GENERAL INFORMATION
The following three types of speakers are available
Scheme 1
- 4 speakers (front door: 16 cm, rear door: 16 cm)
- 6 speakers (tweeter: 3.5 cm, front door: 16 cm, rear door: 16 cm)
- 9 speakers 7 position system (tweeter: 3.5 cm, front door: 16 cm, rear door: 2-way coaxial 16 cm, subwoofer: 25 cm)
Specifications
| Item | Vehicles with 4 or 6 speakers | Vehicles with 9 speakers 7 position system | ||
|---|---|---|---|---|
| Allowable input power | Rated input power | Allowable input power | Rated input power | |
| Tweeter | 25W | 3W | 50W | 25W |
| Front door speaker | 35W | 15W | 75W | 50W |
| Rear door speaker | 35W | 15W | 80W | 50W |
| Subwoofer | 150W/150W | 75W/75W | ||
SPEAKER WATTAGE
For the front door sash trim, two types of tweeters, the balanced dome tweeter < Vehicles with 6 speakers > and soft dome tweeter < Vehicles with 9 speakers 7 position system >, have been established. The soft dome tweeter can play clearer treble with less distortion compared to the balanced dome tweeter. For better treble, two types of front door sash trim, resin type < Vehicles with 6 speakers > and punching metal type < Vehicles with 9 speakers 7 position system >, has been established. With the punching metal type, the metal has been adopted for the punching part to enlarge the punching opening, enabling the playback of cleaner treble.
Scheme 2
The 25-cm dual voice coil subwoofer has been installed to the quarter trim lower (RH), enabling the playback of dynamic deep bass.
Scheme 3
For the front door speaker, two types of speakers, 16-cm paper cone speaker vehicles with 4 or 6 speakers and PP (polypropylene) cone speaker vehicles with 9 speakers 7 position system, are available. For the rear door speaker, two types of speakers, 16-cm paper cone speaker vehicles with 4 or 6 speakers and PP (polypropylene) cone 2-way coaxial speaker vehicles with 9 speakers 7 position system, are available. Compared to the paper cone speakers, the PP (polypropylene) cone speakers can playback crisper bass. The door opening of the vehicles with 9 speakers 7 position system is blocked by using the sheet metal cover and the urethane integrated resin sheet (resin cover and water proof film) to make the door into a speaker box, thus improving the sound quality. As an advantage of the sheet metal cover, the rigidity of the areas around the speaker has been increased, and the higher sound pressure, suppression of high harmonic, and suppression of dumping are achieved to improve sound quality.
Scheme 4
Note. The parts with "*" are installed exclusively to the vehicles with 9 speakers 7 position system.
