>> B << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE SENSOR

Apply 3M™ AAD Part number 8731 or equivalent to the engine coolant temperature sensor.

Scheme 297

Scheme 297: >> B << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE SENSOR

>> C << SEALANT APPLICATION TO OIL PRESSURE SWITCH

Apply 3M™ AAD Part number 8672 or equivalent to the threads of the oil pressure switch.

CAUTIONDo not block the oil passage with sealant.

Scheme 298

Scheme 298

Scheme 299

Scheme 299: >> D << SEALANT APPLICATION TO OIL PRESSURE SWITCH

Scheme 300

Scheme 300
  1. Apply 3M™ AAD Part number 8672 or equivalent to the threads of the oil pressure switch. CAUTION: Do not block the oil passage with sealant.
  2. Using special tool MD998012, tighten the oil pressure switch to the specified torque. Tightening torque: 19 +/- 3 N.m (14 +/- 2 ft-lb)

Scheme 301

Scheme 301: >> E << THERMOSTAT HOUSING INSTALLATION

Scheme 302

Scheme 302
  1. Apply a 3 mm (0.12 inch) diameter bead of sealant MITSUBISHI Genuine Part number MD970389 or equivalent to the groove as shown in the illustration.
  2. Coat the threads of the seal bolt in the illustration with 3M™ AAD Part number 8672 or equivalent before tightening.
  3. Install the housing quickly (within 15 minutes) while the sealant is wet and tighten the bolts to the specified torque. Tightening torque: 24 +/- 4 N.m (18 +/- 2 ft-lb) NOTE: After installation, keep the sealed area away from the coolant for approximately one hour.

>> G << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE GAUGE UNIT

Apply 3M™ AAD Part number 8672 or equivalent to the engine coolant temperature gauge unit.

Scheme 303

Scheme 303: >> G << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE GAUGE UNIT

Scheme 304

Scheme 304: >> H << INTAKE MANIFOLD STAY INSTALLATION
  1. Install the intake manifold stay and tighten the bolts just finger tight.
  2. Check to ensure that the stay is in close contact with the bosses of the intake manifold and cylinder block.
  3. First tighten the intake manifold side bolts to the specified torque, then the cylinder block side bolts to the specified torque. Tightening torque: 31 +/- 3 N.m (23 +/- 2 ft-lb)
