voltage 4 (L) Ground Door key cylinder switch LH LOCK signal Input Key position (Neutral --> Locked) 5 --> 0 5 (L) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is operated DOWN. Battery voltage 6 (R) Ground Door key cylinder switch LH UNLOCK signal Input Key position (Neutral --> Unlocked) 5 --> 0 7 (R) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is operated UP. Battery voltage 8 (G/R) 11 Front door power window motor LH UP signal Output When front LH switch in power window main switch is operated UP. Battery voltage 9 (O) 2 Encoder pulse signal 2 Input When power window motor operates. 10 (W/L) Ground RAP signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF. Battery voltage When front LH or RH door is opened during retained power operation. 0 11 (G/W) 8 Front door power window motor LH DOWN signal Output When front LH switch in power window main switch is operated DOWN. Battery voltage 13 (G/Y) 2 Encoder pulse signal 1 Input When power window motor operates. 14 (LG/W) Ground Power window serial link Input/Output IGN SW ON or power window timer operating. 15 (BR) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 10 17 (B) Ground Ground - - 0 19 (W/R) Ground Battery power supply Input - Battery voltage
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
FAIL-SAFE CONTROL
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
| Malfunction of not yet updated closed position of glass | When glass open/close operation is continuously performed without fully closing more than the specified value (approximately 10 strokes). |
FAIL SAFE REFERENCE CHART
It changes to condition before initialization and the following functions do not operate when switched to fail safe control.
- Auto-up operation
- Anti-pinch function
- Retained power function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.
Scheme 75
TERMINAL REFERENCE CHART Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 3 (W/B) Ground Encoder ground - - 0 4 (G/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates 10 8 (L) 9 Power window motor UP signal Output When power window motor is UP at operated. Battery voltage 9 (G) 8 Power window motor DOWN signal Output When power window motor is DOWN at operated. Battery voltage 10 (W/R) Ground Battery power supply Input - Battery voltage 11 (B) Ground Ground - - 0 12 (G/Y) 3 Encoder pulse signal 1 Input When power window motor operates. 15 (G/W) 3 Encoder pulse signal 2 Input When power window motor operates. 16 (LG/W) Ground Power window serial link Input/Output IGN SW ON or power window timer operating
Scheme 76
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
| Malfunction of not yet updated closed position of glass | When glass open/close operation is continuously performed without fully closing more than the specified value (approximately 10 strokes). |
FAIL SAFE REFERENCE CHART
It changes to condition before initialization and the following functions do not operate when switched to fail safe control.
- Auto-up operation
- Anti-pinch function
- Retained power function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.
Physical Values
TERMINAL REFERENCE CHART Terminal Wire color Signal name Signal input/output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR/W Ignition keyhole illumination Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 SB Combination switch input 5 Input ON Lighting, turn, wiper OFF Wiper dial position 4 3 G/Y Combination switch input 4 Input ON Lighting, turn, wiper OFF Wiper dial position 4 4 Y Combination switch input 3 Input ON Lighting, turn, wiper OFF Wiper dial position 4 5 G/B Combination switch input 2 Input ON Lighting, turn, wiper OFF Wiper dial position 4 6 V Combination switch input 1 9 GR/R Rear window defogger switch Input ON Rear window defogger switch ON 0V Rear window defogger switch OFF 5V 10 G Hazard lamp flash Input OFF ON (opening or closing) 0V OFF (other than above) Battery voltage 11 O Ignition switch (ACC or ON) Input ACC or ON Ignition switch ACC or ON Battery voltage 12 R/L Front door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 13 GR Rear door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 15 L/W Tire pressure warning check connector Input OFF - 5V 18 P Remote keyless entry receiver and optical sensor (ground) Output OFF - 0V 19 V/W Remote keyless entry receiver (power supply) Output OFF Ignition switch OFF 20 G/W Remote keyless entry receiver (signal) Input OFF Stand-by (keyfob buttons released) When remote keyless entry receiver receives signal from keyfob (keyfob buttons pressed) 21 G NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 22 W/V BUS - - Ignition switch ON or power window timer operates 23 G/O Security indicator lamp Output OFF Goes OFF --> illuminates (Every 2.4 seconds) Battery voltage --> 0V 25 BR NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 26 Y/L Rear wiper auto stop switch 2 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) 0V Forward sweep (counterclockwise direction) Fluctuating B Position (full counterclockwise stop position) Battery voltage Reverse sweep (clockwise direction) Fluctuating 27 W/R Compressor ON signal Input ON A/C switch OFF 5V A/C switch ON 0V 28 L/R Front blower monitor Input ON Front blower motor OFF Battery voltage Front blower motor ON 0V 29 W/B Hazard switch Input OFF ON 0V OFF 5V 32 R/G Combination switch output 5 Output ON Lighting, turn, wiper OFF Wiper dial position 4 33 R/Y Combination switch output 4 Output ON Lighting, turn, wiper OFF Wiper dial position 4 34 L Combination switch output 3 Output ON Lighting, turn, wiper OFF Wiper dial position 4 35 O/B Combination switch output 2 Output ON Lighting, turn, wiper OFF Wiper dial position 4 36 R/W Combination switch output 1 37 (1) B/R Key switch and ignition knob switch Input OFF Intelligent Key inserted Battery voltage Intelligent Key inserted 0V 37 (2) B/R Key switch and key lock solenoid Input OFF Key inserted Battery voltage Key inserted 0V 38 W/L Ignition switch (ON) Input ON - Battery voltage 39 L CAN-H - - - - 40 P CAN-L - - - - 42 GR Glass hatch ajar switch Input ON Glass hatch open 0 Glass hatch closed Battery 43 R/B Back door switch (without power back door) or back door latch (door ajar switch) (with power back door) Input OFF ON (open) 0V OFF (closed) Battery voltage 44 O Rear wiper auto stop switch 1 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) Battery voltage Forward sweep (counterclockwise direction) Fluctuating B Position (full counterclockwise stop position) 0V Reverse sweep (clockwise direction) Fluctuating 47 SB Front door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 48 R/Y Rear door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 49 R Cargo lamp Output OFF Any door open (ON) 0V All doors closed (OFF) Battery voltage 51 G/Y Trailer turn signal (right) Output ON Turn right ON 52 G/B Trailer turn signal (left) Output ON Turn left ON 54 Y Rear wiper output circuit 2 Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) 0V Forward sweep (counterclockwise direction) 0V B Position (full counterclockwise stop position) Battery voltage Reverse sweep (clockwise direction) Battery voltage 55 SB Rear wiper output circuit 1 Output ON OFF 0 ON Battery voltage 56 R/G Battery saver output Output OFF 30 minutes after ignition switch is turned OFF 0V ON - Battery voltage 57 Y/R Battery power supply Input OFF - Battery voltage 58 W/R Optical sensor Input ON When optical sensor is illuminated 3.1V or more When optical sensor is not illuminated 0.6V or less 59 G Front door lock assembly LH actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 60 G/B Turn signal (left) Output ON Turn left ON 61 G/Y Turn signal (right) Output ON Turn right ON 62 R/W Step lamp LH and RH Output OFF ON (any door open) 0V OFF (all doors closed) Battery voltage 63 L Interior room/map lamp Output OFF Any door switch ON (open) 0V OFF (closed) Battery voltage 65 V All door lock actuators (lock) Output OFF OFF (neutral) 0V ON (lock) Battery voltage 66 G/Y Front door lock actuator RH, rear door lock actuators LH/RH and back door lock actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 67 B Ground Input ON - 0V 68 W/L Power window power supply (RAP) Output - Ignition switch ON Battery voltage Within 45 seconds after ignition switch OFF Battery voltage More than 45 seconds after ignition switch OFF 0V When front door LH or RH is open or power window timer operates 0V 69 W/R Power window power supply Output - - Battery voltage 70 W/B Battery power supply Input OFF - Battery voltage (1) With Intelligent Key system (2) With remote keyless entry system
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Fail-safe index
BCM performs fail-safe control when any DTC listed below is detected.
| Display contents of CONSULT | Fail-safe | Cancellation |
|---|---|---|
| U1000: CAN COMM CIRCUIT | Inhibit engine cranking | When the BCM re-establishes communication with the other modules. |
FAIL SAFE REFERENCE CHART
