On-Vehicle Service - Except Evolution: Specifications

On-Vehicle Service - Except Evolution: Specifications Mitsubishi Lancer IX

FASTENER TIGHTENING SPECIFICATIONS

ITEM	SPECIFICATION
Key interlock and shift lock mechanisms
Key interlock cable attaching nut	12 ± 2 N.m (107 ± 17 in-lb)
Shift lock cable attaching nut	12 ± 2 N.m (107 ± 17 in-lb)
Transaxle assembly
Automatic transmission fluid drain plug	32 ± 2 N.m (24 ± 1 ft-lb)
Cover attaching bolt	7.0 ± 1.0 N.m (62 ± 9 in-lb)
Center member attaching bolt	69 ± 10 N.m (51 ± 7 ft-lb)
Drive plate bolt	49 ± 3 N.m (36 ± 2 ft-lb)
Driveshaft connecting nut	245 ± 29 N.m (181 ± 21 ft-lb)
Front roll stopper bracket retainer nut	52 ± 7 N.m (39 ± 5 ft-lb)
Lower arm nut connecting nut	108 ± 10 N.m (80 ± 7 ft-lb)
Starter motor attaching bolt	30 ± 3 N.m (22 ± 2 ft-lb)
Tie rod end nut connecting bolt	25 ± 5 N.m (19 ± 3 ft-lb)
Transaxle assembly upper part coupling bolt	48 ± 6 N.m (36 ± 4 ft-lb)
Transaxle control cable connecting nut	12 ± 2 N.m (107 ± 17 in-lb)
Transaxle mount bracket attaching nut	49 ± 5 N.m (36 ± 4 ft-lb)
Transaxle mount stopper attaching nut	81 ± 7 N.m (60 ± 5 ft-lb)
Transaxle control
Bolt attaching nut	12 ± 2 N.m (107 ± 17 in-lb)
Key inter lock cable attaching nut	12 ± 2 N.m (107 ± 17 in-lb)
Lock cam pin attaching nut	4.9 ± 1.0 N.m (44 ± 8 in-lb)
Park/Neutral position switch mounting bolt	11 ± 1 N.m (96 ± 8 in-lb)
Shift knob attaching screw	2.2 ± 0.2 N.m (20 ± 2 in-lb)
Selector lever assembly attaching bolt	12 ± 2 N.m (102 ± 22 in-lb)
Shift lock cable attaching nut	12 ± 2 N.m (107 ± 17 in-lb)
Transaxle control cable attaching bolt	12 ± 2 N.m (107 ± 17 in-lb)
Transaxle control cable connecting nut	12 ± 2 N.m (107 ± 17 in-lb)
