GENERAL INFORMATION

The cooling system is designed to keep every part of the engine at appropriate temperature in whatever condition the engine may be operated. The cooling method is of the water-cooled, pressure forced circulation type in which the water pump pressurizes coolant and circulates it throughout the engine. If the coolant temperature exceeds the prescribed temperature, the thermostat opens to circulate the coolant through the radiator as well so that the heat absorbed by the coolant may be radiated into the air. The water pump is of the centrifugal impeller type and is driven by the drive belt from the crankshaft. The radiator is the corrugated fin, cross flow type.

Scheme 1

Scheme 1: < 2.0L ENGINE Non-turbo, 2.4L ENGINE >
Scheme 1: < 2.0L ENGINE Non-turbo, 2.4L ENGINE >

Scheme 2

Scheme 2: < 2.0L ENGINE Turbo >
Scheme 2: < 2.0L ENGINE Turbo >

SERVICE SPECIFICATIONS

ItemStandard valueLimit
Valve opening pressure of radiator cap kPa (psi)93 - 123 (14 - 18)Minimum 83 (12)
ThermostatValve opening temperature °C (°F)2.0L ENGINE Non-turbo, 2.4L ENGINE87 ± 1.5 (189 ± 3)
2.0L ENGINE Turbo76.5 ± 1.5 (170 ± 3)
Full-opening temperature °C (°F)2.0L ENGINE Non-turbo, 2.4L ENGINE95 (203)
2.0L ENGINE Turbo90 (194)
Valve lift mm (in)8.5 (0.33) or more

SERVICE SPECIFICATIONS

COOLANT

ItemRecommended antifreezeQuantity dm 3 (qt)
Engine coolant [includes 0.65 dm 3 (0.63 qt) in the radiator condenser tank]Dia queen super long life coolant premium or equivalent (1)2.0L ENGINE Non-turbo, 2.4L ENGINE7.0 (7.4)
2.0L ENGINE Turbo7.5 (7.9)
(1) similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology.
(1)Similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology.

COOLANT SPECIFICATIONS

SEALANT

ItemSpecified sealant
Engine coolant temperature sensorThree bond 1324N, LOCTITE 262 or equivalent

SEALANT SPECIFICATIONS

INTRODUCTION

The system cools the engine so that it does not overheat and maintains the engine at an optimum temperature. The system components are the radiator, water pump, thermostat, radiator fan, condenser fan. Possible faults include low coolant, contamination, belt loosening and component damage.

TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure to find most of the engine cooling faults.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find and repair the malfunction by following the SYMPTOM CHART.
  4. Verify that the malfunction is eliminated.

SYMPTOM CHART

SymptomInspection procedureReference
Coolant leak1INSPECTION PROCEDURE 1: COOLANT LEAK
Engine overheating2INSPECTION PROCEDURE 2: ENGINE OVERHEATING
Radiator fan and condenser fan do not operate < 2.0L ENGINE Non-turbo, 2.4L Engine >3INSPECTION PROCEDURE 3: RADIATOR FAN AND CONDENSER FAN DO NOT OPERATE < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Radiator fan and condenser fan do not operate < 2.0L ENGINE Turbo >4INSPECTION PROCEDURE 4: RADIATOR FAN AND CONDENSER FAN DO NOT OPERATE < 2.0L ENGINE TURBO >

SYMPTOM CHART

Scheme 3

Scheme 3: DIAGNOSIS
Scheme 3: DIAGNOSIS
  1. STEP 1. Check for coolant leaks. WARNING: When pressure testing the cooling system, slowly release cooling system pressure to avoid getting burned by hot coolant. CAUTION: Be sure to completely clean away any moisture from the places checked. When the tester is removed, be careful not to spill any coolant. When installing and removing the tester and when testing, be careful not to deform the filler neck of the radiator. Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections. Q: Is leakage present from the radiator hose or connections? YES: Repair or replace the appropriate part, then go to Step 2. NO: There is no action to be taken.
  2. STEP 2. Retest the system. Q: It there still coolant leakage? YES: Return to Step 1 . NO: The procedure is complete.

Scheme 4

Scheme 4: DIAGNOSIS
Scheme 4: DIAGNOSIS
  1. STEP 1. Remove the radiator cap and check for coolant contamination. Q: Is the coolant contaminated with rust and oil? YES: Replace it (Refer to «ENGINE COOLANT CHANGE < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution__engine-coolant-change-20l-engine) ) or (Refer to «ENGINE COOLANT CHANGE < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution__engine-coolant-change-20l-engine) ). NO: There is no action to be taken. Go to Step 2.
  2. STEP 2. Check the radiator cap valve opening pressure. NOTE: Be sure that the cap is clean before testing. Rust or other foreign material on the cap seal will cause an improper reading. Use a cap adapter to attach the cap to the tester. Increase the pressure until the gauge indicator stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi) Q: Does the reading remain at or above the minimum limit? YES: Go to Step 3. NO: Replace the radiator cap. Then go to Step 5 .
  3. STEP 3. Check thermostat operation. Refer to «THERMOSTAT CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Does the thermostat operate correctly? YES: Go to Step 4. NO: Replace the thermostat, then go to Step 5 .
  4. STEP 4. Check the drive belt for slippage or damage. Refer to «DRIVE BELT TENSION CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-non-turbo-except-lancer-evolution) . < 2.0L ENGINE Non-turbo > Refer to «DRIVE BELT TENSION CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-turbo-except-lancer-evolution) . < 2.0L ENGINE Turbo > Refer to «DRIVE BELT TENSION CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-24l-except-lancer-evolution) . < 2.4L ENGINE > Q: Is the drive belt loose or damaged? YES: Adjust or replace the drive belt, then go to Step 5. NO: There is no action to be taken.
  5. STEP 5. Retest the system. Check the engine coolant temperature. Q: Is the engine coolant temperature abnormally high? YES: Return to Step 2 . NO: The procedure is complete.

Scheme 5

Scheme 5: Inspection Procedure 3: Radiator Fan and Condenser Fan do not Operate < 2.0L ENGINE Non-turbo, 2.4L
Scheme 5: Inspection Procedure 3: Radiator Fan and Condenser Fan do not Operate < 2.0L ENGINE Non-turbo, 2.4L

CIRCUIT OPERATION

  1. The engine control module (ECM) transmits the rotation signals of radiator fan and condenser fan, based on the engine coolant temperature signal from the engine coolant temperature sensor, the vehicle speed signal from the vehicle speed sensor < M/T > or the secondary pulley speed sensor signal from the transaxle control module (TCM) < CVT >, and the A/C switch signal from the A/C-ECU using the CAN bus line.
  2. The rotation signals of radiator fan and condenser fan, using the CAN bus line from ECM, turn ON/OFF of the radiator fan relay, condenser fan relay, and fan control relay via ETACS-ECU, to control the radiator fan and condenser fan rotation.

TECHNICAL DESCRIPTION

  1. When the radiator fan and condenser fan do not operate, the wiring harness/connector, fan motor, relay, and ETACS-ECU may have a failure.
  2. The radiator fan and condenser fan do not operate also when the CAN bus line, MFI system, or ETACS system have a failure.

TROUBLESHOOTING HINTS

  1. Malfunction of CAN bus system.
  2. Damaged wiring harness or connector.
  3. Malfunction of the MFI system.
  4. Malfunction of CVT system < CVT. >
  5. Malfunction of the A/C system.
  6. Malfunction of ETACS system.
  7. Malfunction of fusible link number 28.
  8. Malfunction of fusible link number 29.
  9. Malfunction of radiator fan relay.
  10. Malfunction of condenser fan relay.
  11. Malfunction of fan control relay.
  12. Malfunction of radiator fan motor.
  13. Malfunction of condenser fan motor.
  14. Malfunction of ETACS-ECU.
  15. Malfunction of ECM.

DIAGNOSIS PROCEDURE

Required Special Tools

  1. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A
  2. MB991223: Harness Set
  3. MB992006: Extra Fine Probe
CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to CAN BUS LINE DIAGNOSTIC FLOW .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. Use scan tool to diagnose the CAN bus line (Refer to «EXPLANATION ABOUT THE SCAN TOOL (M.U.T.-III) CAN BUS DIAGNOSTICS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__explanation-about-the-scan-tool-mut-iii) .) Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTIC TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 23 .
  2. STEP 2. Using scan tool MB991958, check the MFI system actuator test. Using scan tool to check the MFI system actuator test (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is the check result normal? YES: Go to Step 22 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the MFI system DTC. Using scan tool to read the MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Then go to Step 23 . NO: Go to Step 5 < M/T. > NO: Go to Step 4 < CVT. >
  4. STEP 4. Using scan tool MB991958, read the CVT system DTC < CVT. > Using scan tool to read the CVT system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-function) .) Q: Is any DTC set? YES: Repair the CVT system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#continuously-variable-transaxle-on-vehicle-service-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 23 . NO: Go to Step 5.
  5. STEP 5. Using scan tool MB991958, read the A/C system DTC. Using scan tool to read the A/C system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#heating-air-conditioning-and-ventilation-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#automatic-air-conditioning-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is any DTC set? YES: Repair the A/C system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#heating-air-conditioning-and-ventilation-except-lancer-evolution__diagnostic-trouble-code-chart) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#automatic-air-conditioning-except-lancer-evolution__diagnostic-trouble-code-chart) ) < 2.4L ENGINE. > Then go to Step 23 . NO: Go to Step 6.
  6. STEP 6. Using scan tool MB991958, read the ETACS system DTC. Using scan tool to read the ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the ETACS system (Refer to «DIAGNOSIS CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 23 . NO: Go to Step 7.
  7. STEP 7. Measure the terminal voltage at ETACS-ECU connector C-312. Disconnect the ETACS-ECU connector C-312, and measure at front wiring harness connector side. Turn the ignition switch to the "ON" position. Measure the terminal voltage between ETACS-ECU connector C-312 terminal number 2 and body ground, between ETACS-ECU connector C-312 terminal number 8 and body ground. OK: Battery positive voltage Q: Is the check result normal? YES: Go to Step 13 . NO: Go to Step 8.
  8. STEP 8. Check the condenser fan relay connector A-23X, radiator fan relay connector A-26X, fan control relay connector A-28X, and ETACS-ECU connector C-312, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 9. NO: Repair or replace the damaged connector. Then go to Step 23 .
  9. STEP 9. Check the harness wire between fusible link number 28 and condenser fan relay connector A-23X terminal number 1, between fusible link number 28 and fan control relay connector A-28X terminal number 1, and between fusible link number 29 and radiator fan relay connector A-26X terminal number 3, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 10. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  10. STEP 10. Check the harness wire between condenser fan relay connector A-23X terminal number 2 and ETACS-ECU connector C-312 terminal number 8, between radiator fan relay connector A-26X terminal number 1 and ETACS-ECU connector C-312 terminal number 2, and between fan control relay connector A-28X terminal number 3, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 11. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  11. STEP 11. Check the radiator fan relay, condenser fan relay, and fan control relay. Refer to «COOLING FAN RELAY CONTINUITY CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the relay in good condition? YES: Go to Step 12. NO: Replace the damaged relay. Then go to Step 23 .
  12. STEP 12. Check the fusible link number 28 and fusible link number 29. Q: Is the fusible link in good condition? YES: Go to Step 20 . NO: Replace the damaged fusible link. Then go to Step 23 .
  13. STEP 13. Check the condenser fan relay connector A-23X, radiator fan relay connector A-26X, fan control relay connector A-28X, radiator fan motor connector A-35, and condenser fan motor connector A-40, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connector and terminal in good condition? YES: Go to Step 14. NO: Repair or replace the damaged connector. Then go to Step 23 .
  14. STEP 14. Check the harness wire between fusible link number 28 and condenser fan relay connector A-23X terminal number 4, and between fusible link number 29 and radiator fan relay connector A-26X terminal number 4, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 15. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  15. STEP 15. Check the harness wire between condenser fan relay connector A-23X terminal number 3 and condenser fan motor connector A-40 terminal number 1, and between radiator fan relay connector A-26X terminal number 2 and radiator fan motor connector A-35 terminal number 1, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 16. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  16. STEP 16. Check the harness wire between radiator fan motor connector A-35 terminal number 2 and fan control relay connector A-28X terminal number 5, and between condenser fan motor connector A-40 terminal number 2 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 17. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  17. STEP 17. Check the harness wire between fan control relay connector A-28X terminal number 2 and condenser fan motor connector A-40 terminal number 1, and between fan control relay connector A-28X terminal number 4 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 18. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  18. STEP 18. Check the radiator fan relay, condenser fan relay, and fan control relay. Refer to «COOLING FAN RELAY CONTINUITY CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the relay in good condition? YES: Go to Step 19. NO: Replace the damaged relay. Then go to Step 23 .
  19. STEP 19. Check the radiator fan motor and condenser fan motor. Refer to «COOLING FAN MOTOR CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the fan motor in good condition? YES: Go to Step 20. NO: Replace the damaged fan motor (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) .) Then go to Step 23 .
  20. STEP 20. Using scan tool MB991958, read the ETACS system DTC. Using scan tool to read the ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Q: Is any DTC set? YES: Replace the ETACS-ECU (Refer to «ETACS-ECU»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Then go to Step 23 . NO: Go to Step 21.
  21. STEP 21. Using scan tool MB991958, check the MFI system actuator test. Using scan tool to check the MFI system actuator test (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ) < 2.4L ENGINE. > Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.0L ENGINE Non-turbo > or (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ) < 2.4L ENGINE. > Q: Is the check result normal? YES: Go to Step 22. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 23 .
  22. STEP 22. Check the symptoms. Q: Does the radiator fan and condenser fan operate normal? YES: An intermittent malfunction is suspected (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) ] < 2.0L ENGINE Non-turbo > or [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) ] < 2.4L ENGINE. > When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 23.
  23. STEP 23. Check the symptoms. Q: Does the radiator fan and condenser fan operate normal? YES: The procedure is complete. NO: Return to Step 1 .

Scheme 6

Scheme 6: Inspection Procedure 4: Radiator Fan and Condenser Fan do not Operate < 2.0L ENGINE Turbo >
Scheme 6: Inspection Procedure 4: Radiator Fan and Condenser Fan do not Operate < 2.0L ENGINE Turbo >
  1. The engine control module (ECM) transmits the rotation signals of radiator fan and condenser fan, based on the engine coolant temperature signal from the engine coolant temperature sensor, the vehicle speed signal from the ASC-ECU, and the A/C switch signal from the A/C-ECU using the CAN bus line.
  2. The rotation signals of radiator fan and condenser fan, using the CAN bus line from ECM, turn ON/OFF of the radiator fan relay, condenser fan relay, and fan control relay via ETACS-ECU, to control the radiator fan and condenser fan rotation.
  1. When the radiator fan and condenser fan do not operate, the wiring harness/connector, fan motor, relay, and ETACS-ECU may have a failure.
  2. The radiator fan and condenser fan do not operate also when the CAN bus line, MFI system, or ETACS system have a failure.
  1. Malfunction of CAN bus line.
  2. Damaged wiring harness or connector.
  3. Malfunction of MFI system.
  4. Malfunction of ASC system.
  5. Malfunction of the A/C system.
  6. Malfunction of ETACS system.
  7. Malfunction of fusible link number 28.
  8. Malfunction of fusible link number 29.
  9. Malfunction of radiator fan relay.
  10. Malfunction of condenser fan relay.
  11. Malfunction of fan control relay.
  12. Malfunction of radiator fan motor.
  13. Malfunction of condenser fan motor.
  14. Malfunction of ETACS-ECU.
  15. Malfunction of ECM.

DIAGNOSTIC PROCEDURE

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  2. MB991223: Harness Set
  3. MB992006: Extra Fine Probe
CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code (DTC) may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to CAN BUS LINE DIAGNOSTIC FLOW .)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. Use scan tool to diagnose the CAN bus line (Refer to «EXPLANATION ABOUT THE SCAN TOOL (M.U.T.-III) CAN BUS DIAGNOSTICS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__explanation-about-the-scan-tool-mut-iii) .) Q: Is the check result satisfactory? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «CAN BUS DIAGNOSTIC TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) .) Then go to Step 23 .
  2. STEP 2. Using scan tool MB991958, check the MFI system actuator test. Using scan tool to check the MFI system actuator test (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Q: Is the check result normal? YES: Go to Step 22 . NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the MFI system DTC. Using scan tool to read the MFI system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Then go to Step 23 . NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, read the ASC system DTC. Using scan tool to read the ASC system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-function) .) Q: Is any DTC set? YES: Repair the ASC system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 23 . NO: Go to Step 5.
  5. STEP 5. Using scan tool MB991958, read the A/C system DTC. Using scan tool to read the A/C system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#automatic-air-conditioning-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the A/C system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#automatic-air-conditioning-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 23 . NO: Go to Step 6.
  6. STEP 6. Using scan tool MB991958, read the ETACS system DTC. Using scan tool to read the ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Q: Is any DTC set? YES: Repair the ETACS system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) .) Then go to Step 23 . NO: Go to Step 7.
  7. STEP 7. Measure the terminal voltage at ETACS-ECU connector C-312. Disconnect the ETACS-ECU connector C-312, and measure at front wiring harness connector side. Turn the ignition switch to the "ON" position. Measure the terminal voltage between ETACS-ECU connector C-312 terminal number 2 and body ground, between ETACS-ECU connector C-312 terminal number 8 and body ground. OK: Battery positive voltage Q: Is the check result normal? YES: Go to Step 13 . NO: Go to Step 8.
  8. STEP 8. Check the radiator fan relay connector A-57X, condenser fan relay connector A-58X, fan control relay connector A-59X, and ETACS-ECU connector C-312, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connectors and terminals in good condition? YES: Go to Step 9. NO: Repair or replace the damaged connector. Then go to Step 23 .
  9. STEP 9. Check the harness wire between fusible link number 28 and condenser fan relay connector A-58X terminal number 3, between fusible link number 28 and condenser fan relay connector A-58X terminal number 4, between condenser fan relay connector A-58X terminal number 4 and fan control relay connector A-59X terminal number 1, and between fusible link number 29 and radiator fan relay connector A-57X terminal number 3, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 10. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  10. STEP 10. Check the harness wire between radiator fan relay connector A-57X terminal number 1 and ETACS-ECU connector C-312 terminal number 2, between condenser fan relay connector A-58X terminal number 1 and ETACS-ECU connector C-312 terminal number 8, and between fan control relay connector A-59X terminal number 3, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 11. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  11. STEP 11. Check the radiator fan relay, condenser fan relay, and fan control relay. Refer to «COOLING FAN RELAY CONTINUITY CHECK < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the relay in good condition? YES: Go to Step 12. NO: Replace the damaged relay. Then go to Step 23 .
  12. STEP 12. Check the fusible link number 28 and fusible link number 29. Q: Is the fusible link in good condition? YES: Go to Step 20 . NO: Replace the damaged fusible link. Then go to Step 23 .
  13. STEP 13. Check the radiator fan relay connector A-57X, condenser fan relay connector A-58X, fan control relay connector A-59X, radiator fan motor connector A-35, and condenser fan motor connector A-40, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the connectors and terminals in good condition? YES: Go to Step 14. NO: Repair or replace the damaged connector. Then go to Step 23 .
  14. STEP 14. Check the harness wire between fusible link number 28 and condenser fan relay connector A-58X terminal number 4, and between fusible link number 29 and radiator fan relay connector A-57X terminal number 4, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 15. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  15. STEP 15. Check the harness wire between radiator fan relay connector A-57X terminal number 2 and radiator fan motor connector A-35 terminal number 1, and between condenser fan relay connector A-58X terminal number 2 and condenser fan motor connector A-40 terminal number 1, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 16. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  16. STEP 16. Check the harness wire between radiator fan motor connector A-35 terminal number 2 and fan control relay connector A-59X terminal number 2, and between condenser fan motor connector A-40 terminal number 2 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 17. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  17. STEP 17. Check the harness wire between fan control relay connector A-59X terminal number 4 and condenser fan motor connector A-40 terminal number 1, and between fan control relay connector A-59X terminal number 5 and body ground, for damage. Check harness wire for open/short circuit and damage. Q: Is the harness wires in good condition? YES: Go to Step 18. NO: Repair or replace the damaged harness wire. Then go to Step 23 .
  18. STEP 18. Check the radiator fan relay, condenser fan relay, and fan control relay. Refer to «COOLING FAN RELAY CONTINUITY CHECK < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the relay in good condition? YES: Go to Step 19. NO: Replace the damaged relay. Then go to Step 23 .
  19. STEP 19. Check the radiator fan motor and condenser fan motor. Refer to «COOLING FAN MOTOR CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) . Q: Is the fan motor in good condition? YES: Go to Step 20. NO: Replace the damaged fan motor (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) .) Then go to Step 23 .
  20. STEP 20. Using scan tool MB991958, read the ETACS system DTC. Using scan tool to read the ETACS system DTC (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Q: Is any DTC set? YES: Replace the ETACS-ECU (Refer to «ETACS-ECU»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .) Then go to Step 23 . NO: Go to Step 21.
  21. STEP 21. Using scan tool MB991958, check the MFI system actuator test. Using scan tool to check the MFI system actuator test (Refer to «DIAGNOSTIC FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .) Item 14: Cooling fan (Refer to «ACTUATOR TEST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) ) Q: Is the check result normal? YES: Go to Step 22. NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 23 .
  22. STEP 22. Check the symptoms. Q: Does the radiator fan and condenser fan operate normal? YES: An intermittent malfunction is suspected (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) .) NO: Replace the ECM [Refer to «ENGINE CONTROL MODULE (ECM)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) .] When the ECM is replaced, register the encrypted code (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) Then go to Step 23.
  23. STEP 23. Check the symptoms. Q: Does the radiator fan and condenser fan operate normal? YES: The procedure is complete. NO: Return to Step 1 .

SPECIAL TOOLS

SPECIAL TOOLS Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 Scan tool (M.U.T.-III sub assembly) Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: g: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B instead, the CAN communication does not function correctly. Checking diagnostic trouble code (DTC). Checking actuator test. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adaptor Probe General service tools Checking the continuity and measuring the voltage at the harness connector MB992006 Extra fine probe General service tool Continuity check and voltage measurement at harness wire or connector for loose, corroded or damaged terminals, or terminals pushed back in the connector. MB991871 LLC changer General service tool Coolant refilling MB992042 Water temp sensor wrench MB992042-01 Engine coolant temperature sensor removal and installation

Scheme 7

Scheme 7: SPECIAL TOOLS
Scheme 7: SPECIAL TOOLS

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

ENGINE COOLANT LEAK CHECK

WARNINGWhen pressure testing the cooling system, slowly release cooling system pressure to avoid getting burned by hot coolant.
CAUTIONBe sure to completely clean away any moisture from the places checked. When the tester is taken out, be careful not to spill any coolant. Be careful when installing and removing the tester and when testing not to deform the filler neck of the radiator.
  1. Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections.
  2. If there is leakage, repair or replace the appropriate part.

RADIATOR CAP OPENING PRESSURE CHECK

Note. Be sure that the radiator cap is clean before testing. Rust or other foreign material on the radiator cap seal will cause an improper reading.

Scheme 11

Scheme 11: RADIATOR CAP OPENING PRESSURE CHECK
Scheme 11: RADIATOR CAP OPENING PRESSURE CHECK
  1. Use a cap adapter to attach the radiator cap to the tester.
  2. Increase the pressure until the indicator of the gauge stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi)
  3. Replace the radiator cap if the reading does not remain at or above the limit.

ENGINE COOLANT CHANGE < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

Required Special Tool

  1. MB991871: LLC changer

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15
  1. Remove the engine room under cover front A (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
  2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
  3. Remove the engine room under cover front B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
  4. Disconnect the cooling water line hose and drain the engine coolant in the water jacket.
  5. Drain the water in the water jacket by unplugging the drain plug of the cylinder block.
  6. Remove the radiator condenser tank and drain the engine coolant.
  7. Connect the cooling water line hose.
  8. Replace the cylinder block drain plug gasket, and tighten the drain plug to the specified torque. Tightening torque: 39 ± 3 N.m
  9. Securely tighten the radiator drain plug.
  10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
  11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.0 dm 3 (7.4 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
  12. Tighten the radiator cap securely.
  13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
  14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
  15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
  16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
  17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
  18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
  19. Reinstall the engine room under cover front A, B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

ENGINE COOLANT CHANGE < 2.0L ENGINE TURBO >

Required Special Tool

  1. MB991871: LLC changer

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Remove the engine room under cover front A (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
  2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
  3. Remove the engine room under cover front B. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
  4. Remove the air cleaner intake hose (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
  5. Disconnect the turbocharger water return hose and drain the engine coolant in the water jacket.
  6. Remove the radiator condenser tank and drain the engine coolant.
  7. Connect the turbocharger water return hose.
  8. Reinstall the air cleaner intake hose (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
  9. Securely tighten the radiator drain plug.
  10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
  11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.5 dm 3 (7.9 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
  12. Tighten the radiator cap securely.
  13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
  14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
  15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
  16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
  17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
  18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
  19. Reinstall the engine room under cover front A, B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

WATER PUMP COOLANT LEAK CHECK

If a residue of the coolant draining is found on the drain hole, the vapor hole and the installation surface, check the water pump leakage by following method.

  1. Wipe off the residue of the coolant draining on the water pump. WARNING: Make sure that the coolant is cold when removing the radiator cap.
  2. Remove the radiator cap. CAUTION: Do not pressures 100 kPa (15 psi) or more.
  3. Install the radiator tester and pressures at 100 kPa (15 psi.)
  4. Hold the pressurized state for 20 minutes, and check that the water leakage from the drain hole, the vapor hole or the installation surface of the water pump.
  5. Remove the radiator tester, and install the radiator cap.
  6. Warm up the engine, let it idle for 20 minutes and stop it.
  7. After stopping the engine, and check that the water leakage from the drain hole, the vapor hole or the installation surface of the water pump.
  8. If the water leakage is found in step 4 or 7 , replace the water pump (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) ) or (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) ) .

ENGINE COOLANT CONCENTRATION TEST

RADIATOR FAN RELAY CHECK

Battery voltageTerminal number to be connected to testerContinuity test results
Not applied2 - 4Open circuit
Connect terminal number 1 and battery (-) terminal. Connect terminal number 3 and battery (+) terminal.Continuity (Less than 2 ohms)

RADIATOR FAN RELAY CONTINUITY CHECK

Scheme 18

Scheme 18
Scheme 18

CONDENSER FAN RELAY CHECK

Battery voltageTerminal number to be connected to testerContinuity test results
Not applied3 - 4Open circuit
Connect terminal number 1 and battery (+) terminal. Connect terminal number 2 and battery (-) terminal.Continuity (Less than 2 ohms)

CONDENSER FAN RELAY CONTINUITY CHECK

Scheme 19

Scheme 19
Scheme 19

FAN CONTROL RELAY CHECK

Battery voltageTerminal number to be connected to testerContinuity test results
Not applied2 - 5Continuity (Less than 2 ohms)
4 - 5Open circuit
Connect terminal number 1 and battery (+) terminal. Connect terminal number 3 and battery (-) terminal.2 - 5Open circuit
4 - 5Continuity (Less than 2 ohms)

FAN CONTROL RELAY CONTINUITY CHECK

Scheme 20

Scheme 20
Scheme 20
Battery voltageTerminal number to be connected to testerContinuity test results
Not applied2 - 4Open circuit
Connect terminal number 1 and battery (-) terminal. Connect terminal number 3 and battery (+) terminal.Continuity (Less than 2 ohms)

RADIATOR FAN RELAY CONTINUITY CHECK

Scheme 21

Scheme 21
Scheme 21
Battery voltageTerminal number to be connected to testerContinuity test results
Not applied2 - 4Open circuit
Connect terminal number 1 and battery (-) terminal. Connect terminal number 3 and battery (+) terminal.Continuity (Less than 2 ohms)

CONDENSER FAN RELAY CONTINUITY CHECK

Scheme 22

Scheme 22
Scheme 22
Battery voltageTerminal number to be connected to testerContinuity test results
Not applied2 - 4Continuity (Less than 2 ohms)
2 - 5Open circuit
Connect terminal number 1 and battery (+) terminal. Connect terminal number 3 and battery (-) terminal.2 - 4Open circuit
2 - 5Continuity (Less than 2 ohms)

FAN CONTROL RELAY CONTINUITY CHECK

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24: COOLING FAN MOTOR CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Scheme 24: COOLING FAN MOTOR CHECK < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the fan motor connector.
  2. Check that the fan motor runs when a positive battery terminal is connected to the fan motor-side connector terminal number 1, and terminal number 2 is grounded. Also check to see that there is no abnormal sound emitted from the fan motor at this time.
  3. If the fan motor is defective, replace it (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) .)
  4. Connect the fan motor connector.

Scheme 27

Scheme 27: COOLING FAN MOTOR CHECK < 2.0L ENGINE TURBO >
Scheme 27: COOLING FAN MOTOR CHECK < 2.0L ENGINE TURBO >

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect the fan motor connector.
  2. Check that the fan motor runs when a positive battery terminal is connected to the fan motor-side connector terminal number 1, and terminal number 2 is grounded. Also check to see that there is no abnormal sound emitted from the fan motor at this time.
  3. If the fan motor is defective, replace it (Refer to «REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/cooling-system-mechanical/#engine-cooling-except-lancer-evolution) .)
  4. Connect the fan motor connector.

Scheme 30

Scheme 30: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Scheme 30: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

<< A >> RADIATOR LOWER HOSE DISCONNECTION

Make mating marks on the radiator lower hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

Scheme 31

Scheme 31: << A >> RADIATOR LOWER HOSE DISCONNECTION
Scheme 31: << A >> RADIATOR LOWER HOSE DISCONNECTION

>> A << THERMOSTAT INSTALLATION

CAUTIONMake absolutely sure that no oil adheres to the rubber ring of the thermostat. Also do not fold or scratch the rubber ring during installation.

Install the thermostat so that the jiggle valve is facing straight up. Be careful not to fold or scratch the rubber ring.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33: >> B << RADIATOR LOWER HOSE CONNECTION
Scheme 33: >> B << RADIATOR LOWER HOSE CONNECTION
  1. Insert the radiator lower hose as far as the projection of the cooling water inlet hose fitting.
  2. Align the mating marks on the radiator lower hose and hose clamp, and then connect the radiator lower hose.

Scheme 34

Scheme 34: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >
Scheme 34: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >

Make mating marks on the radiator lower hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

CAUTIONMake absolutely sure that no oil adheres to the rubber ring of the thermostat. Also do not fold or scratch the rubber ring during installation.

Install the thermostat so that the jiggle valve is facing straight up. Be careful not to fold or scratch the rubber ring.

>> B << RADIATOR LOWER HOSE CONNECTION

  1. Insert the radiator lower hose as far as the projection of the cooling water inlet hose fitting.
  2. Align the mating marks on the radiator lower hose and hose clamp, and then connect the radiator lower hose.

Scheme 35

Scheme 35: THERMOSTAT CHECK
Scheme 35: THERMOSTAT CHECK

Scheme 36

Scheme 36
Scheme 36
  1. Immerse the thermostat in water, and heat the water while stirring. Check the thermostat valve opening temperature. Standard value: 87 ± 1.5°C (189 ± 3°F) < 2.0L ENGINE Non-turbo, 2.4L ENGINE > 76.5 ± 1.5°C (170 ± 3°F) < 2.0L ENGINE Turbo >
  2. Check that the amount of valve lift is at the standard value when the water is at the full-opening temperature. NOTE: Measure the valve height when the thermostat is fully closed, and use this measurement to compare the valve height when the thermostat is fully open. Standard value: Full-opening temperature: 95°C (203°F) < 2.0L ENGINE Non-turbo, 2.4L ENGINE > 90°C (194°F) < 2.0L ENGINE Turbo > Amount of valve lift: 8.5 mm (0.33 inch) or more

Scheme 37

Scheme 37: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Scheme 37: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

Scheme 38

Scheme 38: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >
Scheme 38: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >

Scheme 39

Scheme 39: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Scheme 39: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

Required Special Tool

  1. MB992042: Water Temp Sensor Wrench

<< A >> RADIATOR UPPER HOSE DISCONNECTION

Make mating marks on the radiator upper hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

<< B >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

Use special tool MB992042 to remove the engine coolant temperature sensor.

Scheme 40

Scheme 40: << B >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL
Scheme 40: << B >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

>> A << O-RING INSTALLATION

CAUTIONAvoid adhesion of engine oil or grease to the O-ring.

Fit the O-ring in the water pump inlet pipe groove, wet the O-ring circumference or the pipe mounting area inner wall, and then insert the O-ring.

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42: >> B << ENGINE COOLANT TEMPERATURE SENSOR INSTALLATION
Scheme 42: >> B << ENGINE COOLANT TEMPERATURE SENSOR INSTALLATION
  1. Apply the specified sealant to the engine coolant temperature sensor thread. Specified sealant: Three bond 1324N or equivalent NOTE: Install the engine coolant temperature sensor immediately after applying sealant. CAUTION: After the installation, until a sufficient period of time (one hour or more) elapses, do not apply the oil or water to the sealant application area or start the engine.
  2. Use special tool MB992042 to tighten the engine coolant temperature sensor to the specified torque. Tightening torque: 30 ± 9 N.m (22 ± 7 ft-lb)

>> C << RADIATOR UPPER HOSE CONNECTION

  1. Insert radiator upper hose as far as the projection of the cooling water outlet hose fitting.
  2. Align the mating marks on the radiator upper hose and hose clamp, and then connect the radiator upper hose.

Scheme 43

Scheme 43: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >
Scheme 43: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >

Required Special Tool

  1. MB992042: Water Temp Sensor Wrench

Make mating marks on the radiator upper hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

Scheme 44

Scheme 44: << B >> FUEL HIGH-PRESSURE HOSE DISCONNECTION
Scheme 44: << B >> FUEL HIGH-PRESSURE HOSE DISCONNECTION

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Follow the steps below to unlock the fuel high-pressure hose connector. Insert a flat-tipped screwdriver [6 mm (0.24 inch) wide and 1 mm (0.04 inch) thick] into the retainer of the fuel high-pressure hose connector. CAUTION: When pushing up the retainer of the fuel high-pressure hose connector, pay attention to avoid damage to the retainer. Turn the flat-tipped screwdriver inserted into the retainer by 90 degrees angle to push up the retainer and unlock the fuel high-pressure hose connector.
  2. Disconnect the fuel high-pressure hose.

<< C >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

Use special tool MB992042 to remove the engine coolant temperature sensor.

Scheme 47

Scheme 47: << C >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL
Scheme 47: << C >> ENGINE COOLANT TEMPERATURE SENSOR REMOVAL

>> A << ENGINE COOLANT TEMPERATURE SENSOR INSTALLATION

  1. Apply the specified sealant to the engine coolant temperature sensor thread. Specified sealant: Three bond 1324N or equivalent NOTE: Install the engine coolant temperature sensor immediately after applying sealant. CAUTION: After the installation, until a sufficient period of time (one hour or more) elapses, do not apply the oil or water to the sealant application area or start the engine.
  2. Use special tool MB992042 to tighten the engine coolant temperature sensor to the specified torque. Tightening torque: 30 ± 9 N.m (22 ± 7 ft-lb)

Scheme 48

Scheme 48: >> B << FUEL HIGH-PRESSURE HOSE CONNECTION
Scheme 48: >> B << FUEL HIGH-PRESSURE HOSE CONNECTION

Scheme 49

Scheme 49
Scheme 49
  1. Pull up the retainer of fuel high-pressure hose to unlock before installing.
  2. Securely insert the fuel rail stopper into the fuel high-pressure hose connector groove to install the fuel high-pressure hose to the fuel rail. CAUTION: When pushing in the retainer of the fuel high-pressure hose connector, pay attention to avoid damage to the retainer. After the installation of the fuel high-pressure hose, slightly pull the fuel high-pressure hose to check that it is connected securely. At this time, also check that there is approximately 1 mm (0.04 inch) play.
  3. Push in the retainer of the fuel high-pressure hose connector to lock the fuel high-pressure hose and fuel rail.

>> C << O-RING INSTALLATION

CAUTIONAvoid adhesion of engine oil or grease to the O-ring.

Fit the O-ring in the water pump inlet pipe groove, wet the O-ring circumference or the pipe mounting area inner wall, and then insert the O-ring.

>> D << RADIATOR UPPER HOSE CONNECTION

  1. Insert radiator upper hose as far as the projection of the cooling water outlet hose fitting.
  2. Align the mating marks on the radiator upper hose and hose clamp, and then connect the radiator upper hose.

Water Pipe and Hose Check

Check the water pipe and hose for cracks, damage and clogs. Replace them if necessary.

Scheme 50

Scheme 50: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >
Scheme 50: REMOVAL AND INSTALLATION < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

<< A >> RADIATOR UPPER HOSE/RADIATOR LOWER HOSE REMOVAL

Make mating marks on the radiator hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

<< B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL

Remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly according to the following procedure.

Scheme 51

Scheme 51: << B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL
Scheme 51: << B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL
  1. Release the upper locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly.
  2. Slightly raise the fan, fan motor and cooling fan shroud assembly.
  3. Release the lower locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly, and remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly.

>> A << RADIATOR LOWER HOSE/RADIATOR UPPER HOSE INSTALLATION

  1. Insert radiator hose as far as the projection of the cooling water inlet hose fitting, cooling water outlet hose fitting or radiator.
  2. Align the mating marks on the radiator hose and hose clamp, and then connect the radiator hose.

Scheme 52

Scheme 52: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >
Scheme 52: REMOVAL AND INSTALLATION < 2.0L ENGINE TURBO >

Make mating marks on the radiator hose and the hose clamp as shown in illustration to install them in the original position. Then, remove them.

Remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly according to the following procedure.

Scheme 53

Scheme 53: << B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL
Scheme 53: << B >> FAN, FAN MOTOR AND COOLING FAN SHROUD ASSEMBLY REMOVAL
  1. Release the upper locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly.
  2. Slightly raise the fan, fan motor and cooling fan shroud assembly.
  3. Release the lower locks of the radiator assembly from the fan, fan motor and cooling fan shroud assembly, and remove the fan, fan motor and cooling fan shroud assembly from the radiator assembly.
  1. Insert radiator hose as far as the projection of the cooling water inlet hose fitting, cooling water outlet hose fitting or radiator.
  2. Align the mating marks on the radiator hose and hose clamp, and then connect the radiator hose.

See also:
• DRIVE BELT TENSION CHECK
• DRIVE BELT TENSION CHECK
• DRIVE BELT TENSION CHECK
• CAN BUS LINE DIAGNOSTIC FLOW
• EXPLANATION ABOUT THE SCAN TOOL (M.U.T.-III) CAN BUS DIAGNOSTICS
• CAN BUS DIAGNOSTIC TABLE
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC FUNCTION
• DIAGNOSIS CODE CHART
• HARNESS CONNECTOR INSPECTION
• ID CODE REGISTRATION JUDGMENT TABLE
• HOW TO COPE WITH INTERMITTENT MALFUNCTION
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC FUNCTION
• DIAGNOSTIC TROUBLE CODE CHART
• UNDER COVER
• AIR CLEANER
• RECOMMENDED LUBRICANTS AND LUBRICANT CAPACITIES TABLE
• INSPECTION PROCEDURE 1: COOLANT LEAK
• ENGINE COOLANT CHANGE < 2.0L ENGINE NON-TURBO, 2.4L ENGINE >

More articles — Engine
