HOW TO READ DATA LIST

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V. C. I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Scheme 102

1. Connect scan tool MB991958 to the data link connector.
2. Turn the ignition switch to the "ON" position.
3. Select "System Select."
4. Select "ABS/ASC/ASTC" from the system list, and select the "OK" button.
5. Select "Data List."

CHECK OF FREEZE FRAME DATA

The freeze frame data can be checked by using the scan tool.

When detecting fault and storing the DTC, the ECU connected to CAN bus line obtains the data before the determination of the DTC and the data when the DTC is determined, and then stores the ECU status of that time. By analyzing each data from scan tool, the troubleshooting can be performed more efficiently. The displayed items are as the table below.

DISPLAY ITEM LIST

FAIL-SAFE FUNCTIONS

ASC-ECU constantly monitors the input and output signals. If an error is detected in the system, ASC-ECU sends a fail signal and the corresponding indicator light is illuminated or blinks. Various controls are processed depending on the cause of malfunction as shown below.

Illumination Condition Of Warning Light And Display In Case Of Failure

FAIL-SAFE FUNCTIONS WARNING LIGHT AND DISPLAY

Under EBD, ABS, Skid Control, TCL Control And HSA Function In Case Of Failure

FAIL-SAFE FUNCTIONS EBD, ABS, SKID CONTROL, TCL CONTROL AND HSA

PROBABLE CAUSES

1. Damaged wiring harness and connectors
2. External noise interference
3. Malfunction of wheel speed sensor
4. ASC-ECU malfunction
5. Excessive gap between the wheel speed sensor and the magnetic encoder for wheel speed detection
6. Adhesion of foreign materials on the wheel speed sensor
7. Adhesion of foreign materials on the magnetic encoder for wheel speed detection
8. Wheel bearing malfunction
9. Improper installation of the wheel speed sensor
10. Deformation of the magnetic encoder for wheel speed detection
11. Disturbance of magnetization pattern for magnetic encoder for wheel speed detection
12. Missing teeth of the magnetic encoder for wheel speed detection

1. Damaged wiring harness and connectors
2. External noise interference
3. Malfunction of wheel speed sensor
4. ASC-ECU malfunction
5. Excessive gap between the wheel speed sensor and the magnetic encoder for wheel speed detection
6. Adhesion of foreign materials on the wheel speed sensor
7. Adhesion of foreign materials on the magnetic encoder for wheel speed detection
8. Wheel bearing malfunction
9. Improper installation of the wheel speed sensor
10. Deformation of the magnetic encoder for wheel speed detection
11. Disturbance of magnetization pattern for magnetic encoder for wheel speed detection
12. Missing teeth of the magnetic encoder for wheel speed detection

1. Damaged wiring harness and connectors
2. External noise interference
3. Malfunction of wheel speed sensor
4. ASC-ECU malfunction
5. Excessive gap between the wheel speed sensor and the wheel speed detection encoder
6. Adhesion of foreign materials on the wheel speed sensor
7. Adhesion of foreign materials on the wheel speed detection encoder
8. Wheel bearing malfunction
9. Improper installation of the wheel speed sensor
10. Deformation of the wheel speed detection encoder
11. Disturbance of magnetization pattern for wheel speed detection encoder
12. Missing teeth of the wheel speed detection encoder

1. Damaged wiring harness and connectors
2. External noise interference
3. Malfunction of wheel speed sensor
4. ASC-ECU malfunction
5. Excessive gap between the wheel speed sensor and the wheel speed detection encoder
6. Adhesion of foreign materials on the wheel speed sensor
7. Adhesion of foreign materials on the wheel speed detection encoder
8. Wheel bearing malfunction
9. Improper installation of the wheel speed sensor
10. Deformation of the wheel speed detection encoder
11. Disturbance of magnetization pattern for wheel speed detection encoder
12. Missing teeth of the wheel speed detection encoder

1. ASC-ECU malfunction

1. Incorrect brake pedal height
2. Incorrect adjustment of the stoplight switch
3. Master cylinder malfunction
4. Brake booster malfunction
5. ASC-ECU malfunction

1. Incorrect adjustment of brake pedal height
2. Master cylinder malfunction
3. Brake booster malfunction
4. Incorrect installation position of stoplight switch
5. Malfunction of the stoplight switch
6. Brake drag
7. ASC-ECU malfunction

1. Improper adjustment of stoplight switch installation position
2. Malfunction of the stoplight switch
3. Damaged wiring harness and connectors
4. Malfunction of ETACS-ECU
5. ASC-ECU malfunction

1. Steering wheel sensor malfunction
2. G and yaw rate sensor malfunction
3. Improper installation of steering wheel sensor, or G and yaw rate sensor
4. ASC-ECU malfunction
5. Different steering wheel
6. Wheel alignment not performed

1. Damaged wiring harness and connectors
2. ASC-ECU malfunction
3. Battery terminal malfunction

1. Battery failure
2. ASC-ECU malfunction
3. Charging system failed

1. Wrong coding of engine control module (ECM)
2. Engine Control Module (ECM) malfunction
3. ASC-ECU malfunction
4. External noise interference

1. Engine control module (ECM) malfunction
2. TCM or TC-SST-ECU malfunction
3. AWC-ECU malfunction
4. Steering wheel sensor malfunction
5. Malfunction of the CAN bus
6. ASC-ECU malfunction
7. Malfunction of ETACS-ECU
8. ETACS-ECUs have been interchanged between two vehicles.

1. Malfunction of the CAN bus
2. Engine control module (ECM) malfunction
3. ASC-ECU malfunction
4. When the ignition switch is turned to the "ON" position for the first time after the ASC-ECU is replaced.

1. ETACS-ECUs have been interchanged between two vehicles.
2. Malfunction of ETACS-ECU
3. Malfunction of ASC-ECU
4. External noise interference

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. G and yaw rate sensor malfunction
3. ASC-ECU malfunction
4. External noise interference

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. Improper installation of the G and yaw rate sensor
3. G and yaw rate sensor malfunction
4. Malfunction of wheel speed sensor
5. ASC-ECU malfunction
6. External noise interference

Note. When rotated on the four-wheel drum tester, this DTC may be set.

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. Improper installation of the G and yaw rate sensor
3. G and yaw rate sensor malfunction
4. Steering wheel sensor malfunction
5. Improperly installed steering wheel sensor
6. Malfunction of wheel speed sensor
7. ASC-ECU malfunction
8. External noise interference

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. Improper installation of the G and yaw rate sensor
3. Damaged wiring harness and connectors
4. G and yaw rate sensor malfunction
5. ASC-ECU malfunction

ASC-ECU malfunction

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. Damaged wiring harness and connectors
3. G and yaw rate sensor malfunction
4. ASC-ECU malfunction

1. Improper installation of G and yaw rate sensor or steering wheel sensor
2. ASC-ECU malfunction
3. External noise interference

1. Improper installation of steering wheel sensor
2. Wheel alignment not performed
3. Steering wheel sensor malfunction
4. Different steering wheel
5. G and yaw rate sensor malfunction
6. Malfunction of wheel speed sensor
7. ASC-ECU malfunction
8. External noise interference
9. Wrong steering wheel is attached

1. Neutral position of steering wheel sensor not learned
2. Steering wheel sensor malfunction
3. ASC-ECU malfunction

1. Steering wheel sensor malfunction
2. ASC-ECU malfunction
3. External noise interference

1. Different hydraulic unit (For delivery to factory)
2. ASC-ECU malfunction

1. Disconnection of the ASC-ECU connector or the battery terminal when the ignition switch is ON
2. Loose battery terminal
3. Abnormality in battery
4. Damaged wiring harness and connectors
5. ASC-ECU malfunction

1. ASC-ECU malfunction
2. Noise interference

1. Malfunction of ETACS-ECU
2. Engine ECU malfunction
3. ETACS-ECUs have been interchanged between two vehicles.
4. ASC-ECU malfunction
5. ASC-ECUs have been interchanged between two vehicles.
6. ETACS-ECU or ASC-ECU installation error
7. Malfunction of ETACS-ECU coding data

1. Wiring harness or connector failure of CAN bus line
2. ASC-ECU malfunction
3. Other ECU malfunction

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. G and yaw rate sensor malfunction
3. ASC-ECU malfunction
4. External noise interference

1. Malfunction of engine system
2. Malfunction of engine control module (ECM)
3. Malfunction of ASC-ECU
4. External noise interference

1. Steering wheel sensor malfunction
2. ASC-ECU malfunction
3. External noise interference

1. Wiring harness or connector failure for the special CAN bus lines between ASC-ECU and the G and yaw rate sensor
2. Malfunction of the G and yaw rate sensor
3. ASC-ECU malfunction

1. Variant coding for ETACS-ECU has not been implemented.
2. ASC-ECU malfunction

1. Malfunction of ETACS-ECU
2. Malfunction of engine control module (ECM)
3. ETACS-ECUs have been interchanged between two vehicles.
4. Malfunction of ASC-ECU
5. External noise interference
6. ASC-ECUs have been interchanged between two vehicles.

1. Damaged wiring harness and connectors
2. ASC-ECU malfunction
3. Wrong routing of scan tool harness
4. Abnormality in battery or generator
5. Abnormality in power supply voltage to ASC-ECU
6. ECU malfunction of other system

1. Overheat of brake pad

Scheme 103

1. The brake pad thickness is at the limit value or less.
2. The brake fluid amount is at the "LOWER" level or lower.
3. Poor adjustment of the parking brake lever
4. Damaged wiring harness and connectors
5. Parking brake switch malfunction
6. Brake fluid level switch malfunction
7. Combination meter malfunction
8. Malfunction of ETACS-ECU

1. Damaged wiring harness and connectors
2. Malfunction of ETACS-ECU
3. Combination meter malfunction
4. ASC-ECU malfunction
5. Malfunction of coding data for ETACS-ECU

1. Damaged wiring harness and connectors
2. Malfunction of ETACS-ECU
3. Malfunction of the combination meter
4. ASC-ECU malfunction

1. Damaged wiring harness and connectors
2. Malfunction of ETACS-ECU
3. Combination meter malfunction
4. ASC-ECU malfunction
5. Control stop due to the low voltage

Note. Due to the abnormality in the supply voltage, the DTC may not be set even when the ABS warning light is illuminated.

1. Damaged wiring harness and connectors
2. Malfunction of ETACS-ECU
3. Combination meter malfunction
4. ASC-ECU malfunction
5. Control is disabled due to the low voltage

Note. Due to the abnormality in the supply voltage, the DTC may not be set even when the ASC warning display illuminates.

1. Damaged wiring harness and connectors
2. Malfunction of ETACS-ECU
3. Combination meter malfunction
4. ASC-ECU malfunction

1. Damaged wiring harness and connectors
2. ASC OFF switch malfunction
3. Malfunction of ETACS-ECU

1. Hydraulic unit (Integrated with ASC-ECU) malfunction
2. Malfunction of hydraulic circuit
3. Malfunction of brake assembly
4. Malfunction of brake booster
5. Malfunction of master cylinder assembly

1. Low battery output
2. Wiring harness or connector failure of CAN bus line
3. ASC-ECU malfunction
4. Engine coding data problem

1. Damaged wiring harness and connectors
2. Fuse and fusible link malfunction
3. Improper tightening of battery terminal
4. Improper tightening of ground bolt
5. Battery failure
6. Charging system failed
7. ASC-ECU malfunction

1. Mounting of wheels and tires other than with genuine specified size
2. Tire pressure abnormality
3. Tire wear and deterioration
4. Mounting of non-genuine braking device or impact reduction device
5. Wheel alignment abnormality
6. Malfunction of brake related parts
7. Malfunction of the wheel speed sensor
8. Malfunction of the G and yaw rate sensor
9. Steering wheel sensor malfunction
10. Malfunction of hydraulic unit (integrated with ASC-ECU)
11. Malfunction of hydraulic circuit
12. External radio wave noise interference

1. Damaged wiring harness and connectors
2. Fuse and fusible link malfunction
3. Improper tightening of battery terminal
4. Battery failure
5. Charging system failed
6. Steering wheel sensor malfunction

1. Improper installation of the G and yaw rate sensor
2. G and yaw rate sensor malfunction
3. Calibration failure of the brake fluid pressure sensor
4. Seizure of the parking brake switch
5. Malfunction of wheel speed sensor
6. Malfunction of hydraulic unit (integrated with ASC-ECU)
7. Wiring harness or connector failure of CAN bus line
8. Damaged wiring harness and connectors

1. Improper installation of the G and yaw rate sensor
2. G and yaw rate sensor malfunction
3. ASC-ECU malfunction
4. Brake drag
5. Damaged wiring harness and connectors

DATA LIST REFERENCE TABLE

The following items can be read by the scan tool from the ASC-ECU input data.

The following items of ECU input data can be read using scan tool.

1. The system is normal. DATA LIST REFERENCE TABLE Item No. Check item Check condition Normal condition 01 FL wheel speed sensor Perform a test run of the vehicle. The speedometer display and the scan tool display almost agree with each other. < During stop: approximately 0.4 mph (0.7 km/h) 02 FR wheel speed sensor 03 RL wheel speed sensor 04 RR wheel speed sensor 05 Power supply voltage Battery positive voltage (10 to 18 V ASC operable range) 07 Brake switch (input) The brake pedal is depressed. ON The brake pedal is released. OFF 08 Lateral G sensor (+: left turn, -: right turn) Vehicle stopped (level) -0.11 to 0.11 G Running -1 to 1 G 09 G sensor (+: deceleration, -: acceleration) Vehicle stopped (level) -0.04 to 0.04 G Running FWD 0 G (1) (fixed value) AWD -1 to 1 G 10 Master cylinder pressure (+: pressure increase, -: pressure decrease) The brake pedal is depressed. Increases by the amount of the brake pedal depression. The brake pedal is released. -3 to 3 bar 11 Steering angle (+: left turn, -: right turn) Vehicle stopped (the steering wheel is in the neutral position) -6 to 6 deg Running Nearly the same as the steering wheel operation angle < -720 to 720 deg (ASC-ECU normal detection value) > Nearly the same as the steering wheel operation angle < -850 to 850 deg (Sensor normal value as a single unit) > 12 Yaw rate sensor (+: left turn, -: right turn) Vehicle stopped (level) -3.6 to 3.6 deg/s Running -100 to 100 deg/s 14 Brake switch The brake pedal is depressed. ON The brake pedal is released. OFF 15 Emission test mode Emission test mode: ON ON Emission test mode: OFF OFF 26 Brake fluid pressure switch Brake fluid level is lower than the "LOWER" marking. Low Brake fluid level is higher than the "LOWER" marking. Normal 28 ASC/TCL off switch When the ASC OFF switch is not operated (when the ASC control is available) ON When the ASC OFF switch is operated (pressed and held for 3 seconds or more) (when the ASC control is prohibited) OFF When the ASC OFF switch is operated (pressed and held for 15 seconds or more) (when the ASC OFF control is prohibited by fail-safe function) (2) ON 45 SAS OK flag When the steering wheel sensor neutral point is learned Comp When the steering wheel sensor neutral point is not learned Not Comp When the steering wheel sensor is defective SAS fail SAS fail & No Comp 65 Engine Speed When the accelerator pedal is depressed (engine started) The tachometer display and the scan tool display almost agree with each other. 66 Engine torque Displays the engine torque. 67 APS Displays the accelerator pedal opening angle. 68 Allow ESP torque request Permitted 70 Target gear When the selector lever is operated Displays the selector lever position. 71 Actual gear 72 Master cylinder pressure Offset The difference between the neutral position that was input to the ASC-ECU before the master cylinder pressure sensor calibration and the neutral position after the calibration. -8 to 8 bar 73 Lateral G sensor offset The difference between the neutral position that was input to the ASC-ECU before the G and yaw rate sensor calibration and the neutral position after the calibration. -0.15 to 0.15 G 86 Ignition switch Ignition switch: ON ON 87 Ignition switch (input) Ignition switch: ON ON 88 Vehicle speed Perform a test run of the vehicle. The speedometer display and the scan tool display almost agree with each other. 91 Brake pressure sensor The brake pedal is depressed. ON The brake pedal is released. OFF 96 G sensor offset The difference between the neutral positions before the calibration and after the calibration received in the ASC-ECU at G & yaw rate sensor calibration. -0.08 to 0.08 G 97 Yaw rate sensor offset The difference between the neutral position that was input to the ASC-ECU before the G and yaw rate sensor calibration and the neutral position after the calibration. -6.0 to 6.0 deg/s 105 Power supply voltage (input) Battery positive voltage (10 to 18 V ASC operable range) 120 Parking brake switch (Input) When the parking brake lever is pulled up: ON When the parking brake lever is released: OFF 128 A. S. C./TCL off switch (input) The ASC OFF switch is pressed. ON The ASC OFF switch is not operated. OFF (1) The G and yaw rate sensor does not detect longitudinal acceleration of a vehicle, thus "0 G" is always set. (2) When the ASC OFF switch is pressed and held for 15 seconds, the ASC system returns to the ON status.
2. System shutdown by ECU

While ASC-ECU is disabled by the diagnostic function, the scan tool displayed data is different from the actual measurement.

TERMINAL VOLTAGE CHECK

Connect the special tool ASC check harness (MB991997) to measure the voltage between each check connector terminal and the ground terminal (No. 16 or 47).

Scheme 104

ECU TERMINAL CONDITIONS

Scheme 105

1. When performing the continuity check, turn the ignition switch to LOCK (OFF) position, connect the special tool ASC check harness (MB991997) as shown in the illustration, and disconnect the ASC-ECU connector.
2. Check for continuity between terminals shown in the chart below.
3. Terminal layout is shown in the illustration.

BODY GROUND CONTINUITY CONDITIONS

WHEEL SPEED SENSOR OUTPUT CURRENT MEASUREMENT

Required Special Tools

1. MB991709: Wiring harness set

The relevant wheel, on which the wheel speed sensor is fitted, should be free to run.

Scheme 106

1. Remove the wheel speed sensor connector to be checked. CAUTION: For precise measurement, do not connect to the wheel speed sensor-side connector and the wiring harness side connector terminal No. 1.
2. Use the special tool test harness (MB991709) to connect a multimeter between the wheel speed sensor-side connector and the wiring harness connector terminal No. 2.
3. Turn the ignition switch to the "ON" position. CAUTION: Do not rotate the wheel too quickly. Output current changes significantly as the wheel speed detection magnetic encoder comes near or goes away from the wheel speed sensor.
4. Rotate the wheel, on which the wheel speed sensor is fitted, quite slowly to measure the output current with the multimeter. Standard value: 5.9 to 8.4 mA or 11.8 to 16.8 mA
5. If the measurement is not within the standard value, or the output current does not change in proportion to the wheel rotation, replace the wheel speed sensor (Refer to «WHEEL SPEED SENSOR»(ref-592559-S19740126892014011000000) ).

HYDRAULIC UNIT CHECK

Required Special Tools

1. MB991958: scan tool Sub Assembly MB991824: Vehicle Communication Interface (V. C. I.) MB991827: scan tool USB Cable MB991910: scan tool Main Harness A (Vehicles with CAN communication system)

Scheme 107

1. Raise the vehicle using a jack and support the specified points with a rigid rack. CAUTION: Before connecting or disconnecting scan tool, always turn the ignition switch to the LOCK (OFF) position.
2. Before setting scan tool, turn the ignition key to the LOCK (OFF) position.
3. Confirm that the selector lever is in the "N" position, and then start the engine.
4. When carrying out the actuator tests No. 01 to 04, perform the actuator tests using scan tool while depressing the brake pedal. When carrying out the actuator tests No. 05 to 08, perform the actuator tests using scan tool without depressing the brake pedal. When carrying out the actuator tests, rotate the wheel by hands to confirm that the braking force changes. NOTE: While performing the actuator test, the ABS warning light flashes at a rate of 2 Hz. When ASC-ECU is disabled due to the fail-safe function, the scan tool actuator test cannot be performed. After the actuator test has been performed, the ABS warning light, brake waning light, and ASC OFF light or ASC OFF display illuminate until the ignition switch is turned to ON again or the communication between scan tool and ASC-ECU is terminated.
5. This is indicated as shown in the Illustration above.
6. When any malfunction has been found, take a necessary action according to the "Judgment Table." JUDGMENT TABLE Display on scan tool Operation Test result Judgment Cause Measure 01 FL wheel ABS drive 02 FR wheel ABS drive 03 RL wheel ABS drive 04 RR wheel ABS drive Depress the brake pedal to lock the wheel. Select the vehicle to be inspected using scan tool, perform the actuator test. Rotate the selected wheel by hands to confirm the braking force. Braking force decreases for 3 seconds from the lock status. Normal - - The wheel does not lock even if the brake pedal is depressed. Error Clogged brake line other than hydraulic unit Check and clean the brake line. Clogged hydraulic circuit in the hydraulic unit Replace the hydraulic unit assembly. Braking force does not decrease. Faulty routing of hydraulic unit brake tube Route the brake tube correctly. Malfunction of hydraulic unit solenoid valve operation Replace the hydraulic unit assembly. 05 FL wheel TCL drive 06 FR wheel TCL drive 07 RL wheel TCL drive 08 RR wheel TCL drive Select the vehicle to be inspected using scan tool, perform the actuator test. Rotate the selected wheel by hands to confirm the braking force. Lock condition occurs for 3 seconds from the status without braking force. Normal - - The wheel does not lock. Error Faulty routing of hydraulic unit brake tube Clogged brake line other than hydraulic unit Check and clean the brake line. Clogged hydraulic circuit in the hydraulic unit Replace the hydraulic unit assembly.
7. After the inspection, turn the ignition switch to the LOCK (OFF) position, and then disconnect scan tool.

IN THE EVENT OF A DISCHARGED BATTERY

If the engine is started using a booster cable when the battery is completely flat, and the vehicle is then driven without waiting for the battery to be recharged, the engine may misfire and it may not be possible to drive the vehicle. This is because the ASC consumes a large amount of current when carrying out its initial checks. If this happens, recharge the battery fully.

Vehicles Without TC-SST

1. Park the vehicle on a level surface. CAUTION: Before connecting or disconnecting the scan tool, turn the ignition switch to the "LOCK" (OFF) position.
2. Set the scan tool with the ignition "LOCK" (OFF).
3. Turn the ignition switch to the ON position.
4. Select the relevant system from the menu.
5. Select "ABS/ASC/ASTC/WSS" from the system lists in "System select", and press "OK" button.
6. Select "Special function" in "ABS/ASC/ASTC/WSS".
7. Select "Sensor calibration" in "Special function".
8. Select "G sensor calibration" from the selected item, and press "OK" button.
9. The screen displays "G sensor calibration: The selected command will be executed. Are you sure? Caution: Please check the execution conditions." Then press "OK" button.
10. "Execute: The command was executed." will be shown. Then press "OK" button.
11. Select "Lateral G sensor calibration" from the selected item, and press "OK" button.
12. The screen displays "Lateral G sensor calibration: The selected command will be executed. Are you sure? Caution: Please check execution conditions." Then press "OK" button.
13. "Executed: The command was executed." will be shown. Then press "OK" button.
14. Learning neutral point complete
15. Turn the ignition switch to "LOCK" (OFF) position and then disconnect the scan tool.

1. Place the vehicle on a level surface with its road wheels in the straight ahead position. CAUTION: Before connecting or disconnecting the scan tool, turn the ignition switch to the "LOCK" (OFF) position.
2. Set the scan tool with the ignition at "LOCK" (OFF).
3. Ignition switch: ON
4. Select the relevant system from the menu.
5. Select "Steering angle sensor" from the system list in "System select", and press "OK" button.
6. Select "Special function" under "Steering angle sensor".
7. Select "SAS Calibration" under "Special function". NOTE: If the steering angle sensor neutral point has been learned, the display will show "If SAS needs re-calibration, execute SAS calibration after executing SAS initialization". If yes, press "OK" button.
8. As "SAS initialization" is selected under "SAS Calibration", press "OK" button. NOTE: At this time, if the steering angle sensor neutral point has been learned, the display will show "Do you want to start? Note This operation will dear DTCs". Then, press "OK" button.
9. The display should show "Completed." Press "OK" button.
10. Press the OK button.
11. The display should show "SAS Calibration: Do you want to start?". Then press the OK button. NOTE: Please execute after making a tire and a steering wheel straight.
12. The display should show "Completed." Press "OK" button.
13. Turn the ignition switch to "LOCK" (off) position, and then turn the ignition switch ON again.
14. Select the relevant system from the menu.
15. Select "ABS/ASC/ASTC/WSS" from the system list under "System select", and press "OK" button.
16. Select "Special function" under "ABS/ASC/ASTC/WSS".
17. Select "Sensor calibration" under "Special function".
18. Select "SAS calibration" under "Sensor calibration", and press "OK" button.
19. The screen displays "SAS calibration: The selected command will be executed. Are you sure? Caution: Confirm the execution conditions." Then press "OK" button.
20. "Executed: The command was executed." will be shown. Then press "OK" button.
21. Select "Diagnostic trouble code" under "ABS/ASC/ASTC/WSS". If the diagnostic trouble code "C2205 SAS internal failure (past trouble)" is set, clear it.
22. Learning neutral point complete
23. Turn the ignition switch to "LOCK" (OFF) position and then disconnect the scan tool.

Vehicles With TC-SST

>> A << BRAKE TUBE CONNECTION

Install the brake pipe to the hydraulic unit as shown in the illustration.

Scheme 108

1. From master cylinder (primary) < Marking color: Blue >
2. To front brake (RH) < Marking color: Orange and white >
3. To front brake (LH) < Marking color: Red and white >
4. From master cylinder (secondary) < Marking color: Yellow >
5. To rear brake (RH) < Marking color: Pink >
6. To rear brake (LH) < Marking color: White >
