Generators & Regulators - Except Evolution: Overhaul Mitsubishi Lancer IX

Disassembly Service Points

1. A) Front Bracket Assembly Removal - Insert a flat-tipped screwdriver between the front bracket assembly and the stator core, and pry it downward to separate the stator and front bracket assembly. (Scheme 6)
2. B) Generator Pulley Removal - Set the pulley upward, clamp the rotor in a vise, and remove the pulley.
3. C) Stator Removal - Using a soldering iron (180-250W) to unsolder the stator. This work should complete within approximately 4 seconds to prevent heat from transferring to the diode. When removing the rectifier from the regulator assembly, unsolder the points soldered on the rectifier. (Scheme 7)

Scheme 6

Scheme 7

Assembly Service Points

1. A) Regulator Assembly Installation - After installing the regulator assembly, insert a wire through the hold provided on the rear bracket while pressing down on the brush, and secure the brush. (Scheme 8)
2. B) Rotor Assembly Installation - After installing the rotor, remove the wire used to secure the brush.

Scheme 8
