Speaker - Except Lancer Evolution Mitsubishi Lancer Evolution X

Scheme 218

The following three types of speakers are available.

1. 4 speakers (Front door: 16 cm, rear door: 16 cm)
2. 6 speakers (tweeter: 3.5 cm, front door: 16 cm, rear door: 16 cm)
3. 9 speakers (tweeter: 3.5 cm, front door: 16 cm, rear door: 2-way coaxial 16 cm, subwoofer: 25 cm) < Rockford Fosgate® premium sound system >

TWEETER

For the front sash trim, two types of tweeters, the balanced dome tweeter < Vehicles with 6 speakers > and soft dome tweeter < Vehicles with 9 speakers (Rockford Fosgate® premium sound system) >, have been established. The soft dome tweeter can play clearer treble with less distortion compared to the balanced dome tweeter. For better treble, two types of front sash garnish, resin type < Vehicles with 6 speakers > and punching metal type < Rockford Fosgate® premium sound system >, has been established. With the punching metal type, the metal has been adopted for the punching part to enlarge the punching opening, enabling the playback of cleaner treble.

Scheme 219

Scheme 220

Note. The parts with "*" are installed exclusively to the vehicles with Rockford Fosgate® premium sound system.

For the front door speaker, two types of speakers, 16 cm paper cone speaker < vehicles with 4 speakers, 6 speakers > and PP (polypropylene) cone speaker < Rockford Fosgate® premium sound system >, are available. For the rear door speaker, two types of speakers, 16 cm paper cone speaker < Vehicles with 4 speakers, 6 speakers > and PP (polypropylene) cone 2-way coaxial speaker < Vehicles with 9 speakers (Rockford Fosgate® premium sound system) >, are available. Compared to the paper cone speakers, the PP (polypropylene) cone speakers can playback crisper bass. The door opening of the vehicles with 9 speaker (Rockford Fosgate® premium sound system) is blocked by using the sheet metal cover and the urethane integrated resin sheet (resin cover and water proof film) to make the door into a speaker box, thus improving the sound quality. As an advantage of the sheet metal cover, the rigidity of the areas around the speaker has been increased, and the higher sound pressure, suppression of high harmonic, and suppression of dumping are achieved to improve sound quality.

Scheme 221

The one-touch installable speaker (with 3 tabs, fixed by rotating) has been adopted to improve serviceability.

SUBWOOFER < VEHICLES WITH ROCKFORD FOSGATE® PREMIUM SOUND SYSTEM >

The 25 cm dual voice coil subwoofer has been installed to the trunk room < LANCER > or quarter trim (LH) < LANCER SPORTBACK >, enabling the playback of dynamic deep bass.

Scheme 222

Scheme 223

SPEAKER CONNECTION CHECK MODE

Enter the speaker connection check mode according to the following steps

Scheme 224

Scheme 225

1. Turn the Ignition switch to the "ACC" or "ON" position and switch off the radio and CD player.
2. Press the following buttons in that order within sixty seconds from step (1). [CH1] button Rewind button Fast-forward button [CH6] button
3. Check that the speaker, which is displayed on the center panel display, sounds (If the [CH6] button is pressed, the speaker will be changed). NOTE: The display of "FL", "FR", "RL", "RR", "RW" blinks.
4. If a button other than the [CH6] button is pressed, or the ignition switch is turned to "LOCK" (OFF) position, you will exit from the speaker connection check mode.

BUZZ NOISE CHECK MODE

Inserting a CD during the speaker connection check mode shifts the mode to the buzz noise check mode, and the buzz noise sound of each speaker can be checked.

As with the speaker connection check mode, press the [CH6] button to switch the output speaker of the buzz noise check sound.

Check that the buzz noise sound is output from the output speaker of buzz noise check sound.

Note. "SPKR" is displayed as "BUZZ" during buzz noise check mode.

SPEAKER TEST < VEHICLES WITH MMCS >

Refer to SERVICE MODE

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

<< A >> REMOVAL OF FRONT DOOR SPEAKER/REAR DOOR SPEAKER

Disconnect the connector, and remove by twisting as shown in the figure.

Scheme 231

>> A << REAR SPEAKER BOX ASSEMBLY INSTALLATION

Tighten the bolts in the order of 1, 2, 3, 4 shown in the figure.

Scheme 232
