Parking Brakes - Except Lancer Evolution Mitsubishi Lancer Evolution X

SERVICE SPECIFICATIONS

SERVICE SPECIFICATIONS

INTRODUCTION

If the parking brake is faulty, parking brake effort will become insufficient. The cause may be a malfunction of parking brake parts or the parking brake pedal being out of adjustment.

TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a parking brakes fault.

1. Gather Information from the customer.
2. Verify that the condition described by the customer exists.
3. Find the malfunction by following the SYMPTOM CHART.
4. Verify malfunction is eliminated.

SYMPTOM CHART

SYMPTOM CHART

DIAGNOSIS

1. STEP 1. Check the excessive parking brake lever stroke. Refer to «PARKING BRAKE LEVER STROKE CHECK AND ADJUSTMENT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution__parking-brake-lever-stroke-check-and) . Q: Is the parking brake lever stroke adjusted properly? YES: Go to Step 2. NO: Adjust the parking brake lever stroke or check the parking brake cable routing. Then go to Step 5 .
2. STEP 2. Check the parking brake cable for sticking. Q: Is the parking brake cable stuck? YES: Replace the cable. Then go to Step 5 . NO: Go to Step 3.
3. STEP 3. Check the brake lining and brake drum for wear. Refer to «REMOVAL AND INSTALLATION < EXCEPT RALLIART >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) or «REMOVAL AND INSTALLATION < RALLIART >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) . Q: Is the brake lining thickness or brake drum inside diameter out of specification? YES: Replace the rear brake shoe assembly or rear brake disc (Refer to «REMOVAL AND INSTALLATION < EXCEPT RALLIART >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) or «REMOVAL AND INSTALLATION < RALLIART >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) ). Then go to Step 5 . NO: Go to Step 4.
4. STEP 4. Check for oil, water, etc., on the lining contact surfaces. Q: Is oil, water, etc., on the lining contact surface? YES: Replace the part and determine and repair source/cause of foreign material. Then go to Step 5. NO: Carry out the parking brake lining seating procedure (Refer to «PARKING BRAKE LINING SEATING PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution__parking-brake-lining-seating-procedure) ) and then go to Step 5.
5. STEP 5. Retest the system. Q: Is the malfunction eliminated? YES: The procedure is complete. NO: Return to Step 1 .

Scheme 1

TECHNICAL DESCRIPTION (COMMENT)

The parking brake switch turns on and off by operating the parking brake lever, and the brake warning light illuminates and goes out, indicating the operating status of parking brake to the driver.

TROUBLESHOOTING HINTS (THE MOST LIKELY CAUSES FOR THIS CASE:)

1. Damaged wiring harness or connector
2. Parking brake switch defective
3. Combination meter defective

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. STEP 1. Using scan tool MB991958, check combination meter actuator test. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Turn the parking brake switch and brake fluid level switch to "OFF" position. Set scan tool MB991958 to the actuator test mode. Item 13: Indicator4: ON The brake warning light illuminates. Item 13: Indicator 4: OFF The brake warning light goes out. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the combination meter (Refer to «COMBINATION METER ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#combination-meter-except-lancer-evolution) ).
2. STEP 2. Check the parking brake switch. Refer to «PARKING BRAKE SWITCH CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution__parking-brake-switch-check) . Q: Is the parking brake switch normal? YES: Go to Step 3. NO: Replace the parking brake switch (Refer to «PARKING BRAKE LEVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) ). Then go to Step 6 .
3. STEP 3. Connector check: C-117 parking brake switch connector, C-21 intermediate connector and C-04 combination meter connector Q: Is the check result normal? YES: Go to Step 4. NO: Repair or replace the faulty connector (Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) ). Then go to Step 6 .
4. STEP 4. Check the wiring harness for an open circuit between C-117 parking brake switch connector terminal No. 1 and C-04 combination meter connector terminal No. 4. Disconnect C-117 parking brake switch connector from C-04 combination meter connector, and measure at the wiring harness side connector. Measure the resistance between C-117 parking brake switch connector terminal No. 1 and C-04 combination meter connector terminal No. 4. OK: Continuity exists (2 ohms or less) Q: Is the check result normal? YES: Go to Step 5. NO: A open circuit may be present in the wiring harness between C-117 parking brake switch connector terminal No. 1 and C-04 combination meter connector terminal No. 4. Repair the wiring harness if necessary, and then go to Step 6 .
5. STEP 5. Retest the system. Q: Does the brake warning light illuminate when the parking brake lever is pull? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the combination meter (Refer to «COMBINATION METER ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#combination-meter-except-lancer-evolution) ).
6. STEP 6. Retest the system. Q: Does the brake warning light illuminate when the parking brake lever is pulled? YES: The procedure is complete. NO: Return to Step 1 .

PARKING BRAKE LEVER STROKE CHECK AND ADJUSTMENT

Attach the spring scale to the center of the parking brake lever grip. Then, check that the stroke is within the standard value when the parking brake lever is pulled to the vertical direction of the lever with a force of approximately 200 N (45 pounds).

Standard value: 3 to 5 notches

STROKE ADJUSTMENT < VEHICLES WITH REAR DRUM BRAKE >

If the parking brake lever stroke is out of the standard range, adjust as described below

Scheme 2

Scheme 3

1. Remove the floor console box cup holder (Refer to «FLOOR CONSOLE ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Loosen the adjusting nut to the end of the cable rod in order to allow slack in the cables.
3. Depress the brake pedal repeatedly until the stroke no longer changes. NOTE: If the pedal stroke stops changing, the automatic-adjustment mechanism is functioning normally, and the clearance between the shoe and drum is correct. CAUTION: Be careful that the parking brake lever notch number should be within the standard range. If the notch number is too low, rear brake dragging can be caused.
4. Adjust the parking brake lever stroke to the standard value by turning the adjusting nut. After adjustment, check that there is no free play between the adjusting nut and the parking brake lever.
5. After the parking brake lever stroke is adjusted, raise the rear of the vehicle. Release the parking brake, and turn the rear wheels to confirm that the rear brakes are not dragging.

STROKE ADJUSTMENT < VEHICLES WITH REAR DISK BRAKE >

If the parking brake lever stroke is out of the standard range, adjust as described below

Scheme 4

1. Remove the floor console box cup holder (Refer to «FLOOR CONSOLE ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Loosen the adjusting nut to the end of the cable rod in order to allow slack in the cables.
3. Remove the rear brake disk adjusting hole plug. Then insert a flat-tipped screwdriver to turn the adjuster to the arrow direction shown in illustration (to expand the shoe) until the parking brake shoe makes contact and the disk can no longer be turned. Back off the adjuster to the opposite direction by five notches. CAUTION: Be careful that the parking brake lever notch number should be within the standard range. If the notch number is too low, rear brake dragging can be caused.
4. Adjust the parking brake lever stroke to the standard value by turning the adjusting nut. After adjustment, check that there is no free play between the adjusting nut and the parking brake lever.
5. After the parking brake lever stroke is adjusted, raise the rear of the vehicle. Release the parking brake, and turn the rear wheels to confirm that the rear brakes are not dragging.

PARKING BRAKE SWITCH CHECK

Scheme 5

1. Remove the floor console assembly (Refer to «FLOOR CONSOLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Check for continuity between the parking brake switch terminal and the switch mounting bolt. PARKING BRAKE SWITCH CONTINUITY CHART Check condition Normal condition When parking brake lever is pulled. Continuity exists (2 ohms or less) When parking brake lever is released. No continuity

PARKING BRAKE LINING SEATING PROCEDURE

Perform lining seating by the following procedure when replacing the parking brake shoe assemblies or the rear brake disks, or when brake performance is insufficient.

1. Adjust the parking brake lever stroke to the standard value (Refer to «PARKING BRAKE LEVER STROKE CHECK AND ADJUSTMENT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution__parking-brake-lever-stroke-check-and) ).
2. Hook a spring scale onto the center of the parking brake lever grip and pull it with a force of 98 - 147 N (22 - 33 pounds) in a direction perpendicular to the handle.
3. Drive the vehicle at a constant speed of 35 - 50 km/h (22 - 31 mph) for 100 meters (328 feet).
4. Release the parking brake and let the brakes cool for five to ten minutes.
5. Repeat the procedure in steps 2 to 4 four or five times.

REMOVAL AND INSTALLATION

Scheme 6

<< A >> PARKING BRAKE REAR CABLE DISCONNECTION

Disconnect the parking brake rear cable according to the procedure below.

Scheme 7

Scheme 8

1. Release the parking brake, and loosen the adjusting nut.
2. Remove the floor console bracket rear mounting bolts.
3. Slide the floor console bracket rear, and disconnect the parking brake rear cable from the hole shown in illustration by the arrows.

>> A << PARKING BRAKE REAR CABLE CONNECTION INSTALLATION

Scheme 9

Scheme 10

1. Connect the parking brake rear cable to the equalizer as shown in the figure.
2. Install the parking brake rear cable connection, and then tighten the floor console bracket rear mounting bolts to the specified torque. Tightening torque: 9.5 ± 3.5 N.m (84 ± 30 in-lb)

Scheme 11

Disconnect the parking brake rear cable according to the procedure below.

1. Release the parking brake, and loosen the adjusting nut.
2. Remove the floor console bracket rear mounting bolts.
3. Slide the floor console bracket rear, and disconnect the parking brake rear cable from the hole shown in illustration by the arrows.

<< B >> PARKING BRAKE REAR CABLE AND BACKING PLATE CONNECTION REMOVAL

Withdraw the parking brake cable from the backing plate.

Note. Insert a 10 mm-wrench into the parking brake cable to facilitate the cable withdrawal.

Scheme 12

1. Connect the parking brake rear cable to the equalizer as shown in the figure.
2. Install the parking brake rear cable connection, and then tighten the floor console bracket rear mounting bolts to the specified torque. Tightening torque: 9.5 ± 3.5 N.m (84 ± 30 in-lb)

Scheme 13

Disconnect the parking brake rear cable according to the procedure below.

1. Release the parking brake, and loosen the adjusting nut.
2. Remove the floor console bracket rear mounting bolts.
3. Slide the floor console bracket rear, and disconnect the parking brake rear cable from the hole shown in illustration by the arrows.

1. Connect the parking brake rear cable to the equalizer as shown in the figure.
2. Install the parking brake rear cable connection, and then tighten the floor console bracket rear mounting bolts to the specified torque. Tightening torque: 9.5 ± 3.5 N.m (84 ± 30 in-lb)

Scheme 14

<< A >> REAR BRAKE CALIPER ASSEMBLY REMOVAL

1. Remove the rear brake caliper assembly with the brake hose.
2. Secure the removed rear brake caliper assembly with a wire or other similar material at a position where it will not interfere with the removal and installation operations.

<< B >> RETAINER REMOVAL

Use a flat-tipped screwdriver or a similar tool to open up the retainer joint. Then remove the retainer.

Scheme 15

>> A << WAVE WASHER INSTALLATION

Install the wave washer in the direction shown in the illustration.

Scheme 16

>> B << RETAINER INSTALLATION

Use pliers or a similar tool to close the retainer end onto the pin.

Scheme 17

>> C << ADJUSTER ASSEMBLY INSTALLATION

Install the adjuster assemblies. The shoe adjusting bolt should be mounted to the rear of the vehicle for the right wheel, and to the front of the vehicle for the left wheel.

Scheme 18

>> D << SHOE-TO-ANCHOR SPRING INSTALLATION

The shoe-to-anchor springs are not interchangeable because their spring loads are different. The one with blue paint mark should be installed to the front of the vehicle, and the other with yellow paint to the rear of the vehicle, respectively.

Scheme 19

Scheme 20

1. Remove the rear brake caliper assembly with the brake hose.
2. Secure the removed rear brake caliper assembly with a wire or other similar material at a position where it will not interfere with the removal and installation operations.

Use a flat-tipped screwdriver or a similar tool to open up the retainer joint. Then remove the retainer.

Scheme 21

Install the wave washer in the direction shown in the illustration.

Use pliers or a similar tool to close the retainer end onto the pin.

Scheme 22

Install the adjuster assemblies. The shoe adjusting bolt should be mounted to the rear of the vehicle for the right wheel, and to the front of the vehicle for the left wheel.

Scheme 23

The shoe-to-anchor springs are not interchangeable because their spring loads are different. The one with blue paint mark should be installed to the front of the vehicle, and the other with yellow paint to the rear of the vehicle, respectively.

Scheme 24

1. Measure the lining thickness at the most worn area. Standard value: 2.8 mm (0.11 inch) Limit: 1.0 mm (0.04 inch)
2. If the thickness is less than the limit value, replace the right and left shoe and lining assemblies as a set.

Scheme 25

1. Measure the inside diameter of the brake drum at two positions or more. Standard value: 168.0 mm (6.61 inches) < Except RALLIART > 190.0 mm (7.48 inches) < RALLIART > Limit: 169.0 mm (6.65 inches) < Except RALLIART > 191.0 mm (7.52 inches) < RALLIART >
2. If the inside diameter is more than limit value or if there is excessive wear, replace the brake disc.
