SPECIAL TOOLS
Transaxle
SPECIAL TOOLS REFERENCE CHART Tool Tool number and name Supersession Application MB990590 Real axle shaft oil seal remover MB990211-01 Removal of outer race of reduction gear bearing and differential side bearing MB992039 Slide hammer puller MB992039-01 Removal of outer race of reduction gear bearing and differential side bearing MB992139 Spring compressor - Removal and installation of reverse brake MB990779 Bar - Installation of differential side bearing outer race (converter housing side) < F1CJA > MB990780 Real axle shaft bushing installer - Installation of differential side bearing outer race (converter housing side and transaxle case side) < F1CJA > MB991168 Differential oil seal installer MB991168-01 Installation of differential side bearing outer race (converter housing side and transaxle case side) < W1CJA > MB991702 Adapter - Installation of differential side bearing outer race (converter housing side) < W1CJA > MB990932 Installer adapter - Reduction gear bearing outer race MB990938 Installer bar - Reduction gear bearing outer race MB992075 Handle - Installation of oil seal MB992141 Oil seal installer - Installation of converter housing oil seal MB992206 Oil seal installer - Installation of converter housing side oil seal < F1CJA > MB992140 Oil seal installer - Installation of side oil seal MB990810 Side bearing puller - Removal of reduction gear bearing inner race (converter housing side), removal of differential side bearing inner race (converter housing side), removal of differential side bearing inner race (transaxle case side) MB990947 Lower arm push arbor MB990947-01 Removal of reduction gear bearing inner race (converter housing side) MD999566 Crow - Removal of reduction gear bearing inner race (converter housing side) MB990984 Mount bushing lower roll insulator arbor - Removal of reduction gear bearing inner race (transaxle case side) MD998917 Bearing remover - Removal of reduction gear bearing inner race (transaxle case side) MD998812 Installer cap MIT304180-A or General service tool Installation of reduction gear bearing inner race (converter housing side and transaxle case side), installation of differential side bearing outer race (converter housing side), installation of differential side bearing inner race (converter housing side), installation of reduction pinion gear MD998813 Installer-100 MIT304180-A or General service tool Installation of reduction gear bearing inner race (converter housing side and Transaxle case side), installation of differential side bearing outer race (converter housing side), installation of differential side bearing inner race (converter housing side), installation of reduction pinion gear MD998819 Installer adapter (40) - Installation of reduction gear bearing inner race (converter housing side and Transaxle case side), installation of reduction pinion gear MB991452 Oil seal installer - Removal of differential side bearing inner race (converter housing side) < W1CJA > MD998823 Installer adapter (48) - Installation of differential side bearing inner race (transaxle case side) MB992138 Bearing Installer - Installation of differential side bearing inner race (converter housing side) < W1CJA >
Scheme 356
Scheme 357
Scheme 358
Scheme 359
Scheme 360
Scheme 361
Scheme 362
Scheme 363
Scheme 364
Scheme 365
Scheme 366
Scheme 367
Scheme 368
Transfer
TRANSFER TOOLS REFERENCE CHART Tool Tool number and name Supersession Application MD998812 Installer cap MIT304180-A or General service tool Installation of reduction gear bearing inner race (converter housing side and transaxle case side), installation of differential side bearing outer race (converter housing side), installation of differential side bearing inner race (converter housing side), installation of reduction pinion gear installation of transfer oil seal MB992154 Oil seal installer - Installation of transfer oil seal MB992075 Handle - Installation of oil seal MB992142 Oil seal installer - Installation of transfer oil seal MB990936 Oil seal installer - Installation of transfer oil seal
