HEADLIGHT BULB (LOW-BEAM) REPLACEMENT < VEHICLES WITHOUT DISCHARGE HEADLIGHT >
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Scheme 30
- Twist the socket cover to remove.
- Disconnect the connector, and twist the headlight bulb (low-beam) to remove.
HEADLIGHT BULB (HIGH-BEAM) REPLACEMENT
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Scheme 31
- Twist the socket cover to remove.
- Disconnect the connector, and twist the headlight bulb (high-beam) to remove.
POSITION LIGHT BULB REPLACEMENT
Disconnect the connector, and twist the position light socket to remove it.
Scheme 32
Scheme 33
- Remove the headlight support upper panel. (Refer to «REMOVAL AND INSTALLATION»(ref-592985-S16799188142014011300000) ).
- Disconnect the connector, and twist the front turn-signal light socket to remove it.
<< A >> HEADLIGHT BULB REMOVAL < VEHICLES WITH DISCHARGE HEADLIGHT >
| CAUTION | Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb. |
Scheme 34
Scheme 35
Scheme 36
- Twist the socket cover to remove.
- Disconnect the igniter.
- Release the bulb securing spring, and remove the bulb.
<< B >> HEADLIGHT CONTROL UNIT (HARNESS) REMOVAL < VEHICLES WITH DISCHARGE HEADLIGHT >
When removing the wiring harness from the headlight assembly, because the wiring harness is fixed using the resin washer, remove by pressing out the wiring harness to above the resin washer.
Scheme 37
>> A << HEADLIGHT CONTROL UNIT INSTALLATION < VEHICLES WITH DISCHARGE HEADLIGHT >
When installing the wiring harness to the headlight assembly, fit the wiring harness into the resin washer.
Scheme 38
Scheme 39
<< A >> LIGHTING CONTROL SENSOR REMOVAL
While pushing the clamp to the windshield side, pry up the clamp to disengage the right and left claws using the screwdriver (-), and then remove the lighting control sensor.
Scheme 40
>> A << LIGHTING CONTROL SENSOR INSTALLATION
| CAUTION | After executing the lighting control sensor (rain sensor) adaptation, do not touch the lighting control sensor (or do not move it from the fixed position). |
- Mount the lighting control sensor onto the optical coupler, and then connect the connector.
- When reusing the lighting control sensor or when the lighting control sensor is pushed to check the installation condition, install the connector and the lighting control sensor cover and wipe the windshield thoroughly. When the windshield is dry, execute the lighting control sensor (rain sensor) adaptation. < Refer to «LIGHTING CONTROL SENSOR (RAIN SENSOR) ADAPTATION»(ref-593015-S31060413392014011300000) >. NOTE: Be careful not to touch the lighting control sensor receiver. (The lighting control sensor receiver has limited resistance to oil).
