Continuously Variable Transaxle (Cvt) Overhaul: Removal & Installation Mitsubishi Outlander III

Automatic Trans 30 illustrations ~825 words

<< A >> SNAP RING REMOVAL

Using a flat blade screwdriver etc., remove the snap ring from the forward clutch drum.

Scheme 101

Scheme 101: << A >> SNAP RING REMOVAL

<< B >> INTERNAL GEAR REMOVAL

Remove the internal gear from the forward clutch drum.

Scheme 102

Scheme 102: << B >> INTERNAL GEAR REMOVAL

<< C >> SNAP RING REMOVAL

Using a flat blade screwdriver etc., remove the snap ring from the forward clutch drum.

Scheme 103

Scheme 103: << C >> SNAP RING REMOVAL

<< D >> SNAP RING REMOVAL

Remove the snap ring using snap ring pliers, and remove the input shaft from the forward clutch drum.

Scheme 104

Scheme 104: << D >> SNAP RING REMOVAL

<< E >> SEAL RING REMOVAL

Remove the seal rings (small and big) from the input shaft.

Scheme 105

Scheme 105: << E >> SEAL RING REMOVAL

>> A << SEAL RING INSTALLATION

CAUTIONApply Vaseline when installing the seal rings. Do not re-use the seal rings.

Install the seal rings (small and big) on the input shaft.

>> B << SNAP RING INSTALLATION

CAUTIONBe careful not to strain the snap ring by expanding it excessively. Do not re-use the snap ring.

Install the input shaft on the forward clutch drum, and attach the snap ring.

>> C << SNAP RING INSTALLATION

CAUTIONDo not re-use the snap ring.

Install the snap ring on the forward clutch drum.

>> D << INTERNAL GEAR INSTALLATION

Install the internal gear on the forward clutch drum.

>> E << SNAP RING INSTALLATION

CAUTIONDo not re-use the snap ring.

Install the snap ring on the forward clutch drum.

<< A >> NUT REMOVAL

Remove the nut from the reduction gear sub-assembly.

Scheme 106

Scheme 106: << A >> NUT REMOVAL

<< B >> REDUCTION GEAR BEARING REMOVAL

CAUTIONAlign the tang of special tool as shown in the illustration.

Scheme 107

Scheme 107

Scheme 108

Scheme 108

Using the special tools MB990810, MB990947 and MD999566, remove the inner race of reduction gear bearing (converter housing side) from the reduction gear sub-assembly.

<< C >> REDUCTION GEAR BEARING REMOVAL

Using the special tools MB990984 and MD998917, remove the outer race of reduction gear bearing (transaxle case side) from the reduction gear sub-assembly.

Scheme 109

Scheme 109: << C >> REDUCTION GEAR BEARING REMOVAL

>> A << REDUCTION GEAR BEARING INSTALLATION

CAUTIONDo not re-use the inner race. Replace the inner race together with the outer race.

Using the special tools MD998812, MD998813 and MD998819, install the inner race of reduction gear bearing (transaxle case side) on the reduction gear sub-assembly.

Scheme 110

Scheme 110

>> B << REDUCTION GEAR BEARING INSTALLATION

CAUTIONDo not re-use the inner race. Replace the inner race together with the outer race.

Using the special tools MD998812, MD998813 and MD998819, install the inner race of reduction gear bearing (converter housing side) on the reduction gear sub-assembly.

Scheme 111

Scheme 111

>> C << NUT INSTALLATION

Install the nut on the reduction gear sub-assembly to the specified torque.

Tightening torque: 250 N.m (184 ft-lb)

Scheme 112

Scheme 112: >> C << NUT INSTALLATION

>> A << REDUCTION PINION GEAR/IDLER GEAR INSTALLATION

CAUTIONWhen attaching the idler gear to the reduction pinion gear, make sure the center boss portion A faces the reduction pinion gear.
Center boss portion ALong
Center boss portion BShort

CENTER BOSS REFERENCE

Using the special tools MD998812, MD998813 and MD998819, attach the idler gear to the reduction pinion gear.

Scheme 113

Scheme 113

Scheme 114

Scheme 114

Scheme 115

Scheme 115: DISASSEMBLY AND ASSEMBLY

Required special tools

  1. MB990810: Side bearing puller
  2. MB991452: Oil seal installer
  3. MD998812: Installer cap
  4. MD998813: Installer-100
  5. MD998823: Installer adapter (48)
  6. MB992138: Bearing Installer

<< A >> DIFFERENTIAL SIDE BEARING REMOVAL

Using the special tool MB990810, remove the inner race of differential side bearing (transaxle case side) from the differential sub-assembly.

Scheme 116

Scheme 116: << A >> DIFFERENTIAL SIDE BEARING REMOVAL

<< B >> DIFFERENTIAL SIDE BEARING REMOVAL

Using the special tools MB990810 and MB991452 < W1CJA >, remove the inner race of differential side bearing (converter housing side) from the differential sub-assembly.

Scheme 117

Scheme 117: << B >> DIFFERENTIAL SIDE BEARING REMOVAL

Scheme 118

Scheme 118

>> A << DIFFERENTIAL SIDE BEARING INSTALLATION

CAUTIONDo not re-use the inner race. Replace the inner race together with the outer race.

Using the special tool MD998812, MD998813 and MD998823 < F1CJA > or MB992138 < W1CJA >, install the inner race of reduction gear bearing (converter housing side) on the reduction gear sub-assembly.

Scheme 119

Scheme 119

Scheme 120

Scheme 120
CAUTIONDo not re-use the inner race. Replace the inner race together with the outer race.

Using the special tools MD998812, MD998813 and MD998823, install the inner race of reduction gear bearing (transaxle case side) on the reduction gear sub-assembly.

Scheme 121

Scheme 121

>> A << DIFFERENTIAL CASE/FINAL GEAR INSTALLATION

CAUTIONWhen attaching the final gear to the differential case, make sure the side with the bigger distance from the edge to the flange A face the differential case.
Distance from gear edge to flange ALong
Distance from gear edge to flange BShort

GEAR EDGE TO FLANGE DISTANCE

Scheme 122

Scheme 122

Install the final gear on the differential case, and tighten the fastening bolts to the specified torque.

Tightening torque: 130 N.m (96 ft-lb)

Scheme 123

Scheme 123

Scheme 124

Scheme 124: DISASSEMBLY AND ASSEMBLY

Required special tools

  1. MD998812: Installer cap
  2. MB992154: Oil seal installer
  3. MB992075: Handle
  4. MB992142: Oil seal installer
  5. MB990936: Installer adapter

Scheme 125

Scheme 125: >> A << COVER INSTALLATION
  1. Apply a 1.5 mm diameter bead of sealant as illustrated onto the cover. 3M™ATD Part No. 8660 or equivalent
  2. Attach the cover to the transfer and tighten it to the specified torque. Tightening torque: 12 ± 2 N.m (106 ± 18 in-lb)

>> B << OIL SEAL INSTALLATION

CAUTIONPay attention to the transfer case that can possibly twist when the pin projection is too large.

Scheme 126

Scheme 126

Scheme 127

Scheme 127

Scheme 128

Scheme 128
  1. Adjust the projection allowances of the two pins of the special tool, Oil Seal Installer (MB992154) to be 0.2 ± 0.1 mm (0.007 ± 0.003 in). NOTE: The two pins are inserted into the special tool, Oil Seal Installer (MB992154). When the oil seal is replaced, the traces are found on the transfer case so that the replacement using the specified special tool can be recognized.
  2. Apply specified grease to the oil seal lip area. Specified grease: Retinax A
  3. Using the special tool MD998812 and MB992154, install the oil seal.
  4. Check whether the two traces are found on the transfer case.

Scheme 129

Scheme 129: >> C << OIL SEAL INSTALLATION
  1. Using the special tool MB992075 and MB992142, install the oil seal.
  2. Apply specified grease to the oil seal lip area. Specified grease: Retinax A

Scheme 130

Scheme 130: >> D << OIL SEAL INSTALLATION
  1. Using the special tool MB990936, install the oil seal.
  2. Apply transfer oil to the lip of oil seal.
