FUEL FILTER : Removal and Installation
The fuel filter is part of the Fuel level sensor, fuel filter and fuel pump assembly and is not serviced separately. Refer to REMOVAL AND INSTALLATION
Scheme 8
Note. The viscous paper type filter does not need cleaning between replacement intervals. Replace the air filter as necessary for periodic maintenance. Refer to " FOR USA AND CANADA : Introduction of Periodic Maintenance " FOR MEXICO : Introduction of Periodic Maintenance ".
- Remove the air cleaner case (upper).
- Remove the air cleaner filter from the air cleaner case (lower).
INSTALLATION
- Install the new air cleaner filter in the air cleaner case (lower).
- Install the air cleaner case (upper).
Scheme 9
- Before starting the engine make sure the vehicle is parked on a flat and level surface, then check the oil level. If the engine is already running, turn it off and allow 10 minutes before checking.
- Check that the oil level is within the low (L) to high (H) range as indicated on the dipstick.
- If the engine oil level is out of range, add oil as necessary. Refer to " «FOR USA AND CANADA : Fluids and Lubricants»(ref-382161-S12522039562011011400000) ".
Installation is in the reverse order of removal.
Spark Plug Types
| Make | NGK | |
|---|---|---|
| Model | Standard model | FFV model |
| Standard type (1) | DILFR5A-11 | DILFR5A-11D |
| Gap (Nominal) | 1.1 mm (0.043 in) | 1.1 mm (0.043) |
| (1) : Always check with the Parts Department for the latest information. | ||
| (1) | Always check with the Parts Department for the latest information. |
SPARK PLUG SPECIFICATION
| CAUTION | Do not drop or shock spark plug. |
TRANSFER FLUID : Replacement
| CAUTION | If using the vehicle for towing, the transfer fluid must be replaced as specified. Refer to " FOR USA AND CANADA : Introduction of Periodic Maintenance " FOR MEXICO : Introduction of Periodic Maintenance ". |
Scheme 10
- Stop engine.
- Remove the drain plug and gasket and drain the fluid.
- Install the drain plug with a new gasket to the transfer. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-382185-S11347808432011011400000) ". CAUTION: Do not reuse gasket.
Scheme 11
- Remove the filler plug and gasket.
- Fill the transfer with new fluid until the fluid level reaches the specified limit near the filler plug hole. Fluid grade and capacity : Refer to " «FOR USA AND CANADA : Fluids and Lubricants»(ref-382161-S12522039562011011400000) , «FOR MEXICO : Fluids and Lubricants»(ref-382161-S21838976482011011400000) ". CAUTION: Carefully fill fluid. (Fill up for approx. 3 minutes.)
- Leave the vehicle for 3 minutes, and check fluid level again.
- Install the filler plug with a new gasket to the transfer. Tighten to the specified torque. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-382185-S11347808432011011400000) ". CAUTION: Do not reuse gasket.
