AIR CLEANER FILTER : Removal and Installation
REMOVAL
Scheme 32
Scheme 33
- Unhook clips (A).
- Remove holder (3) from air cleaner case (2), and then remove air cleaner filter (1) from holder.
INSTALLATION
Note the following, and install in the reverse order of removal.
- Install the air cleaner filter by aligning the seal with the notch of air cleaner case.
OIL FILTER : Removal and Installation
REMOVAL
| CAUTION | Oil filter is provided with relief valve. Use genuine NISSAN oil filter or equivalent. Be careful not to get burned when engine and engine oil may be hot. When removing, prepare a shop cloth to absorb any engine oil leakage or spillage. Never allow engine oil to adhere to drive belt. Completely wipe off any engine oil that adheres to engine and vehicle. |
Scheme 34
- Remove engine undercover with power tool.
- Using oil filter wrench [SST: KV10115801 (J-38956)] (A), remove oil filter.
INSTALLATION
Scheme 35
Scheme 36
- Remove foreign materials adhering to oil filter installation surface.
- Apply engine oil to the oil seal contact surface of new oil filter.
- Screw oil filter manually until it touches the installation surface, then tighten it by 2/3 turn (A). Or tighten to the specification. Oil filter: : 17.7 N.m (1.8 kg-m, 13 ft-lb)
SPARK PLUG : Removal and Installation
REMOVAL
Scheme 37
- Remove engine cover with power tool. Refer to " «EXPLODED VIEW»(ref-402630-S30675446912011053100000) ".
- Remove air cleaner case and air duct (RH and LH). Refer to " «EXPLODED VIEW»(ref-402630-S30945629272011053100000) ".
- Remove electric throttle control actuator. Refer to " «EXPLODED VIEW»(ref-402630-S33004613582011053100000) ".
- Remove ignition coil. Refer to " «REMOVAL AND INSTALLATION»(ref-402630-S14338146372011053100000) ".
- Remove spark plug with a spark plug wrench (commercial service tool).
INSTALLATION
Installation is the reverse order of removal.
