Remote Controlled Mirror Operation
- The mirror on the door mirror moves up/down and left/right by operating the remote controlled door mirror switch when the ignition switch is at the "ON" or "ACC" position.
Heated Door Mirror Operation
- The rear window defogger relay switch is activated (ON) by turning on the A/C-ECU built-in rear window defogger switch when the ignition switch is in the "ON" position. When the rear window defogger relay is turned ON, power is supplied to the rear window defogger and door mirror, and the heater of the door mirror (heated door mirror) starts operations. The rear window defogger comes with a timer function and will automatically turn OFF the switch approximately 20 minutes after the rear window defogger switch is turned ON. The heated door mirror operations are also terminated along with the rear window defogger, at this time.
CIRCUIT OPERATION
If both of the door mirror heaters do not operate normally it may be due to a malfunction in the rear window defogger system.
If either of the heated door mirror do not operate normally, it may be due to malfunctions in the heated door mirror circuit or door mirror.
DOOR MIRROR ASSEMBLY OPERATION CHECK
Remove the door trim, and then connect the battery to the door mirror assembly connector to check that the door mirror operates.
Scheme 1
| Battery connection | Operation direction |
|---|---|
| Connect terminal 13 to the negative battery terminal. Connect terminal 4 to the positive battery terminal. | Up |
| Connect terminal 13 to the positive battery terminal. Connect terminal 4 to the negative battery terminal. | Down |
| Connect terminal 13 to the negative battery terminal. Connect terminal 12 to the positive battery terminal. | Right |
| Connect terminal 13 to the positive battery terminal. Connect terminal 12 to the negative battery terminal. | Left |
DOOR MIRROR ASSEMBLY OPERATION CHECK
