Power Door Locks - Except Evolution: Removal & Installation Mitsubishi Lancer IX

A) Door Check Installation

Install the door check so that the identification mark faces upward. (Scheme 1)

Scheme 1

B) Lower Sash Installation

Securely insert the rear lower sash into the window rear sash.

C) Door Inside Handle Installation

1. Install the inside lock cable to the door inside handle as follows: Install the inner cable end in the inside lock cable to the clip in the door inside handle. (Scheme 2) Turn the inside lock knob to the door lock position. Install the outer cable end to the door inside handle securely. Install the clip to the inner cable.
2. Install the inside handle rod to the door inside handle.
3. Install the door inside handle to the door.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

A) Door Inside Handle Cover Removal

1. Insert a flat-tipped screwdriver into the rear end of the tapping screw cap on the door inside handle cover, and pry out the cap to the direction shown. (Scheme 6)
2. Insert special tool MB990784 into the clearance between the door inside handle cover and the door inside handle, and disengage the claws of the door inside handle.
3. Insert special tool MB990784 into the rear end of the inside handle cover, and pry out the cover to the direction shown. (Scheme 7) Then remove the door inside handle cover.

Scheme 6

Scheme 7

B) Clip Removal

Use cloth to remove the clip as shown. (Scheme 8)

Scheme 8

A) Waterproof Film Installation

Apply the specified adhesive on the waterproof film as shown. (Scheme 3)

B) Regulator Handle/Clip Installation

1. Install escutcheon and regulator handle to the clip.
2. Close the door window glass fully, and then install the regulator handle. (Scheme 9)

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13
