Power Supply, Ground & Circuit Elements: Wiring — Power Supply, Ground & Circuit Elements — Body Electrical

HOW TO READ HARNESS LAYOUT

The following Harness Layouts use a map style grid to help locate connectors on the drawings

Scheme 1

Scheme 1: HOW TO READ HARNESS LAYOUT

Main Harness, Console Sub-harness, Console Switch Sub-harness and Optical Sensor Sub-harness
Engine Room Harness and Engine Room Sub-harness
Engine Room Harness (Passenger Compartment)
Engine Control Harness and Engine Control Sub-harness
Chassis Harness and Rear Sonar Sensor Sub-harness
Body Harness, Left Front Seat Harness and Third Row Power Folding Seat Sub-harness
Body No. 2 Harness and Right Front Seat Harness
Room Lamp Harness, Room Lamp Sub-harness A and Room Lamp Sub-harness B
Back Door Harness, Back Door No. 2 Harness, Back Door RH Harness, Back Door LH Harness and Back Door No. 2 RH Harness

To use the grid reference

Find the desired connector number on the connector list.
Find the grid reference.
On the drawing, find the crossing of the grid reference letter column and number row.
Find the connector number in the crossing zone.
Follow the line (if used) to the connector.

Scheme 2

Scheme 2: OUTLINE

Scheme 3

Scheme 3: MAIN HARNESS

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 7: ENGINE ROOM HARNESS

C4	E1	GR/2	Ambient sensor	E3	E114	B/6	Delta stroke motor
D3	E2	W/16	To F32	D1	E116	W/2	Condenser-2
C3	E3	B/2	Horn	D3	E117	GR/2	Front wheel sensor RH
C3	E4	Y/2	Crash zone sensor	D3	E118	B/2	IPDM E/R (intelligent power distribution module engine room)
C1	E5	W/24	To F14	C1	E119	W/16	IPDM E/R (intelligent power distribution module engine room)
D4	E6	B/6	Front combination lamp LH (with daytime light system)	D1	E120	W/6	IPDM E/R (intelligent power distribution module engine room)
C2	E7	GR/2	Fusible link box (battery)	D1	E120	W/6	IPDM E/R (intelligent power distribution module engine room)
B2	E8	GR/2	Dropping resistor	E1	E121	BR/12	IPDM E/R (intelligent power distribution module engine room)
C2	E9		Body ground	C1	E122	W/12	IPDM E/R (intelligent power distribution module engine room)
D4	E11	B/6	Front combination lamp LH (without daytime light system)	D1	E123	BR/8	IPDM E/R (intelligent power distribution module engine room)
D3	E12	B/5	Stop lamp relay	D1	E124	B/6	IPDM E/R (intelligent power distribution module engine room)
D4	E14		Body ground	F3	E125	B/47	ABS actuator and electric unit (control unit)
B2	E15		Body ground	D4	E126		Body ground
C1	E16	B/40	ECM	C2	E130	W/2	Compressor motor relay
E4	E18	GR/2	Front wheel sensor LH	C3	E131	W/2	Compressor motor relay
D1	E19	W/16	To F33	C2	E135	GR/2	Transfer dropping resistor
E3	E21	GR/2	Brake fluid level switch	C1	E140	BR/6	Trailer tow relay 2
E2	E23	GR/6	Front wiper motor	B2	E153	W/2	Transfer motor relay
D4	E24		Body ground	B2	E154	W/2	Transfer motor relay
F3	E25	BR/3	Intelligent key warning buzzer	D3	E156	L/4	Trailer turn relay LH
C3	E27	BR/2	Fusible link box (battery)	D3	E157	L/4	Trailer turn relay RH
C2	E30	/1	Fusible link box (battery)	D5	E158	B/3	Front sonar sensor LH outer
E3	E31	GR/3	Front pressure sensor	D5	E159	GR/3	To E164
E3	E32	GR/3	Rear pressure sensor	B4	E160	GR/3	To E165
C1	E39	W/2	To F34	C3	E161	B/3	Battery current sensor
D3	E40	B/3	To E201	B4	E162	B/3	Front sonar sensor LH inner
D3	E41	SMJ	To C1	C5	E163	B/3	Front sonar sensor RH inner
E1	E46	B/5	Transfer shift high relay	D5	E164	GR/3	To E159
D2	E47	B/5	Transfer shift low relay	A4	E165	GR/3	To E160
C3	E48	B/3	Refrigerant pressure sensor	A3	E166	B/3	Front sonar sensor RH outer
E3	E49	B/6	Active booster	Engine room sub-harness
D1	E69	L/4	Transfer shut off relay	D3	E201	B/3	To E40
D5	E101	B/2	Front fog lamp LH	C1	E202	/1	Fusible link box (battery)
A3	E102	B/2	Front fog lamp RH	C1	E203		Engine ground
C3	E103	B/5	Daytime light relay	C3	E204	/1	Generator
D4	E105	BR/2	Front and rear washer motor	C3	E205	B/3	Generator
E4	E106	BR/2	Washer fluid level switch	C3	E206	/1	Generator
B3	E107	B/6	Front combination lamp RH
B3	E108	B/6	Front combination lamp RH (without daytime light system)

HARNESS CONNECTOR REFERENCE

Scheme 8

Scheme 8: ENGINE ROOM HARNESS (PASSENGER COMPARTMENT)

A3	E10	W/10	To M6
G3	E17	W/4	Fuel pump control module (FPCM)
C4	E20	B/8	Accelerator pedal position (APP) sensor
A3	E26	W/16	To M91
A3	E29	Y/4	To M10
G3	E33	B/1	To M66
A3	E34	W/24	To B40
A4	E35	W/12	To B41
A4	E36	W/2	To B42
B3	E37	BR/2	ASCD brake switch
B3	E38	B/2	Stop lamp switch
B3	E109	GR/2	Pedal adjusting motor assembly (with automatic drive positioner)
C4	E110	GR/3	Pedal adjusting motor assembly
G4	E139	W/8	To B107
F3	E142	W/24	Transfer control unit
F3	E143	GR/24	Transfer control unit
G3	E152	SMJ	To M31
B3	E167	GR/2	Pedal adjusting motor (without automatic drive positioner)

HARNESS CONNECTOR REFERENCE

Scheme 9

Scheme 9: ENGINE CONTROL HARNESS

D5	F3	B/1	A/C Compressor	D4	F42	GR/2	Fuel injector No. 5
D5	F4	GR/1	Oil pressure switch	D3	F45	GR/2	Fuel injector No. 7
D2	F5	GR/4	Air fuel ratio (A/F) sensor 1 (bank 2)	B4	F46	B/3	Power steering pressure sensor
C4	F6	GR/3	Ignition coil No. 2 (with power transistor)	E4	F47	GR/3	Ignition coil No. 1 (with power transistor)
C3	F7	GR/3	Ignition coil No. 4 (with power transistor)	E4	F48	GR/3	Ignition coil No. 3 (with power transistor)
C3	F8	GR/3	Ignition coil No. 6 (with power transistor)	E4	F49	GR/3	Ignition coil No. 5 (with power transistor)
E2	F9	G/10	A/T assembly	D4	F50	W/6	Electric throttle control actuator
C2	F10		Engine ground	E4	F51	GR/3	Ignition coil No. 7 (with power transistor)
D3	F11	B/3	Crankshaft position sensor (POS)	D2	F52	GR/3	Ignition coil No. 8 (with power transistor)
E1	F12	G/4	Heated oxygen sensor 2 (bank 2)	E5	F53	B/6	Mass air flow sensor
F2	F13	G/4	Heated oxygen sensor 2 (bank 1)	B2	F54	B/81	ECM
B2	F14	W/24	To E5	F1	F55	B/2	ATP switch
D4	F15	GR/2	EVAP canister purge volume control solenoid valve	F2	F56	B/8	Transfer terminal cord assembly
E5	F16		Engine ground	G1	F57	B/2	Transfer motor
C4	F18	GR/2	Fuel injector No. 2	F2	F58	GR/6	Transfer control device
D4	F20	GR/2	Fuel injector No. 4	F1	F59	B/2	Wait detection switch
F4	F21	GR/2	Condenser-1	F1	F60	GR/2	Neutral-4LO switch
D3	F22	GR/2	Fuel injector No. 6	D5	F61	G/2	Intake valve timing control solenoid valve (bank 1)
D5	F23	B/3	Camshaft position sensor (phase)	D5	F62	B/3	Intake valve timing control position sensor (bank 1)
D4	F26	B/6	To F101	C4	F63	G/2	Intake valve timing control solenoid valve (bank 2)
E3	F27	/1	Starter motor	C4	F64	B/3	Intake valve timing control position sensor (bank 2)
E3	F28	GR/1	Starter motor	E3	F65	GR/4	Air fuel ratio (A/F) sensor 1 (bank 1)
D4	F30	GR/2	Fuel injector No. 1	C2	F68	GR/2	Water valve
D3	F31	GR/2	Fuel injector No. 8	Engine control sub-harness
B2	F32	W/16	To E2	C3	F101	B/6	To F26
C2	F33	W/16	To E19	C3	F102	B/2	Knock sensor (bank 1)
C2	F34	W/2	To E39	C3	F103	GR/2	Engine coolant temperature sensor
B3	F39		Fusible link (battery)	C3	F104	B/2	Knock sensor (bank 2)
D4	F41	GR/2	Fuel injector No. 3

HARNESS CONNECTOR REFERENCE

Scheme 10

Scheme 10: CHASSIS HARNESS

G2	C1	SMJ	To E41	A4	C13	GR/6	To C108
B5	C2	B/7	Trailer	A5	C15	B/7	Trailer receptacle
A3	C3	GR/8	To C101	Rear sonar sensor sub-harness
C3	C4	GR/3	Evap control system pressure sensor	A4	C101	GR/8	To C3
D2	C5	GR/5	Fuel level sensor unit and fuel pump (without flex fuel)	A3	C102	B/3	Rear sonar sensor LH outer
C3	C6	B/2	Evap canister vent control valve	B4	C103	B/3	Rear sonar sensor LH inner
B4	C7	GR/2	Rear bumper antenna	B4	C104	B/3	Rear sonar sensor RH inner
C4	C8	B/3	Height sensor	C5	C105	B/3	Rear sonar sensor RH outer
B4	C9	B/4	Suspension air compressor	A5	C106	GR/2	License plate lamp LH
C4	C10	BR/2	Rear wheel sensor RH	B5	C107	GR/2	License plate lamp RH
C4	C11	BR/2	Rear wheel sensor LH	A4	C108	GR/6	To C13
D2	C12	GR/5	Fuel level sensor unit and fuel pump (with flex fuel)

HARNESS CONNECTOR REFERENCE

Scheme 11

Scheme 11: BODY HARNESS

G3	B3	W/16	Suspension control unit	Front seat LH harness
D4	B6	W/18	To D201	C3	B200	W/16	To B37 (with automatic drive positioner)
C5	B7		Body ground	D5	B202	W/32	Driver seat control unit
D4	B8	W/3	Front door switch LH	D5	B203	W/16	Driver seat control unit
C4	B9	Y/12	Air bag diagnosis sensor unit	C4	B204	GR/5	Sliding motor LH (with automatic drive positioner)
E5	B10	Y/2	Front LH side air bag module	D3	B205	W/4	Reclining motor LH (with automatic drive positioner)
E5	B14	Y/2	Front LH seat belt pre-tensioner	C4	B206	GR/5	Lifting motor (front) (with automatic drive positioner)
E5	B15	Y/2	LH side air bag (satellite) sensor	D4	B207	GR/5	Lifting motor (rear) (with automatic drive positioner)
E3	B18	W/3	Rear door switch LH	D4	B208	W/10	Power seat switch LH (with automatic drive positioner)
G1	B19		Body ground	D4	B209	W/3	Front seat heater LH
F2	B24	W/16	Sonar control unit (rear)	D3	B211	W/2	To B45 (without automatic drive positioner)
B4	B32	W/6	To B124	C5	B212	GR/2	Sliding motor LH (without automatic drive positioner)
G2	B35	B/3	Rear combination lamp LH	D3	B213	W/2	Reclining motor LH (without automatic drive positioner)
D3	B37	W/16	To B200 (with automatic drive positioner)	C4	B214	GR/2	Lifting motor (front) (without automatic drive positioner)
C4	B38	Y/2	LH side front curtain air bag module	D4	B215	GR/2	Lifting motor (rear) (without automatic drive positioner)
C5	B40	W/24	To E34	D4	B216	W/10	Power seat switch LH (without automatic drive positioner)
C5	B41	W/12	To E35	Third row power folding seat sub-harness
C5	B42	W/2	To E36	F2	B400	W/10	To B75
B4	B43	W/16	To B111	E3	B401	GR/12	Third row power folding seat control unit
D3	B45	W/2	To B211 (without automatic drive positioner)	E3	B402	W/10	Third row power folding seat control unit
F1	B48	W/18	To D401	E3	B403	GR/4	Third row power folding seat motor LH
F1	B49	W/2	To D402	E2	B404	W/4	To B425
G2	B52	W/2	Rear power vent window motor LH	E2	B425	W/4	To B404
F2	B54	Y/2	LH side rear curtain air bag module	E3	B426	GR/4	Third row power folding seat motor RH
G3	B55	W/26	Back door control unit
F2	B56	GR/16	Sonar control unit (front and rear)
G2	B57	GR/10	Sonar control unit (front and rear)
G1	B63	W/6	Back door close switch
B5	B69	SMJ	To M40
G2	B70	B/3	Rear combination lamp LH
G5	B71	B/2	Back-up lamp LH
D5	B72	BR/6	Subwoofer
C4	B74	Y/4	Seat belt buckle pre-tensioner assembly LH
F2	B77	W/10	To B400
F2	B76	GR/2	Luggage area antenna

HARNESS CONNECTOR REFERENCE

Scheme 12

Scheme 12: BODY NO. 2 HARNESS

F5	B101	W/16	To M84	A1	B140	W/6	To D601
A3	B105	B/3	Rear combination lamp RH	E5	B141	W/8	Bluetooth control unit
D4	B106	W/18	To D301	E5	B142	W/32	Bluetooth control unit
F4	B107	W/8	To E139	E2	B145	W/16	To R200
E4	B108	W/3	Front door switch RH	E2	B146	BR/24	To R201
F4	B111	W/16	To B43	F4	B149	SMJ	To M36
E3	B113	Y/12	Air bag diagnosis sensor unit	B3	B150	W/2	Rear power vent window motor RH
D5	B114	Y/2	RH side air bag (satellite) sensor	B2	B153	W/2	Cargo lamp
C4	B116	W/3	Rear door switch RH	E5	B154	W/2	To B303
F5	B117		Body ground	B3	B155	B/6	Air mix door motor (rear)
E5	B118	W/3	Front seat heater RH	B3	B156	B/6	Mode door motor (rear)
A3	B119	W/2	Condenser-3	E4	B157	Y/4	Seat belt buckle pre-tensioner assembly RH
A2	B120	W/2	Condenser-4	F4	B161	W/20	To M157
F4	B124	W/6	To B32	C3	B162	BR/6	Third row power folding seat switch passenger side (front)
E4	B126	Y/2	Front RH side air bag module	A3	B163	W/6	Third row power folding seat switch passenger side (rear)
D4	B127	Y/2	Front RH seat belt pre-tensioner	C3	B164	W/6	Third row power folding seat switch driver side (front)
C3	B128	Y/2	RH side rear curtain air bag module	A3	B165	BR/6	Third row power folding seat switch driver side (rear)
F4	B129	Y/2	RH side front curtain air bag module	B2	B166	B/2	Rear sonar buzzer
A3	B130	B/3	Rear combination lamp RH	Front seat RH harness
A3	B132		Body ground	E4	B303	W/2	To B154
A4	B133	W/4	Variable blower control (rear)	F4	B308	W/6	Power seat switch RH
B4	B134	W/2	Rear blower motor	E4	B309	GR/2	Sliding motor RH
A4	B135	B/2	Back-up lamp RH	E4	B350	Y/8	To B136
D4	B136	W/8	To B350	E4	B351	B/18	Occupant classification system control unit
D4	B137	W/3	Belt tension sensor	E4	B352	B/3	Occupant classification system sensor
B3	B138	B/3	Rear cargo power socket	E4	B372	W/2	Reclining motor RH
A2	B139	W/16	To D602

HARNESS CONNECTOR REFERENCE

Scheme 13

Scheme 13: ROOM LAMP HARNESS

A4	R1	W/16	To M1	C3	R107	W/8	To R9
A4	R2	W/12	To M2	C2	R108	B/6	Rear air control (front)
D3	R3	W/2	Vanity lamp LH	D2	R109	W/4	Microphone
C3	R4	W/10	Sunroof motor assembly	Room lamp sub-harness B
C2	R6	W/16	To R101	D1	R200	W/16	To B145
C3	R7	GR/10	Auto anti-dazzling inside mirror	D1	R201	BR/24	To B146
B3	R8	W/2	Vanity lamp RH	C2	R202	W/12	Video monitor
D3	R9	W/8	To R107	D1	R203	W/3	Personal lamp 2ND row
Room lamp sub-harness A				D2	R204	W/16	Rear audio remote control unit
C2	R101	W/16	To R6	E1	R205	W/3	Personal lamp 3RD row
C3	R102	GR/8	Front room/map lamp assembly	D2	R209	B/6	Rear air control (rear)
D3	R104	GR/6	Sunroof switch	E1	R210	W/2	Over head console area antenna

HARNESS CONNECTOR REFERENCE

Scheme 14

Scheme 14: FRONT DOOR LH HARNESS

D1	BR/24	To M9	D9	GR/6	Front power window motor LH
D2	W/16	To M8	D10	BR/16	Door mirror remote control switch (with automatic drive positioner)
D3	W/10	To M158	D11	W/2	Front step lamp LH
D4	W/16	Door mirror LH (with automatic drive positioner)	D12	W/2	Front door speaker LH
D5	W/8	Seat memory switch	D13	W/16	Door mirror remote control switch (without automatic drive positioner)
D6	W/6	Door mirror LH (without automatic drive positioner)	D14	B/6	Front door lock assembly LH
D7	W/16	Main power window and door lock/unlock switch	D15	GR/2	Front outside antenna LH
D8	W/3	Main power window and door lock/unlock switch	D16	GR/2	Front door request switch LH

HARNESS CONNECTOR REFERENCE

Scheme 15

Scheme 15: FRONT DOOR RH HARNESS

D101	W/10	To M75	D109	W/2	Front step lamp RH
D102	BR/20	To M74	D112	W/2	Front door speaker RH
D104	GR/6	Front power window motor RH	D114	B/6	Front door lock actuator RH
D105	W/16	Power window and door lock/unlock switch RH	D115	GR/2	Front outside antenna RH
D106	W/6	Door mirror RH (without automatic drive positioner)	D116	GR/2	Front door request switch RH
D107	W/16	Door mirror RH (with automatic drive positioner)

HARNESS CONNECTOR REFERENCE

Scheme 16

Scheme 16: REAR DOOR LH HARNESS

D201	W/18	To B6
D203	W/8	Rear power window switch LH
D204	GR/2	Rear power window motor LH
D205	B/6	Rear door lock actuator LH
D206	W/2	Rear step lamp LH
D207	BR/2	Rear door speaker LH (with Bose audio system)
D208	BR/2	Rear door tweeter LH
D209	W/2	Rear door speaker LH (with base audio system)

HARNESS CONNECTOR REFERENCE

Scheme 17

Scheme 17: REAR DOOR RH HARNESS

D301	W/18	To B106
D303	W/8	Rear power window switch RH
D304	GR/2	Rear power window motor RH
D305	B/6	Rear door lock actuator RH
D306	W/2	Rear step lamp RH
D307	BR/2	Rear door speaker RH (with Bose audio system)
D308	BR/2	Rear door tweeter RH
D309	W/2	Rear door speaker RH (with base audio system)

HARNESS CONNECTOR REFERENCE

Scheme 18

Scheme 18: BACK DOOR HARNESS

Back door No. 2 LH harness				Back door RH harness
E2	D401	W/18	To B48	B3	D701	W/16	To D606
E2	D402	W/2	To B49	A3	D702	W/6	To D605
D2	D403	GR/2	High-mounted stop lamp	D3	D704	W/6	Rear wiper motor
G3	D405	W/18	To D501	C4	D706	GR/2	Back door handle switch
F2	D406	B/1	Rear window defogger	D2	D707	B/1	Glass hatch ajar switch
Back door LH harness				D3	D708	W/4	Back door lock actuator
G3	D501	W/18	To D405	B4	D715	BR/2	Pinch strip RH
E3	D502	W/3	Back door switch	B4	D716	BR/2	Back door speaker RH
E4	D503	W/8	Back door latch
E4	D504	W/4	Rear view camera
F4	D514	BR/2	Back door warning chime
F4	D517	BR/2	Pinch strip LH
F4	D518	BR/2	Back door speaker LH
Back door No. 2 RH harness
C2	D601	W/6	To B140
C2	D602	W/16	To B139
D2	D603		Body ground
B2	D604	B/1	Rear window defogger
A3	D605	W/6	To D702
B3	D606	W/16	To D701

HARNESS CONNECTOR REFERENCE

Scheme 19

Scheme 19: ENGINE COMPARTMENT

Scheme 20

Scheme 20: PASSENGER COMPARTMENT

Scheme 21

HARNESS CONNECTOR (TAB-LOCKING TYPE)

The tab-locking type connectors help prevent accidental looseness or disconnection.
The tab-locking type connectors are disconnected by pushing or lifting the locking tab(s). Refer to the figure below.

Refer to HARNESS CONNECTOR (SLIDE-LOCKING TYPE) for description of the slide-locking type connector.

CAUTION

Do not pull the harness or wires when disconnecting the connector.

[Example]

Scheme 22

HARNESS CONNECTOR (SLIDE-LOCKING TYPE)

A new style slide-locking type connector is used on certain systems and components, especially those related to OBD.
The slide-locking type connectors help prevent incomplete locking and accidental looseness or disconnection.
The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the figure below.

CAUTION

Do not pull the harness or wires when disconnecting the connector. Be careful not to damage the connector support bracket when disconnecting the connector.

Scheme 23

Scheme 23: [Example]

HARNESS CONNECTOR (LEVER LOCKING TYPE)

Lever locking type harness connectors are used on certain control units and control modules such as ECM, ABS actuator and electric unit (control unit), etc.
Lever locking type harness connectors are also used on super multiple junction (SMJ) connectors.
Always confirm the lever is fully locked in place by moving the lever as far as it will go to ensure full connection.

Scheme 24

HARNESS CONNECTOR (DIRECT-CONNECT SRS COMPONENT TYPE)

SRS direct-connect type harness connectors are used on certain SRS components such as air bag modules and seat belt pre-tensioners.
Always pull up to release black locking tab prior to removing connector from SRS components.
Always push down to lock black locking tab after installing connector to SRS components. When locked, the black locking tab is level with the connector housing.

Scheme 25

Power Supply, Ground & Circuit Elements: Wiring Nissan Armada I рестайлинг

HOW TO READ HARNESS LAYOUT

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

HARNESS CONNECTOR (TAB-LOCKING TYPE)

Scheme 22

HARNESS CONNECTOR (SLIDE-LOCKING TYPE)

Scheme 23

HARNESS CONNECTOR (LEVER LOCKING TYPE)

Scheme 24

HARNESS CONNECTOR (DIRECT-CONNECT SRS COMPONENT TYPE)

Scheme 25

More articles — Power Supply, Ground & Circuit Elements

Login / Signup

Enter the code

You have successfully logged in!
