Glass & Window System: Removal & Installation Nissan Armada I рестайлинг

INSTALLATION

Installation is in the reverse order of removal.

1. Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished with it.
2. While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out by passenger compartment air pressure when a door is closed.
3. The molding must be installed securely so that it is in position and leaves no gap.
4. Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely cured (preferably 24 hours). Curing time varies with temperature and humidity.

Scheme 92

Repairing Water Leaks for Windshield

Leaks can be repaired without removing and reinstalling glass.

If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage. This can be done by applying water to the windshield area while pushing glass outward.

To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

Scheme 93

REMOVAL

1. Remove the rear spoiler. Refer to " «REMOVAL AND INSTALLATION»(ref-382167-S24852654932011011400000) ".
2. Disconnect the rear window defogger electrical connectors.
3. Remove the rear glass stays.
4. Remove the hinge nuts and the rear glass assembly.
5. Remove the striker and handle.
6. Remove the rear glass hinges.

Installation is in the reverse order of removal.

Scheme 94

Scheme 95

1. Remove the front door finisher panel. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".
2. Position aside the vapor barrier.
3. Remove the hole cover over rear glass bolt.
4. Temporarily reconnect the power window switch.
5. Operate the power window main switch to raise/lower the door window until the glass bolts can be seen.
6. Remove the inside seal.
7. Remove the glass bolts.
8. While holding the front door glass, raise it at the rear end and pull the glass out of the sash toward the outside of the door.

Installation is in the reverse order of removal.

Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)

1. Remove the front door finisher panel. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".
2. Position aside the vapor barrier.
3. Remove the hole cover over rear glass bolt.
4. Temporarily reconnect the power window switch.
5. Operate the power window main switch to raise/lower the door window until the glass bolts can be seen.
6. Remove the glass bolts.
7. Raise the front door glass and hold it in place with suitable tool.
8. Disconnect the harness connector from the regulator assembly.
9. Remove the bolts and the regulator assembly.

1. Install the regulator assembly.
2. Connect the harness connector to the regulator assembly.
3. Align the glass and install the glass bolts. Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
4. Reset the limit switch. Follow the "Setting of Limit Switch" procedure.
5. Reposition the vapor barrier.
6. Install the front door finisher panel. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".

Installation is in the reverse order of removal.

Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)

Fitting Inspection

1. Check that the glass is securely fit into the glass run groove.
2. Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)], and check that the clearance to the sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts, guide rail bolts, and glass and carrier plate bolts to correct the glass position.

Scheme 96

1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".
2. Position aside the vapor barrier.
3. Temporarily reconnect the power window switch.
4. Operate the power window switch to raise/lower the door window until the glass bolts can be seen.
5. Remove the inside seal.
6. Remove the glass bolts.
7. Raise the glass and hold in place with suitable tool.
8. Remove the bolts, and the regulator and guide channel.
9. Disconnect the connector from the regulator assembly.

1. Connect the harness connector to the regulator assembly and install the regulator and guide channel.
2. Install the glass from outside to ensure that it is in both the front and rear glass channels. Tighten glass bolts to the specified torque. Glass bolts : 6.1 N.m (0.62 kg-m, 54 in-lb)
3. Install the inside seal.
4. Reposition the vapor barrier.
5. Install the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S04466027832011011400000) ".

Scheme 97

1. Remove the luggage side finisher lower. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
2. Remove the luggage side finisher upper. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
3. Remove the rear side window latch bolts.
4. Remove the hinge nuts and the rear side window.

Installation is in the reverse order of removal.

1. Install the glass from outside to insure that it is even with the top and bottom of the opening.

Scheme 98

1. Remove the rear luggage side finisher lower. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
2. Remove the rear luggage side finisher upper. Refer to " «REMOVAL AND INSTALLATION»(ref-382173-S02337537752011011400000) ".
3. Disconnect the rear side window motor harness.
4. Remove the rear side window motor bolts.
5. Remove the nuts and the rear side window.

Installation is in the reverse order of removal.

1. Install the glass from outside to insure that it is even with the top and bottom of the opening.
