Generators & Regulators - Evolution: Removal & Installation Mitsubishi Lancer IX

Removal Service Points

1. A) Fuel Injector, Fuel Rail, Fuel Return Pipe & Fuel Pressure Regulator Assembly Removal - After loosening the fuel rail mounting bolts, move the fuel injector, fuel rail, fuel return pipe and the fuel pressure regulator as an assembly aside in order to make room for the generator removal.
2. B) Drive Belt Removal - Securely insert the spindle handle or ratchet handle with a 1/2" (12.7 mm) insertion angle into the jig hole of the auto-tensioner, and turn the auto-tensioner counterclockwise until it hits the stopper. (Scheme 25) Align hole A with hole B, insert an L-shaped hexagon wrench, etc. to fix and then remove the drive belt. (Scheme 26)
3. C) Generator Removal - Raise the engine with a floor jack and remove the generator upward from the engine room.

Scheme 25

Scheme 26

For disassembly procedures (Scheme 27)

Scheme 27
