HEADLIGHT ADJUSTMENT (LOW-BEAM)
| CAUTION | Do not cover a headlight for more than three minutes to prevent the plastic headlight lens deformation. Be sure to adjust the aiming adjustment screw in the tightening direction. |
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
- The low-beam headlight will project on the screen upper edge of the beam (cut-off).
- Turn the adjusting screw to achieve the specified low-beam cut-off location on the aiming screen. Standard value < Vehicles without discharge headlight >: (Vertical direction) Horizontal line (H) ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle) (Horizontal direction): ± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle) from the axis, which is 266.1 mm (10.5 inches) (2 degrees angle) rightward from the vertical line (V) Standard value < Vehicles with discharge headlight >: (Vertical direction) 53.2 mm (2.1 inches) (0.4 degrees) below horizontal line (H). ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle) (Horizontal direction): Elbow point intersects the vertical line (V). ± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle) NOTE: High-beam pattern should be correct when the low-beams are adjusted properly.
