CHECK OF FREEZE FRAME DATA

The freeze frame data can be checked by using the scan tool ( HOW TO COPE WITH INTERMITTENT MALFUNCTION ).

When detecting fault and storing the DTC, the ECU connected to CAN bus line obtains the data before the determination of the DTC and the data when the DTC is determined, and then stores the ECU status of that time. By analyzing each data from scan tool, the troubleshooting can be performed more efficiently. The displayed items are as the table below.

DISPLAY ITEM LIST

DISPLAY ITEM LIST

JUDGEMENT CRITERIA

With the ignition switch at the ON position and the system voltage at 10 - 16 volts (data from ETACS-ECU), if the combination meter becomes unable to transmit data normally due to the CAN-B bus circuit malfunction, the combination meter determines that a problem has occurred.

JUDGMENT CRITERIA

With the ignition switch in the ON position, system voltage between 10-16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communication with engine control module cannot be established for 600 ms or more, the combination meter determines that a problem has occurred.

PROBABLE CAUSES

1. The CAN bus line may be defective.
2. The combination meter may be defective.
3. The engine control module may be defective.

With the ignition switch in the ON position, system voltage between 10 - 16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communication with ETACS-ECU cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10-16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communication with SRS-ECU cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10 - 16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communications with occupant classification-ECU cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10-16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communication with A/C-ECU or heater control unit cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10 - 16 V (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communication with KOS-ECU or WCM cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10 - 16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communications with radio and CD player or CD changer cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10 - 16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communications with hands free module cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the ignition switch in the ON position, system voltage between 10 - 16 volts (data from ETACS-ECU), power supply fuse (IOD fuse) is OK, or odometer value is 80.5 km (50 miles) or more, and the communications with audio visual navigation unit cannot be established for 2, 500 ms or more, the combination meter determines that a problem has occurred.

With the global coding counter value "0," if all the global coding data (vehicle information) are not stored, the combination meter determines that a problem has occurred.

SERVICE DATA

Note. For some information result read out by the ECU, the specific items may not be displayed.

SERVICE DATA CHART

CHECK PROCEDURE FOR EACH MULTI INFORMATION DISPLAY SCREEN

WARNING SCREEN

When malfunctions occur to the vehicle, the following warning screens are displayed. If these screens are not displayed normally or if they continue to be displayed even after the factor is eliminated, take measures according to the action procedure.

MULTI WARNING INFORMATION CHART Display content Message Factor Action procedure REMOVE KEY Displayed with the sounding of tone alarm when the driver's door is opened with the key inserted in the ignition switch key cylinder. If the ignition key reminder warning tone alarm is not being sounded, perform the troubleshooting for the ignition key reminder warning tone alarm (Refer to INSPECTION PROCEDURE 4: TONE ALARM DOES NOT SOUND NORMALLY. ). TURN OFF LIGHTS Displayed with the sounding of tone alarm when the driver's door is opened with the ignition switch at the LOCK (OFF) or ACC position and the lighting switch at the tail or head position. If the lighting monitor warning tone alarm is not being sounded, perform the troubleshooting for the lighting monitor warning tone alarm (Refer to INSPECTION PROCEDURE 4: TONE ALARM DOES NOT SOUND NORMALLY. ). ALARM ACTIVATING Displayed while the theft alarm is in operation. If the warning screen is not displayed normally or if the screen continues to be displayed, carry out the troubleshooting for the theft alarm (Refer to HOW TO DIAGNOSE THE CAN BUS LINES ). - Displayed when the following operations are carried out with the ignition switch at positions other than the LOCK (PUSH OFF) position after the engine is stopped. When the driver's door is opened When the doors are closed and locked If the warning screen is not displayed If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the KOS (Refer to DIAGNOSTIC TROUBLE CODE CHART ). KEY BATTERY LOW Displayed when the KOS key battery is running low. KEY NOT DETECTED Displayed if carrying a KOS key with different ID code or the KOS key is outside the operative range. Displayed when the keyless operation key is taken out of the car when the IG knob is in other than the LOCK position, and all the doors are closed. KEY STILL IN VEHICLE Displayed when the front door outside handle lock switch is turned to ON position while the keyless operation key is left in the vehicles. CHECK DOORS Displayed when the door ajar prevention function is in operation. KEYLESS OPERATION SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to KOS. LOW TIRE PRESSURE Displayed when the tire air pressure is an abnormality. (except spare tire) If the warning screen is not displayed normally or erased, carry out the troubleshooting for the TPMS (Refer to DIAGNOSIS ). TPMS SERVICE REQUIRED Displayed when the TPMS is an abnormality. BRAKE SYSTEM SERVICE REQUIRED Displayed when the brake fluid amount is insufficient or a malfunction occurs to the brake device. If the warning screen is not displayed normally or if the screen continues to be displayed, check the brake fluid or brake device. Refer to ON-VEHICLE SERVICE . RELEASE PARKING BRAKE Displayed if vehicle is driven with the parking brake engaged. If the warning screen is not displayed normally or if the screen continues to be displayed, check the parking brake. Refer to ON-VEHICLE SERVICE . ABS SERVICE REQUIRED Displayed when a malfunction occurs to the anti-lock braking system (ABS). If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the ABS (Refer to TROUBLE SYMPTOM CHART ). - If any of the doors or liftgate is not closed completely, the location of the ajar door is displayed with the sounding of tone alarm. If the door ajar warning tone alarm does not sound, perform the troubleshooting for the door ajar warning tone alarm. Refer to INSPECTION PROCEDURE 4: TONE ALARM DOES NOT SOUND NORMALLY. . CLOSE HOOD Displayed when the hood is open. If the warning screen is not displayed normally, or if the screen continues to be displayed, check the hood latch switch input signal. Refer to INSPECTION PROCEDURE 12: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE HOOD SWITCH . ENGINE OVERHEATING STOP SAFELY Displayed when overheated. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the engine (Refer to TROUBLE SYMPTOM CHART ). TRANSMISSION OVERHEATING SLOW DOWN Displayed when the transmission oil temperature becomes high. If the warning screen is not displayed normally or if the screen continues to be displayed, check the TC-SST diagnostic trouble code. Refer to DIAGNOSTIC TROUBLE CODE CHART . TRANSMISSION SERVICE REQUIRED Displayed when there is a malfunction to the TC-SST. FASTEN SEAT BELT Displayed when the ignition switch is turned ON without the driver's seat belt fastened. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the seat belt reminder warning light. Refer to INSPECTION PROCEDURE 5: THE COMBINATION METER LIGHT DOES NOT ILLUMINATE NORMALLY OR THE MULTI INFORMATION DISPLAY IS NOT DISPLAYED NORMALLY. . FUEL SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to the fuel system. If the warning screen is not displayed normally or if the screen continues to be displayed, check the combination meter diagnostic trouble code. Refer to INSPECTION PROCEDURE 5: THE COMBINATION METER LIGHT DOES NOT ILLUMINATE NORMALLY OR THE MULTI INFORMATION DISPLAY IS NOT DISPLAYED NORMALLY. . REFUEL Displayed when the remaining fuel amount is small. If the warning screen is not displayed normally or if the screen continues to be displayed, refuel immediately. LOW OIL PRESSURE Displayed when there is a malfunction to the engine oil circulation system. If the warning screen is not displayed normally or if the screen continues to be displayed, check the engine oil amount. Refer to TROUBLE SYMPTOM CHART . CHARGING SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to the charging system. If the warning screen is not displayed normally or if the screen continues to be displayed, check the charging system. Refer to OUTPUT CURRENT TEST and REGULATED VOLTAGE TEST . AIRBAG SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to the SRS air bag or to the pre-tensioner mechanism. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the SRS air bag/pre-tensioner mechanism warning light. Refer to SRS AIR BAG DIAGNOSIS . ASC SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to the ASC. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the ASC. Refer to TROUBLE SYMPTOM CHART . 4WD SYSTEM SERVICE REQUIRED Displayed when there is a malfunction to the S-AWC or ACD. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the S-AWC or ACD. Refer to TROUBLE SYMPTOM CHART . POSSIBLE ICY ROADS Displayed with the sounding of tone alarm when the ambient temperature is 37°F (3°C) or less. If the freeze warning tone alarm does not sound with the ambient temperature of 37°F (3°C) or less, perform the troubleshooting for the freeze warning tone alarm. Refer to INSPECTION PROCEDURE 4: TONE ALARM DOES NOT SOUND NORMALLY. . ENGINE SYSTEM SERVICE REQUIRED Displayed when the timing chain becomes worn. If the warning screen is not displayed normally or if the screen continues to be displayed, visually check the elongation of the timing chain. Refer to TIMING CHAIN ELONGATION VISUAL CHECK

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

OTHER SCREENS

The screen displays the operation state of each system, periodic checkup timing, or timing for taking a rest during driving. If the screen display differs from the actual system operation state or if the screen is not displayed at the set timing, take measures according to the action procedure.

MULTI WARNING INFORMATION CHART Display content Message System operation state Action procedure - Displayed when the ASC is in operation. If the warning screen is not displayed normally or if the screen continues to be displayed, perform the troubleshooting for the ASC. Refer to SYMPTOM CHART . ROUTINE MAINTENANCE REQUIRED Displayed when the set period elapses. - REST REMINDER Displayed when the set time elapses

Scheme 195

Scheme 196

TERMINALS REFERENCE CHART

SPEEDOMETER CHECK

Scheme 197

Scheme 198

1. Adjust the pressure of tires to the specified level (Refer to «ON-VEHICLE SERVICE»(ref-592592-S20675601162014011000000) ).
2. Where applicable, ensure that the TPMS warning light is not illuminating or flashing.
3. Press the ASC OFF switch for 3 seconds or more to stop the ASC operation.
4. Set the vehicle onto a speedometer tester and place the rear wheels on a free roller.
5. To prevent the wheel from moving from side to side, attach tension bars to the tie-down hook, and secure both ends to anchor plates.
6. To prevent the vehicle from moving, attach a chain or wire to the rear retraction hook, and make sure the end of the chain or wire is secured.
7. Check if the speedometer indicator range is within the standard values. Standard value : SPEEDOMETER INDICATION CHART Standard indication {mph (km/h)} Indication tolerance {mph (km/h)} 10 (16) 8.5 - 11.5 (13.6 - 18.4) 25 (40) 23.5 - 26.5 (37.6 - 42.4) 50 (80) 48.5 - 51.5 (77.6 - 82.4) 75 (120) 73.5 - 76.5 (117.6 - 122.4) 100 (161) 98.5 - 102.5 (158.6 - 165.0) 125 (201) 123.5 - 127.5 (198.6 - 205.0) 150 (241) 148.5 - 153.5 (239.0 - 247.0) 175 (282) 173.5 - 179.0 (279.2 - 288.0) Standard value : SPEEDOMETER INDICATION CHART standard indication {km/h (mph)} Indication tolerance {km/h (mph)} 20 (12.4) 19 - 24 (11.8 - 14.9) 40 (24.8) 40 - 44 (24.8 - 27.3) 80 (49.7) 80 - 85 (49.7 - 52.8) 120 (74.6) 120.5 - 125.5 (74.9 - 78.0) 160 (99.4) 160.5 - 165.5 (99.7 - 102.8) 200 (124.3) 200.5 - 207.0 (124.6 - 128.6) 240 (149.1) 240.5 - 247.0 (149.4 - 153.5) 280 (174.0) 280.5 - 289.0 (174.3 - 179.6)
8. If not within the standard value, check the tire size. If an incorrect size of tire is used, replace it and check again. If the tire size is correct, a defect may be present in components and circuit between the ASC and the combination meter. Check the following items. ASC (refer to «DIAGNOSIS»(ref-592593-S16656763792014011000000) ). Combination meter (refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ).

TACHOMETER CHECK

When the actuator tests (item No. 2) are performed using scan tool MB991958, check that the tachometer indication tolerance is within the standard value.

Note. Values in () indicates the reference value.

Standard value

ENGINE SPEED CHART

Scheme 199

1. Remove the fuel pump module (Refer to «FUEL TANK»(ref-592649-S18614075632014011000000) ).
2. When float of the fuel level sensor is in stopper positions F and E, ensure that resistance between the fuel level sensor terminal and ground terminal is within the standard value. Standard value: FLOAT POSITION CHART Float position Gauge resistance value (ohms) Main Sub Stopper position "F" 6.5 ± 1.0 6.5 ± 1.0 Stopper position "E" 41.9 ± 1.0 78.1 ± 1.0
3. When the float is moved slowly between stopper positions "F" and "E", ensure that the resistance is smoothly changing.

Scheme 200

1. Remove the fuel pump module (Refer to «FUEL TANK»(ref-592649-S18614075632014011000000) ).
2. When float is moved to contact the float arm on the stopper, ensure that stopper positions "F" (height A) and "E" (height B) are within the standard value. Standard value: FLOAT POSITION CHART Float position Float height [mm (in)] Main Sub Stopper position "F" (height A) 140.9 (5.5) 14.2 ± 3.0 (0.5 ± 0.1) Stopper position "E" (height B) 39.1 (1.5) 179.3 ± 3.0 (7.0 ± 0.1)

METER INFORMATION SWITCH CHECK

TESTER CONNECTION AND SPECIFIED CONDITION

Scheme 201

2. NEXT SCHEDULE REMINDER CANCEL

The next warning period is cancelled, and its following warning period can be set.

Scheme 202

Scheme 203

1. On the "Service Reminder" screen, select "2 Next schedule reminder cancel." NOTE: The screen indicates that the warning period (Nos. 1 and 2 in the data list) is "1, 000 mile" and "1 month."
2. Press the "OK" button.
3. The next warning period is cancelled, and its following warning period is set. NOTE: The screen indicates that the warning period (Nos. 1 and 2 in the data list) is changed to "8, 500 mile" and "7 month."

3. EXTRA REMINDER SETTING

In addition to the current warning period, the temporary service reminder warning period can be set.

Scheme 204

Scheme 205

Scheme 206

1. On the "Service Reminder" screen, select "3 Extra reminder setting." NOTE: The screen indicates that the temporary warning period (Nos. 4 and 5 in the data list) has not been set.
2. Set the temporary warning period (distance or month) of the "Set value." NOTE: Either input of distance or month can execute the setting.
3. Press the "OK" button.
4. The temporary warning period is set. NOTE: The screen indicates that "2 month" has been added to the temporary warning period (No. 5 in the data list). (The distance of No. 4 in the data list has not been set).

4. EXTRA REMINDER CANCEL

The temporary service reminder warning period which has been set can be cancelled.

Scheme 207

Scheme 208

1. On the "Service Reminder" screen, select "4 Extra reminder cancel." NOTE: The screen indicates that "3000 mile" and "2 month" have been set to the temporary warning period (Nos. 4 and 5 in the data list).
2. Press the "OK" button.
3. The temporary warning period is cancelled. NOTE: The screen indicates that the temporary warning period (Nos. 4 and 5 in the data list) has been cancelled.

5. PERIODIC REMINDER SCHEDULE SET

The service reminder schedule can be changed.

Note. In addition to the operation of the scan tool MB991958, the schedule can be changed by operating the meter information switch on the combination meter. Refer to HOW TO OPERATE THE SCAN TOOL MB991958 .

Scheme 209

Scheme 210

Scheme 211

1. On the "Service Reminder" screen, select "5 Periodic reminder schedule set." NOTE: The screen indicates that the current schedule (No. 7 in the data list) has been set to "NAS 10."
2. Set the schedule to be changed from "Set value."
3. Press the "OK" button.
4. The schedule is changed. NOTE: The screen indicates that the current schedule (No. 7 in the data list) has been changed to "NAS 11."

7. OPTIONAL INT SCHEDULE SETTING

In addition to the existing schedule, the optional service reminder schedule can be set.

Scheme 212

Scheme 213

Scheme 214

1. On the "Service Reminder" screen, select "7 Optional INT schedule setting." NOTE: The screen indicates that the optional schedule (Nos. 12 and 13 in the data list) has not been set.
2. Set the optional schedule (distance or month) of the "Set value." NOTE: Either input of distance or month can execute the setting.
3. Press the "OK" button.
4. The optional schedule is set. The set schedule becomes effective by executing "5 Periodic reminder schedule set" and setting the schedule to "Optional INT." NOTE: The screen indicates that "2 month" has been added to the optional schedule (No. 13 in the data list). (The distance of No. 12 in the data list has not been set). Relationship between the elapsed months and the elapsed days which are used by the service reminder function SERVICE REMINDER FUNCTION CHART Number of months Number of days 1 30 - 60 2 61 - 90 3 91 - 121 4 122 - 151 5 152 - 182 6 183 - 212 7 213 - 243 8 244 - 273 9 274 - 303 10 304 - 334 11 335 - 364 12 365 - 395 13 396 - 425 14 426 - 456 15 457 - 486 16 487 - 516 17 517 - 547 18 548 - 577 19 578 - 608 20 609 - 638 21 639 - 669 22 670 - 699 23 700 - 730 24 731 - 760 25 761 - 790 26 791 - 821 27 822 - 851 28 852 - 882 29 883 - 912 30 913 - 943 31 944 - 973 32 974 - 1, 003 33 1, 004 - 1, 034 34 1, 035 - 1, 064 35 1, 065 - 1, 095 36 1, 096 - 1, 125 37 1, 126 - 1, 156 38 1, 157 - 1, 186 39 1, 187 - 1, 217 40 1, 218 - 1, 247 41 1, 248 - 1, 277 42 1, 278 - 1, 308 43 1, 309 - 1, 338 44 1, 339 - 1, 369 45 1, 370 - 1, 399 46 1, 400 - 1, 430 47 1, 431 - 1, 460 48 1, 461 - 1, 491 NOTE: When the number of elapsed days is 0 to 29, the number of elapsed months is 0. The combination meter performs calculation using 365.25 days for one year and 30.4375 days for one month.

HOW TO CANCEL THE SERVICE REMINDER WARNING

1. Turn the ignition switch to the "OFF" position.
2. By operating the meter information switch, the warning period is displayed on the multi information display.
3. Press the meter information switch once for 1.2 seconds or longer.
4. The service reminder indicator flashes.
5. While the service reminder indicator flashes, press the meter information switch once for less than 1.2 seconds.
6. The service reminder indicator is turned ON, and "CLEAR" is displayed on the multi information display for 3 seconds.
7. After "CLEAR" is displayed for 3 seconds, the warning period to the next time is displayed.

HOW TO SET THE SCHEDULE

1. Turn the ignition switch to the "OFF" position.
2. By operating the meter information switch, the warning period is displayed on the multi information display.
3. Press the meter information switch once for 1.2 seconds or longer.
4. The service reminder indicator flashes.
5. While the service reminder indicator flashes, press the meter information switch for 1.2 seconds or longer and 3 times consecutively.
6. The service reminder indicator is turned ON, and the current schedule is displayed on the multi information display.
7. While the current schedule is displayed, press the meter information switch for less than 1.2 seconds and 3 times consecutively.
8. The multi information display is shifted to the schedule selection mode.
9. When the meter information switch is pressed for less than 1.2 seconds, the schedule is shifted, and when the meter information switch is pressed for 1.2 seconds or longer, the displayed schedule is set. NOTE: For schedule, "JPN", "GCC", "EU" and "AUS" can also be selected. However, the setting shall be for "NAS" only.
10. The schedule set in Step 9 is displayed for 3 seconds, and the warning period to the next time is displayed. SCHEDULE CHART Schedule Contents of schedule NAS 10 Elapsed time (month) Every 6 elapsed months Driving distance (miles) Every 7, 500 miles of driving distance Driving distance (km) Every 12, 000 km of driving distance NAS 11 Elapsed time (month) Every 3 elapsed months Driving distance (miles) Every 3, 750 miles of driving distance Driving distance (km) Every 6, 000 km of driving distance NAS 20 (initial setting) Elapsed time (month) Every 5 elapsed months Driving distance (miles) Every 5, 000 miles of driving distance Driving distance (km) Every 8, 000 km of driving distance NAS 21 Elapsed time (month) Every 4 elapsed months Driving distance (miles) Every 3, 750 miles of driving distance Driving distance (km) Every 6, 000 km of driving distance Optional INT The optional schedule can be set. (Only scan tool MB991958 can be set.) OFF Display Without function. "OFF" is displayed on the multi information display. Function OFF Without function (Only scan tool MB991958 can be set.) NOTE: For schedule, "JPN", "GCC/EXP", "EU" and "AUS" can also be selected. However, the setting shall be for "NAS" only.

HOW TO INACTIVATE THE SERVICE REMINDER FUNCTION

By setting to "OFF Display" or "Function OFF" when the schedule is set, the service reminder function can be inactivated.

When "OFF Display" is selected

1. Even if the service reminder screen is displayed by operating the meter information switch, "OFF" is displayed.

When "Function OFF" is selected

1. Even when the check warning period is reached, the service reminder display is not displayed.
2. Even with the meter information switch operation, the service reminder screen is not displayed.
