Contents Section: Cruise Control Systems All sections

Cruise Control - Except Lancer Evolution Mitsubishi Lancer Evolution X

Cruise Control Systems 33 illustrations ~15833 words

GENERAL INFORMATION

By using the cruise control system, the driver can drive at preferred speeds in a range of approximately 40 to 200 km/h (25 to 125 mph) without depressing the accelerator pedal. For this cruise control system, in conjunction with the electronic throttle valve control system, the engine control module (ECM) electronically controls the throttle valve.

Scheme 1

Scheme 1: < 2.0L ENGINE Non-turbo, 2.4L ENGINE >
Scheme 1: < 2.0L ENGINE Non-turbo, 2.4L ENGINE >

Scheme 2

Scheme 2: < 2.0L ENGINE Turbo >
Scheme 2: < 2.0L ENGINE Turbo >

INTRODUCTION TO CRUISE CONTROL SYSTEM DIAGNOSIS

The cruise control system allows driving without stepping on the accelerator pedal by setting a random speed between approximately 40 km/h (25 mph) and 200 km/h (125 mph). Malfunctions in this system can be investigated by the following methods.

Cruise control system diagnostic trouble codes

The cruise control system consists of the engine control module (ECM), control switches and sensors. The control switches and sensors monitor the state of the vehicle. The ECM controls the throttle valve opening angle in the throttle body in accordance with the input signals from the control switches and sensors. If the ECM detects a malfunction on any of those components, the ECM estimates where the problem may be occurring, and will set a diagnostic trouble code (DTC). DTCs cover the cruise control switch, stoplight switch and ECM.

DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will check most of the possible causes of an cruise control system malfunction.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Check the vehicle for any cruise control system DTC (Refer to «HOW TO READ DIAGNOSTIC TROUBLE CODES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .)
  4. If you can verify the condition but no cruise control system DTCs are set, the malfunction may be intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  5. If you can verify the condition but there are no cruise control system DTCs, find the fault (Refer to «SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__symptom-chart) .)
  6. If there is an cruise control system DTC, record the number of the code, then erase the code (Refer to «HOW TO ERASE DIAGNOSTIC TROUBLE CODES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__how-to-erase-diagnostic-trouble-codes) .)
  7. Re-create the cruise control system DTC set conditions to see if the same cruise control system DTC will set again (Refer to «HOW TO READ DIAGNOSTIC TROUBLE CODES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) If the same cruise control system DTC sets again, perform the diagnostic procedures for the set code (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-trouble-code-dtc-chart) .)

Scheme 3

Scheme 3: HOW TO READ DIAGNOSTIC TROUBLE CODES
Scheme 3: HOW TO READ DIAGNOSTIC TROUBLE CODES

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Turn the ignition switch to the "ON" position while press the "COAST/SET" switch. Then, within one second, release the "COAST/SET" switch and press the "ACC/RES" switch.
  2. Read a DTC by observing the flash display pattern of the "CRUISE" indicator light in the combination meter.

Diagnostic result display method when using the "CRUISE" indicator light

DTC REFERENCE CHART When the DTC 23 is set When no DTC is set

Scheme 8

Scheme 8
Scheme 8

Note. Other on-board diagnostic items are also output as voltage waveforms corresponding to diagnostic trouble code numbers.

HOW TO ERASE DIAGNOSTIC TROUBLE CODES

Disconnect the negative (-) battery cable.

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III.)

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 9

Scheme 9
Scheme 9
  1. Start up the personal computer.
  2. Connect special tool MB991827 to special tool MB991824 and the personal computer.
  3. Connect special tool MB991910 to special tool MB991824.
  4. Connect special tool MB991910 to the data link connector.
  5. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in green color.
  6. Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ DATA LIST

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "System Select" from the start-up screen.
  4. Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
  5. "Select "AUTO CRUISE" from "System List", and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
  6. Select the "MITSUBISHI."
  7. Select the "Data List." NOTE: When the "Data List Reference Table" button is selected, the service data reference table is displayed, and the normal values can be checked.

HOW TO DIAGNOSE THE CAN BUS LINE

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select the "CAN Bus Diagnosis" from the start-up screen.
  4. When the vehicle information is displayed, confirm that it matches the vehicle whose CAN bus lines will be diagnosed. If they match, go to Step 8 . If not, go to Step 5.
  5. Select the "view vehicle information" button.
  6. Enter the vehicle information and select the "OK" button.
  7. When the vehicle information is displayed, confirm again that it matches the vehicle which whose CAN bus lines will be diagnosed. If they match, go to Step 8. If not, go to Step 5 .
  8. Press the "OK" button.
  9. When the optional equipment screen is displayed, choose the one which the vehicle is fitted with, and then select the "OK" button.

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Check according to the inspection chart that is appropriate for the DTC.

DTC numberInspection Item
15Cruise control switch system
22Stoplight switch system
23ECM and its related components

DIAGNOSTIC TROUBLE CODE (DTC) CHART

Scheme 10

Scheme 10: DTC 15: Cruise Control Switch System
Scheme 10: DTC 15: Cruise Control Switch System

CIRCUIT OPERATION

This circuit judges the signals of each switch ("ON/OFF", "CANCEL", "COAST/SET" and "ACC/RES") of the cruise control switch. The ECM detects the state of the cruise control switch by sensing the voltages shown below.

  1. When all switches are released: 4.7 - 5.0 volts
  2. When the "ON/OFF" switch is pressed: 0 - 0.5 volt
  3. When the "CANCEL" switch is pressed: 1.0 - 1.8 volts
  4. When the "COAST/SET" switch is pressed: 2.3 - 3.0 volts
  5. When the "ACC/RES" switch is pressed: 3.5 - 4.2 volts

Check Condition

  1. The "CRUISE" indicator light illuminates.

Judgment Criteria

  1. This DTC is set when the ECM terminal voltage is different from the standard value.
  2. Or, this DTC is set when the "COAST/SET" switch or "ACC/RES" switch is stuck to ON.

TROUBLESHOOTING HINTS (THE MOST LIKELY CAUSES FOR THIS CASE:)

  1. Damaged harness or connector.
  2. Malfunction of the cruise control switch.
  3. Malfunction of the clock spring.
  4. Malfunction of the ECM.

DIAGNOSIS PROCEDURE

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  2. MB991223: Harness Set
  3. MB992006: Extra Fine Probe
  4. MB992110: Power Plant ECU Check Harness

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. STEP 1. Using scan tool MB991958, check the data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 25 . NO: Go to Step 2.
  2. STEP 2. Measure the power supply voltage at cruise control switch connector C-203 by backprobing. Remove the cruise control switch from the steering wheel with the cruise control switch connector connected (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ). Connect the negative (-) battery cable that was disconnected when the driver's air bag module was removed. Do not disconnect cruise control switch connector C-203. Turn the ignition switch to the "ON" position. Do not operate the cruise control switch. Measure the power supply voltage between cruise control switch connector C-203 terminal number 3 and body ground by backprobing. Q: Is the measured voltage between 4.7 and 5.0 volts? YES: Go to Step 14 . NO: Go to Step 3.
  3. STEP 3. Measure the power supply voltage at ECM connector B-109. Disconnect the ECM connectors [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > Connect special tool MB992110 between the ECM and the body-side harness connector. Turn the ignition switch to the "ON" position. Do not operate the cruise control switch. Measure the power supply voltage between special tool 48-pin connector terminal number 107 (ECM connector B-109 terminal number 107) and body ground. Q: Is the measured voltage between 4.7 and 5.0 volts? YES: Go to Step 10 . NO: Go to Step 4.
  4. STEP 4. Check ECM connector B-109 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 5. NO: Repair or replace the damaged connector. Then go to Step 26 .
  5. STEP 5. Check the harness wire for short circuit to body ground between the ECM connector B-109 terminal number 107 and the cruise control switch connector C-203 terminal number 3. Disconnect ECM connector B-109 and measure at the harness connector side [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > Turn the ignition switch to the "LOCK" (OFF) position. Measure the continuity between ECM connector B-109 terminal number 107 and body ground. Q: Is the measured continuity open circuit? YES: Go to Step 24 . NO: Go to Step 6.
  6. STEP 6. Check intermediate connector C-127, cruise control switch connector C-203, and clock spring connectors C-204 and C-205, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 7. NO: Repair or replace the damaged connector. Then go to Step 26 .
  7. STEP 7. Check the harness wire between ECM connector B-109 terminal number 107 and clock spring connector C-205 terminal number 5, and between clock spring connector C-204 terminal number 2 and cruise control switch connector C-203 terminal number 3, for damage. Check harness wire for short circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 8. NO: Repair or replace the damaged harness wire. Then go to Step 26 .
  8. STEP 8. Check the clock spring. Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Non-turbo and 2.4L ENGINE. > Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Turbo. > Q: Is the clock spring in good condition? YES: Go to Step 9. NO: Replace the clock spring (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo and 2.4L ENGINE > or (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Turbo. > Then go to Step 26 .
  9. STEP 9. Check the cruise control switch. Refer to «CRUISE CONTROL SYSTEM COMPONENT CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) . Q: Is the cruise control switch in good condition? YES: Go to Step 13 . NO: Replace the cruise control switch (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ). Then go to Step 26 .
  10. STEP 10. Check ECM connector B-109, intermediate connector C-127, cruise control switch connector C-203, and clock spring connectors C-204 and C-205, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connectors and terminal in good condition? YES: Go to Step 11. NO: Repair or replace the damaged connector. Then go to Step 26 .
  11. STEP 11. Check the harness wire between ECM connector B-109 terminal number 107 and clock spring connector C-205 terminal number 5, and between clock spring connector C-204 terminal number 2 and cruise control switch connector C-203 terminal number 3, for damage. Check harness wire for open circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 12. NO: Repair or replace the damaged harness wire. Then go to Step 26 .
  12. STEP 12. Check the clock spring. Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Non-turbo and 2.4L ENGINE. > Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Turbo. > Q: Is the clock spring in good condition? YES: Go to Step 13. NO: Replace the clock spring (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo and 2.4L ENGINE > or (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Turbo. > Then go to Step 26 .
  13. STEP 13. Using scan tool MB991958, check the data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 25 . NO: Go to Step 14.
  14. STEP 14. Measure the ground voltage at cruise control switch connector C-203 by backprobing. Remove the cruise control switch from the steering wheel with the cruise control switch connector connected (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ). Connect the negative (-) battery cable that was disconnected when the driver's air bag module was removed. Do not disconnect cruise control switch connector C-203. Turn the ignition switch to the "ON" position. Press and hold the "ON/OFF" switch, and measure the ground voltage between cruise control switch connector C-203 terminal number 2 and body ground by backprobing. Q: Is the measured voltage 0.5 volt or less? YES: Go to Step 20 . NO: Go to Step 15.
  15. STEP 15. Measure the ground voltage at ECM connector B-109. Disconnect the ECM connectors [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > Connect special tool MB992110 between the ECM and the body-side harness connector. Turn the ignition switch to the "ON" position. Press and hold the "ON/OFF" switch, and measure the ground voltage between special tool 48-pin connector terminal number 95 (ECM connector B-109 terminal number 95) and body ground. Q: Is the measured voltage 0.5 volt or less? YES: Go to Step 17 . NO: Go to Step 16.
  16. STEP 16. Check ECM connector B-109 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 24 . NO: Repair or replace the damaged connector. Then go to Step 26 .
  17. STEP 17. Check intermediate connector C-127, cruise control switch connector C-203, and clock spring connectors C-204 and C-205, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connectors and terminal in good condition? YES: Go to Step 18. NO: Repair or replace the damaged connector. Then go to Step 26 .
  18. STEP 18. Check the harness wire between ECM connector B-109 terminal number 95 and clock spring connector C-205 terminal number 4, and between clock spring connector C-204 terminal number 3 and cruise control switch connector C-203 terminal number 2, for damage. Check harness wire for open circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 19. NO: Repair or replace the damaged harness wire. Then go to Step 26 .
  19. STEP 19. Check the clock spring. Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Non-turbo and 2.4L ENGINE. > Refer to «INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Turbo. > Q: Is the clock spring in good condition? YES: Go to Step 24 . NO: Replace the clock spring (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo and 2.4L ENGINE > or (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Turbo. > Then go to Step 26 .
  20. STEP 20. Check ECM connector B-109, intermediate connector C-127, cruise control switch connector C-203, and clock spring connectors C-204 and C-205, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connectors and terminal in good condition? YES: Go to Step 21. NO: Repair or replace the damaged connector. Then go to Step 26 .
  21. STEP 21. Check the harness wire between ECM connector B-109 terminal number 95 and clock spring connector C-205 terminal number 4, and between clock spring connector C-204 terminal number 3 and cruise control switch connector C-203 terminal number 2, for damage. Check harness wire for short circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 22. NO: Repair or replace the damaged harness wire. Then go to Step 26 .
  22. STEP 22. Check the clock spring. Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Non-turbo and 2.4L ENGINE. > Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) < 2.0L ENGINE Turbo. > Q: Is the clock spring in good condition? YES: Go to Step 23. NO: Replace the clock spring (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo and 2.4L ENGINE > or (Refer to «DRIVER'S AIR BAG MODULES AND CLOCK SPRING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ) < 2.0L ENGINE Turbo. > Then go to Step 26 .
  23. STEP 23. Check the cruise control switch. Refer to «CRUISE CONTROL SYSTEM COMPONENT CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) . Q: Is the cruise control switch in good condition? YES: Go to Step 24. NO: Replace the cruise control switch (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ). Then go to Step 26 .
  24. STEP 24. Using scan tool MB991958, check the data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 25. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 26 .
  25. STEP 25. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches, read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 15 set? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 26. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  26. STEP 26. Using scan tool MB991958, check data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 27. NO: Return to Step 2 .
  27. STEP 27. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches, read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 15 set? YES: Return to Step 1 . NO: The procedure is complete.

Scheme 14

Scheme 14: DTC 22: Stoplight Switch System
Scheme 14: DTC 22: Stoplight Switch System

Scheme 15

Scheme 15
Scheme 15
  1. For the stoplight switch, two switches, a stoplight switch for the stoplight illumination and a brake switch exclusively for the cruise control system, are incorporated to improve the reliability.
  2. As for the stoplight switch, when the brake pedal is depressed/released, the stoplight switch ON/OFF signal is transmitted from the ETACS-ECU to the ECM via CAN bus line.
  3. As for the brake switch, the ECM connector B-109 terminal number 108 monitor the state of the brake switch. The brake switch turn ON/OFF when the brake pedal is depressed/released, and the input signal to the ECM connector B-109 terminal number 108 changes. According to this change, the ECM judges the state of the brake switch.
  1. The "CRUISE" indicator light illuminates.
  1. Open/short in stoplight switch circuit.
  2. Open circuit in the brake switch circuit (between ECM connector B-109 terminal number 108 and body ground).
  3. Malfunction of CAN bus line.
  1. Malfunction of CAN bus system.
  2. Damaged harness or connector.
  3. Malfunction of the stoplight switch.
  4. Malfunction of the ETACS-ECU
  5. Malfunction of the ECM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  2. MB991223: Harness Set
  3. MB992006: Extra Fine Probe CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 16 .
  2. STEP 2. Using scan tool MB991958, check data list item 74: Brake light switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 10 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check ETACS system data list item 290: Brake light switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for ETACS system (Refer to «DATA LIST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__data-list-reference-table) .) Item 290: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 16 . NO: Go to Step 4.
  4. STEP 4. Check stoplight switch connector C-32, and ETACS-ECU connector C-304 and C-312, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 5. NO: Repair or replace the damaged connector. Then go to Step 16 .
  5. STEP 5. Check the harness wire between ETACS-ECU connector C-304 terminal number 1 and stoplight switch connector C-32 terminal number 2, and between stoplight switch connector C-32 terminal number 1 and ETACS-ECU connector C-312 terminal number 16, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 6. NO: Repair or replace the damaged harness wire. Then go to Step 16 .
  6. STEP 6. Check fuse number 2 at the ETACS-ECU. Q: Is the fuse in good condition? YES: Go to Step 7. NO: Check the stoplight system harness and replace the fuse. Then go to Step 16 .
  7. STEP 7. Check the stoplight switch. Refer to «STOPLIGHT SWITCH CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) . Q: Is the stoplight switch operating properly? YES: Go to Step 8. NO: Replace the stoplight switch (Refer to «BRAKE PEDAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) .) Then go to Step 16 .
  8. STEP 8. Using scan tool MB991958, check ETACS system data list item 290: Brake light switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for ETACS system (Refer to «DATA LIST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__data-list-reference-table) .) Item 290: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 9. NO: Replace the ETACS-ECU (Refer to «ETACS-ECU»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Then go to Step 16 .
  9. STEP 9. Using scan tool MB991958, check data list item 74: Brake light switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 10. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 16 .
  10. STEP 10. Using scan tool MB991958, check data list item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 15 . NO: Go to Step 11.
  11. STEP 11. Check ECM connector B-109 and stoplight switch connector C-32, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 12. NO: Repair or replace the damaged connector. Then go to Step 16 .
  12. STEP 12. Check the harness wire between ECM connector B-109 terminal number 108 and stoplight switch connector C-32 terminal number 3, and between stoplight switch connector C-32 terminal number 4 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wire in good condition? YES: Go to Step 13. NO: Repair or replace the damaged harness wire. Then go to Step 16 .
  13. STEP 13. Check the stoplight switch. Refer to «STOPLIGHT SWITCH CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) . Q: Is the stoplight switch operating properly? YES: Go to Step 14. NO: Replace the stoplight switch (Refer to «BRAKE PEDAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) .) Then go to Step 16 .
  14. STEP 14. Using scan tool MB991958, check data list item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 15. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 16 .
  15. STEP 15. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery cable. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) With the cruise control switches not operated, depress the brake pedal for several seconds, and then read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 22 set? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 16. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  16. STEP 16. Using scan tool MB991958, check data list item 74: Brake light switch and item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 17 NO: Return to Step 2 .
  17. STEP 17. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery cable. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) With the cruise control switches not operated, depress the brake pedal for several seconds, and then read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 22 set? YES: Return to Step 1 . NO: The procedure is complete.

DTC SET CONDITIONS

This DTC is set when there is an failure in the ECM and its related components.

  1. Malfunction of the MFI system.
  2. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, check for MFI system DTC. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo >, (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ) < 2.0L ENGINE Turbo >, or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo >, (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ) < 2.0L ENGINE Turbo >, or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 3 . NO: Go to Step 2.
  2. STEP 2. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches, read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 23 set? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 3. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  3. STEP 3. Read the cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches, read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC 23 set? YES: Return to Step 1 . NO: The procedure is complete.

SYMPTOM CHART

SymptomInspection procedure numberReference
Communication with scan tool is not possible.Communication with the ECM only is impossible. < 2.0L ENGINE Non-turbo >Refer to INSPECTION PROCEDURE 1: COMMUNICATION WITH ECM IS NOT POSSIBLE .
Communication with the ECM only is impossible. < 2.0L ENGINE Turbo >Refer to INSPECTION PROCEDURE 1: COMMUNICATION WITH ECM IS NOT POSSIBLE
Communication with the ECM only is impossible. < 2.4L ENGINE >Refer to INSPECTION PROCEDURE 1: COMMUNICATION WITH ECM IS NOT POSSIBLE
When the brake pedal is depressed, cruise control is not cancelled.1INSPECTION PROCEDURE 1: WHEN THE BRAKE PEDAL IS DEPRESSED, CRUISE CONTROL IS NOT CANCELLED.
When the clutch pedal is depressed, cruise control is not cancelled < M/T. >2INSPECTION PROCEDURE 2: WHEN THE CLUTCH PEDAL IS DEPRESSED, CRUISE CONTROL IS NOT CANCELLED < M/T. >
When the selector lever is moved to "N" position, cruise control is not cancelled < CVT. >3INSPECTION PROCEDURE 3: WHEN THE SELECTOR LEVER IS MOVED TO "N" POSITION, CRUISE CONTROL IS NOT CANCELLED < CVT. >
When the shift lever is moved to "N" position, cruise control is not cancelled < TC-SST. >4INSPECTION PROCEDURE 4: WHEN THE SHIFT LEVER IS MOVED TO "N" POSITION, CRUISE CONTROL IS NOT CANCELLED < TC-SST. >
When the "CANCEL" switch is pressed, cruise control is not cancelled.5INSPECTION PROCEDURE 5: WHEN THE "CANCEL" SWITCH IS PRESSED, CRUISE CONTROL IS NOT CANCELLED.
Cruise control cannot be set (No response "COAST/SET" switch and "ACC/RES" switch is pressed) < 2.0L ENGINE Non-turbo, 2.4L ENGINE. >6INSPECTION PROCEDURE 6: CRUISE CONTROL CANNOT BE SET (NO RESPONSE "COAST/SET" SWITCH AND "ACC/RES" SWITCH IS PRESSED) < 2.0L ENGINE NON-TURBO, 2.4L ENGINE. >
Cruise control cannot be set (No response "COAST/SET" switch and "ACC/RES" switch is pressed) < 2.0L ENGINE Turbo. >7INSPECTION PROCEDURE 7: CRUISE CONTROL CANNOT BE SET (NO RESPONSE "COAST/SET" SWITCH AND "ACC/RES" SWITCH IS PRESSED) < 2.0L ENGINE TURBO. >
Hunting (repeated acceleration and deceleration) occurs at the set vehicle speed < M/T. >8INSPECTION PROCEDURE 8: HUNTING (REPEATED ACCELERATION AND DECELERATION) OCCURS AT THE SET VEHICLE SPEED < M/T. >
Hunting (repeated acceleration and deceleration) occurs at the set vehicle speed < CVT. >9INSPECTION PROCEDURE 9: HUNTING (REPEATED ACCELERATION AND DECELERATION) OCCURS AT THE SET VEHICLE SPEED < CVT. >
Hunting (repeated acceleration and deceleration) occurs at the set vehicle speed < TC-SST. >10INSPECTION PROCEDURE 10: HUNTING (REPEATED ACCELERATION AND DECELERATION) OCCURS AT THE SET VEHICLE SPEED < TC-SST. >
When the "ON/OFF" switch is turned ON, "CRUISE" indicator light does not illuminate (However, cruise control system is normal.)11INSPECTION PROCEDURE 11: WHEN THE "ON/OFF" SWITCH IS TURNED ON, "CRUISE" INDICATOR LIGHT DOES NOT ILLUMINATE (HOWEVER, CRUISE CONTROL SYSTEM IS NORMAL.)

SYMPTOM CHART

COMMENT

  1. Malfunction of CAN bus line.
  2. The stoplight switch circuit is suspected.
  1. Malfunction of CAN bus system.
  2. Damaged harness or connector.
  3. Malfunction of the stoplight switch.
  4. Malfunction of the ETACS-ECU.
  5. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to CAN BUS LINE DIAGNOSTIC FLOW .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 4 .
  2. STEP 2. Using scan tool MB991958, check data list item 74: Brake light switch and item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 3 NO: Repair the stoplight switch system (Refer to «DTC 22: STOPLIGHT SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 4 .
  3. STEP 3. Check the symptoms. Q: When the brake pedal is depressed, is the cruise control cancelled? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo >, or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 4.
  4. STEP 4. Check the symptoms. Q: When the brake pedal is depressed, is the cruise control cancelled? YES: The procedure is complete. NO: Return to Step 1 .

Scheme 16

Scheme 16: Inspection Procedure 2: When the Clutch Pedal is Depressed, Cruise Control is not Cancelled < M/T. >
Scheme 16: Inspection Procedure 2: When the Clutch Pedal is Depressed, Cruise Control is not Cancelled < M/T. >
  1. Terminal number 85 of the ECM connector B-109 monitors the clutch switch state.
  2. The clutch switch turns ON/OFF when the clutch pedal is depressed/released, and the input signal to the ECM changes. According to this change, the ECM judges the clutch switch status.

The cause is probably a malfunction of the clutch switch circuit.

  1. Damaged harness or connector.
  2. Malfunction of the clutch switch.
  3. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  2. MB991223: Harness Set
  3. MB992006: Extra Fine Probe
  1. STEP 1. Using scan tool MB991958, check data list item 78: Clutch switch. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 78: Clutch switch. When the clutch pedal is depressed, the display on scan tool MB991958 should be "ON." When the clutch pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 6 . NO: Go to Step 2.
  2. STEP 2. Check ECM connector B-109 and clutch switch connector C-42, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 3. NO: Repair or replace the damaged connector. Then go to Step 7 .
  3. STEP 3. Check the harness wire between ECM connector B-109 terminal number 85 and clutch switch connector C-42 terminal number 2, and between clutch switch connector C-42 terminal number 1 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 4. NO: Repair or replace the damaged harness wire. Then go to Step 7 .
  4. STEP 4. Check the clutch switch. Refer to «CLUTCH SWITCH CHECK < VEHICLES WITH CRUISE CONTROL >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/clutches-manual-hydraulic/#clutch-on-vehicle-service-except-lancer-evolution__clutch-switch-check-vehicles-with) . Q: Is the clutch switch operating properly? YES: Go to Step 5. NO: Replace the clutch switch (Refer to «CLUTCH PEDAL AND MASTER CYLINDER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/clutches-manual-hydraulic/#clutch-on-vehicle-service-except-lancer-evolution) .) Then go to Step 7 .
  5. STEP 5. Using scan tool MB991958, check data list item 78: Clutch switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 78: Clutch switch. When the clutch pedal is depressed, the display on scan tool MB991958 should be "ON." When the clutch pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 6. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 7 .
  6. STEP 6. Check the symptoms. Q: When the clutch pedal is depressed, is the cruise control cancelled? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 7.
  7. STEP 7. Check the symptoms. Q: When the clutch pedal is depressed, is the cruise control cancelled? YES: The procedure is complete. NO: Return to Step 1 .

When the selector lever is operated, the selector lever position signal from the transmission range switch is sent to the TCM. ECM receives the selector lever position signal from the TCM via the CAN bus line.

  1. Malfunction of CAN bus line.
  2. Malfunction of CVT system.
  1. Malfunction of CAN bus system.
  2. Damaged harness or connector.
  3. Malfunction of CVT system.
  4. Malfunction of the transmission range switch.
  5. Malfunction of the TCM.
  6. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 6 .
  2. STEP 2. Using scan tool MB991958, check the CVT system data list item 49: Transmission range switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for CVT system (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-function) .) Item 49: Transmission range switch. Q: Is the switch operating properly? YES: Go to Step 3. NO: Repair the CVT system (Refer to «DTC P0705: MALFUNCTION OF TRANSMISSION RANGE SWITCH»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution) .) Then go to Step 6 .
  3. STEP 3. Using scan tool MB991958, read the CVT system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for CVT system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-function) .) Q: Is any DTC set? YES: Repair the CVT system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 6 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list item 88: Neutral switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 88: Neutral switch. When selector lever is at the "P" and "N" position, the display on scan tool MB991958 should be "ON." When selector lever is other than "P" and "N" position, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 5. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6 .
  5. STEP 5. Check the symptoms. Q: When the selector lever is moved to "N" position, is the cruise control cancelled? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6.
  6. STEP 6. Check the symptoms. Q: When the selector lever is moved to "N" position, is the cruise control cancelled? YES: The procedure is complete. NO: Return to Step 1 .

When the shift lever is in the "N" position, the "N" position signal is transmitted from the shift lever ECU to the ECM via CAN bus line.

  1. Malfunction of CAN bus line.
  2. Malfunction of shift lever system.
  1. Malfunction of CAN bus system.
  2. Damaged harness or connector.
  3. Malfunction of the shift lever system.
  4. Malfunction of the shift lever ECU.
  5. Malfunction of the TC-SST-ECU.
  6. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 7 .
  2. STEP 2. Using scan tool MB991958, check the shift lever system data list item 01: Shift lever position. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for shift lever system (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Item 01: Shift lever position. Q: Is the switch operating properly? YES: Go to Step 3. NO: Repair the shift lever system (Refer to «DTC P198E, 198F: LEVER POSITION SENSOR SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Then go to Step 7 .
  3. STEP 3. Using scan tool MB991958, read the shift lever system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for shift lever system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the shift lever system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Then go to Step 7 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, read the TC-SST system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for shift lever system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the TC-SST system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Then go to Step 7 . NO: Go to Step 5.
  5. STEP 5. Using scan tool MB991958, check data list item 88: Neutral switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 88: Neutral switch. When shift lever is at the "N" or "P" position, the display on scan tool MB991958 should be "ON." When shift lever is other than "N" or "P" position, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 6. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 7 .
  6. STEP 6. Check the symptoms. Q: When the shift lever is moved to "N" position, is the cruise control cancelled? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 7.
  7. STEP 7. Check the symptoms. Q: When the shift lever is moved to "N" position, is the cruise control cancelled? YES: The procedure is complete. NO: Return to Step 1 .

The cause is probably an open-circuit in the output circuit inside the "CANCEL" switch.

  1. Malfunction of the cruise control switch.
  2. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Scheme 17

Scheme 17
Scheme 17
  1. STEP 1. Using scan tool MB991958, check the data list item 75: Cancel switch. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 2. NO: Repair the cruise control switch system (Refer to «DTC 15: CRUISE CONTROL SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 3 .
  2. STEP 2. Check the symptoms. Q: When the "CANCEL" switch is pressed, is the cruise control cancelled? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 3.
  3. STEP 3. Check the symptoms. Q: When the "CANCEL" switch is pressed, is the cruise control cancelled? YES: The procedure is complete. NO: Return to Step 1 .
  1. The fail-safe function is probably canceling cruise control system. In this case, checking the cruise control system, MFI system, CVT system < CVT > and CAN bus line system DTCs. The scan tool MB991958 can also be used to check if the circuits of each input switch are normal or not by checking the data list.
  2. In addition, if the option coding data written into the ECM is not normal, the cruise control system does not work. NOTE: Press the cruise control switches one by one securely. Otherwise, the cruise control system may not be started.
  1. Malfunction of the CAN bus line system.
  2. ECM option coding data error
  3. Malfunction of the MFI system.
  4. Malfunction of the CVT system < CVT. >
  5. Malfunction of the cruise control switch.
  6. Malfunction of the stoplight switch.
  7. Malfunction of the clutch switch < M/T. >
  8. Malfunction of the transmission. range switch < CVT. >
  9. Malfunction of the TCM < CVT. >
  10. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 11 .
  2. STEP 2. Using scan tool MB991958, check for ECM option coding data. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for ECM option coding data (Refer to «CODING LIST»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__coding-list) .) Q: Is the cruise control item of the ECM option coding data enabled? YES: Go to Step 3. NO: Set the ECM option coding data again. (Refer to «CODING LIST»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__coding-list) .) Then go to Step 11 .
  3. STEP 3. Using scan tool MB991958, check for MFI system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) ). Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 11 . NO: Go to Step 5 < M/T. > NO: Go to Step 4 < CVT. >
  4. STEP 4. Using scan tool MB991958, check for CVT system DTC < CVT. > Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for CVT system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-function) .) Q: Is any DTC set? YES: Repair the CVT system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 11 . NO: Go to Step 5.
  5. STEP 5. Check for cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches. With the cruise control switches not operated, depress the brake pedal for several seconds, and then read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC set? YES: Repair the cruise control system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-trouble-code-dtc-chart) .) Then go to Step 11 . NO: Go to Step 6.
  6. STEP 6. Using scan tool MB991958, check data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 7. NO: Repair the cruise control switch system (Refer to «DTC 15: CRUISE CONTROL SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  7. STEP 7. Using scan tool MB991958, check data list item 74: Brake light switch and item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 8 < M/T. > YES: Go to Step 9 < CVT. > NO: Repair the stoplight switch system (Refer to «DTC 22: STOPLIGHT SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  8. STEP 8. Using scan tool MB991958, check data list item 78: Clutch switch < M/T. > Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 78: Clutch switch. When the clutch pedal is depressed, the display on scan tool MB991958 should be "ON." When the clutch pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 10 . NO: Repair the clutch switch system (Refer to «INSPECTION PROCEDURE 2: When the Clutch Pedal is Depressed, Cruise Control is not Cancelled < M/T. >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  9. STEP 9. Using scan tool MB991958, check data list item 88: Neutral switch < CVT. > Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 88: Neutral switch. When selector lever is at the "P" and "N" position, the display on scan tool MB991958 should be "ON." When selector lever is other than "P" and "N" position, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 10. NO: Repair the transmission range switch system (Refer to «INSPECTION PROCEDURE 3: When the Selector Lever is Moved to "N" Position, Cruise Control is not Cancelled < CVT. >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  10. STEP 10. Check the symptoms. Q: Can cruise control be set? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 11.
  11. STEP 11. Check the symptoms. Q: Can cruise control be set? YES: The procedure is complete. NO: Return to Step 1 .
  1. The fail-safe function is probably canceling cruise control system. In this case, checking the cruise control system, MFI system, TC-SST system, shift lever system and CAN bus line system DTCs. The scan tool MB991958 can also be used to check if the circuits of each input switch are normal or not by checking the data list.
  2. In addition, if the option coding data written into the ECM is not normal, the cruise control system does not work. NOTE: Press the cruise control switches one by one securely. Otherwise, the cruise control system may not be started.
  1. Malfunction of the CAN bus line system.
  2. ECM option coding data error
  3. Malfunction of the MFI system.
  4. Malfunction of the TC-SST system.
  5. Malfunction of the shift lever system.
  6. Malfunction of the cruise control switch.
  7. Malfunction of the stoplight switch.
  8. Malfunction of the TC-SST-ECU.
  9. Malfunction of the shift lever ECU.
  10. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to CAN BUS LINE DIAGNOSTIC FLOW .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 11 .
  2. STEP 2. Using scan tool MB991958, check for ECM option coding data. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for ECM option coding data (Refer to «CODING LIST»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__coding-list) .) Q: Is the cruise control item of the ECM option coding data enabled? YES: Go to Step 3. NO: Set the ECM option coding data again. (Refer to «CODING LIST»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__coding-list) .) Then go to Step 11 .
  3. STEP 3. Using scan tool MB991958, check for MFI system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Then go to Step 11 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check for TC-SST system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for TC-SST system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the TC-SST system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Then go to Step 11 . NO: Go to Step 5.
  5. STEP 5. Using scan tool MB991958, check for shift lever system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for shift lever system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the shift lever system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) .) Then go to Step 11 . NO: Go to Step 6.
  6. STEP 6. Check for cruise control system DTC. Disconnect the negative (-) battery terminal, to erase the DTC of the cruise control system. Connect the negative (-) battery terminal. Turn the ignition switch to the "ON" position, and press the "ON/OFF" switch to turn the cruise control system to ON (turn on the "CRUISE" indicator light.) After turning the cruise control system to ON, when 2 minutes or more has elapsed without operating the cruise control switches. With the cruise control switches not operated, depress the brake pedal for several seconds, and then read the DTC of the cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is DTC set? YES: Repair the cruise control system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-trouble-code-dtc-chart) .) Then go to Step 11 . NO: Go to Step 7.
  7. STEP 7. Using scan tool MB991958, check data list item 75: Cancel switch, item 86: Main switch, item 91: Resume switch and item 92: Set switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 75: Cancel switch. When "CANCEL" switch is pressed, the display on scan tool MB991958 should be "ON." When "CANCEL" switch is released, the display on scan tool MB991958 should be "OFF." Item 86: Main switch. When the "ON/OFF" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ON/OFF" switch is pressed again, the display on scan tool MB991958 should be "OFF." Item 91: Resume switch. When the "ACC/RES" switch is pressed, the display on scan tool MB991958 should be "ON." When the "ACC/RES" switch is released, the display on scan tool MB991958 should be "OFF." Item 92: Set switch. When the "COAST/SET" switch is pressed, the display on scan tool MB991958 should be "ON." When the "COAST/SET" switch is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 8. NO: Repair the cruise control switch system (Refer to «DTC 15: CRUISE CONTROL SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  8. STEP 8. Using scan tool MB991958, check data list item 74: Brake light switch and item 89: Normally closed brake switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 74: Brake light switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Item 89: Normally closed brake switch. When the brake pedal is depressed, the display on scan tool MB991958 should be "ON." When the brake pedal is released, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 9. NO: Repair the stoplight switch system (Refer to «DTC 22: STOPLIGHT SWITCH SYSTEM»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) .) Then go to Step 11 .
  9. STEP 9. Using scan tool MB991958, check data list item 88: Neutral switch. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 88: Neutral switch. When shift lever is at the "N", "P", "R" position, the display on scan tool MB991958 should be "ON." When shift lever is other than "N", "P", "R" position, the display on scan tool MB991958 should be "OFF." Q: Is the switch operating properly? YES: Go to Step 10. NO: Repair the shift lever system (Refer to «INSPECTION PROCEDURE 4: When the Shift Lever is Moved to "N" Position, Cruise Control is not Cancelled < TC-SST. >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution) ). Then go to Step 11 .
  10. STEP 10. Check the symptoms. Q: Can cruise control be set? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 11.
  11. STEP 11. Check the symptoms. Q: Can cruise control be set? YES: The procedure is complete. NO: Return to Step 1 .

The vehicle speed sensor or the throttle body is suspected.

  1. Malfunction of the MFI system
  2. Malfunction of the vehicle speed sensor.
  3. Malfunction of the throttle body.
  4. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, check for MFI system DTC. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 4 . NO: Go to Step 2.
  2. STEP 2. Using scan tool MB991958, check data list item 04: Vehicle speed. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 04: Vehicle speed. Q: Is the check result satisfactory? YES: Go to Step 3. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 4 .
  3. STEP 3. Check the symptoms. Q: Does hunting occur? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 4. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  4. STEP 4. Check the symptoms. Q: Does hunting occur? YES: Return to Step 1 . NO: The procedure is complete.
  1. The secondary pulley speed sensor signal (vehicle speed signal) or the throttle body is suspected.
  2. The secondary pulley speed sensor signal (vehicle speed signal) is transmitted from the TCM to the ECM via CAN bus line. NOTE: When the vehicle is driven with the low-speed gear in the sport mode, hunting occurs easily, however, this is not a failure.
  1. Malfunction of the CAN bus line system.
  2. Malfunction of the CVT system.
  3. Malfunction of the MFI system.
  4. Malfunction of the secondary pulley speed sensor.
  5. Malfunction of the throttle body.
  6. Malfunction of the TCM.
  7. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 6 .
  2. STEP 2. Using scan tool MB991958, check for CVT system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for CVT system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-function) .) Q: Is any DTC set? YES: Repair the CVT system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 6 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check for MFI system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 6 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list item 04: Vehicle speed. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 04: Vehicle speed. Q: Is the check result satisfactory? YES: Go to Step 5. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6 .
  5. STEP 5. Check the symptoms. Q: Does hunting occur? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  6. STEP 6. Check the symptoms. Q: Does hunting occur? YES: Return to Step 1 . NO: The procedure is complete.
  1. The wheel speed sensor signal (vehicle speed signal) or the throttle body is suspected.
  2. The wheel speed sensor signal (vehicle speed signal) is transmitted from the ASC-ECU to the ECM via CAN bus line.
  1. Malfunction of the CAN bus line system.
  2. Malfunction of the ASC system
  3. Malfunction of the MFI system
  4. Malfunction of the throttle body.
  5. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 6 .
  2. STEP 2. Using scan tool MB991958, check for ASC system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for ASC system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the ASC system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 6 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check for MFI system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Then go to Step 6 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list item 04: Vehicle speed. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to data reading mode for cruise control system (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Item 04: Vehicle speed. Q: Is the check result satisfactory? YES: Go to Step 5. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6 .
  5. STEP 5. Check the symptoms. Q: Does hunting occur? YES: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6. NO: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .)
  6. STEP 6. Check the symptoms. Q: Does hunting occur? YES: Return to Step 1 . NO: The procedure is complete.
  1. The ECM detects "ON/OFF" switch ON signal to illuminate the "CRUISE" indicator light.
  2. The "CRUISE" indicator light illuminate signal is transmitted from the ECM to the combination meter via CAN bus line.
  1. The CAN bus line between the ECM and the ETACS-ECU and between the ETACS-ECU and the combination meter may be defective.
  2. The combination meter, ETACS-ECU or ECM may also be defective.
  1. Malfunction of CAN bus system.
  2. Damaged harness or connector.
  3. Malfunction of the combination meter.
  4. Malfunction of the ETACS-ECU.
  5. Malfunction of the ECM.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A CAUTION: If there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Diagnose the CAN bus line (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Q: Is the check result satisfactory? YES: Go to Step 2 NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 6 .
  2. STEP 2. Using scan tool MB991958, check for MFI system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo >, (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ) < 2.0L ENGINE Turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is DTC U0141 set? YES: Repair the MFI system (Refer to «DTC U0141: ETACS-ECU TIME-OUT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo >, (Refer to «DTC U0141: ETACS-ECU TIME-OUT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ) < 2.0L ENGINE Turbo > or (Refer to «DTC U0141: ETACS-ECU TIME-OUT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 6 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check for ETACS system DTC. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Check for ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Q: Is DTC U0155 set? YES: Repair the ETACS system (Refer to «DTC U0155: COMBINATION METER CAN TIME OUT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__dtc-u0155-combination-meter-can-timeout) .) Then go to Step 6 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check the combination meter system actuator test item 7: Cruise indicator 1. Connect scan tool MB991958 to the data link connector (Refer to «DIAGNOSTIC TROUBLESHOOTING STRATEGY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__diagnostic-troubleshooting-strategy) .) Turn the ignition switch to the "ON" position. Set scan tool MB991958 to check the actuator test for combination meter system item 7: indicator 1. Q: Is the check result satisfactory? YES: Go to Step 5. NO: Repair the combination meter system (Refer to «INSPECTION PROCEDURE 5: THE COMBINATION METER LIGHT DOES NOT ILLUMINATE NORMALLY OR THE MULTI INFORMATION DISPLAY IS NOT DISPLAYED NORMALLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#combination-meter-except-lancer-evolution__inspection-procedure-5-the-combination-meter) .) Then go to Step 6 .
  5. STEP 5. Check the symptoms. Q: When the "ON/OFF" switch is turned ON, is the "CRUISE" indicator light illuminated? YES: It can be assumed that this malfunction is intermittent (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 6.
  6. STEP 6. Check the symptoms. Q: When the "ON/OFF" switch is turned ON, is the "CRUISE" indicator light illuminated? YES: The procedure is complete. NO: Return to Step 1 .

DATA LIST REFERENCE TABLE

CAUTIONDriving tests always need two people: one driver and one observer. When shifting the selector lever to "D" range apply the brakes should be applied so that the vehicle does not move forward.
M.U.T.-III scan tool displayItem numberInspection itemInspection requirementNormal condition
Brake light switch74Stoplight switch (for stoplight circuit)Ignition switch: "ON"Brake pedal: DepressedON
Brake pedal: ReleasedOFF
Cancel code57Cancel codeIgnition switch: "ON"The cancel code, which set when the cruise control system was cancelled at the last time.
Cancel switch75Cruise control switch ("CANCEL" switch)Ignition switch: "ON""CANCEL" switch: PressedON
"CANCEL" switch: ReleasedOFF
Clutch switch78Clutch switch < M/T >Ignition switch: "ON"Clutch pedal: DepressedON
Clutch pedal: ReleasedOFF
Cruise switch81Cruise control system operationCruise control system: activeON
Cruise control system: InactiveOFF
Main switch86Cruise control switch ("ON/OFF" switch)Ignition switch: "ON""ON/OFF" switch: PressedON
"ON/OFF" switch: Pressed againOFF
Neutral switch88Transmission range switch < CVT > or Neutral switch < TC-SST >Ignition switch: "ON"Selector lever or shift lever: "N" or "P" positionON
Selector lever or shift lever: Other than "N" or "P" positionOFF
Normally closed brake switch89Stoplight switch (for Cruise control circuit)Ignition switch: "ON"Brake pedal: DepressedON
Brake pedal: ReleasedOFF
Resume switch91Cruise control switch ("ACC/RES" switch)Ignition switch: "ON""ACC/RES" switch: PressedON
"ACC/RES" switch: ReleasedOFF
Set switch92Cruise control switch ("COAST/SET" switch)Ignition switch: "ON""COAST/SET" switch: PressedON
"COAST/SET" switch: ReleasedOFF
Vehicle speed04Vehicle speed signalRoad test the vehicleThe speedometer and scan tool MB991958 display the same value.

DATA LIST REFERENCE

ECM TERMINAL VOLTAGE REFERENCE CHART FOR CRUISE CONTROL SYSTEM OPERATION

Required Special Tool

  1. MB992110: Power plant ECU check harness

Use special tool MB992110, check the ECM terminal voltage.

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the all ECM connectors, and connect special tool MB992110 in between [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo >, [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ] < 2.0L ENGINE Turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. >
  2. Measure the voltages between the check connector terminals of special tool MB992044 and ground terminals (ECM connector B-109 terminal number 81 or 93.)

Special tool - Power plant ECU check harness (MB992110) connector: Component side

Scheme 19

Scheme 19
Scheme 19
Terminal numberCheck itemCheck conditionNormal condition
85Clutch switch < M/T >Ignition switch: "ON"Depress the clutch pedal.1V or less
Release the clutch pedal.Battery positive voltage
107Cruise control switch power supplyIgnition switch: "ON"All switches: Released4.7 - 5.0 V
"ON/OFF" switch: Pressed0 - 0.5 V
"CANCEL" switch: Pressed1.0 - 1.8 V
"COAST/SET" switch: Pressed2.3 - 3.0 V
"ACC/RES" switch: Pressed3.5 - 4.2 V
108Stoplight switch (for Cruise control circuit)Ignition switch: "ON"Depress the brake pedal.Battery positive voltage
Release the brake pedal.1V or less
109Vehicle speed sensor < M/T >Ignition switch: "ON" Move the vehicle forward slowly0 - 1 <=> 4 - 5 V (changes repeatedly)

ECM CONNECTOR TERMINAL NUMBER REFERENCE CHART

SPECIAL TOOLS

SPECIAL TOOLS Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 Scan tool (M.U.T.-III sub assembly) Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: g: MB991826 M.U.T.-III trigger harness is not necessary when pushing V.C.I. ENTER key. CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B or C instead, the CAN communication does not function correctly. Checking data list MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adaptor Probe General service tools Checking the continuity and measuring the voltage at the harness connector MB992006 Extra fine probe General service tool Continuity check and voltage measurement at harness wire or connector for loose, corroded or damaged terminals, or terminals pushed back in the connector. MB992110 Power plant ECU check harness - Measuring the terminal voltage at the ECM

Scheme 20

Scheme 20: SPECIAL TOOLS
Scheme 20: SPECIAL TOOLS

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23: "ON/OFF" SWITCH CHECK
Scheme 23: "ON/OFF" SWITCH CHECK

Scheme 24

Scheme 24
Scheme 24
  1. Turn the ignition switch to the "ON" position.
  2. Check that the "CRUISE" indicator light within the combination meter illuminates when the "ON/OFF" switch is pressed (cruise control system: ON.)
  3. Press the "ON/OFF" switch again (cruise control system: OFF), and check that the "CRUISE" indicator light within the combination meter goes out.

Scheme 25

Scheme 25: CRUISE CONTROL SETTING
Scheme 25: CRUISE CONTROL SETTING

Scheme 26

Scheme 26
Scheme 26
  1. Start the engine.
  2. Press the "ON/OFF" switch (cruise control system: ON, "CRUISE" indicator light: illuminated.)
  3. Drive at the desired speed, above approximately 40 km/h (25 mph.)
  4. Press the "COAST/SET" switch.
  5. Check to be sure that when the "COAST/SET" switch is released the speed is the constant speed. NOTE: If the vehicle speed decreases to approximately 15 km/h (9 mph) below the set speed because of climbing a hill for example, it is normal for the cruise control to be cancelled. When the vehicle speed becomes low-speed limit [approximately 40 km/h (25 mph)] or less, driving at constant speed will be cancelled even if the vehicle speed does not decrease 15 km/h (9 mph) or more.

Scheme 27

Scheme 27: SPEED-INCREASE SETTING
Scheme 27: SPEED-INCREASE SETTING

Scheme 28

Scheme 28
Scheme 28
  1. Start the engine.
  2. Press the "ON/OFF" switch (cruise control system: ON, "CRUISE" indicator light: illuminated.)
  3. Set to the desired speed, above approximately 40 km/h (25 mph.)
  4. Press the "ACC/RES" switch.
  5. Check to be sure that acceleration continues while the "ACC/RES" switch is pressed, and that the speed at the time it was released becomes the constant driving speed. NOTE: Acceleration can be continued even if the vehicle speed has passed the high-speed limit [approximately 200 km/h (125 mph)]. But the constant driving speed when the "ACC/RES" switch is released will be recorded as the high-speed limit.

SPEED-REDUCTION SETTING

  1. Start the engine.
  2. Press the "ON/OFF" switch (cruise control system: ON, "CRUISE" indicator light: illuminated.)
  3. Set to the desired speed, above approximately 40 km/h (25 mph.)
  4. Press the "COAST/SET" switch.
  5. Check to be sure that deceleration continues while the "COAST/SET" switch is pressed, and that the speed at the time it was released becomes the constant driving speed. NOTE: When the vehicle speed reaches the low limit [approximately 40 km/h (25 mph)] during deceleration, the cruise control will be cancelled.

Scheme 29

Scheme 29: RETURN TO THE SET SPEED BEFORE CANCELLATION AND CRUISE CONTROL CANCELLATION
Scheme 29: RETURN TO THE SET SPEED BEFORE CANCELLATION AND CRUISE CONTROL CANCELLATION

Scheme 30

Scheme 30
Scheme 30
  1. Start the engine.
  2. Press the "ON/OFF" switch (cruise control system: ON, "CRUISE" indicator light: illuminated.)
  3. Set to the desired speed, above approximately 40 km/h (25 mph.)
  4. When any of the following operations are performed while at constant speed during cruise control, check if normal driving is resumed and deceleration occurs. The "CANCEL" switch is pressed. The brake pedal is depressed.
  5. At a vehicle speed of approximately 40 km/h (25 mph) or higher, check if when the "ACC/RES" switch is pressed, the vehicle speed returns to the speed before cruise control driving was cancelled, and constant speed driving occurs.
  6. When the "ON/OFF" switch is pressed again (cruise control system: OFF) while driving at constant speed, check if normal driving is resumed and deceleration occurs.

Scheme 31

Scheme 31: CRUISE CONTROL SWITCH CHECK
Scheme 31: CRUISE CONTROL SWITCH CHECK

Scheme 32

Scheme 32
Scheme 32
  1. Remove the cruise control switch (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cruise-control-systems/#cruise-control-except-lancer-evolution__removal-and-installation-20l-engine) ).
  2. Measure the resistance between terminal number 2 and terminal number 3 when each of the "ON/OFF", "CANCEL", "COAST/SET" and "ACC/RES" switches is pressed. If the values measured at the time each switch is pressed correspond to those in the table below, the resistance values are correct. CRUISE CONTROL SWITCH POSITION CHART Terminal connector of tester Switch position Specified condition 2 - 3 All switches are released. Open circuit "ON/OFF" switch is pressed Continuity (less than 2 ohms) "CANCEL" switch is pressed 202.5 - 208 ohms "COAST/SET" switch is pressed 610.5 - 624.5 ohms "ACC/RES" switch is pressed 1838 - 1877 ohms
  3. Check that the cruise control switch illuminates when a positive battery terminal is connected to the connector terminal number 4, and terminal number 1 is grounded.

STOPLIGHT SWITCH CHECK

CLUTCH SWITCH CHECK < M/T >

TRANSMISSION RANGE SWITCH ("N" POSITION) < CVT >

THROTTLE ACTUATOR CONTROL MOTOR

Refer to THROTTLE ACTUATOR CONTROL MOTOR CHECK < 2.0L ENGINE Non-turbo. > Refer to THROTTLE ACTUATOR CONTROL MOTOR CHECK < 2.0L ENGINE Turbo. > Refer to THROTTLE ACTUATOR CONTROL MOTOR CHECK < 2.4L ENGINE. >

REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

WARNINGBefore removing the driver's air bag module assembly, always refer to SERVICE PRECAUTIONS and DRIVER'S AIR BAG MODULE AND CLOCK SPRING .

Scheme 33

Scheme 33
Scheme 33

REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >

Since the cruise control switch is mounted on the spoke of the steering wheel garnish, refer to Steering Wheel for removal and installation (Refer to STEERING WHEEL .)

See also:
• HOW TO COPE WITH INTERMITTENT MALFUNCTIONS
• ENGINE CONTROL MODULE (ECM)
• ENGINE CONTROL MODULE (ECM)
• ENGINE CONTROL MODULE (ECM)
• HARNESS CONNECTOR INSPECTION
• INSPECTION
• ID CODE REGISTRATION JUDGMENT TABLE
• CAN BUS LINE DIAGNOSTIC FLOW
• CAN BUS DIAGNOSTICS TABLE
• DATA LIST REFERENCE TABLE
• STOPLIGHT SWITCH CHECK
• ETACS-ECU
• CLUTCH SWITCH CHECK < VEHICLES WITH CRUISE CONTROL >
• CLUTCH PEDAL AND MASTER CYLINDER
• DIAGNOSTIC FUNCTION
• DTC P0705: MALFUNCTION OF TRANSMISSION RANGE SWITCH
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC FUNCTION
• CODING LIST
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC TROUBLE CODE CHART
• DTC U0155: COMBINATION METER CAN TIME OUT
• INSPECTION PROCEDURE 5: THE COMBINATION METER LIGHT DOES NOT ILLUMINATE NORMALLY OR THE MULTI INFORMATION DISPLAY IS NOT DISPLAYED NORMALLY
• TRANSMISSION RANGE SWITCH CONTINUITY CHECK
• STEERING WHEEL
• HOW TO READ DIAGNOSTIC TROUBLE CODES
• SYMPTOM CHART
• HOW TO ERASE DIAGNOSTIC TROUBLE CODES
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLESHOOTING STRATEGY
• REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

More articles — Accessories & Equipment
