Cooling Fans - Evolution: Removal & Installation Mitsubishi Lancer IX

Removal & Installation

1. Remove under cover.
2. Drain engine coolant.
3. Remove battery and battery tray.
4. Remove air cleaner assembly.
5. Remove air hose "E", air pipe "C", and air hose "D". See appropriate article in ENGINES.
6. Remove air pipe "B" mounting bolt. (Scheme 7)
7. Disconnect fan control module connector. (Scheme 7)
8. Disconnect the cooling fan motor connector.
9. Remove fan control module.
10. Remove cooling fan motor, cooling fan, and shroud assembly.
11. Remove cooling fan.
12. Remove cooling fan motor.
13. Remove cooling fan shroud.
14. To install, reverse removal procedures.

Scheme 6

Scheme 7
