FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION | |
|---|---|---|
| Clutch control | Clutch release concentric cylinder mounting bolt | 9.8 ± 2.0 N.m (87 ± 17 ft-lb) |
| Clutch master cylinder mounting nut | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Clutch pipe flare nut | 15 ± 1 N.m (11 ± 1 ft-lb) | |
| Eye bolt | 30 ± 4 N.m (22 ± 3 ft-lb) | |
| Pushrod jam nut | 13 ± 2 N.m (115 ± 18 in-lb) | |
| Retainer assembly nut | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Clutch pedal | Clutch master cylinder mounting nut | 12 ± 2 N.m (102 ± 22 in-lb) |
| Pedal support member mounting bolt | 12 ± 2 N.m (102 ± 22 in-lb) | |
| Clutch pedal position switch setting nut | 12 ± 2 N.m (109 ± 21 in-lb) | |
Fastener Tightening Specifications
GENERAL SPECIFICATION
| ITEM | SPECIFICATION |
|---|---|
| Clutch master cylinder I.D. mm (in) | 15.87 (5/8) |
General Specification Chart
