>> B << BLEEDING OF MASTER CYLINDER ASSEMBLY

When removed the master cylinder assembly, bleed the master cylinder in the following procedure to make bleeding of the brake pipeline easier (When no brake fluid is in the master cylinder).

Scheme 43

Scheme 43: >> B << BLEEDING OF MASTER CYLINDER ASSEMBLY
  1. Fill the brake fluid reservoir with the brake fluid.
  2. Depress and hold the brake pedal.
  3. Another operator closes the master cylinder outlets with his fingers.
  4. In this condition, release the brake pedal.
  5. Repeat Steps 2 to 4 for 3 or 4 times to fill the master cylinder with the brake fluid.

Scheme 44

Scheme 44: MASTER CYLINDER AND BRAKE BOOSTER

Scheme 45

Scheme 45: VACUUM HOSE AND VACUUM PIPE

When removed the master cylinder assembly, bleed the master cylinder in the following procedure to make bleeding of the brake pipeline easier (When no brake fluid is in the master cylinder).

Scheme 46

Scheme 46: >> B << BLEEDING OF MASTER CYLINDER ASSEMBLY
  1. Fill the brake fluid reservoir with the brake fluid.
  2. Depress and hold the brake pedal.
  3. Another operator closes the master cylinder outlets with his fingers.
  4. In this condition, release the brake pedal.
  5. Repeat Steps 2 to 4 for 3 or 4 times to fill the master cylinder with the brake fluid.

Scheme 47

Scheme 47: REMOVAL AND INSTALLATION

Scheme 48

Scheme 48: >> A << BRAKE HOSE INSTALLATION
  1. Pass the brake hose through the hole in the body-side bracket.
  2. Install the brake hose to the brake caliper.
  3. Install the brake hose at the two fixing points.
  4. Twist the brake hose toward the lesser torsion between the brake hose and body-side bracket as shown in the illustration, and fix it to the body-side bracket with a clip.

Scheme 49

Scheme 49: DISASSEMBLY AND ASSEMBLY - 15-INCH FRONT DISC BRAKE

Note. Install the brake pad assembly (with wear indicator) to the inner side of the brake disc, making sure that the wear indicator is located on the top.

Scheme 50

Scheme 50: LUBRICATION POINTS
