Horn - Except Lancer Evolution Mitsubishi Lancer Evolution X

Horns 4 illustrations

Scheme 1: < EXCEPT RALLIART >

>> A << HORN (LOW)/HORN (HIGH) INSTALLATION

Use the ground bolts as the mounting bolts for horn (LOW) and horn (HIGH). The ground bolts have "E" mark on the bolt heads.

Scheme 2: >> A << HORN (LOW)/HORN (HIGH) INSTALLATION

Scheme 3: < RALLIART >

Use the ground bolts as the mounting bolts for horn (LOW) and horn (HIGH). The ground bolts have "E" mark on the bolt heads.

Battery voltage	Terminal number	Normal condition
At no energization	3 - 4	No continuity
With current supply [terminal 1 (-), terminal 2 (+)]	3 - 4	Continuity exists (2 ohms or less)

HORN RELAY TERMINALS CONTINUITY CHART
