Propeller Shaft - Except Lancer Evolution Mitsubishi Lancer Evolution X

GENERAL INFORMATION

The propeller shaft has the following features

1. The 3-piece, 4-joint type propeller shaft with a center bearing is adopted.
2. For the joint Nos. 1, 2, and 4, the caulking type universal joint with excellent properties of balance accuracy is equipped.
3. For joint No. 3, the lightweight and compact LJ (Lebro Joint) is equipped.
4. The dual anti-vibration construction is located at the center bearing to vehicle body joint, reducing vibration (gear noise).
5. The heat protector is adopted to the center bearing bracket.
6. The lead-free grease is adopted for the universal joint and LJ (Lebro Joint).

Scheme 1

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

SERVICE SPECIFICATION

SERVICE SPECIFICATIONS

LUBRICANTS

LUBRICANTS SPECIFICATIONS

ADHESIVE

ADHESIVE SPECIFICATIONS

INTRODUCTION TO PROPELLER SHAFT DIAGNOSIS

If an abnormal noise is heard from the propeller shaft while driving, some parts of the propeller shaft may be worn or damaged, or some mounting bolts may be loose.

PROPELLER SHAFT DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted all of the possible ways to find a propeller shaft fault.

1. Gather information from the customer.
2. Verify that the condition described by the customer exists.
3. Find the malfunction by following the SYMPTOM CHART.
4. Verify malfunction is eliminated.

SYMPTOM CHART

SYMPTOM CHART

DIAGNOSIS

1. STEP 1. Check if the propeller shaft flange yoke and rear differential connecting nuts and the center bearing mounting nuts are loose. Propeller shaft flange yoke and rear differential connecting nuts tightening torque: 54 ± 5 N.m (40 ± 3 ft-lb) Center bearing mounting nuts tightening torque: 41 ± 5 N.m (30 ± 3 ft-lb) Q: Are the connecting nuts and mounting nuts tightened to the specified torque? YES: Go to Step 2. NO: Tighten the connecting nuts and mounting nuts to the specified torque. Then go to Step 3 .
2. STEP 2. Check the sleeve yoke's spline of front propeller shaft for wear. Q: Is wear apparent? YES: Replace the propeller shaft. Then go to Step 3. NO: Go to Step 3.
3. STEP 3. Retest the system. Q: Is the abnormal noise eliminated? YES: The procedure is complete. NO: Recheck from Step 1 .

Scheme 2

1. STEP 1. Check the propeller shaft run-out. Remove the propeller shaft. (Refer to «PROPELLER SHAFT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/driveshaft-universal-joints/#propeller-shaft-except-lancer-evolution) .) Measure the propeller shaft runout. Limit: 0.5 mm (0.02 inch) Q: Is the measured value within the limit? YES: Go to Step 2. NO: Replace the propeller shaft. Then go to Step 2.
2. STEP 2. Retest the system. Q: Is the abnormal noise eliminated? YES: The procedure is complete. NO: Recheck from Step 1 .

SPECIAL TOOL

SPECIAL TOOLS REFERENCE CHART Tool Tool number and name Supersession Application MD998801 Bearing remover - Removal of the center bearing assembly

Scheme 3

Scheme 4

1. Place the gearshift lever to the "N" position.
2. Check the propeller shaft for dent, damage or crack.
3. Check the propeller shaft universal joint, oil seal for crack or damage. If abnormality is recognized, replace the propeller shaft with a new one.

Scheme 5

1. Place the gearshift lever to the "N" position.
2. Hold the tube of propeller shaft by one hand, and apply force by the other hand to the flange yoke or sleeve yoke in rotating direction, axial direction, and perpendicular direction for checking looseness. If looseness is recognized, replace the propeller shaft with a new one.

Scheme 6

1. Place the gearshift lever to the "N" position.
2. Make phase alignment marks on the flange yoke and differential companion flange and disconnect the flange yoke.
3. Hold the tube of propeller shaft by one hand, and apply force by the other hand to the flange yoke in flection direction for checking flection. If showing a sign of catch in the flection direction is recognized, replace the propeller shaft with a new one.

Scheme 7

<< A >> PROPELLER SHAFT FLANGE YOKE AND REAR DIFFERENTIAL CONNECTION NUT

Put mating marks on the flange yoke and the differential companion flange and remove the connecting nuts.

Scheme 8

<< B >> PROPELLER SHAFT ASSEMBLY REMOVAL

Insert a rag or similar materials into the joint boots, and remove the propeller shaft assembly by aligning the front propeller shaft with the rear shaft.

Scheme 9

Scheme 10

>> B << PROPELLER SHAFT FLANGE YOKE AND REAR DIFFERENTIAL CONNECTION NUT INSTALLATION

If the propeller shaft is reused, align the mating marks and install the connecting nuts.

Tightening torque: 54 ± 5 N.m (40 ± 3 ft-lb)

PROPELLER SHAFT RUNOUT

Check the deflection of the front, center and rear shafts.

Limit: 0.5 mm (0.02 inch)

Scheme 11

Required Special Tool

1. MD998801: Bearing Remover

Scheme 12

<< A >> COMPANION FLANGE REMOVAL

Make mating marks on the companion flange and center propeller shaft, and then remove the companion flange.

Scheme 13

<< B >> CENTER BEARING ASSEMBLY REMOVAL

Use special tool MD998801 to remove the center bearing assembly from the center propeller shaft.

Scheme 14

<< C >> BOLT REMOVAL

Make mating marks on the rear propeller shaft, LJ assembly and companion flange, and then remove the bolt.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Remove the LJ boot from the LJ assembly.
2. Make mating marks on the outer race, cage and inner race, and then remove the outer race and ball. NOTE: Note the positions of the balls so that they can be reinstalled in their original positions.
3. Remove the inner race with cage from the rear propeller shaft assembly by using a puller (commercially available).
4. Wipe off the grease and clean the outer race, inner race, cage and balls.
5. If it is not possible to disassemble the outer race of LJ assembly, remove the LJ assembly from the rear propeller shaft assembly by using a puller (commercially available).

<< E >> LJ BOOT REMOVAL

When the LJ boot is reused, tape the spline part on the rear propeller shaft and then remove the LJ boot.

>> A << LJ BOOT INSTALLATION

1. Install the boot band.
2. Wrap a plastic tape around the spline part on the rear propeller shaft and then install the LJ boot.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Apply a thin coat of the specified grease to the ball grooves of the inner and outer races. Specified grease: Repair kit grease
2. Assemble the LJ assembly outer race, cage, balls, and inner race with their mating marks aligned.
3. Apply specified grease to the LJ assembly. Specified grease: Repair kit grease Amount to use: 75 ± 5 g (2.6 ± 0.1 ounces)
4. Apply a little of the specified adhesive to the surface which has groove (for packing) of LJ assembly (shown by arrows in the illustration), fix the rubber packing. Specified adhesive: 3M™ AAD Part No. 8730, 8731 or equivalent
5. Set the groove side of LJ assembly (for packing) toward the LJ boot side and install them.
6. Align the mating marks of LJ assembly and rear propeller shaft, then install the LJ assembly to rear propeller shaft using socket wrench.
7. Using the bolt, align the bolt holes of the LJ boot and the LJ assembly and install LJ boot to the LJ assembly.
8. Install the rubber packing of the companion flange side in the same manner as described in (4) above.

Scheme 24

Scheme 25

1. Install the center bearing assembly to the center propeller shaft in the direction shown in the illustration.
2. After aligning the mating marks of the companion flange and center propeller shaft, install them.
3. Tightening the self locking nut, press fit the center bearing assembly using companion flange.

Scheme 26

1. Install the center bearing assembly to the center propeller shaft in the direction shown in the illustration.
2. After aligning the mating marks of the companion flange and center propeller shaft, install them.
3. Tightening the self locking nut, press fit the center bearing assembly using companion flange.
