WIPER/WASHER SWITCH CONTINUITY CHECK
| Switch position | Tester connection | Specified condition |
|---|---|---|
| OFF | Open circuit | |
| Windshield intermittent wiper interval adjusting knob | 8 - 3 | Operating the adjusting knob changes the resistance. |
WIPER/WASHER SWITCH CONTINUITY CHECK - 1 OF 2
Scheme 10
| Switch position | Tester connection | Specified condition | |
|---|---|---|---|
| Windshield wiper switch | Hi | 8 - 4 | Continuity exists (2 ohms or less) |
| Int | 8 - 5 | Continuity exists (2 ohms or less) | |
| Lo | 8 - 6 | Continuity exists (2 ohms or less) | |
| Mist | 8 - 10 | Continuity exists (2 ohms or less) | |
| Windshield washer switch | 8 - 7 | Continuity exists (2 ohms or less) | |
| Rear wiper switch | 8 - 9 | Continuity exists (2 ohms or less) | |
| Rear washer switch | 8 - 11 | Continuity exists (2 ohms or less) | |
WIPER/WASHER SWITCH CONTINUITY CHECK - 2 OF 2
Scheme 11
- Remove the lighting switch and the wiper/washer switch.
- Check that the continuity is present for the same terminal numbers (No. 2-11) of the column switch body connectors that remain on the steering column. COLUMN SWITCH (SWITCH BODY PART) CONTINUITY CHECK Column switch body Tester connection Specified condition Lighting switch side connector Wiper/washer switch side connector 2 - 2 3 - 3 4 - 4 5 - 5 6 - 6 7 - 7 8 - 8 9 - 9 10 - 10 11 - 11 Continuity exists (2 ohms or less)
