Basic Brake System: Maintenance Mitsubishi Outlander II

BRAKE FLUID LEVEL SWITCH CHECK

The brake fluid level switch is normal when the following conditions are met: When the brake fluid level is above "MIN," continuity is detected; and when the level is below "MIN," no continuity is detected.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Visually check the thickness of brake pad from the inspection hole of the caliper body. Standard value: 10.0 mm (0.39 inch) Minimum limit: 2.0 mm (0.08 inch)
2. When the thickness is lower than the limit value, replace both brake pads (right and left) as a set.
3. Remove the parts indicated in the figure, swivel the caliper assembly upward and retain it with a wire or similar tool.
4. Remove the following parts from the caliper assembly. Shim Pad assembly front Pad & clip assembly rear Pad assembly RH, pad & wear indicator assembly LH Clip
5. In order to measure the brake drag force after pad installation, measure the hub sliding torque with no pad attached. (Refer to «FRONT DISC BRAKE ASSEMBLY»(ref-269527-S20178259182007103100000) .)
6. Install the pad and caliper assembly, and check the brake drag force. (Refer to «FRONT DISC BRAKE ASSEMBLY»(ref-269527-S20178259182007103100000) .)

Scheme 37

1. Remove any dirt and rust on the brake disc surface.
2. Measure thickness of the brake disc at the sliding area with the brake pad at four or more points. Standard value: Front 26.0 mm (1.02 inch) Rear 10.0 mm (0.39 inch) Minimum limit: Front 24.4 mm (0.96 inch) Rear 8.4 mm (0.33 inch)
3. When any one of the thicknesses is lower than the limit value, replace both brake discs and pads (right and left) as a set.
