CHECK OF IGNITION KEY REMINDER WARNING FUNCTION (STEERING LOCK REMINDER TONE ALARM BY KOS)
- Close the driver's door, unlock the steering lock, and turn the key (for the vehicle with KOS, the emergency key is inversely inserted into the keyless operation key) to the LOCK (OFF) position (the key is being inserted). < Vehicles with WCM and vehicles with KOS (When using the emergency key) >
- Release the steering wheel lock with the driver's door closed, and turn the IG knob to the position other than the LOCK (OFF) position. < Vehicles with KOS (When not using the emergency key) >
- Change the driver's door state from closed to open.
- Check that the tone alarm sounds normally.
- If a malfunction is found, carry out the troubleshooting (Refer to «TROUBLE SYMPTOM CHART»(ref-592561-S38314954302014011000000) ).
IGNITION SWITCH CONTINUITY CHECK
With the ignition switch mounted to the vehicle, disconnect and check the ignition switch connection connector.
| Ignition key position | Terminal number | Normal condition |
|---|---|---|
| LOCK | 1 - 2, 1 - 4, 1 - 5, 1 - 6 | No continuity |
| ACC | 1 - 6 | Continuity exists (2 ohms or less) |
| ON | 1 - 2 - 4 - 6 | Continuity exists (2 ohms or less) |
| START | 1 - 2 - 5 | Continuity exists (2 ohms or less) |
IGNITION SWITCH CONTINUITY TABLE
