TRANSAXLE MODELS
| Transaxle model | Engine model | Vehicle model |
|---|---|---|
| F1CJA-2-A3U | 4B11 | GA2W |
| F1CJA-2-A3T | 4B11 | GA2W |
| W1CJA-2-A3UA | 4B11 | GA2W |
| W1CJA-2-A3TA | 4B11 | GA2W |
TRANSAXLE MODELS REFERENCE
Scheme 267
Scheme 268
Scheme 269
TRANSFER
| Item | N.m |
|---|---|
| Transfer mounting bolt | 68 ± 9 (50 ± 7 ft-lb) |
| Cover mounting bolt | 12 ± 2 (106 ± 18 in-lb) |
FASTENER TIGHTENING SPECIFICATION
SEALANT(S) AND ADHESIVE(S)
Transaxle
| Item | Specified sealant and adhesive |
|---|---|
| Converter housing | Loctite 509 |
SEALANT AND ADHESIVE SPECIFICATION
Transfer
| Item | Specified sealant and adhesive |
|---|---|
| Cover | 3M™ATD Part No. 8660 or equivalent |
SEALANT AND ADHESIVE SPECIFICATION
FORM-IN-PLACE GASKET (FIPG)
This transaxle has several areas where the form-in-place gasket (FIPG) is used for sealing. To ensure that the FIPG fully serves its purpose, it is necessary to observe some precautions when applying it. Bead size, continuity and location are of paramount importance.
Too thin a bead could cause leaks. Too thick a bead, on the other hand, could be squeezed out of location, causing blocking or narrowing of fluid passages. To prevent leaks or blocking of passages, therefore, it is absolutely necessary to apply the FIPG evenly without a break, while observing the correct bead size.
FIPG hardens as it reacts with the moisture in the atmospheric air, and it is usually used for sealing metallic flange areas.
| CAUTION | When re-applying liquid gasket (FIPG), be sure that: Residues of FIPG are cleared from all the ins and outs of parts; Use Mitsubishi genuine parts cleaner (MZ100387) or equivalent to well degrease the FIPG-applied surface. FIPG is correctly applied in accordance with FIPG Application. |
Surface Preparation
Thoroughly remove all substances deposited on the FIPG application surface, using a gasket scraper.
Make sure that the FIPG application surfaces is flat and smooth. Also make sure that the surface is free from oils, greases and foreign substances. Do not fail to remove old FIPG that may remain in the fastener fitting holes.
LUBRICANT(S)
Transaxle
| Item | Specified lubricant |
|---|---|
| CVT fluid application parts | DiaQueen CVTF-J1 |
| Vaseline application parts | White Vaseline (main ingredient: isoparaffinic hydrocarbon) |
LUBRICANT SPECIFICATIONS - TRANSAXLE
Transfer
| Item | Specified lubricant |
|---|---|
| Grease application parts | Retinax A |
| Hypoid gear oil application parts | Hypoid gear oil API classification GL-5 SAE 80 |
LUBRICANT SPECIFICATION - TRANSFER
INPUT SHAFT AND INTERNAL GEAR
Check if there is a damage or deformation, and replace if any defect is found.
Scheme 270
Required special tools
- MB990810: Side bearing puller
- MB990947: Lower arm push arbor
- MD999566: Crow
- MB990984: Mount bushing lower roll insulator arbor
- MD998917: Bearing remover
- MD998812: Installer Cap
- MD998813: Installer-100
- MD998819: Installer adapter (40)
