Combination Meter - Lancer Evolution: Diagnosis Mitsubishi Lancer X рестайлинг

Gauges & Instrument Panels 10 illustrations ~10582 words

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

Refer to CONTENTS OF TROUBLESHOOTING .

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 160

Scheme 160
Scheme 160
  1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
  2. Start up the personal computer.
  3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
  4. Connect special tool MB991910 to special tool MB991824.
  5. Connect special tool MB991910 to the data link connector.
  6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
  7. Start the scan tool system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "System select" from the start-up screen.
  4. Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
  5. Select "Meter" from "System List," and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
  6. Select "Diagnostic Trouble Code" to read the DTC.
  7. If a DTC is set, it is shown.
  8. Choose "Erase DTCs" to erase the DTC.

HOW TO DIAGNOSE THE CAN BUS LINES

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "CAN bus diagnosis" from the start-up screen.
  4. When the vehicle information is displayed, confirm that it matches the vehicle being diagnosed. If they match, go to Step 8 . If not, go to Step 5.
  5. Select the "view vehicle information" button.
  6. Enter the vehicle information and select the "OK" button.
  7. When the vehicle information is displayed, confirm again that it matches the vehicle being diagnosed. If they match, go to Step 8. If not, go to Step 5 .
  8. Select the "OK" button.
  9. When the optional equipment screen is displayed, choose the one which the vehicle is fitted with, and then select the "OK" button.

DIAGNOSTIC TROUBLE CODE CHART

CAUTIONDuring troubleshooting, a DTC code associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, check all systems for DTC code(s). If DTC code(s) are set, erase them all. When the combination meter is required to be replaced as a result of the troubleshooting, the current driving distance and number of elapsed days to be used for service reminder function must be entered into the meter after the replacement. Therefore, read "Integrated mileage for reminder," "Integrated days for reminder," "Mileage until Extra reminder," "Months until Extra reminder," and "Current Schedule" from the meter before the replacement using the special function of scan tool MB991958, and note them. For the operation method of scan tool MB991958, refer to HOW TO SET BY OPERATING THE SCAN TOOL MB991958 . If "Integrated mileage for reminder" or "Integrated days for reminder" cannot be read by the scan tool MB991958, follow the method described below. For the driving distance for check warning, use the driving distance displayed on the multi information display. For the elapsed days for check warning, calculate the number of elapsed days from the delivery date to the customer (service remainder function start date) and current date.
DTC No.Diagnostic item
B1200Malfunction of odometer
B1201Abnormal fuel information
B1208Malfunction of LCD heater
B1209Test mode
B2203VIN not programmed
B2463The sticking of rheostat switch
B2464The sticking of meter information switch
B2465Ignition switch signal error
U0019Bus off (CAN-B)
U0100Engine control module CAN timeout
U0141ETACS CAN timeout
U0151SRS-ECU CAN timeout
U0154Occupant classification-ECU CAN timeout
U0164A/C-ECU or heater control unit CAN timeout
U0168KOS-ECU or WCM CAN timeout
U0184Audio CAN timeout
U0197Hands free module CAN timeout
U0245Audio visual navigation unit CAN timeout
U1415Coding not completed/Data fail

DIAGNOSTIC TROUBLE CODE CHART

TROUBLE JUDGMENT

If the odometer information, which is stored in the combination meter, is abnormal when the ignition switch at the ON position and the system voltage is 10-16 volts (data from ETACS-ECU), DTC B1200 is stored.

TROUBLESHOOTING HINTS

The combination meter may be defective.

DIAGNOSIS

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if diagnostic trouble code is set. Q: Is the DTC set? YES: Replace the combination meter, and then go to Step 2. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  2. STEP 2. Recheck for diagnostic trouble code. Check if DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if diagnostic trouble code is set. Q: Is the DTC set? YES: Go to Step 1 . NO: The procedure is complete.

With the ignition switch at the ON position and the system voltage at 10-16 volts (data from ETACS-ECU), if the combination meter detects the abnormal resistance of fuel level sensor circuit for 64 seconds continuously, DTC B1201 is stored.

  1. The fuel pump module [fuel level sensor (main)] may be defective.
  2. The fuel level sensor (sub) may be defective.
  3. The combination meter may be defective.
  4. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB991223: Harness Set
  2. MB992006: Extra Fine Probe
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 161

Scheme 161
Scheme 161
  1. STEP 1. Check fuel pump module connector D-22 and fuel level sensor (sub) connector D-13 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is fuel pump module connector D-22 and fuel level sensor (sub) connector D-13 in good condition? YES: Go to Step 2. NO: Repair the connector.
  2. STEP 2. Check the fuel level sensor. Check to see if the fuel level sensor is normal (Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) ). Q: Is the check result normal? YES: Go to Step 3. NO: Replace the fuel pump module or fuel level sensor (sub).
  3. STEP 3. Measure the resistance at fuel pump module connector D-22. Disconnect pump module connector D-22, and measure at the wiring harness side. Measure the resistance value between terminal 1 and ground. The measured value should be 2 ohm or less. Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Check the wiring harness between fuel pump module connector D-22 (terminal 1) and ground. Check the ground wire for open circuit. Q: Is the wiring harness between fuel pump module connector D-22 (terminal 1) and ground in good condition? YES: Go to Step 7 . NO: Repair the wiring harness.
  5. STEP 5. Check combination meter connector C-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is combination meter connector C-04 in good condition? YES: Go to Step 6. NO: Repair the connector.
  6. STEP 6. Check the wiring harness between fuel pump module connector D-22 (terminal 2) and combination meter connector C-04 (terminal 18). Check the communication lines for open circuit and short circuit. NOTE: Also check intermediate connector C-23. If intermediate connector C-23 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Are the wiring harness between fuel pump module connector D-22 (terminal 2) and combination meter connector C-04 (terminal 18) in good condition? YES: Go to Step 7. NO: Repair the wiring harness. The fuel gauge should work normally.
  7. STEP 7. Using scan tool MB991958, perform actuator test. Item 03: Fuel gauge (target value): 0-100% Fuel gauge shows 100 % Q: Is the check result normal? YES: Go to Step 8. NO: Replace the combination meter.
  8. STEP 8. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the combination meter. NO: The procedure is complete.

TROUBLE JUDGEMENT

With the ignition switch at the ON position and the system voltage at 10-16 volts (data from ETACS-ECU), if the combination meter detects the LCD heater malfunction, the DTC B1208 is stored.

The combination meter may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Recheck for diagnostic trouble code.

Check again if the DTC is set to the combination meter.

CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.
  1. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ."
  2. Turn the ignition switch from "LOCK" (OFF) position to "ON" position.
  3. Check if DTC is set.
  4. Turn the ignition switch to the "LOCK" (OFF) position.

Q: Is the DTC set?

  1. YES: Replace the combination meter.
  2. NO: The procedure is complete.

When the mode is changed to the meter test mode (supplier mode), the combination meter stores the DTC B1209.

The combination meter may be defective

Replace the combination meter.

With the ignition switch at the ON position, if the VIN code is not written to the combination meter, DTC B2203 is stored.

  1. The CAN bus line may be defective.
  2. The ETACS-ECU may be defective.
  3. The combination meter may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code Check again if the DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Troubleshoot the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). NO: Go to Step 3.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the combination meter detects the rheostat switch pressed state for 60 seconds or more continuously, DTC B2463 is stored.

  1. The combination meter may be defective.
  2. The combination meter bezel (rheostat switch knob) may be defective.

DIAGNOSTIC PROCEDURE

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Check the rheostat switch. Check whether an abnormality is present to the combination meter and the rheostat switch knob attached to the combination meter bezel. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the combination meter or combination meter bezel.
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if diagnostic trouble code is set. Q: Is the DTC set? YES: Replace the combination meter, and then go to Step 3. NO: The procedure is complete.
  3. STEP 3. Recheck for diagnostic trouble code. Check if DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if diagnostic trouble code is set. Q: Is the DTC set? YES: Go to Step 1 . NO: The procedure is complete.

If the combination meter detects the meter information switch pressed state for 60 seconds or more continuously, DTC B2464 is stored.

  1. The meter information switch may be defective
  2. The combination meter may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB991223: Harness Set
  2. MB992006: Extra Fine Probe
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 162

Scheme 162
Scheme 162
  1. STEP 1. Check meter information switch connector C-02 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is meter information switch connector C-02 in good condition? YES: Go to Step 2. NO: Repair the connector.
  2. STEP 2. Check the meter information switch. Check the meter information switch (Refer to «METER INFORMATION SWITCH CHECK»(ref-592598-S06314576182014011000000) ). Q: Is the check result normal? YES: Go to Step 3. NO: Replace the meter information switch.
  3. STEP 3. Measure at meter information switch connector C-02 in order to the ground circuit to the meter information switch. Disconnect meter information switch connector C-02, and measure at the wiring harness side. Measure the resistance value between terminal 4 and ground. The measured value should be 2 ohm or less. Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Check the wiring harness between meter information switch connector C-02 (terminal 4) and ground. Check the ground wire for open circuit. Q: Is the wiring harness between fuel meter information switch connector C-02 (terminal 4) and ground in good condition? YES: Go to Step 7 . NO: Repair the wiring harness.
  5. STEP 5. Check combination meter connector C-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is combination meter connector C-04 in good condition? YES: Go to Step 6. NO: Repair the connector.
  6. STEP 6. Check the wiring harness between meter information switch connector C-02 (terminal 1) and combination meter connector C-04 (terminal 3). Check the communication line for open circuit and short circuit. Q: Are the wiring harness between meter information switch connector C-02 (terminal 1) and combination meter connector C-04 (terminal 3) in good condition? YES: Go to Step 7. NO: Repair the wiring harness.
  7. STEP 7. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Go to Step 1 . NO: The procedure is complete.

If 5 seconds or more elapses with the ignition switch state and the data from the CAN communication contradicted, the combination meter stores the DTC B2465.

  1. The CAN bus line may be defective
  2. The ETACS-ECU may be defective
  3. The combination meter may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code Check if DTC is set to the ETACS-ECU. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Troubleshoot the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). NO: Go to Step 2.
  2. STEP 2. Using scan tool MB991958, diagnose the CAN bus line. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  3. STEP 3. Combination meter operation check Check that the combination meter works normally. Q: Is the check result normal? YES: Go to Step 4. NO: Check the power supply circuit of combination meter (Refer to «INSPECTION PROCEDURE 1: POWER SUPPLY CIRCUIT CHECK.»(ref-592598-S09605295272014011000000) ).
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

DIAGNOSTIC FUNCTION

If the CAN-B circuit malfunction occurs, the combination meter sets DTC U0019.

The CAN bus line may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 163

Scheme 163
Scheme 163
  1. STEP 1. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Go to Step 2. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  2. STEP 2. Using scan tool MB991958, diagnose the CAN bus line. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).

The combination meter sets DTC U0100 when it cannot receive "CHECK ENGINE" signals from the engine control module.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the engine control module diagnostic trouble code. Check if DTC is set to the engine control module. Q: Is the DTC set? YES: Troubleshoot the engine (Refer to «DIAGNOSIS»(ref-592621-S18275897742014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if DTC U0100 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the engine control module. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the engine control module and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the engine control module and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the signal from ETACS-ECU cannot be received, the combination meter sets the DTC U0141.

  1. The CAN bus line may be defective
  2. The combination meter may be defective
  3. The ETACS-ECU may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check again if the DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Diagnose the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the A/C diagnostic trouble code. Check if DTC U0141 is set to the A/C-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the ETACS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the ETACS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the signal from SRS-ECU cannot be received, the combination meter sets DTC U0151.

  1. The CAN bus line may be defective
  2. The SRS-ECU may be defective
  3. The combination meter may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the SRS-ECU diagnostic trouble code Check again if the DTC is set to the SRS-ECU. Q: Is the DTC set? YES: Troubleshoot the SRS (Refer to «TROUBLESHOOTING»(ref-592595-S26035912682014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the A/C-ECU diagnostic trouble code. Check if the DTC U0151 is set to the A/C-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the SRS-ECU. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the SRS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the SRS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

When the signals from occupant classification-ECU cannot be received, the combination meter sets DTC U0154.

  1. The CAN bus line may be defective.
  2. The combination meter may be defective.
  3. The occupant classification-ECU may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the occupant classification-ECU diagnostic trouble code. Check if DTC is set to the occupant classification-ECU. Q: Is the DTC set? YES: Troubleshoot the SRS (Refer to «DIAGNOSIS»(ref-592595-S02457228182014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the A/C-ECU diagnostic trouble code. Check if the DTC U0154 is set to the A/C-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the occupant classification-ECU. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the occupant classification-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the occupant classification-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the signal from A/C-ECU or heater control unit cannot be received, the combination meter sets DTC U0164.

  1. The CAN bus line may be defective.
  2. The A/C-ECU may be defective.
  3. The heater control unit may be defective.
  4. The combination meter may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the A/C diagnostic trouble code. Check if DTC is set to the A/C-ECU or heater control unit. Q: Is the DTC set? YES: Troubleshoot the A/C-ECU or heater control unit (Refer to «A/C DIAGNOSIS»(ref-592583-S22899019132014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if the DTC U0164 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the A/C-ECU or heater control unit. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the A/C-ECU or heater control unit and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the A/C-ECU or heater control unit and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the signal from KOS-ECU or WCM cannot be received, the combination meter sets DTC U0168.

  1. Malfunction of CAN bus line may be defective.
  2. Malfunction of the KOS-ECU may be defective.
  3. Malfunction of the WCM may be defective.
  4. Malfunction of combination meter may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the KOS-ECU or WCM diagnostic trouble code. Check again if the DTC is set to the KOS-ECU or WCM. Q: Is the DTC set? YES: Troubleshoot the KOS or WCM (Refer to «TROUBLESHOOTING»(ref-592599-S30396047812014011000000) or «TROUBLESHOOTING»(ref-592600-S38912740882014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the diagnostic trouble code. Check if the DTC U0168 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the WCM or KOS-ECU. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the WCM or KOS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the WCM or KOS-ECU and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

When the signals from radio and CD player or CD changer cannot be received, the combination meter sets the DTC U0184.

  1. The CAN bus line may be defective.
  2. The combination meter may be defective.
  3. The radio and CD player or CD changer may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the audio diagnostic trouble code. Check again if the DTC is set to the audio. Q: Is the DTC set? YES: Troubleshoot the radio and CD player (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592601-S42323872682014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if the DTC U0184 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the radio and CD player or CD changer. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the radio and CD player or CD changer and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the radio and CD player or CD changer and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

When the signals from hands free module cannot be received, the combination meter sets DTC U0197.

  1. The CAN bus line may be defective.
  2. The combination meter may be defective.
  3. The hands free module may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the hands free module diagnostic trouble code. Check again if the DTC is set to the hands free module. Q: Is the DTC set? YES: Troubleshoot the hands-free cellular phone system. NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if the DTC U0197 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the hands free module. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the hands free module and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the hands free module and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

When the signals from audio visual navigation unit cannot be received, the combination meter sets DTC U0245.

  1. The CAN bus line may be defective.
  2. The combination meter may be defective.
  3. The audio visual navigation unit may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the audio visual navigation unit diagnostic trouble code. Check if DTC is set to the audio visual navigation unit. Q: Is the DTC set? YES: Troubleshoot the MMCS (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592603-S21819533662014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if the DTC U0245 is set to the ETACS-ECU. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the CAN box unit (audio visual navigation unit). NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the CAN box unit (audio visual navigation unit) and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the ETACS-ECU. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the CAN box unit (audio visual navigation unit) and the combination meter (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

If the vehicle information data is not registered to the combination meter, the combination meter sets DTC U1415.

  1. The CAN bus line may be defective.
  2. The combination meter may be defective.
  3. The ETACS-ECU may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check if DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Troubleshoot the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). NO: Go to Step 3.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the combination meter. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ).

TROUBLE SYMPTOM CHART

CAUTIONDuring troubleshooting, a DTC code associated with another system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, confirm all systems for DTC code(s). If DTC code(s) are set, erase them all. When the combination meter is required to be replaced as a result of the troubleshooting, the current driving distance and number of elapsed days to be used for service reminder function must be entered into the meter after the replacement. Therefore, read "Integrated mileage for reminder," "Integrated days for reminder," "Mileage until Extra reminder," "Months until Extra reminder," and "Current Schedule" from the meter before the replacement using the special function of scan tool MB991958, and note them. For the operation method of scan tool MB991958, refer to HOW TO SET BY OPERATING THE SCAN TOOL MB991958 . If "Integrated mileage for reminder" or "Integrated days for reminder" cannot be read by the scan tool MB991958, follow the method described below. For the driving distance for check warning, use the driving distance displayed on the multi information display. For the elapsed days for check warning, calculate the number of elapsed days from the delivery date to the customer (service remainder function start date) and current date.
Trouble symptomInspection Procedure
Power supply circuit check.Refer to INSPECTION PROCEDURE 1: POWER SUPPLY CIRCUIT CHECK.
The speedometer does not work (the other meters work).Refer to INSPECTION PROCEDURE 2: THE SPEEDOMETER DOES NOT WORK (THE OTHER METERS WORK).
The tachometer does not work (the other meters work).Refer to INSPECTION PROCEDURE 3: THE TACHOMETER DOES NOT WORK (THE OTHER METERS WORK).
Tone alarm does not sound normally.Refer to INSPECTION PROCEDURE 4: TONE ALARM DOES NOT SOUND NORMALLY.
The combination meter light does not illuminate normally or the multi information display is not displayed normally.Refer to INSPECTION PROCEDURE 5: THE COMBINATION METER LIGHT DOES NOT ILLUMINATE NORMALLY OR THE MULTI INFORMATION DISPLAY IS NOT DISPLAYED NORMALLY.
The multi information display screen cannot be changed with the operation of the meter information switch.Refer to INSPECTION PROCEDURE 6: THE MULTI INFORMATION DISPLAY SCREEN CANNOT BE CHANGED WITH THE OPERATION OF THE METER INFORMATION METER SWITCH.

TROUBLE SYMPTOM CHART

Scheme 164

Scheme 164: Inspection Procedure 1: Power Supply Circuit Check
Scheme 164: Inspection Procedure 1: Power Supply Circuit Check

Scheme 165

Scheme 165
Scheme 165
  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. The combination meter may be defective

Required Special Tools

  1. MB991223: Harness Set
  2. MB992006: Extra Fine Probe
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167

Scheme 168

Scheme 168
Scheme 168
  1. STEP 1. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 2.
  2. STEP 2. Check combination meter connector C-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is combination meter connector C-04 in good condition? YES: Go to Step 3. NO: Repair the defective connector.
  3. STEP 3. Check the battery power supply circuit to the combination meter. Measure the voltage at combination meter connector C-04. Disconnect the connector, and measure at the wiring harness side. Turn the ignition switch to the LOCK (OFF) position. Measure the voltage between terminals 1 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Check the wiring harness between combination meter connector C-04 (terminal 1) and the fusible link (36). Check the power supply line (battery supply) for open circuit and short circuit. NOTE: Also check ETACS-ECU connectors C-307 and C-317 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If ETACS-ECU connectors C-307 and C-317 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between combination meter connector C-04 (terminal 1) and the fusible link (36) in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Repair the wiring harness.
  5. STEP 5. Check the battery power supply circuit to the combination meter. Measure the voltage at combination meter connector C-04. Disconnect the connector, and measure at the wiring harness side. Turn the ignition switch to the ON position. Measure the voltage between terminals 2 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 8 . NO: Go to Step 6.
  6. STEP 6. Using scan tool MB991958, check data list. Check the input signal from the ignition switch (IG1) in the ETACS-ECU. Check the ETACS data list. Turn the ignition switch to the "ON" position. ITEM CHART Item No. Item name Normal condition Item 254 IG voltage Approximately 12 volts (battery positive voltage) Turn the ignition switch to the "LOCK" (OFF) position. Q: Do the scan tool MB991958 display the item "IG voltage" is normal condition? YES: Go to Step 7. NO: Troubleshoot the ETACS-ECU. Refer to «INSPECTION PROCEDURE 2 "THE IGNITION SWITCH (IG1) SIGNAL IS NOT RECEIVED»(ref-592588-S39981581642014011000000) ."
  7. STEP 7. Check the wiring harness between combination meter connector C-04 (terminal 2) and the fusible link (34). Check the power supply line (battery supply) for open circuit and short circuit. NOTE: Also check ETACS-ECU connectors C-309 and C-317 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If ETACS-ECU connector C-309 or C-317 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between combination meter connector C-04 (terminal 2) and the fusible link (34) in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Repair the wiring harness.
  8. STEP 8. Check the ground circuit to the combination meter. Test at combination meter connector C-04. Disconnect combination meter connector C-04 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 13 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 10 . NO: Go to Step 9.
  9. STEP 9. Check the wiring harness between combination meter connector C-04 (terminal 13) and ground. Check the ground wire for open circuit. Q: Is the wiring harness between combination meter connector C-04 (terminal 13) and ground in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Repair the wiring harness.
  10. STEP 10. Retest the system. Check that the combination meter works normally. Q: Is the check result satisfactory? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Replace the combination meter.
  1. The ASC-ECU may be defective
  2. The combination meter may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the ASC-ECU diagnostic trouble code. Check if diagnostic trouble code is set to the ASC. Q: Is the DTC set? YES: Troubleshoot the ASC (Refer to «DIAGNOSIS»(ref-592593-S16656763792014011000000) ). NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list. Turn the ignition switch to the "ON" position. Check the data list on the combination meter. Item 80: Speedometer Should read vehicle speed. Turn the ignition switch to the "LOCK" (OFF) position. Q: Does it read vehicle speed? YES: Go to Step 5. NO: Replace the combination meter.
  5. STEP 5. Using scan tool MB991958, check actuator test. Turn the ignition switch to the "ON" position. Conduct the actuator test of the combination meter. Item 1: Speedometer The speedometer operates up to the set position. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normally? YES: Go to Step 6. NO: Replace the combination meter.
  6. STEP 6. Retest the system. Check that the speedometer works normally. Q: Is the check result normal? YES: The procedure is complete. NO: Go to Step 1 .
  1. The combination meter may be defective
  2. The engine control module may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the MFI diagnostic trouble code. Check if DTC is set to the engine control module. Q: Is the DTC set? YES: Troubleshoot the MFI (Refer to «DIAGNOSIS»(ref-592621-S18275897742014011000000) ). NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list. Turn the ignition switch to the "ON" position. Check the data list on the combination meter. Item 87: Tachometer Should read engine speed. Turn the ignition switch to the "LOCK" (OFF) position. Q: Does it read engine speed? YES: Go to Step 5. NO: Troubleshoot the MFI (Refer to «DIAGNOSIS»(ref-592621-S18275897742014011000000) ). Complete the engine troubleshooting, and then go to Step 6 .
  5. STEP 5. Using scan tool MB991958, check actuator test. Turn the ignition switch to the "ON" position. Conduct the actuator test of the combination meter. Item 2: Tachometer The tachometer operates up to the set position. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normally? YES: Go to Step 6. NO: Replace the combination meter.
  6. STEP 6. Retest the system Check that the tachometer works normally. Q: Is the check result normal? YES: The procedure is complete. NO: Go to Step 1 .

Inspection Procedure 4: Tone Alarm Does Not Sound Normally

CAUTIONBefore replacing the combination meter, be sure to check that the power supply circuit, ground circuit, and communication circuit are normal.
  1. The combination meter may be defective
  2. The each ECU may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read for any diagnostic trouble code. Check if diagnostic trouble code is set to the engine control module, TC-SST-ECU, ASC-ECU, ETACS-ECU, WCM, KOS-ECU, audio and A/C-ECU. Q: Is the DTC set to the any of the above? YES : Troubleshoot the engine control module (Refer to «DIAGNOSIS»(ref-592621-S18275897742014011000000) ). YES : Troubleshoot the TC-SST (Refer to «DIAGNOSIS»(ref-592623-S16232072802014011000000) ). YES : Troubleshoot the ASC (Refer to «DIAGNOSIS»(ref-592593-S16656763792014011000000) ). YES : Troubleshoot the ETACS (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). YES : Troubleshoot the WCM (Refer to «DIAGNOSIS»(ref-592600-S38912740882014011000000) ). YES : Troubleshoot the KOS (Refer to «DIAGNOSIS»(ref-592599-S30396047812014011000000) ). YES : Troubleshoot the audio (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592601-S42323872682014011000000) ). YES : Troubleshoot the A/C (Refer to «AUTO A/C DIAGNOSIS»(ref-592583-S07652827442014011000000) ). NO : Go to Step 4.
  4. STEP 4. Check by scan tool MB991958 "Special Function" Using scan tool MB991958, select "Test" from the special function of the combination meter. Execute the following item to check the tone alarm. Item 3: Buzzer (AUTO) Q: Is the check result normal? YES: Go to Step 5. NO: Replace the combination meter.
  5. STEP 5. Retest the system Check that the tone alarm normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Replace the combination meter.

Inspection Procedure 5: The Combination Meter Light Does Not Illuminate Normally Or The Multi Information Display Is Not Displayed Normally

CAUTIONBefore replacing the combination meter, be sure to check that the power supply circuit, ground circuit, and communication circuit are normal.
  1. The combination meter may be defective
  2. The each ECU may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(ref-592596-S42814782062014011000000) ).
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check again if the DTC is set to the combination meter. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read for any diagnostic trouble code. Check again if the DTC is set to the engine control module, TC-SST-ECU, WCM, KOS-ECU, ASC-ECU, SRS-ECU, ETACS-ECU and A/C-ECU. Q: Is the DTC set to the any of the above? YES : Troubleshoot the engine control module (Refer to «DIAGNOSIS»(ref-592621-S18275897742014011000000) ). YES : Troubleshoot the TC-SST (Refer to «DIAGNOSIS»(ref-592623-S16232072802014011000000) ). YES : Troubleshoot the ASC (Refer to «DIAGNOSIS»(ref-592593-S16656763792014011000000) ). YES : Troubleshoot the WCM (Refer to «DIAGNOSIS»(ref-592600-S38912740882014011000000) ). YES : Troubleshoot the KOS (Refer to «DIAGNOSIS»(ref-592599-S30396047812014011000000) ). YES : Troubleshoot the SRS (Refer to «DIAGNOSIS»(ref-592595-S26035912682014011000000) ). YES : Troubleshoot the ETACS (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592588-S03824957682014011000000) ). YES : Troubleshoot the A/C (Refer to «AUTO A/C DIAGNOSIS»(ref-592583-S07652827442014011000000) ). NO : Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check actuator test. Turn the ignition switch to the "ON" position. Conduct the actuator test of the combination meter. Item 7: Indicator1 Item 8: Indicator2 Item 9: Indicator3 Item 10: Indicator4 Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normal? YES: Go to Step 5. NO: Replace the combination meter.
  5. STEP 5. Check by scan tool MB991958 "Special Function" Using scan tool MB991958, select "Test" from the special function of the combination meter. Execute the following item to check the liquid crystal display. Item 2: LCD (AUTO) Q: Is the check result normal? YES: Go to Step 6. NO: Replace the combination meter.
  6. STEP 6. Retest the system. Check that display lights or warning lights are illuminated normally, or multi information display is displayed normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Replace the combination meter.
  1. The meter information meter switch may be defective
  2. The combination meter may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB991223: Harness Set
  2. MB992006: Extra Fine Probe
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592598-S19057775672014011000000) ." Turn the ignition switch to the "ON" position. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Troubleshoot the combination meter (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592598-S42095597642014011000000) ). NO: Go to Step 2.
  2. STEP 2. Check meter information switch connector C-02 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is meter information switch connector C-02 in good condition? YES: Go to Step 3. NO: Repair the connector.
  3. STEP 3. Check the meter information meter switch. Check the meter information meter switch (Refer to «METER INFORMATION SWITCH CHECK»(ref-592598-S06314576182014011000000) ). Q: Is the check result normal? YES: Go to Step 4. NO: Replace the meter information meter switch.
  4. STEP 4. Measure at meter information switch connector C-02 in order to the ground circuit to the meter information switch. Disconnect meter information switch connector C-02, and measure at the wiring harness side. Measure the resistance value between terminal 4 and ground. The measured value should be 2 ohm or less. Q: Does the measured resistance value correspond with this range? YES: Go to Step 6 . NO: Go to Step 5.
  5. STEP 5. Check the wiring harness between meter information switch connector C-02 (terminal 4) and ground. Check the ground wires for open circuit. Q: Is the wiring harness between fuel meter information switch connector C-02 (terminal 4) and ground in good condition? YES: Go to Step 6. NO: Repair the wiring harness.
  6. STEP 6. Check combination meter connector C-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is combination meter connector C-04 in good condition? YES: Go to Step 7. NO: Repair the connector.
  7. STEP 7. Check the wiring harness between meter information switch connector C-02 (terminal 1) and combination meter connector C-04 (terminal 3). Check the output lines for open circuit. Q: Are the wiring harness between meter information switch connector C-02 (terminal 1) and combination meter connector C-04 (terminal 3) in good condition? YES: Go to Step 8. NO: Repair the wiring harness.
  8. STEP 8. Retest the system. Check that the multi information display screen switches normally when the meter information meter switch is operated. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(ref-592586-S21436341472014011000000) ). NO: Replace the combination meter.

ACTUATOR TEST

Item No.Item nameTest itemDriven content or unit
1 (1)SpeedometerPointer setting
2TachometerPointer settingR/min
3Fuel gaugeStatus settingOhm
5Meter illuminationStatus setting%
7Indicator1By turning ON/OFF the item values, indicators can be illuminated/extinguished and tone alarm can be sounded.ON/OFF
8Indicator2ON/OFF
9Indicator3ON/OFF
10Indicator4ON/OFF
(1) Depending on the main scale of the speedometer, the unit that can be tested changes. Unit is displayed as "-" on the scan tool MB991958 screen.
(1)Depending on the main scale of the speedometer, the unit that can be tested changes. Unit is displayed as "-" on the scan tool MB991958 screen.

ACTUATOR TEST CHART

TEST (SPECIAL FUNCTION)

Item No.Item nameTest content
2LCD (AUTO)The display screen will be changed in the following order. A black full screen is displayed. The version information is displayed. A white full screen is displayed. A screen with black and white gradation is displayed.
3Buzzer (AUTO)The tone alarm sounds.

ACTUATOR TEST CHART

HOW TO SET BY OPERATING THE SCAN TOOL MB991958

CAUTIONIf the combination meter needs to be replaced, the current driving distance and elapsed days must be entered into the meter after the replacement in order to be used for service reminder function. Therefore, read "Integrated mileage for reminder," "Integrated days for reminder," "Mileage until Extra reminder," "Months until Extra reminder," and "Current schedule" from the meter before the replacement using the special function of the scan tool MB991958, and note them. If "Integrated mileage for reminder" or "Integrated days for reminder" cannot be read from the meter using the scan tool MB991958, use the following method. As for the driving distance for check warning, use the driving distance displayed on the multi information display. As for the elapsed days for check warning, calculate the number of elapsed days from the delivery date to the customer (service reminder function start date) and current date. After the service reminder function has started, when the elapsed days for check warning is reset for the vehicle whose battery is removed for a long period (15 days or more), calculate the elapsed days from the delivery date to the customer (service reminder function start date) and the current date, and then input it.

Using the scan tool MB991958, the following service reminder functions can be set. Before setting, check the current status (schedule, driving distance and elapsed days).

  1. Reminder reset (Indicator off)
  2. Next schedule reminder cancel
  3. Extra reminder setting
  4. Extra reminder cancel
  5. Periodic reminder schedule set
  6. Integrated value adjustment
  7. Optional INT schedule setting

HOW TO OPERATE THE SCAN TOOL MB991958

CAUTIONBefore setting, if the combination meter does not start measuring the elapsed time, turn the ignition switch to the ON position while pressing the meter information switch to start a measurement.

Scheme 169

Scheme 169
Scheme 169
  1. Connect the scan tool MB991958 to the data link connector.
  2. Start the scan tool system on the PC and turn the ignition switch to the "ON" position.
  3. Select "Meter" on the "System Select" screen, and press the "OK" button.
  4. Select "Special Function" on the next screen.
  5. Select "Service Reminder" on the "Special function" screen.
  6. Select the function to be executed from "Function List." 1 Reminder reset (Indicator off) (Refer to «1. REMINDER RESET (INDICATOR OFF)»(ref-592598-S30804234552014011000000) ). 2 Next schedule reminder cancel (Refer to «2. NEXT SCHEDULE REMINDER CANCEL»(ref-592598-S08507350742014011000000) ). 3 Extra reminder setting (Refer to «3. EXTRA REMINDER SETTING»(ref-592598-S00822722352014011000000) ). 4 Extra reminder cancel (Refer to «4. EXTRA REMINDER CANCEL»(ref-592598-S06697021332014011000000) ). 5 Periodic reminder schedule set (Refer to «5. PERIODIC REMINDER SCHEDULE SET»(ref-592598-S40816975702014011000000) ). 6 Integrated value adjustment (Refer to «6. INTEGRATED VALUE ADJUSTMENT»(ref-592598-S09673263682014011000000) ). 7 Optional INT schedule setting (Refer to «7. OPTIONAL INT SCHEDULE SETTING»(ref-592598-S23534013522014011000000) ).

More articles — Combination Meter - Lancer Evolution
