REMOTE CONTROLLED MIRROR SWITCH CONTINUITY CHECK
| Switch position | Tester connection | Specified condition | |
|---|---|---|---|
| Left side | Up | 1 - 6, 9 - 11 | Continuity (Less than 2 ohms) |
| Down | 1 - 11, 6 - 9 | ||
| Right | 1 - 6, 9 - 10 | ||
| Left | 1 - 10, 6 - 9 | ||
| Right side | Up | 1 - 6, 3 - 9 | |
| Down | 1 - 3, 6 - 9 | ||
| Right | 1 - 6, 2 - 9 | ||
| Left | 1 - 2, 6 - 9 | ||
REMOTE CONTROLLED MIRROR SWITCH CONTINUITY CHECK
Scheme 13
HEATED DOOR MIRROR CHECK
| CAUTION | When relocating the car between locations with extremely different temperatures (warm and cold), leave the car in the location for a while to adapt to the temperature prior to checking it. |
Check that the resistance value between the connector terminals is at the standard value.
Standard value: 7.2 ± 1.4 ohms at 25°C (77°F)
