Active Skid Control System (Asc) - Lancer Evolution: Specifications Mitsubishi Lancer X

SERVICE SPECIFICATIONS

ItemStandard value
Wheel speed sensor current mA5. 9 - 8.4 or 11.8 - 16.8
Wheel speed sensor insulation resistance Mohms5 or more

SERVICE SPECIFICATIONS

DTC C121C: Torque request signal rejection

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines. Whenever the ECU is replaced, ensure that the CAN bus lines are normal. When the hydraulic unit (integrated with ASC-ECU) is replaced, always perform the calibration of steering wheel sensor, G and yaw rate sensor, brake fluid pressure sensor, cut valve, and inlet valve.(Refer to IN THE EVENT OF A DISCHARGED BATTERY, STEERING WHEEL SENSOR CALIBRATION, MASTER CYLINDER BRAKE FLUID PRESSURE SENSOR CALIBRATION, and CALIBRATION OF CUT VALVE AND INLET VALVE.)

Actuator test specifications

Item No.Check itemDriven component
01FL wheel ABS driveSolenoid valve for the corresponding channel of the hydraulic unit and pump motor (simplified inspection mode)
02FR wheel ABS drive
03RL wheel ABS drive
04RR wheel ABS drive
05FL wheel TCL drive
06FR wheel TCL drive
07RL wheel TCL drive
08RR wheel TCL drive
09Engine TCL driveOutputs the engine torque control signal (engine torque = 0 N.m) to the engine ECU for three seconds.

ACTUATOR TEST SPECIFICATIONS

Scheme 1

Scheme 1: Operation pattern of items 01 to 08
