GENERAL INFORMATION

The is a system that integrates the keyless entry function with which remote operation (opening/closing of all doors, opening of trunk lid < LANCER >, liftgate < LANCER SPORTBACK > and warning function to warn a person who intends to damage the vehicle*) can be performed by operating the lock/unlock/trunk lid button or panic button on the ignition key (transmitter). Also, WCM incorporates the immobilizer function, which prohibits the starting of engine using an unauthorized key, and the tire pressure monitoring system (TPMS), which issues a warning to a driver by illuminating or flashing the warning light if an abnormality to the tire pressure or system is detected. WCM has the following features

  1. The ignition key has an indicator light that enables the driver to check if the signal is transmitted correctly or if the battery in the key is discharged.
  2. Each vehicle is provided with two ignition keys, and up to eight ignition keys can be registered.
  3. Settings of the keyless entry function can be adjusted using a customization function. NOTE: *: Horn sounds, and headlights and taillights flash.

Scheme 1

Scheme 1: < LANCER >
Scheme 1: < LANCER >

Scheme 2

Scheme 2: < LANCER SPORTBACK >
Scheme 2: < LANCER SPORTBACK >
Parts nameFunctional description
Wireless control module (WCM)Controls the keyless entry functions, TPMS functions and starting of the engine by using the following communications. Communications with ETACS-ECU, ECM, ASC-ECU and combination meter via CAN Wire communication with the steering lock unit Wireless communication with the ignition key Wireless communication with the TPMS transmitter
Ignition keyThe ignition key receives signals sent from WCM, certifies the key ID, calculates the key ID, and sends the reply data signal to WCM. The ignition key also sends signals to WCM when the lock/unlock/trunk lid < LANCER > button and panic button on it are operated.
Combination meter (Multi information display, TPMS warning light)Communicates with WCM via CAN. Send ignition switch status. Receives the warning request or warning information from WCM, activates (1) the TPMS warning light. Warning symbol and message is additionally displayed on the Multi information display.
ETACS-ECUCommunicates with WCM via CAN. By the door lock/unlock request, trunk lid open request, or panic alarm request from WCM, ETACS-ECU outputs the lock/unlock signal, trunk lid open signal, or panic alarm signal. When the door lock/unlock signal is output, ETACS-ECU flashes or illuminates the turn signal light and dome light to notify that the lock/unlock operation is performed.
ASC-ECUCommunicates with WCM via CAN. Sends the vehicle speed data.
Engine control module (ECM)Communication with WCM via CAN. Send atmospheric pressure data.
TPMS transmitterMeasure tire pressure directly, then send radio frequency signal to WCM.
NOTE: (1) Illuminates for tire pressure warning. *: Flashes for about 1 minute and then continuously illuminated for TPMS malfunction warning.
NOTE
(1) Illuminates for tire pressure warning. *: Flashes for about 1 minute and then continuously illuminated for TPMS malfunction warning.
(1)Illuminates for tire pressure warning.

MAIN COMPONENTS AND FUNCTION TABLE

Scheme 3

Scheme 3: < LANCER >
Scheme 3: < LANCER >

Scheme 4

Scheme 4: < LANCER SPORTBACK >
Scheme 4: < LANCER SPORTBACK >

Note. In case of replacement of WCM, all keyless ID, key ID and tire pressure sensor ID should be re-registered using scan tool MB991958 (M.U.T.-III sub-assembly).

TRANSMITTER

The transmitter button operation allows the system to operate as follows

FunctionTransmitter operationSystem operation
Standard function (lock/unlock/trunk lid open < LANCER >)Press the lock button once.All doors (including the liftgate < LANCER SPORTBACK >) are locked. NOTE: If the retracting function of the electric folding mirrors is added using a customization function, it can be retracted in synchronisation with a lock operation.
Press the unlock button once.All doors (including the liftgate < LANCER SPORTBACK >) are unlocked. NOTE: If the opening function of the electrical folding mirrors is added as an adjustment function, it can be opened in synchronization with an unlock operation.
Open the trunk lid < LANCER >Press the trunk lid button twice (press the button once, and press it again within 5 seconds).
Panic alarm systemPanic buttonPress once (press and hold for 1 second).Starts the panic alarm (headlights flash and horn honks for three minutes)
Lock button, unlock button or panic buttonPress againStops the panic alarm in progress
Power door locks with selective unlockingPress the unlock button once to unlock the driver's door, and within 2 seconds, press the unlock button again to unlock the front passenger's door, rear doors and liftgate < LANCER SPORTBACK >.Power door locks with selective unlocking. NOTE: Using a customization function, the power door locks with selective unlocking can be enabled or disabled.
NOTE
If the retracting function of the electric folding mirrors is added using a customization function, it can be retracted in synchronisation with a lock operation.
NOTE
If the opening function of the electrical folding mirrors is added as an adjustment function, it can be opened in synchronization with an unlock operation.
NOTE
Using a customization function, the power door locks with selective unlocking can be enabled or disabled.

KEYLESS ENTRY FUNCTION TABLE

SPECIAL TOOLS

SPECIAL TOOLS Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 M.U.T.-III sub assembly Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: M.U.T.-III main harness A (MB991910) should be used. M.U.T.-III main harness B and C should not be used for this vehicle. ETACS-ECU check (Diagnostic trouble code, service data) MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Test harness LED harness LED harness adaptor Probe General service tools Continuity check and voltage measurement at harness wire or connector for loose, corroded or damaged terminals, or terminals pushed back in the connector. Connector pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting MB990784 Ornament remover General service tool Steering column cover removal

Scheme 5

Scheme 5: SPECIAL TOOLS
Scheme 5: SPECIAL TOOLS

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 8

Scheme 8
Scheme 8
  1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
  2. Start up the personal computer.
  3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
  4. Connect special tool MB991910 to special tool MB991824.
  5. Connect special tool MB991910 to the data link connector.
  6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
  7. Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "System select" from the start-up screen.
  4. Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
  5. Select "WCM" from "System List", and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
  6. Select "Diagnostic Trouble Code." to read the DTC.
  7. If a DTC is set, it is shown.
  8. Choose "Erase DTCs" to erase the DTC.

CHECK OF FREEZE FRAME DATA

The freeze frame data can be checked by using the scan tool (refer to HOW TO COPE WITH INTERMITTENT MALFUNCTIONS ).

When detecting fault and storing the DTC, the ECU connected to CAN bus line obtains the data before the determination of the DTC and the data when the DTC is determined, and then stores the ECU status of that time. By analyzing each data from scan tool, the troubleshooting can be performed more efficiently. The displayed items are as the table below.

Item No.Item nameData itemUnit
01OdometerTotal driving distance after the diagnostic trouble code is generatedMile (1)
02Ignition cycleNumber of times the ignition switch is turned "ON" or "LOCK (OFF)" after the past failure transitionNumber of counts is displayed.
04Current trouble accumulative timeCumulative time for current malfunction of diagnostic trouble codeMin
(1) If a failure occurs to both the ABS-ECU and ETACS-ECU, 0000 mile or FFFF mile is displayed to the scan tool MB991958.
(1)If a failure occurs to both the ABS-ECU and ETACS-ECU, 0000 mile or FFFF mile is displayed to the scan tool MB991958.

DISPLAY ITEM LIST

ID CODES REGISTRATION JUDGMENT TABLE

CAUTIONDo not replace the engine control module (ECM) and WCM at the same time. When replacing several ECUs, always replace one ECU at a time, register the necessary IDs in it, and then replace the next ECU.

The transponder (a small transmitter) in the ignition key, WCM, and the ECM have their own ID codes stored in them. When the cases listed in the table below occur, the ID codes must be registered in the WCM or ECM again.

Note. Up to eight ignition keys (key ID and keyless entry secret code) can be stored in the memory of WCM.

ItemOperation contents and procedureReference for registration contents
When the ECM is replacedRegister the ENG the key code. Write VIN.ENG key code & VIN reg (Refer to HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING ).
When WCM is replacedWrite VIN Register all the key IDs of the ignition keys again. Register all the keyless IDs of the ignition keys again. Register the TPMS transmittersWrite the VIN (Refer to HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING ). Key registration, Keyless ID Registration and TPMS transmitter ID registration (Refer to ID CODES REGISTRATION PROCEDURE ).
When the ignition key added individually (2)Register all the key IDs of the ignition keys again. Register all the keyless IDs of the ignition keys again.Key Registration and Keyless ID Registration (Refer to ID CODES REGISTRATION PROCEDURE )
When the ignition key is lost individuallyRegister all the key IDs of ignition keys other than the lost one again. Register all the keyless IDs of ignition keys other than the lost one again.
When the ignition key is replaced by the full service key set or the steering lock service key set.Register the key ID of the replaced ignition key again. < Barcode No. input > Register the keyless ID for all the ignition keys again.Key Registration (Barcode No.) and Keyless ID Registration (Refer to ID CODES REGISTRATION PROCEDURE )
When the key (1) is replaced by the door service key set or trunk lid service key set.Operation is not needed
When TPMS transmitter is replacedRegister the TPMS transmitterRegistering tire pressure sensor ID (Refer to ID CODES REGISTRATION PROCEDURE ).
(1) Key (the key that can be used to lock/unlock the door or trunk lid only) (2) When available, key registration should be done beginning with a key that has been registered.
(1)Key (the key that can be used to lock/unlock the door or trunk lid only)
(2)When available, key registration should be done beginning with a key that has been registered.

ID CODES REGISTRATION JUDGMENT TABLE

SUPPLY UNIT LIST FOR INDIVIDUAL KEY

SUPPLY UNIT LIST FOR INDIVIDUAL KEY Ignition key (without transmitter) Ignition key (with transmitter) < LANCER > Ignition key (with transmitter) < LANCER SPORTBACK >

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY (1 OF 2) Full service key set < Vehicles with keyless entry system > Full service key set < Vehicles without keyless entry system (LANCER) > Steering lock service key set (A: Without transmitter, B: With transmitter)

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY (2 OF 2) Door service key set (LH), Door service key set (RH) < Vehicles without keyless entry system > NOTE: Key (It can only be used for locking and unlocking, and it cannot start the engine.) Trunk lid service key set < Vehicles without keyless entry system (LANCER) > NOTE: Key (t can only be used for locking and unlocking, and it cannot start the engine.)

Scheme 12

Scheme 12: Registration flow chart
Scheme 12: Registration flow chart

WARNINGS/ALARMS < VEHICLES WITHOUT COLOR LIQUID CRYSTAL DISPLAY >

If the TPMS fails or the tire pressure is low, the WCM warns the driver of that state by the TPMS warning light and the multi information display in the combination meter.

WARNINGS/ALARMS < VEHICLES WITHOUT COLOR LIQUID CRYSTAL DISPLAY TABLE Display contents Message Item State Warning operations Warning cancellation conditions (Cancels warning operations when one of the conditions met) TPMS warning light Multi information display Not displayed - TPMS warning light bulb open circuit check The ignition switch is turned from "LOCK" (OFF) to "ON." Illuminates for 3 seconds. - 3 seconds have passed after the TPMS warning light is lit. LOW TIRE PRESSURE Tire pressure alarm The received tire pressure value is under the alarm ON threshold value. Illuminates. Symbol and "LOW TIRE PRESSURE" is displayed. The received tire pressure value is over the alarm OFF threshold value. SERVICE REQUIRED TPMS failure warning ID not stored The TPMS transmitter ID is not registered in the WCM. Flashes (1) Symbol and "SERVICE REQUIRED" is displayed. ID is registered normally. Defective EEPROM Abnormality of data in the EEPROM of the WCM is detected. Data in the EEPROM of the WCM is checked to be normal. Problem in signal reception The signals from TPMS transmitters cannot be received while driving for about 20 minutes. The signal from the TPMS transmitter that was warned is received. Defective sensor The sensor failure signal is received from the TPMS transmitter. A normal signal is received from the TPMS transmitter that was warned. The battery voltage of the TPMS transmitter is low. The reception problem warning is activated because of the low battery voltage of the TPMS transmitter. The signal of normal battery voltage is received from the TPMS transmitter that was warned. Vehicle speed input problem The vehicle speed is not input. The vehicle speed is input. Abnormal vehicle speed value The vehicle speed value is abnormal. The normal vehicle speed value is received. NOTE: (1) Change to continuous illumination after flashing for about 1 minute

Scheme 13

Scheme 13: WARNINGS/ALARMS < VEHICLES WITHOUT COLOR LIQUID CRYSTAL DISPLAY >
Scheme 13: WARNINGS/ALARMS < VEHICLES WITHOUT COLOR LIQUID CRYSTAL DISPLAY >

WARNINGS/ALARMS < VEHICLES WITH COLOR LIQUID CRYSTAL DISPLAY >

If the TPMS fails or the tire pressure is low, the WCM warns the driver of that state by the TPMS warning light and the multi information display in the combination meter.

WARNINGS/ALARMS < VEHICLES WITH COLOR LIQUID CRYSTAL DISPLAY TABLE Display contents Message Item State Warning operations Warning cancellation conditions (Cancels warning operations when one of the conditions met) TPMS warning light Multi information display Not displayed - TPMS warning light bulb open circuit check The ignition switch is turned from "LOCK" (OFF) to "ON." Illuminates for 3 seconds. - 3 seconds have passed after the TPMS warning light is lit. LOW TIRE PRESSURE Tire pressure alarm The received tire pressure value is under the alarm ON threshold value. Illuminates. Symbol and "LOW TIRE PRESSURE" is displayed. The received tire pressure value is over the alarm OFF threshold value. TPMS SERVICE REQUIRED TPMS failure warning ID not stored The TPMS transmitter ID is not registered in the WCM. Flashes (1) Symbol and "SERVICE REQUIRED" is displayed. ID is registered normally. Defective EEPROM Abnormality of data in the EEPROM of the WCM is detected. Data in the EEPROM of the WCM is checked to be normal. Problem in signal reception The signals from TPMS transmitters cannot be received while driving for about 20 minutes. The signal from the TPMS transmitter that was warned is received. Defective sensor The sensor failure signal is received from the TPMS transmitter. A normal signal is received from the TPMS transmitter that was warned. The battery voltage of the TPMS transmitter is low. The reception problem warning is activated because of the low battery voltage of the TPMS transmitter. The signal of normal battery voltage is received from the TPMS transmitter that was warned. Vehicle speed input problem The vehicle speed is not input. The vehicle speed is input. Abnormal vehicle speed value The vehicle speed value is abnormal. The normal vehicle speed value is received. NOTE: (1) Change to continuous illumination after flashing for about 1 minute

DIAGNOSTIC TROUBLE CODE CHART

CAUTIONDuring diagnosis, a DTC associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, confirm all systems for DTC(s). If DTC(s) are set, erase them all.
Diagnostic trouble code numberDiagnostic item
B1731Engine control module communication timeout
B1761VIN code not programmed
B1A08Keyless/KOS key1 performance
B1A09Keyless/KOS key2 performance
B1A0AKeyless/KOS key3 performance
B1A0BKeyless/KOS key4 performance
B1A0CKeyless key 5 performance
B1A0DKeyless key 6 performance
B1A0EKeyless key 7 performance
B1A0FKeyless key 8 performance
B1A10Keyless/KOS key 1 low battery
B1A11Keyless/KOS key 2 low battery
B1A12Keyless/KOS key 3 low battery
B1A13Keyless/KOS key 4 low battery
B1A14Keyless key 5 low battery
B1A15Keyless key 6 low battery
B1A16Keyless key 7 low battery
B1A17Keyless key 8 low battery
B1A24Key ID not registered
B1A25Key ID unmatched
B1A28Engine control module authenticate error
B1A35Transponder read error
B2101IG SW start POS.circuit low
B2102IG SW start POS.circuit high
B2204Coding data mismatch
B2206VIN code mismatch
B2352Antenna fail
B2401Keyless/KOS key ID not register
B2416ECU internal error
C1608EEPROM error
C1900 (WCM) or C1900 (KOS)No registration
C1901 (WCM) or C1901 (KOS)Vehicle speed information abnormality
C1912 (WCM) or C1912 (KOS)Tire inflation pressure warning 1
C1922 (WCM) or C1922 (KOS)Tire inflation pressure warning 2
C1932 (WCM) or C1932 (KOS)Tire inflation pressure warning 3
C1942 (WCM) or C1942 (KOS)Tire inflation pressure warning 4
C1910Transmitter low battery voltage abnormality 1
C1920Transmitter low battery voltage abnormality 2
C1930Transmitter low battery voltage abnormality 3
C1940Transmitter low battery voltage abnormality 4
C1911Reception abnormality 1
C1921Reception abnormality 2
C1931Reception abnormality 3
C1941Reception abnormality 4
C1913Acceleration sensor abnormality 1
C1923Acceleration sensor abnormality 2
C1933Acceleration sensor abnormality 3
C1943Acceleration sensor abnormality 4
C1914Pressure sensor abnormality 1
C1924Pressure sensor abnormality 2
C1934Pressure sensor abnormality 3
C1944Pressure sensor abnormality 4
C1915 (WCM) or C1915 (KOS)Transmitter OFF mode 1
C1925 (WCM) or C1925 (KOS)Transmitter OFF mode 2
C1935 (WCM) or C1935 (KOS)Transmitter OFF mode 3
C1945 (WCM) or C1945 (KOS)Transmitter OFF mode 4
U0019Bus off (CAN-B)
U0141ETACS-ECU CAN timeout
U0151SRS-ECU CAN timeout
U0154Occupant classification-ECU CAN timeout
U0155Combination meter CAN timeout
U0164A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C > CAN timeout
U0184Audio CAN timeout
U0195Satellite radio tuner CAN timeout
U0245Audio visual navigation unit CAN timeout
U1412 (WCM) or U1412 (KOS)Implausible vehicle speed signal received
U1415Coding not completed/Data fail
U1417Implausible coding data

DIAGNOSTIC TROUBLE CODE CHART

DTC B1731: Engine control module communication timeout

CAUTIONWhen the DTC B1731 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

DTC SET CONDITION

WCM checks that the engine control module data has been received via the CAN bus lines, and if not, sets the DTC No. B1731.

TECHNICAL DESCRIPTION (COMMENT)

If no data [ETACS transmits engine random number data to WCM via the CAN bus lines] is received from the engine control module via the CAN bus lines when the ignition switch is turned to ON position, it is judged as abnormal.

TROUBLESHOOTING HINTS

  1. Malfunction of CAN bus line
  2. Malfunction of WCM
  3. Malfunction of ETACS-ECU
  4. Damaged wiring harness and connectors
  5. Malfunction of engine control module

DIAGNOSIS

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the engine control module diagnostic trouble code. Check again if the DTC is set to the engine control module. Q: Is the DTC set? YES: Troubleshoot the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0100 is set to ETACS-ECU. Q: Is the DTC set? YES: Go to Step 5 . NO: Go to Step 4.
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) After registering the ID codes, go to Step 6 . NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the engine control module and record the VIN (Refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) ). Then go to Step 6. NO: The procedure is complete.
  6. STEP 6. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

DTC B1761: VIN code not programmed

CAUTIONWhen the DTC No. B1761 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1761 when no VIN is recorded in it.

WCM determines that the abnormality is present when no VIN is recorded in it.

  1. VIN not programmed
  2. Malfunction of the WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Register the VIN and recheck the diagnostic trouble code. Register VIN in WCM (Refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) ) and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The procedure is complete.

DTC B1A08: Keyless/KOS key1 performance; DTC B1A09: Keyless/KOS key2 performance; DTC B1A0A: Keyless/KOS key3 performance; DTC B1A0B: Keyless/KOS key4 performance; DTC B1A0C: Keyless key 5 performance; DTC B1A0D: Keyless key 6 performance; DTC B1A0E: Keyless key 7 performance; DTC B1A0F: Keyless key 8 performance

CAUTIONWhen replacing the ECU, always check that the communication circuit is normal.

The door locking/unlocking code is automatically updated every time the doors are locked (rolling code). WCM stores DTC B1A08, B1A09, B1A0A, B1A0B, B1A0C, B1A0D, B1A0E, or B1A0F when it receives wrong signal (rolling code out of synchronization) from the transmitter.

  1. B1A08: WCM determines that the abnormality is present when the rolling code received from the transmitter 1 (the first transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  2. B1A09: WCM determines that the abnormality is present when the rolling code received from the transmitter 2 (the second transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  3. B1A0A: WCM determines that the abnormality is present when the rolling code received from the transmitter 3 (the third transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  4. B1A0B: WCM determines that the abnormality is present when the rolling code received from the transmitter 4 (the fourth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  5. B1A0C: WCM determines that the abnormality is present when the rolling code received from the transmitter 5 (the fifth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  6. B1A0D: WCM determines that the abnormality is present when the rolling code received from the transmitter 6 (the sixth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  7. B1A0E: WCM determines that the abnormality is present when the rolling code received from the transmitter 7 (the seventh transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  8. B1A0F: WCM determines that the abnormality is present when the rolling code received from the transmitter 8 (the eighth transmitter registered in WCM) greatly differs from the rolling code stored in WCM.
  1. Rolling code out of synchronization
  2. Malfunction of the transmitter
  3. Malfunction of the WCM
  1. STEP 1. Synchronize the rolling code and recheck the diagnostic trouble code. Synchronize the rolling code. Push the lock button or unlock button of transmitter twice or more. If the keyless operation does not resume by the procedure above, register the key again (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Recheck if the diagnostic trouble code is set. Push the lock button or unlock button of transmitter. Check if the diagnostic trouble code is set. Q: Is the DTC set? YES: Go to Step 2. NO: The diagnosis is complete.
  2. STEP 2. Check whether the diagnostic trouble code is reset. Replace the transmitter by which the diagnostic trouble code is set with a new one, register the key (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ), and recheck if the diagnostic trouble code is set. Push the lock button or unlock button of transmitter. Check if the diagnostic trouble code is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). NO: The diagnosis is complete.

DTC B1A10: Keyless/KOS key 1 low battery; DTC B1A11: Keyless/KOS key 2 low battery; DTC B1A12: Keyless/KOS key 3 low battery; DTC B1A13: Keyless/KOS key 4 low battery; DTC B1A14: Keyless key 5 low battery; DTC B1A15: Keyless key 6 low battery; DTC B1A16: Keyless key 7 low battery; DTC B1A17: Keyless key 8 low battery

CAUTIONWhen replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1A10, B1A11, B1A12, B1A13, B1A14, B1A15, B1A16, or B1A17 when it receives low battery voltage signal from the transmitter.

  1. B1A10: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 1 (the first transmitter registered in WCM) five consecutive times.
  2. B1A11: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 2 (the second transmitter registered in WCM) five consecutive times.
  3. B1A12: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 3 (the third transmitter registered in WCM) five consecutive times.
  4. B1A13: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 4 (the fourth transmitter registered in WCM) five consecutive times.
  5. B1A14: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 5 (the fifth transmitter registered in WCM) five consecutive times.
  6. B1A15: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 6 (the sixth transmitter registered in WCM) five consecutive times.
  7. B1A16: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 7 (the seventh transmitter registered in WCM) five consecutive times.
  8. B1A17: WCM determines that the abnormality is present when it receives low battery voltage signal from the transmitter 8 (the eighth transmitter registered in WCM) five consecutive times.
  1. Battery failure in the transmitter
  2. Malfunction of the transmitter
  3. Malfunction of WCM
  1. STEP 1. Replace the battery in the transmitter and recheck the diagnostic trouble code. Replace the battery in the transmitter by which the DTC is set with a new one, and recheck if the DTC is set (Refer to «TRANSMITTER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Replace the battery in the transmitter by which the DTC is set. Use the transmitter to lock/unlock the doors. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 2. NO: The diagnosis is complete (Discharged battery).
  2. STEP 2. Replace the transmitter and recheck the diagnostic trouble code. Replace the transmitter by which the DTC is set with a new one, register the key ID and the keyless entry secret code (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ), and recheck if the DTC is set. Use the transmitter to lock/unlock the doors. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). NO: The diagnosis is complete.

DTC B1A24: Key ID not registered

CAUTIONWhen the DTC B1A24 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1A24 when the encrypted code was not registered in it.

WCM determines that the abnormality is present, if the ignition key's key ID is not registered in WCM when the ignition switch is turned ON.

  1. Key ID not registered
  2. Malfunction of the ignition key
  3. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Register the key ID and recheck the diagnostic trouble code. Register the key ID of the ignition key (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The procedure is complete.

DTC B1A25: Key ID unmatched

CAUTIONWhen the DTC B1A25 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1A25 when the received key ID is different from the one registered in it.

WCM determines that the abnormality is present, if the key ID for the ignition key does not match the one registered in WCM when the ignition switch is turned ON.

  1. Malfunction of the ignition key
  2. Accessory key not registered
  3. Accessory WCM not registered
  4. Key is registered to another vehicle
  5. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Register the key ID and recheck the diagnostic trouble code. Register the key ID of the ignition key (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Replace the ignition key and recheck the diagnostic trouble code. Replace the ignition key by which the DTC is set with the other key, and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Register the key ID and recheck the diagnostic trouble code. Register the key ID of the ignition key (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 5. NO: The procedure is complete.
  5. STEP 5. Replace the ignition key and recheck the diagnostic trouble code. Replace the ignition key with a new one, register the key ID and keyless ID of the new key, (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). NO: The procedure is complete.

DTC B1A28: Engine control module authenticate error

CAUTIONWhen the DTC B1A28 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1A28 when the ignition key certification result and the engine control module starting condition do not match.

WCM determines that the abnormality is present, if the key certification result and the engine control module starting condition do not match after the engine start permission communication is completed.

  1. Malfunction of CAN bus line
  2. Malfunction of WCM
  3. Engine control module malfunction
  4. VIN registered in engine control module unmatched

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the engine control module diagnostic trouble code. Check again if the DTC is set to the engine control module. Q: Is the DTC set? YES: Troubleshoot the MFI system (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the diagnostic trouble code. Check if the DTC is set to the WCM. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is DTC B1761 or B2206 set other than B1A28? YES: Perform the troubleshooting for each DTC. Refer to «DTC B1761: VIN CODE NOT PROGRAMMED»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__dtc-b1761-vin-code-not-programmed) and «DTC B2206: VIN CODE MISMATCH»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) . NO: Go to Step 4.
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 5. NO: The diagnosis is complete.
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace the engine control module and record VIN (Refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) ). NO: The procedure is complete.

DTC B1A35: Transponder read error

CAUTIONWhen DTC B1A35 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

WCM sets DTC B1A35 when it cannot receive data from the transponder.

WCM determines that the abnormality is present, if it cannot receive the key ID for the ignition key when the ignition switch is turned ON.

  1. Malfunction of the ignition key
  2. Malfunction of WCM
  3. Interference of the encrypted code

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Check the ignition key inserted in the key cylinder for interference. Q: Are there other ignition keys or anything that interferes with the communication (things that generate radio waves such as magnets or air-cleaning device that has a power plug) near the ignition key inserted in the key cylinder? YES: Move away or remove other ignition keys or anything that interferes with the communication, and go to Step 3. NO: Go to Step 3.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 4. NO: The procedure is complete.
  4. STEP 4. Replace the ignition key and recheck the diagnostic trouble code. Replace the ignition key by which the DTC is set with the other key, and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 5. NO: Go to Step 6 .
  5. STEP 5. Register the key ID and recheck the diagnostic trouble code. Register the key ID of the ignition key (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Go to Step 6. NO: The procedure is complete.
  6. STEP 6. Replace the ignition key and recheck the diagnostic trouble code. Replace the ignition key by which the DTC is set with a new one, register the key ID of the new key, (refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). NO: The procedure is complete.

Scheme 14

Scheme 14: DTC B2101: IG SW start POS.circuit low; DTC B2102: IG SW start POS.circuit high
Scheme 14: DTC B2101: IG SW start POS.circuit low; DTC B2102: IG SW start POS.circuit high

WCM sets DTC B2101 or B2012 when the actual state of the ignition switch and the ignition switch position information received from ETACS-ECU via CAN do not match.

WCM determines that the abnormality is present, if it has detected discrepancy in the ignition switch level shown below ten consecutive times when WCM has received the CAN message (ignition switch position information) from ETACS-ECU with the ignition switch turned to the ON or START position.

B2101

  1. Status of ignition switch: OFF position
  2. Ignition switch position information from the ETACS-ECU: ON

B2102

  1. Status of ignition switch: ON position
  2. Ignition switch position information from the ETACS-ECU: OFF
  1. Malfunction of CAN bus line
  2. Malfunction of the WCM
  3. Malfunction of the ignition switch
  4. Damaged wiring harness and connectors
  5. Malfunction of ETACS-ECU

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Check ETACS-ECU connector C-317 and WCM connector C-09 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-317 and WCM connector C-09 in good condition? YES: Go to Step 3. NO: Repair the defective connector.
  3. STEP 3. Check the wiring harness between WCM connector C-09 (terminal No. 9) and ETACS-ECU connector C-317 (terminal No .5). Check the power supply line for open circuit. NOTE: Also check joint connector (1) C-03 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (1) C-03 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between WCM connector C-09 (terminal No. 9) and ETACS-ECU connector C-317 (terminal No. 5) in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector.
  4. STEP 4. Using scan tool MB991958, check data list. Use the ETACS-ECU data list to check the signals related to the ignition voltage. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. DATA LIST ITEM 254 Item No. Item name Normal conditions Item 254 IG voltage Battery positive voltage Q: Does scan tool MB991958 display the item "IG voltage" as normal condition? YES: Go to Step 5. NO: Diagnose the ETACS-ECU. Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) .
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC B2204: Coding data mismatch

CAUTIONWhen DTC B2204 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

If the vehicle information data transmitted from the ETACS-ECU via the CAN bus lines is different from that registered in the WCM, the WCM sets the DTC No. B2204.

WCM determines that the abnormality is present when the vehicle information registered in it does not match the vehicle information data.

  1. Malfunction of WCM
  2. Malfunction of ETACS-ECU

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code Check if a coding-related DTC is set in the ETACS-ECU. Q: Is the DTC set? YES: Troubleshoot the ETACS. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) .) NO: Go to Step 3.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

WCM sets DTC B2206 when chassis number registered in it and the VIN that has been transmitted on the CAN bus do not match.

WCM determines that the abnormality is present when VIN registered in it and the one that has been transmitted on the CAN bus do not match.

  1. Malfunction of WCM
  2. VIN registered in engine ECU unmatched
  3. WCM being registered to another vehicle

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Check the VIN registered in the engine control module and the VIN of the vehicle. Check if the VIN registered in the engine control module matches with the VIN of the vehicle. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. On the system selection screen of the M.U.T.-III, select "MFI/GDI/Diesel". Select "Coding." Select "VIN Information." Compare with the VIN of the vehicle. Q: Does the VIN of the engine control module match with the VIN of the vehicle? YES: Go to Step 2. NO: Write the VIN to the engine control module. [Refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) ]. Record VIN and go to Step 2.
  2. STEP 2. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). After registering the ID codes, go to Step 3. NO: The procedure is complete.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Turn the ignition switch to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace the engine control module and record the VIN [Refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) ]. NO: The procedure is complete.

WCM sets the DTC B2352 when open or short circuit to the ground in the antenna is detected.

When the ignition switch is turned ON, WCM transmits signal to the antenna. When the antenna is found faulty, WCM determines that the abnormality is present.

TROUBLESHOOTING HINT

Malfunction of WCM (Open circuit in antenna)

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Recheck for diagnostic trouble code.

Check again if the DTC is set to the WCM.

CAUTIONTo prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958).
  1. Connect scan tool MB991958 to the data link connector. Erase the DTC.
  2. Turn the ignition switch from "LOCK" (OFF) position to "ON" position.
  3. Check if DTC is set.
  4. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The procedure is complete.

DTC B2401: Keyless/KOS key ID not register

CAUTIONIf the DTC B2401 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

If the keyless ID registered transmitter is not registered to the WCM, the WCM sets the DTC No. B2401.

If the number of keyless ID registered transmitter is zero, the WCM determines that there is a problem.

  1. Malfunction of CAN bus line
  2. Failure of transmitter registration process
  3. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958). Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Register the transmitter and recheck the diagnostic trouble code. Register the keyless ID (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ), and recheck if the DTC is set. Erase the DTC. Turn the ignition switch from the "LOCK" (OFF) position to the "ON" position. Check if the DTC is set. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The procedure is complete.

WCM sets DTC B2416 when it determines an abnormal status within itself.

WCM determines that the abnormality is present, if the data abnormality is found when the ignition switch is turned ON and then EEPROM is written.

Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Recheck for diagnostic trouble code.

Check again if the DTC is set to the WCM.

CAUTIONTo prevent damage to scan tool (MB991958), always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool (MB991958).
  1. Connect scan tool MB991958 to the data link connector.
  2. Erase the DTC.
  3. Turn the ignition switch from "LOCK" (OFF) position to "ON" position.
  4. Check if DTC is set.
  5. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC C1608: EEPROM Error

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

WCM incorporates EEPROM (nonvolatile memory), and that EEPROM stores the TPMS, WCM and immobilizer information. When the data in EEPROM is failed, this code is set.

The most likely causes for this DTC to set are

  1. Damaged wiring harness and connector
  2. Malfunction of WCM

Required Special Tools

  1. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN BUS LINE DIAGNOSTIC FLOW»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code check Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1608 set? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then go to Step 3. NO: The procedure is complete.
  3. STEP 3. Diagnostic trouble code check Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1608 set? YES: Start over at Step 1 . NO: The procedure is complete.

DTC C1900: No Registration

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

When the ID registration information of the TPMS transmitter is not stored in the WCM, and/or when the WCM is replaced with a new one, this code is set. If the ID registration mode is terminated forcibly or time-out after one or more TPMS transmitters are registered in the ID registration mode, the ID information in the WCM is erased, and this diagnostic trouble code is set.

The most likely causes for this DTC to set are

  1. Damaged wiring harness and connector
  2. Malfunction of TPMS transmitter
  3. Malfunction of WCM
  4. ID code registration failed.

Required Special Tools

  1. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 2. NO: Repair the CAN bus lines (Refer to «CAN COMMUNICATION-RELATED DTC (U-CODE) TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-communication-related-dtc-u-code-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code check Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1900 set? YES: Register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then go to Step 3. NO: The procedure is complete.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1900 reset? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then start over at Step 1 . NO: The procedure is complete.

DTC C1901: Vehicle speed information abnormality

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

WCM receives the wheel speed information from ASC-ECU via the CAN-bus line. Although WCM receives the information that the wheel is not currently rotated from ASC-ECU, if the TPMS transmitter sends the information that the wheel is rotated, this code is set.

The most likely causes for this DTC to set are

  1. Damaged wiring harness and connector
  2. Malfunction of TPMS transmitter
  3. Malfunction of WCM
  4. Malfunction of ASC-ECU
  5. Malfunction of ETACS-ECU

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1901 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Check for other diagnostic trouble code. Check if the diagnostic trouble code is set from ASC-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) ). Q: Is the check result normal? YES: Go to Step 4. NO: Carry out the troubleshooting for ASC-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) ). Then go to Step 6 .
  4. STEP 4. Check for other diagnostic trouble code. Check if the diagnostic trouble code is set from ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). Q: Is the check result normal? YES: Go to Step 5. NO: Troubleshoot the set DTC (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). Then go to Step 6 .
  5. STEP 5. Check the TPMS transmitter acceleration. Check the acceleration value of each TPMS transmitter by the air pressure of data list (Refer to «DATA LIST REFERENCE TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__data-list-reference-table) ). OK: Acceleration value: 5G or less Q: Is the check result OK? YES: Replace the WCM and register ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 6. NO: Replace the TPMS transmitter and register ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 6.
  6. STEP 6. Recheck for diagnostic trouble code. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1901 set? YES: Start over at Step 1 . NO: The procedure is complete.

DTC C1910: Transmitter low battery voltage abnormality 1; DTC C1920: Transmitter low battery voltage abnormality 2; DTC C1930: Transmitter low battery voltage abnormality 3; DTC C1940: Transmitter low battery voltage abnormality 4; DTC C1911: Reception abnormality 1; DTC C1921: Reception abnormality 2; DTC C1931: Reception abnormality 3; DTC C1941: Reception abnormality 4

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

DTC C1910, C1920, C1930, C1940

  1. When the reception abnormality warning is activated because of the low battery voltage of the TPMS transmitter.

DTC C1911, C1921, C1931, C1941

  1. When WCM cannot receive the signals from the TPMS transmitters while driving for about 20 minutes, this code is set.

The most likely causes for this DTC to set are

  1. Low battery that is incorporated into the TPMS transmitter
  2. Damaged wiring harness and connector
  3. Registered IDs unmatched
  4. Malfunction of TPMS transmitter
  5. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Q: Is the DTC C1910, C1920, C1930, C1940, C1911, C1921, C1931 or C1941 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Check for TPMS transmitter. Identify the TPMS transmitter which the DTC is set by TPMS transmitter check (Refer to «CHECK AT ECU TERMINALS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). NOTE: The TPMS transmitter which cannot be checked may be faulty or the ID code may not be registered, thus do not replace it, but register the ID code. If the transmitter is faulty, it is replaced in the ID code registration process. Q: Are there any TPMS transmitters which are identified? YES: Among the checked TPMS transmitters, replace the TPMS transmitters to which the DTC is set. Then register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 4. NO: Even when no transmitter is checked, register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then go to Step 4.
  4. STEP 4. Diagnostic trouble code recheck after register the ID codes Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1910, C1920, C1930, C1940, C1911, C1921, C1931 or C1941 set? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then start over at Step 1 . NO: The procedure is complete.

DTC C1912: Tire inflation pressure warning 1; DTC C1922: Tire inflation pressure warning 2; DTC C1932: Tire inflation pressure warning 3; DTC C1942: Tire inflation pressure warning 4

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

When the tire pressure included in the signal from the TPMS transmitter is less than the specified value, WCM sets this code.

The most likely causes for this DTC to set is

  1. Drop of tire pressure
  2. Loose TPMS transmitter mounting nut
  3. Flat tire
  4. TPMS transmitter malfunction
  5. WCM malfunction
  6. CAN-bus line malfunction

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Q: Is DTC C1912, C1922, C1932 or C1942 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Tire check Check that there is no abnormality for the items below. Flat tire Cracked tire Air leak from valve Loose TPMS transmitter mounting nut (Refer to «TPMS TRANSMITTER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Q: Is the check result normal? YES: Go to Step 4. NO: Repair or replace it. Then go to Step 4.
  4. STEP 4. Diagnostic trouble code check Turn the ignition switch to the "ON" position, and adjust the pressure to the recommended tire pressure. Check if the DTC is set. Q: Is DTC C1912, C1922, C1932 or C1942 set? YES: Go to Step 5. NO: The procedure is complete.
  5. STEP 5. Diagnostic trouble code check Drive the vehicle for five minutes. NOTE: Even within 5 minutes, if the TPMS warning light goes out, finish the driving and perform the operation (2). Check if the DTC is set. Q: Is DTC C1912, C1922, C1932 or C1942 set? YES: Go to Step 6. NO: The procedure is complete.
  6. STEP 6. Tire pressure check by M.U.T.-III Perform the transmitter check using the M.U.T.-III (Refer to «REGISTRATION USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__registration-using-scan-tool-mb991958-mut-iii) ), and check the tire pressure values of all the wheels. Check the tire pressure of all the wheels using the tire pressure gauge. Compare the measured value (1) with (2). OK: 20 kPa (2.9 psi) or less NOTE: Do not replace the TPMS transmitter which cannot be checked. Q: Is the check result OK? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 9 . NO: Go to Step 7.
  7. STEP 7. Tire pressure check by M.U.T.-III Perform the transmitter check using the M.U.T.-III (Refer to «REGISTRATION USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__registration-using-scan-tool-mb991958-mut-iii) ), and check the tire pressure values of all the wheels. Check the tire pressure of all the wheels using the tire pressure gauge. Compare the measured value (1) with (2). OK: 20 kPa (2.9 psi) or less Q: Is the check result OK? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 9 . NO: Replace the TPMS transmitter and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 8.
  8. STEP 8. Recheck for diagnostic trouble code. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1912, C1922, C1932 or C1942 set? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 9. NO: The procedure is complete.
  9. STEP 9. Recheck for diagnostic trouble code. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1912, C1922, C1932 or C1942 set? YES: Start over at Step 1 . NO: The procedure is complete.

DTC C1913: Acceleration sensor abnormality 1; DTC C1923: Acceleration sensor abnormality 2; DTC C1933: Acceleration sensor abnormality 3; DTC C1943: Acceleration sensor abnormality 4; DTC C1914: Pressure sensor abnormality 1; DTC C1924: Pressure sensor abnormality 2; DTC C1934: Pressure sensor abnormality 3; DTC C1944: Pressure sensor abnormality 4

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

DTC C1913, C1923, C1933, C1943

  1. The TPMS transmitter detects if the wheel is rotated by the acceleration sensor and sends the signals to WCM. When the TPMS transmitter judges that the acceleration sensor is failed, the failure signal is send to WCM, and WCM sets this code.

DTC C1914, C1924, C1934, C1944

  1. The TPMS transmitter detects if the tire pressure sensor is normal and sends the signal to WCM. When the TPMS transmitter judges that the tire pressure sensor is failed, the failure signal is send to WCM, and WCM sets this code.

The most likely causes for this DTC to set are

  1. Low battery that is incorporated into the TPMS transmitter
  2. Damaged wiring harness and connector
  3. Registered IDs unmatched
  4. Malfunction of TPMS transmitter
  5. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Q: Is the DTC C1913, C1923, C1933, C1943, C1914, C1924, C1934 or C1944 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Check for TPMS transmitter. Identify the TPMS transmitter which the DTC is set by TPMS transmitter check (Refer to «CHECK AT ECU TERMINALS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). NOTE: The TPMS transmitter which cannot be checked may be faulty or the ID code may not be registered, thus do not replace it, but register the ID code. If the transmitter is faulty, it is replaced in the ID code registration process. Q: Are there any TPMS transmitters which are identified? YES: Among the checked TPMS transmitters, replace the TPMS transmitters to which the DTC is set. Then register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 4. NO: Even when no transmitter is checked, register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then go to Step 4.
  4. STEP 4. Diagnostic trouble code recheck after register the ID codes Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC C1913, C1923, C1933, C1943, C1914, C1924, C1934 or C1944 set? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then start over at Step 1 . NO: The procedure is complete.

DTC C1915: Transmitter OFF mode 1; DTC C1925: Transmitter OFF mode 2; DTC C1935: Transmitter OFF mode 3; DTC C1945: Transmitter OFF mode 4

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

When the TPMS transmitter(s) is in the OFF MODE, this code is set.

The most likely causes for this DTC to set are

  1. OFF mode cancellation not performed
  2. Damaged wiring harness and connector
  3. Malfunction of TPMS transmitter
  4. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is DTC C1915, C1925, C1935 or C1945 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Diagnostic trouble code check Drive the vehicle for five minutes. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Are the all DTC C1915, C1925, C1935 and C1945 set? YES: Replace the TPMS transmitters of all the four wheels, and register ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 4. NO: Register the ID codes (Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) ). Then go to Step 4.
  4. STEP 4. Diagnostic trouble code recheck after register the ID codes Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is DTC C1915, C1925, C1935 or C1945 set? YES: Replace the WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then start over at Step 1 . NO: The procedure is complete.

DTC U0019: Bus off (CAN-B)

CAUTIONIf DTC U0019 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

If the CAN-B circuit malfunctions, the WCM sets DTC U0019.

If WCM cannot perform the data transmission in normal conditions due to a malfunction of the CAN-B bus circuit, WCM determines that there is a problem.

The CAN bus line may be defective

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/door-locks-anti-theft-systems/#keyless-operation-system-kos-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0141: ETACS-ECU CAN timeout

CAUTIONIf the DTC U0141 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

DIAGNOSTIC FUNCTION

If the signal from ETACS-ECU cannot be received, the WCM sets DTC U0141.

  1. Malfunction of CAN bus line
  2. Malfunction of WCM
  3. Malfunction of ETACS-ECU

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check again if the DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Diagnose the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0141 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0151: SRS-ECU CAN timeout

CAUTIONIf the DTC U0151 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

If no signal from SRS-ECU can be received, WCM sets diagnostic trouble code U0151.

  1. The CAN bus line may be defective
  2. The SRS-ECU may be defective
  3. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the SRS-ECU diagnostic trouble code. Check again if the DTC is set to the SRS-ECU. Q: Is the DTC set? YES: Troubleshoot the SRS (Refer to «DIAGNOSTIC TROUBLE CODE CHART < SRS-ECU >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0151 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the SRS-ECU. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0154: Occupant classification-ECU CAN timeout

CAUTIONIf DTC U0154 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

When the signals from occupant classification-ECU cannot be received, the WCM sets DTC U0154.

  1. The CAN bus line may be defective.
  2. The WCM may be defective.
  3. The occupant classification-ECU may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the SRS-ECU diagnostic trouble code. Check if DTC is set to the SRS-ECU. Q: Is the DTC set? YES: Troubleshoot the SRS. (Refer to «DIAGNOSTIC TROUBLE CODE CHART < Occupant classification-ECU >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) .) NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0154 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the occupant classification-ECU. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0155: Combination meter CAN timeout

CAUTIONIf the diagnostic trouble code U0155 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

TROUBLE JUDGMENT

If no signal from the combination meter can be received, WCM sets DTC U0155.

  1. Malfunction of CAN bus line
  2. Combination meter malfunction
  3. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the combination meter diagnostic trouble code. Check if DTC is set to the combination meter. Q: Is the DTC set? YES: Troubleshoot the combination meter. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#combination-meter-except-lancer-evolution__diagnostic-trouble-code-chart) .) NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C > diagnostic trouble code. Check if the DTC U0155 is set to the A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C >. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the combination meter. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the combination meter and the WCM. (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) )
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the combination meter and the WCM. (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) )

DTC U0164: A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C > CAN timeout

CAUTIONIf DTC U0164 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

If the signal from A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C > cannot be received, the WCM sets DTC U0164.

  1. The CAN bus line may be defective.
  2. The A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C > may be defective.
  3. The WCM may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the A/C < vehicles with A/C > or heater < vehicles without A/C > diagnostic trouble code Check if DTC is set to the A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C >. Q: Is the DTC set? YES: Troubleshoot the A/C < vehicles with A/C > or heater < vehicles without A/C > (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#heating-air-conditioning-and-ventilation-except-lancer-evolution__diagnostic-trouble-code-chart) for MANUAL A/C AND HEATER DIAGNOSIS or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-hvac-system/#automatic-air-conditioning-except-lancer-evolution__diagnostic-trouble-code-chart) for AUTO A/C DIAGNOSIS ). NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0164 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the A/C-ECU < vehicles with A/C > or heater control unit < vehicles without A/C >. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0184: Audio CAN timeout

CAUTIONIf DTC U0184 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

When the signals from radio and CD player or CD changer cannot be received, the WCM sets DTC U0184.

  1. The CAN bus line may be defective.
  2. The WCM may be defective.
  3. The radio and CD player or CD changer may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the audio diagnostic trouble code. Check again if the DTC is set to the audio. Q: Is the DTC set? YES: Troubleshoot the radio and CD player. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/entertainment-systems/#radio-and-cd-player-except-lancer-evolution__diagnostic-trouble-code-chart) < radio and cd player >. NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0184 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the radio and CD player or CD changer. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U0195: Satellite radio tuner CAN timeout

CAUTIONIf DTC U0195 is set to the ETACS-ECU, always diagnose the CAN bus line. Before replacing the ECU, ensure that the communication circuit is normal.

If the signal from satellite radio tuner cannot be received, the WCM sets DTC U0195.

  1. The satellite radio tuner may be defective.
  2. The WCM may be defective.
  3. The CAN bus may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the satellite radio tuner diagnostic trouble code. Check if DTC is set to the satellite radio tuner. Q: Is the DTC set? YES: Troubleshoot the satellite radio. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/entertainment-systems/#satellite-radio-tuner-except-lancer-evolution__diagnosis) .) NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0195 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the satellite radio tuner. NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the satellite radio tuner and the WCM. (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) )
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction such as a poor connection or open circuit in the CAN bus lines between the satellite radio tuner and the WCM. (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) )

DTC U0245: Audio visual navigation unit CAN timeout

CAUTIONIf DTC U0245 is set, be sure to diagnose the CAN bus line. When replacing the ECU, always check that the communication circuit is normal.

When the signals from audio visual navigation unit cannot be received, the WCM sets DTC U0245.

  1. The CAN bus line may be defective.
  2. The WCM may be defective.
  3. The audio visual navigation unit may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the audio visual navigation unit diagnostic trouble code. Check if DTC is set to the audio visual navigation unit. Q: Is the DTC set? YES: Troubleshoot the MMCS. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/entertainment-systems/#mitsubishi-multi-communication-system-mmcs-except-lancer-evolution) < MMCS >.) NO: Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC U0245 is set to the combination meter. Q: Is the DTC set? YES: Go to Step 4. NO: Go to Step 5 .
  4. STEP 4. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace the audio visual navigation unit. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U1412: Implausible vehicle speed signal received

CAUTIONIf there is any problem in the CAN bus lines, an incorrect diagnostic trouble code may be set. Prior to this diagnosis, diagnose the CAN bus lines (Refer to DIAGNOSTIC TROUBLE CODE DIAGNOSIS ).

TPMS DTC SET CONDITION

WCM receives the wheel speed information from ASC-ECU via the CAN-bus line. If WCM cannot receive the information about the wheel speed sensor from ASC-ECU, this code is set.

The most likely causes for this DTC to set are

  1. Damaged wiring harness and connector
  2. Malfunction of ASC-ECU
  3. Malfunction of WCM
  4. Malfunction of ETACS-ECU

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. M.U.T.-III CAN bus diagnostics Use scan tool to diagnose the CAN bus lines. Q: Is the check result normal? YES: Go to Step 3 . NO: Repair the CAN bus lines (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). On completion, go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck after resetting CAN bus lines Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC U1412 set? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Check for other diagnostic trouble code. Check if the diagnostic trouble code is set from ASC-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) ). Q: Is the check result normal? YES: Go to Step 4. NO: Carry out the troubleshooting for ASC-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/anti-locktraction-control/#active-stability-control-system-asc-except-lancer-evolution__diagnostic-trouble-code-chart) ). Then go to Step 5 .
  4. STEP 4. Check for other diagnostic trouble code. Check if the diagnostic trouble code is set from ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). Q: Is the check result normal? YES: Replace the WCM and register ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). Then go to Step 5. NO: Carry out the troubleshooting (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). Then go to Step 5.
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Turn the ignition switch to the "ON" position. Check if the DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC U1412 reset? YES: Start over at Step 1 . NO: The procedure is complete.

DTC U1415: Coding not completed/Data fail

CAUTIONIf DTC U1415 is set, diagnose the CAN bus lines. When replacing the ECU, always check that the communication circuit is normal.

If the vehicle information data is not registered to the combination meter, the WCM sets DTC U1415.

JUDGMENT CRITERIA

With the global coding counter value "0," if all the global coding data (vehicle information) are not stored, the WCM determines that a problem has occurred.

  1. The CAN bus line may be defective.
  2. The WCM may be defective.
  3. The ETACS-ECU may be defective.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check if a coding-related DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Troubleshoot the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
  3. STEP 3. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DTC U1417: Implausible coding data

CAUTIONIf diagnostic trouble code U1417 is set in WCM, always diagnose the CAN bus lines. If there is any fault in the CAN bus lines, an incorrect diagnostic trouble code may be set. In this case, the set diagnostic trouble code is not highly reliable. Before replacing the ECU, ensure that the communication circuit is normal. When diagnostic trouble code U1417 is set in WCM, the diagnostic trouble code may also be set in ETACS-ECU. When the diagnostic trouble code is set in ETACS-ECU, carry out the diagnosis of the diagnostic trouble code for ETACS-ECU first.

CIRCUIT OPERATION

WCM receives the vehicle information stored in the ETACS-ECU via CAN bus lines.

DTC SET CONDITIONS

WCM communicates with ETACS-ECU via CAN bus lines. This diagnostic trouble code is set when the vehicle information received from the ETACS-ECU is invalid.

PROBABLE CAUSES

  1. Malfunction of ETACS-ECU
  2. Engine control module malfunction
  3. ETACS-ECUs have been interchanged between two vehicles.
  4. WCM malfunction
  5. External noise interference
  6. WCMs have been interchanged between two vehicles.

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Using scan tool MB991958, read the other system diagnostic trouble code. Check if DTC is set to the ETACS-ECU or engine control module. Q: Is the DTC set? YES (DTC is set to ETACS-ECU.): Troubleshoot the ETACS. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) .) YES (DTC is set to the engine control module.): Troubleshoot the MFI system. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0-Non turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0-Turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >.) NO: Go to Step 3.
  3. STEP 3. Check part number of ETACS-ECU Check the part number of ETACS-ECU. OK: 8637A465 Q: Is the check result normal? YES: Go to Step 4. NO: Replace ETACS-ECU.
  4. STEP 4. Check part number of WCM Check the part number of WCM. OK: MN141352 Q: Is the check result normal? YES: Go to Step 5. NO: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .)
  5. STEP 5. Recheck for diagnostic trouble code. Check again if the DTC is set to the WCM. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .) NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

DATA LIST REFERENCE TABLE

Item No.Scan tool MB991958 displayCheck conditionsNormal conditions
1Received key data (ID)Key ID for stored ignition key
2Received key data (button)Switch display of transmitter
13Number of registered IMMOB.keyNumber of stored ignition keys (Number of registered ignition keys that can start the engine)
21Air pressure, Tire 1
22Air pressure, Tire 2
23Air pressure, Tire 3
24Air pressure, Tire 4
25 (1)Air pressure, Tire 5
31Acceleration, Tire 1
32Acceleration, Tire 2
33Acceleration, Tire 3
34Acceleration, Tire 4
35 (1)Acceleration, Tire 5
36Threshold of PRS. warningThe tire pressure is within the specified value range.OFF
The tire pressure is not within the specified value range.ON
37Threshold of PRS. warning releaseThe tire pressure is within the specified value range.ON
The tire pressure is not within the specified value range.OFF
38Number of registered TPMS IDNumber of stored TPMS
39Ignition signal (CAN data)Ignition switch status information received from ETACS-ECU via CAN:ONON
Ignition switch status information received from ETACS-ECU via CAN:OFFOFF
40Ignition signal (Port input)Ignition switch: ONON
Ignition switch: OFFOFF
41VSSDrive the vehicleThe scan tool and the speedometer readings are approximately the same
50Registered ID reception, Tier1Ignition switch: ONYes
Ignition switch: OFFNo
51Registered ID reception, Tier2Ignition switch: ONYes
Ignition switch: OFFNo
52Registered ID reception, Tier3Ignition switch: ONYes
Ignition switch: OFFNo
53Registered ID reception, Tier4Ignition switch: ONYes
Ignition switch: OFFNo
54 (1)Registered ID reception, Tier5
61Air pressure, Tire1 (not adjusted)
62Air pressure, Tire2 (not adjusted)
63Air pressure, Tire3 (not adjusted)
64Air pressure, Tire4 (not adjusted)
65 (1)Air pressure, Tire5 (not adjusted)
NOTE: (1) shows that it is displayed but not used.
NOTE
(1) shows that it is displayed but not used.
(1)Shows that it is displayed but not used.

DATA LIST REFERENCE TABLE

TROUBLE SYMPTOM CHART

CAUTIONDuring diagnosis, a DTC associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, check all systems for DTC(s). If DTC(s) are set, erase them all.
Trouble symptomInspection procedure numberReference
Scan tool cannot communicate with WCM.1INSPECTION PROCEDURE 1: SCAN TOOL CANNOT COMMUNICATE WITH WCM.
The ignition key cannot be registered using scan tool.2INSPECTION PROCEDURE 2: THE IGNITION KEY CANNOT BE REGISTERED USING SCAN TOOL.
Engine does not start.3INSPECTION PROCEDURE 3: ENGINE DOES NOT START.
Abnormality in WCM power supply and ground circuits.4INSPECTION PROCEDURE 4: ABNORMALITY IN WCM POWER SUPPLY AND GROUND CIRCUITS.
Keyless entry system does not work.5INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK.
Keyless entry hazard light answerback function, the dome light answerback function or the horn answerback function does not work normally.6INSPECTION PROCEDURE 6: KEYLESS ENTRY HAZARD LIGHT ANSWERBACK FUNCTION, THE DOME LIGHT ANSWERBACK FUNCTION OR THE HORN ANSWERBACK FUNCTION DOES NOT WORK NORMALLY.
The timer lock function does not work after the doors have been unlocked by the keyless entry system.7INSPECTION PROCEDURE 7: THE TIMER LOCK FUNCTION DOES NOT WORK AFTER THE DOORS HAVE BEEN UNLOCKED BY THE KEYLESS ENTRY SYSTEM.
The trunk is not opened when the keyless entry transmitter "TRUNK" button is operated < LANCER >.8INSPECTION PROCEDURE 8: THE TRUNK IS NOT OPENED WHEN THE KEYLESS ENTRY TRANSMITTER "TRUNK" BUTTON IS OPERATED < LANCER >.
Power door locks with selective unlocking does not work.9INSPECTION PROCEDURE 9: POWER DOOR LOCKS WITH SELECTIVE UNLOCKING DOES NOT WORK.

TROUBLE SYMPTOM CHART

Inspection Procedure 1: Scan tool cannot communicate with WCM

CAUTIONBefore replacing the ECU, ensure that the communication circuit is normal.

If the M.U.T.-III cannot communicate with the WCM, the CAN bus lines may be defective. If the WCM does not work, the WCM or the power supply circuit may be defective.

  1. Malfunction of the power supply or ground of WCM
  2. Malfunction of CAN bus line
  3. Malfunction of WCM

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  2. STEP 2. Check the power supply circuit and the ground circuit to WCM. Refer to «INSPECTION PROCEDURE 4: ABNORMALITY IN WCM POWER SUPPLY AND GROUND CIRCUITS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__inspection-procedure-4-abnormality-in-wcm) . Q: Are the power supply circuit and the ground circuit to WCM in good condition? YES: Go to Step 3. NO: Repair the power supply circuit and the ground circuit to WCM.
  3. STEP 3. Retest the system Check if scan tool can communicate with WCM. Q: Does the scan tool cannot communicate with WCM in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .)

If only some ignition keys cannot be registered, the ignition key itself may be faulty. If no ignition key can be registered, the key assembly may have already been registered for another vehicle, or the WCM may be faulty.

  1. Malfunction of the ignition key
  2. Damaged wiring harness and connectors
  3. Malfunction of WCM
  4. Ignition key registered for other vehicle

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Check the ignition key inserted in the key cylinder for interference. Q: Are there other ignition keys or anything that interferes with the communication (things that generate radio waves such as magnets and an air-cleaning device that has a power plug) near the ignition key inserted in the key cylinder? YES: Move away or remove other ignition keys or things that interfere with the communication (things that generate radio waves such as magnets and a air-cleaning device that has a power plug) near the ignition key. Then, go to step 2. NO: Go to Step 3 .
  2. STEP 2. Retest the system Check that the ignition key can be registered. Q: Is the ignition key that cannot be registered using scan tool? YES: Go to Step 3. NO: The procedure is complete.
  3. STEP 3. Check which ignition key cannot be registered. Q: Can any one of the ignition keys be registered? YES (Only some keys): Replace the key that cannot be registered and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). After registering the ID codes, go to Step 5 . NO (All keys): Go to Step 4.
  4. STEP 4. Retest the system Check the scan tool screen when the key was not able to be registered. Q: Is the error message of scan tool screen "Abnormality in key"? YES (Abnormality in key): Carry out DTC B1A25: Key ID unmatched and DTC B1A35: Transponder read error (Refer to «DTC B1A25: KEY ID UNMATCHED»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__dtc-b1a25-key-id-unmatched) and «DTC B1A35: TRANSPONDER READ ERROR»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__dtc-b1a35-transponder-read-error) ). Then, go to Step 5. NO (ECU internal error): Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ).
  5. STEP 5. Retest the system Check that the ignition key can be registered. Q: Is the ignition key that cannot be registered using scan tool? YES: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ). NO: The procedure is complete.

If the fuel injection does not work, WCM and the MFI system may have a problem. This symptom is not considered abnormal when the engine is started by an ignition key that has not been registered.

  1. Malfunction of battery
  2. Malfunction of the MFI system
  3. Malfunction of WCM
  4. Malfunction of CAN bus line
  5. Malfunction of the transponder
  6. VIN not programmed

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
  1. STEP 1. Check the battery voltage. Measure the battery voltage when cranking. The voltage should measure 8 volt or more. Q: Is the measured voltage 8 volt or more? YES: Go to Step 2. NO: Check the battery. (Refer to «BATTERY TEST»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#battery-except-lancer-evolution) .)
  2. STEP 2. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
  3. STEP 3. Using scan tool MB991958, read the MFI system diagnostic trouble code. Check if DTC is set to the engine control module. Q: Is the DTC set? YES: Troubleshoot the MFI system. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >.) NO: Go to Step 4.
  4. STEP 4. Using scan tool MB991958, read the WCM diagnostic trouble code. Check if DTC is set to the WCM. Q: Is the DTC set? YES: Troubleshoot the WCM. (Refer to «STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__standard-flow-of-diagnostic-troubleshooting) .) NO: Go to Step 5.
  5. STEP 5. Check that the engine starts. Q: Does the engine start? YES: The procedure is complete. NO: Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo > or «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >. When the cause of the failure cannot be tracked down by the troubleshooting in MFI system, replace WCM and register the ID codes. (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) .)

Inspection Procedure 4: Abnormality in WCM power supply and ground circuits

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the WCM does not work at all or if the WCM cannot communicate with the scan tool, the WCM power supply or the ground circuit may be defective.

  1. Damaged wiring harness and connectors
  2. Malfunction of the WCM

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. STEP 1. Check WCM connector C-09 and ETACS-ECU connector C-317 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is the WCM connector C-09 and ETACS-ECU connector C-317 in good condition? YES: Go to Step 2. NO: Repair the defective connector.
  2. STEP 2. Check the wiring harness between WCM connector C-09 (terminal No. 6, 9) and the ETACS-ECU connector C-317 (terminal No. 10, 5) for open circuit. Disconnect WCM connector C-09 and ETACS-ECU connector C-317, and check the wiring harness. Check the wiring harness between WCM connector C-09 (terminal No. 6) and ETACS-ECU connector C-317 (terminal No. 10) OK: Continuity exists (2 ohms or less) Check the wiring harness between WCM connector C-09 (terminal No. 9) and ETACS-ECU connector C-317 (terminal No. 5) OK: Continuity exists (2 ohms or less) NOTE: Also check joint connector (1) C-03 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (1) C-03 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between WCM connector C-09 and the ETACS-ECU connector C-317 in good condition? YES: Go to Step 3. NO: Repair the wiring harness between WCM connector C-09 (terminal No. 6, 9) and ETACS-ECU connector C-317 (terminal No. 10, 5).
  3. STEP 3. Check the wiring harness between the WCM connector C-09 (terminal No. 7) and the ground for open circuit. Disconnect the connector and measure the resistance at the wiring harness side. Turn the ignition switch to the ON position. Measure the resistance between terminal No. 7 and the ground. OK: Continuity exists (2 ohms or less) Q: Is the wiring harness between WCM connector C-09 and the ground in good condition? YES: Go to Step 4. NO: Repair the wiring harness between WCM connector C-09 (terminal No. 7) and ground.
  4. STEP 4. Retest the system Q: Does the abnormality in WCM power supply and ground circuits in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ).

Inspection Procedure 5: Keyless entry system does not work

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

The lock/unlock signals from the transmitter are received by WCM, and then sent to ETACS-ECU from WCM. When ETACS-ECU receives signals from the key reminder switch and all the door switches, ETACS-ECU actuates the keyless entry system.

  1. The key reminder switch may be defective
  2. The door switches may be defective
  3. The liftgate latch assembly may defective < LANCER SPORTBACK >
  4. The keyless entry transmitter may be defective
  5. The WCM may be defective
  6. The ETACS-ECU may be defective
  7. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  8. Option coding information

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, check for CAN bus the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the CAN bus lines related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Repair the CAN bus line (Refer to «CAN BUS DIAGNOSTICS TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__can-bus-diagnostics-table) ). NO: Go to Step 2.
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
  3. STEP 3. Check the power supply system With the ignition switch in the LOCK (OFF) position, check if the following function operates normally: Hazard warning light Q: Is the check result normal? YES: Go to Step 4. NO: Refer to «MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .
  4. STEP 4. Verify the central door locking system. Check that the central door locking system works normally. Q: Is the check result normal? YES: Go to Step 5. NO: Refer to «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/door-locks-anti-theft-systems/#door-system-except-lancer-evolution__trouble-symptom-chart) .
  5. STEP 5. Using scan tool MB991958, check data list. Check the signals related to the keyless entry system operation. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "LOCK" (OFF) position. Check the ETACS data list. Close the driver's door. Close the passenger's door. Close the RH-side rear door. Close the LH-side rear door. Close the liftgate < LANCER SPORTBACK >. Remove the ignition key from the ignition key cylinder. ETACS DATA LIST ITEMS TABLE Item No. Item name Normal condition Item 256 Dr door ajar switch Close Item 257 As door ajar switch Close Item 258 RR door ajar switch Close Item 259 RL door ajar switch Close Item 260 Trunk/gate trunk ajar switch Close Item 264 Handle lock switch Key in --> Key out OK: Normal condition are displayed. Q: Are the check result normal? YES < Normal conditions are displayed for all the items. >: Go to Step 6. NO < Normal condition is not displayed for item No. 256. >: Refer to «INSPECTION PROCEDURE 6: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE FRONT DOOR SWITCH (RH)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) . NO < Normal condition is not displayed for item No. 257. >: Refer to «INSPECTION PROCEDURE 5: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE FRONT DOOR SWITCH (LH)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) . NO < Normal condition is not displayed for item No. 258. >: Refer to «INSPECTION PROCEDURE 8: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE REAR DOOR SWITCH (RH)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) . NO < Normal condition is not displayed for item No. 259. >: Refer to «INSPECTION PROCEDURE 7: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE REAR DOOR SWITCH (LH)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) . NO < Normal condition is not displayed for item No. 260 (LANCER SPORTBACK). >: Refer to «INSPECTION PROCEDURE 9: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE LIFTGATE SWITCH. < LANCER SPORTBACK >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) . NO < Normal condition is not displayed for item No. 264. >: Refer to «INSPECTION PROCEDURE 3: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE KEY REMINDER SWITCH»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .
  6. STEP 6. Retest the system. Check if the keyless entry system works normally. Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace WCM and register the ID codes (Refer to «ID CODES REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) ).

Inspection Procedure 6: Keyless entry hazard light answerback function, the dome light answerback function or the horn answerback function does not work normally

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the hazard warning light and the dome light works normally, ETACS-ECU may be faulty. Also, the answerback function may have been disabled using the customization function.

  1. The turn signal lights may be defective
  2. The dome light may be defective
  3. The horn may be defective
  4. The ETACS-ECU may be defective
  5. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  1. STEP 1. Verify the operation hazard warning light. Check that the hazard warning light illuminate normally. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 1: THE HAZARD WARNING LIGHT DO NOT ILLUMINATE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/steering-column-switches/#hazard-warning-light-switch-except-lancer-evolution__inspection-procedure-1-the-hazard-warning) .
  2. STEP 2. Verify the operation of the dome light. Check that the dome lights illuminate normally. Q: Is the check result normal? YES: Go to Step 3. NO: Refer to «INSPECTION PROCEDURE 1: THE FRONT DOME LIGHT DOES NOT ILLUMINATE NORMALLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/interiorillumination-lights/#dome-light-except-lancer-evolution__inspection-procedure-1-the-front-dome) or «INSPECTION PROCEDURE 2: THE REAR DOME LIGHT DOES NOT ILLUMINATE NORMALLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/interiorillumination-lights/#dome-light-except-lancer-evolution__inspection-procedure-2-the-rear-dome) .
  3. STEP 3. Verify the horn. Check that the horn normally. Q: Is the check result normal? YES: Go to Step 4. NO: Replace the horn (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/steering-column-switches/#hazard-warning-light-switch-except-lancer-evolution__removal-and-installation) ).
  4. STEP 4. Check the operation of the keyless entry system. Operate the transmitter and check that all doors lock and unlock. Q: Is the check result normal? YES: Go to Step 5. NO: Refer to «INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__inspection-procedure-5-keyless-entry-system) ."
  5. STEP 5. Check the customize function (Hazard light answerback). Check that any one of the followings other than "Lock: 0, Unlock: 0" is set for "Hazard answerback" with a customization function. Lock:1, Unlock:2 Lock:1, Unlock:0 Lock:0, Unlock:2 Lock:2, Unlock:1 Lock:2, Unlock:0 Lock:0, Unlock:1 Q: Is the check result normal? YES: Go to Step 6. NO: Set "Hazard answerback" to any one other than "Lock: 0, Unlock: 0" with a customization function (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__customization-function) ).
  6. STEP 6. Check the customize function (Horn answerback). Check that any one of the followings other than "Not sound horn" is set for "Horn chirp by keyless" with a customization function. Lock any time W lock any time Q: Is the check result normal? YES: Go to Step 7. NO: Set "Horn chirp by keyless" to any one other than "Not sound horn" with a customization function (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__customization-function) ).
  7. STEP 7. Check of the troubles Check if the keyless entry answerback function works normally. Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace ETACS-ECU.

Inspection Procedure 7: The timer lock function does not work after the doors have been unlocked by the keyless entry system

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the timer lock function does not work normally, the keyless entry transmitter input signal circuit or ETACS-ECU may be faulty.

  1. The keyless entry transmitter may be defective
  2. The ETACS-ECU may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  1. STEP 1. Check the operation of the keyless entry system. Operate the transmitter and check that all doors lock and unlock. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__inspection-procedure-5-keyless-entry-system) .
  2. STEP 2. Check the customize function. The "Timer lock timer" has been set to one of the followings with the customization function. Check if the doors are locked at the set period. 30sec 60sec 120sec 180sec Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace ETACS-ECU.

Inspection Procedure 8: The trunk is not opened when the keyless entry transmitter "TRUNK" button is operated < LANCER >

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 18

Scheme 18
Scheme 18

WCM receives the trunk signal from the transmitter, and sends the signal to ETACS-ECU.

  1. The keyless entry transmitter may be defective
  2. The WCM may be defective
  3. The ETACS-ECU may be defective
  4. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A

Scheme 19

Scheme 19
Scheme 19
  1. STEP 1. Check the operation of the keyless entry system. Operate the transmitter and check that all doors lock and unlock. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__inspection-procedure-5-keyless-entry-system) .
  2. STEP 2. Using scan tool MB991958, check for diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
  3. STEP 3. Check trunk lid lock actuator connector F-12 and ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is trunk lid lock actuator connector F-12 and ETACS-ECU connector C-311 in good condition? YES: Go to Step 4. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
  4. STEP 4. Check the trunk lid latch assembly. Remove the trunk lid latch assembly. Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#trunk-lid-lancer) . TRUNK LID LATCH ASSEMBLY CHECK Lever position Battery connection Lever operation At the "LOCK" position Connect terminal No. 2 and the negative battery terminal. Connect terminal No. 3 and the positive battery terminal. The lever moves from the "LOCK" position to the "UNLOCK" position. Q: Is the trunk lid actuator normal? YES: Go to Step 5. NO: Replace the trunk lid latch assembly.
  5. STEP 5. Check the ground circuit to the trunk lid lock actuator. Measure the resistance at trunk lid lock actuator connector F-12. Disconnect trunk lid lock actuator connector F-12 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 2 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 7 . NO: Go to Step 6.
  6. STEP 6. Check the wiring harness between trunk lid lock actuator connector F-12 (terminal 2) and ground. Check the ground wires for open circuit. NOTE: Also check intermediate connector F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-23 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between trunk lid lock actuator connector F-12 (terminal 2) and ground in good condition? YES: No action is necessary and testing is complete. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the trunk lid opener function works normally.
  7. STEP 7. Check the wiring harness between trunk lid lock actuator connector F-12 (terminal 3) and ETACS-ECU connector C-311 (terminal 1). Check the input/output line for open or short circuit. NOTE: Also check intermediate connectors D-14, F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connectors D-14, F-23 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between trunk lid lock actuator connector F-12 (terminal 3) and ETACS-ECU connector C-311 (terminal 1) in good condition? YES: Go to Step 8. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the trunk lid opener function works normally.
  8. STEP 8. Retest the system. Check if the keyless entry system (trunk lid open) works normally. Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU. When the ETACS-ECU is replaced, register the keyless ID. Refer to «ID CODES REGISTRATION PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) .

Inspection Procedure 9: Power door locks with selective unlocking does not work

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

COMMENT ON TROUBLE SYMPTOM

If the keyless entry system works normally and only the power door locks with selective unlocking does not work normally, ETACS-ECU may be defective. In addition, it is possible that the function has been disabled by using the customization function.

  1. Malfunction of ETACS-ECU
  2. Damaged wiring harness and connectors

DIAGNOSTIC PROCEDURE

  1. STEP 1. Check the customization Q: Are the power door locks with selective unlocking enabled by the customization function? YES: Go to Step 2. NO: Set the power door locks with selective unlocking to "Enabled" by using the customization function. Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__customization-function) .
  2. STEP 2. Keyless entry system operation check Press the unlock button of the transmitter and check that only the driver's door is unlocked. Then, press the unlock button once again within 2 seconds after that to check that the front passenger's door, rear doors, and liftgate < LANCER SPORTBACK > are unlocked. Q: Does the keyless entry system work normally? YES: Go to Step 3. NO (Only the driver's door is not unlocked.): Replace the ETACS-ECU. NO (The driver's door, front passenger's door, rear doors, and liftgate < LANCER SPORTBACK > are not unlocked.): Refer to «INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__inspection-procedure-5-keyless-entry-system) .
  3. STEP 3. Check of the troubles Check that the power door locks with selective unlocking works normally. Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace ETACS-ECU.

Scheme 20

Scheme 20: CHECK AT ECU TERMINALS
Scheme 20: CHECK AT ECU TERMINALS
Terminal No.Check itemsCheck conditionsNormal conditions
1 - 5
6Power supply (Battery)AlwaysBattery positive voltage
7GroundAlways1 V or less
8
9Power supply (Ignition switch: IG1)Ignition switch: ONBattery positive voltage
10CAN L
11CAN H

ECU CONNECTOR TERMINAL REFERENCE TABLE

REGISTRATION USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY)

Required Special Tools

  1. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A

The ID codes necessary for the engine immobilizer system, the keyless entry system and the TPMS can be registered using the scan tool MB991958 (M.U.T.-III sub assembly). KOS and keyless operation key are indicated as F.A.S.T and F.A.S.T.-key respectively in the scan tool MB991958 (M.U.T.-III sub assembly) screen.

CAUTIONIf the ignition key with transmitter is added or replaced, register the key (key ID), and then register the keyless ID again.
CAUTIONDo not register the ignition key registered for other vehicles.

SUPPLY UNIT LIST FOR INDIVIDUAL KEY

SUPPLY UNIT LIST FOR INDIVIDUAL KEY (EXCEPT SPORTBACK) Ignition key (without transmitter) Ignition key (with transmitter) < LANCER >

SUPPLY UNIT LIST FOR INDIVIDUAL KEY Ignition key (with transmitter) < LANCER SPORTBACK >

Scheme 21

Scheme 21
Scheme 21

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY (1 OF 2) Full service key set < Vehicles with keyless entry system > Full service key set < Vehicles without keyless entry system (LANCER) > Steering lock service key set (A: Without transmitter, B: With transmitter)

Scheme 22

Scheme 22
Scheme 22

KEY SUPPLY UNIT LIST FOR OTHER THAN INDIVIDUAL KEY (2 OF 20 Door service key set (LH), Door service key set (RH) < Vehicles without keyless entry system > NOTE: Key (It can only be used for locking and unlocking, and it cannot start the engine.) Trunk lid service key set < Vehicles without keyless entry system (LANCER) > NOTE: Key (It can only be used for locking and unlocking, and it cannot start the engine.)

Note. When re-registering the key (key ID and keyless ID), all the keys (key ID and keyless ID) registered before must be re-registered because all of them will be erased. After registering the keys, make sure that the engine is started normally with all of the keys registered.

Screen Flow Of Scan Tool Mb991958 (M.U.T.-Iii Sub Assembly)

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Connect the scan tool to the 16-pin data link connector as follows.

Note. For details on how to use the scan tool, refer to the M.U.T.-III User's Manual.

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Start the scan tool MB991958 system on the personal computer and turn the ignition switch to the "ON" position.
  2. Select "F.A. S.T./IMMO/Keyless/TPMS" button from the "System Select" screen. Then, select the applicable option code item and push the OK button.
  3. Select "Special Function" on the next screen.
  4. Select the button of the operation to be performed from the "Special Function" screen. "Tire Pressure Sensor ID Registration": When the TPMS transmitter is replaced and/or the WCM is replaced. "Tire Pressure Sensor Check": When the tire pressure sensor data is checked. "Tire Pressure Sensor ID Check": When the tire pressure sensor ID is checked. "Key Registration": When the ignition key is replaced or added as a single unit and/or the WCM replaced. "Key Registration (Barcode No.)": When the ignition key is replaced by the full service key set. The steering lock service key set is replaced by the piece. "Keyless ID Reg.": When the ignition key is replaced or added as a single unit and the immobi and keyless key assembly. "ENG Key Code Reg.": It doesn't use it. "ENG Key Code & VIN Reg.": When the engine control module is replaced. "Additional key registration": When the ignition key is added as a single unit. NOTE: For "ENG Key Code & VIN Reg," refer to «HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-perform-vehicle-identification-number) .
  5. After operation check, turn the ignition switch to the "LOCK" (OFF) position.
  6. Remove the scan tool MB991958.

Scheme 27

Scheme 27: "Key Registration"/"Additional key registration" METHOD
Scheme 27: "Key Registration"/"Additional key registration" METHOD

Scheme 28

Scheme 28
Scheme 28
  1. When "Key registration" or "Additional key registration" screen is displayed, enter the password for the key registration and press the OK button. Then, "Executing!" is displayed and the registration process starts. NOTE: If the wrong password is entered consecutively 5 times, the password entry for the key registration will be disabled for 16 minutes. The key registration cannot be cancelled during the operation.
  2. When the key registration is completed, "Completed" is displayed. To register the next key, follow the message on the screen and press the OK button. Then, "Executing!" is displayed again and the registration process for the next key starts. To finish the key registration, press the cancel button. NOTE: In order to register another key consecutively after registering the first key, the ignition switch must be turned to the ON position with the second key within 30 seconds after turning it to the "LOCK" (OFF) position with the first key. Up to eight keys can be registered. When the key cannot be registered using scan tool MB991958, refer to «INSPECTION PROCEDURE 2: THE IGNITION KEY CANNOT BE REGISTERED USING SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) .

Scheme 29

Scheme 29: "Key Registration (Barcode No.)" METHOD
Scheme 29: "Key Registration (Barcode No.)" METHOD

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. When "Key Registration (Barcode No.)" screen is displayed, enter the password for the key registration and press the OK button. NOTE: If the wrong password is entered consecutively 5 times, the password entry for the key registration will be disabled for 16 minutes.
  2. Follow the message on the screen to enter the bar code No., and then press the OK button.
  3. When "Do you want to start?" is displayed, press the OK button to start the registration, or press the Cancel button to cancel the registration.
  4. "Completed" is displayed. Press the OK button to finish the registration. NOTE: When the key cannot be registered using scan tool MB991958, refer to «INSPECTION PROCEDURE 2: THE IGNITION KEY CANNOT BE REGISTERED USING SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution) .

Scheme 33

Scheme 33: "Keyless ID Reg." METHOD
Scheme 33: "Keyless ID Reg." METHOD

Scheme 34

Scheme 34
Scheme 34
  1. On the "Keyless ID Reg." screen, enter the password and press the OK button.
  2. Register within 1 minute and send the programming packet* to register the keyless ID. To register multiple keys, register the next key within 1 minute from the registration operation of previous key. Complete the registration of necessary keys, then press the OK button to finish the keyless ID registration. NOTE: Up to eight ignition keys can be registered. *: Programming packet sending procedure Complete the following steps 1 to 3 within four seconds. Press and hold both the lock and the unlock switch for 1 second or longer. Release both the lock and the unlock switch for 0.5 second or longer. Press the unlock switch.
  3. Push the OK button after "Keyless ID Registration was finished." is displayed.
  4. Check number of the keyless IDs registered.

"Tire Pressure Sensor ID Registration" METHOD

  1. Select "4tires ID Reg. (Change tire PRS.)" and start the tire pressure sensor ID registration. CAUTION: Register all tire pressure sensor IDs within twenty minutes.
  2. "4 SNSR ID Registration Do you want to start? Note Finish ID Registration within 20 minutes." is displayed. Then, press "OK." NOTE: If the ID code registration is not finished within 20 minutes, all the ID codes registered in the TPMS transmitter before will be erased. For this reason, the ID codes need to be registered again.
  3. Decrease the tire pressure to 174 kPa (25.2 psi) or less by changing 20 kPa (2.9 psi) or more, and register the TPMS transmitter ID code of each wheel to WCM. NOTE: You can start out the operations from any TPMS transmitter. The tire pressure sensor ID registration has no order. On completion of the TPMS transmitter ID code registration, the TPMS transmitter ID code is displayed on the scan tool screen. Scan tool cannot identify which registered TPMS transmitter is used for each wheel. For this reason, write down the tire number for each wheel when the tire number and ID code is displayed on the scan tool during ID code registration. It may take approximately one minute for the ID code to be displayed on the scan tool screen after the tire pressure is reduced. If the ID code is not displayed, reduce the tire pressure another 20 kPa (2.9 psi) or more. If the ID code is not displayed yet, rotate the tire to displace the TPMS transmitter, and reduce the tire pressure 20 kPa (2.9 psi) or more again. If the ID code cannot be registered for all the four wheels, the WCM may be faulty, thus replace the WCM. If the ID code can be registered for one wheel or more, the TPMS transmitter in which the code cannot be registered may be faulty, thus replace that TPMS transmitter.
  4. "4 SNSR ID Registration Completed." is displayed. Then, select "OK." NOTE: The TPMS indicator illuminates for tire pressure alarm.
  5. After one minute or more has passed, correct the tire pressure for all wheels with ignition switch "ON".
  6. Check the data list "Registered ID reception, Tire 1, 2, 3, 4" if "YES" is displayed for each tire. When "NO" is displayed, drive the vehicle for approximately 5 minutes, check the display again. If "NO" is still displayed, register the ID code again.

"TPMS transmitter check" METHOD

According to the following procedures, identify which registered TPMS transmitter corresponds to which wheel, and check the tire pressure and acceleration value of each TPMS transmitter.

  1. Check the data list "Air Pressure, Tire1, 2, 3, 4" and write down the tire pressure for all wheels. NOTE: The display at this time is the data received most recently.
  2. Perform the following procedures for four wheels in order, identify the wheel by checking the tire pressure of each wheel. Change the pressure of tire for 20 kPa (2.9 psi) or more so that the TPMS transmitter sends the latest sensor data (The tire pressure can either be decreased or increased). Check the data list screen to determine which tire number corresponds to the wheel whose tire pressure has changed. NOTE: It may take approximately one minute that the data of tire pressure change is displayed on the scan tool screen. If the data of tire pressure change is not displayed on the scan tool screen, the most possible cause is that the radio wave sent from the TPMS transmitter cannot be received. In this case, the radio wave may be received by performing the procedures from (1) again after turning the tire to change the TPMS transmitter position. If the tire pressure change is still not displayed on the scan tool screen, the TPMS transmitter in which the ID code is not registered may be installed, or the TPMS transmitter may be faulty. Therefore, perform ID code registration or replace the TPMS transmitter according to the instructions of troubleshooting for DTCs. (At this time, do not register the ID codes or replace the TPMS transmitter.)
  3. Check the tire pressure or acceleration value shown in the screen (if needed).
  4. After checking by the tire pressure change, adjust the checked tire pressure to the proper value.

"Tire Pressure Sensor ID Check" METHOD

  1. Select "Tire Pressure Sensor ID Check".
  2. Check the registered TPMS transmitter IDs on the scan tool screen.

REGISTRATION NOT USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY) < USA ONLY >

When the ignition key is lost or additional keys are requested, the ignition key must be used to register key ID.

CAUTIONTwo ignition keys that have been registered are needed.

Scheme 35

Scheme 35
Scheme 35
  1. Turn the ignition switch to the "ON" position using the registered ignition key and keep it there for 5 seconds.
  2. Turn the ignition switch to the "LOCK" (OFF) position, and remove the registered ignition key.
  3. Within 30 seconds after the ignition key is removed, insert the other registered ignition key that has already been registered and turn the ignition switch to the "ON" position.
  4. The immobilizer indicator starts flashing in approximately 10 seconds after the ignition switch is turned to the "ON" position.
  5. When the immobilizer indicator starts flashing, turn the ignition switch to the "LOCK" (OFF) position and remove the ignition key. NOTE: When an error occurs while the immobilizer indicator is flashing, the immobilizer indicator extinguishes.
  6. Within 30 seconds after the immobilizer indicator flashes in Step 5 , insert the ignition key to be added and turn the ignition switch to the "ON" position.
  7. When registering another ignition key, repeat the procedure from the beginning. NOTE: < When the additional ignition key cannot be registered > When the immobilizer indicator is not illuminated during registration When the immobilizer indicator does not change in 3 seconds after carrying out step 6 < When the additional registration of the ignition key terminates automatically > When 30 seconds have passed before inserting the ignition key in Step 3 after the ignition key is removed in Step 2 . When 30 seconds have passed after the immobilizer indicator flashed

KEYLESS ID NOT USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY) < USA ONLY >

When the keyless ID code is already registered in the transmitter, the keyless ID code can be registered without using the scan tool MB991958 (M.U.T.-III sub assembly) according to the following procedures.

  1. Prepare all the transmitters for ID code registration before starting the operation.
  2. Press the unlock button of the transmitter in which the keyless ID code is registered.
  3. After pressing the unlock button, press the lock button within 4 seconds to less than 10 seconds.
  4. Release the lock button within 10 seconds after pressing it.
  5. Release the unlock button 0.5 seconds after releasing the lock button. NOTE: The WCM erases the keyless ID codes of the transmitters other than the operated transmitter. NOTE: The WCM sets the transmitter registration number to 1.
  6. When the operations from Step 1 to Step 4 are completed, the door can be locked or unlocked, and the mode shifts to the customer-programming mode. Within 1 minute after the mode shifted to the customer-programming mode, the signal for registration is transmitted from the transmitter to be added. NOTE: How to transmit the transmitter registration signal Press the lock button and the unlock button of the transmitter to be added for 1 second or more simultaneously. Release the lock button and the unlock button simultaneously. After releasing the lock button and unlock button simultaneously, when 0.5 seconds or more has elapsed, press the unlock button. NOTE: The WCM receives the registration signal, and stores the keyless ID code of the transmitter. NOTE: The WCM adds the transmitter registration number by 1.
  7. When the operation of Step 5 is finished, the door can be locked or unlocked to notify that the transmitter registration is completed.
  8. To register another transmitter, repeat the operation of Step 5 within 1 minute after the previous transmitter registration.
  9. The customer-programming mode is terminated by any of the following conditions. When the registration of 8 transmitters are completed When 1 minute has elapsed without registration after the shift to the customer-programming mode when 1 minute has elapsed after previous transmitter registration When the engine speed is more than 200 RPM The EEPROM abnormality occurs [When the EEPROM abnormality occurs during the transmitter registration, delete all the transmitters stored (including the transmitters used for the shift to the customer-programming mode), and finish the customer-programming mode.]

TPMS TRANSMITTER CHECK

TPMS TRANSMITTER ID CHECK

KEYLESS ENTRY SYSTEM CHECK

Check the keyless entry system as described below. If it does not work, perform troubleshooting. Refer to TROUBLE SYMPTOM CHART .

  1. Operate the transmitter to check that the doors and liftgate < LANCER SPORTBACK > can be locked and unlocked.
  2. Operate the transmitter to check that the answerback function works in response to doors and liftgate < LANCER SPORTBACK > locking/unlocking. NOTE: The hazard answerback setting can be changed using the customization function. Confirm which setting is activated before performing these checks. Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__customization-function) .

INSPECTION OF KEYLESS ENTRY TIMER LOCK FUNCTION

Attempt to unlock the doors and the liftgate < LANCER SPORTBACK > by using the transmitter. If the doors and the liftgate < LANCER SPORTBACK > are not locked within 30 seconds, carry out diagnosis. Note that the doors will not be locked if the ignition key is inserted within the 30-second period, or the doors and the liftgate < LANCER SPORTBACK > are opened. Refer to TROUBLE SYMPTOM CHART .

Note. The operation time of the keyless entry timer lock function can be set using the customization function. Confirm the operation time before performing the diagnosis. Refer to CUSTOMIZATION FUNCTION .

POWER DOOR LOCKS WITH SELECTIVE UNLOCKING INSPECTION

Press the unlock button on the transmitter once to unlock only the driver's door. Press the unlock button of the transmitter once again within 2 seconds after the driver's door is unlocked, and check that the front passenger's door, rear doors, and liftgate < LANCER SPORTBACK > are unlocked. If they are not unlocked, carry out troubleshooting. Refer to TROUBLE SYMPTOM CHART .

Note. Press the unlock button on the transmitter once to unlock only the driver's door. When the unlock button of the transmitter is pressed once again more than 2 seconds after the driver's door is unlocked, only the driver's door is unlocked.

Note. The setting of the power door locks with selective unlocking can be changed using the customization function. Confirm which setting is activated before performing these checks. Refer to CUSTOMIZATION FUNCTION .

CUSTOMIZATION FUNCTION

By operating the ETACS system or MMCS of scan tool MB991958, the following functions can be programmed. The programmed information is held even when the battery is disconnected.

Adjustment item (scan tool display)Adjustment itemAdjusting contents (scan tool display)Adjusting contents
Hazard answer backAdjustment of the number of keyless hazard warning light answer back flashesLock:1, Unlock:2LOCK: Flashes once, UNLOCK: Flashes twice (initial condition)
Lock:1, Unlock:0LOCK: Flashes once, UNLOCK: No flash
Lock:0, Unlock:2LOCK: No flash, UNLOCK: Flash twice
Lock:2, Unlock:1LOCK: Flash twice, UNLOCK: Flash once
Lock:2, Unlock:0LOCK: Flash twice, UNLOCK: No flash
Lock:0, Unlock:1LOCK: No flash, UNLOCK: Flash once
Lock:0, Unlock:0No function
Door unlock modeAdjustment of power door locks with selective unlocking < Vehicles with keyless entry system >All doors unlockWithout function: The first operation of keyless entry system or unlock operation by KOS unlocks all doors.
Dr door unlockWith function: The first operation of keyless entry system or unlock operation by KOS unlocks the driver's door only, and the second unlock operation within 2 seconds after that unlocks all doors. (initial condition)
Auto door unlockAdjustment of the auto door unlock functionDisabledWithout function (initial condition) < M/T, CVT, TC-SST >
Always (P pos)With function: Operates when the shift lever or the selector lever is moved to the P position. < CVT, TC-SST >
Always(Lock pos)With function: Operates when the ignition switch is moved to the LOCK (OFF) position. < M/T, CVT, TC-SST >
Duration of horn chirpHorn sounding time during horn answer backShort0.01 second (initial condition)
Long0.02 second
Horn chirp by keylessHorn chirp by keyless entry system < vehicles without auto light >Not sound hornNo horn answerback function
Lock any timeThe horn sounds when the lock button of keyless entry transmitter is pressed once.
W lock any timeThe horn sounds when the lock button of keyless entry transmitter is pressed twice. (initial condition)
Horn chirp by keyless entry system < vehicles with auto light >Not sound hornNo horn answerback function
Lock any timeThe horn sounds when the lock button of keyless entry transmitter is pressed once.
Lock/auto ONDuring daytime, while the lighting switch is in the AUTO position, the horn sounds once when the lock is pressed once.
W lock any timeThe horn sounds when the lock button of keyless entry transmitter is pressed twice. (initial condition)
Timer lock timerTimer lock period adjustment30 sec30 seconds (initial condition)
60 sec60 seconds
120 sec120 seconds
180 sec180 seconds
Panic alarm switchWith/without panic alarm functionDisableNo function
EnableWith function (initial condition)

CUSTOMIZATION FUNCTION TABLE

Note. *: F.A.S.T. (Free-hand Advanced Security Transmitter)

REMOVAL AND INSTALLATION

CAUTIONWhen WCM has been replaced, all key ID codes should be registered, referring to the ID CODE REGISTRATION JUDGMENT TABLE .

Scheme 36

Scheme 36
Scheme 36

>> A << WCM INSTALLATION

Check that the top claw of WCM is fixed securely to the boss of steering lock and the antenna is not floated on the key cylinder.

DISASSEMBLY AND ASSEMBLY

WARNINGCoin-type lithium battery may contain perchlorate materials. Special handling may apply. For additional information, see www.dtsc.ca.gov/hazardouswaste/perchlorate.

Scheme 37

Scheme 37
Scheme 37

<< A >> UPPER COVER REMOVAL

CAUTIONTo prevent damage to the transmitter, wrap a flat-tipped screwdriver with protective tape before prying.

Insert a flat-tipped screwdriver in the area shown in the figure, and remove the upper cover by prying it with the screwdriver.

Scheme 38

Scheme 38
Scheme 38

<< B >> BATTERY REMOVAL

CAUTIONDo not allow water or dust to enter the inside of the transmitter assembly when it is open. Also, do not touch the precision electronic device. To prevent damage to the transmitter assembly, wrap a flat-tipped screwdriver with protective tape before prying.

Insert a flat-tipped screwdriver in the area shown in the figure, and remove the battery by prying it with the screwdriver.

Scheme 39

Scheme 39
Scheme 39

>> A << BATTERY INSTALLATION

CAUTIONDo not allow water or dust to enter the inside of the transmitter assembly when it is open. Also, do not touch the precision electronic device.

Install a new battery to the transmitter assembly with its (+) side facing towards the master key side.

Battery required for replacement: Coin type battery CR1620

Scheme 40

Scheme 40
Scheme 40
WARNINGCertain components of this vehicles, such as TPMS transmitters, may contain perchlorate materials. Special handling may apply. For additional information, see www.dtsc.ca.gov/hazardouswaste/perchlorate.

Scheme 41

Scheme 41
Scheme 41

<< A >> CAP/VALVE CORE/NUT REMOVAL

CAUTIONEnsure cap is always in place except when adjusting tire pressure.
  1. Remove the valve cap.
  2. Rotate tire so that valve stem is in the 6 o'clock position.
  3. Use a long-reach 17.2 mm (0.68 inch) socket to unscrew the valve nut a few turns. Slowly push valve stem into tire so that tire pressure is relieved.
  4. Once tire pressure is released, remove nut and let TPMS transmitter fall into tire.

<< B >> TPMS TRANSMITTER REMOVAL

CAUTIONBe careful not to damage the TPMS transmitter.

Scheme 42

Scheme 42
Scheme 42
  1. Place on tire changing machine and break both tire beads ensuring that the TPMS transmitter remains in the bottom of the tire.
  2. Lubricate tire well and remove outer side of the tire.
  3. Reach inside the tire and remove the TPMS transmitter.
  4. Remove tire from rim using proper tire changing equipment procedures.

<< C >> SEAL WASHER/VALVE REMOVAL

CAUTIONRemove the seal washer to prevent scratching the valve of the TPMS transmitter.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. Hold the TPMS transmitter and the seal washer, then extract the seal washer. Take care to not damage the valve thread.
  2. Clean the TPMS transmitter and the valve stem. < In case of not removing the valve > NOTE: If the valve comes out from the transmitter, install it to where it was. (This is not failure)
  3. Removal the valve from housing as shown in the figure.

>> A << VALVE/SEAL WASHER/TPMS TRANSMITTER/NUT INSTALLATION

CAUTIONInstall the seal washer to prevent scratching the valve of the TPMS transmitter.

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Install the valve to housing as shown in the figure.
  2. Insert the seal washer up to the base of the TPMS transmitter, making sure to secure the valve base with a thumb as shown in the figure. Wipe the seal and threading. CAUTION: Visually check that TPMS transmitter is not deformed or damaged. When installing the TPMS transmitter, be sure the rim, seal valve and nut are clean. Ensure the grommet is located inside the valve hole before installing the nut. While installing the nut, push the TPMS transmitter to maintain the lower lip of the transmitter case is in contact with the rim without clearance. While installing the valve nut, ensure the tool is kept aligned to the valve and the valve hole.
  3. Install the valve, in the valve hole, without modifying the angle of the stem (retain position of delivery). The laser marking should be visible at the operator.
  4. When the valve is completely inserted, maintain the TPMS transmitter in contact with the rim, then screw manually the nut until the contact with the wheel.
  5. While maintaining the TPMS transmitter contact with the rim by applying pressure to the back of the valve, slightly press on the cap to wards the center of the wheel in order to adapt the angle of the valve/TPMS transmitter to the profile of the rim. It is mandatory to guarantee the contact of the housing unit on the rim drop center.
  6. While maintaining the TPMS transmitter and valve in position, screw the nut with a torque wrench. Take care that the wrench socket is correctly inserted on the nut. Specified torque: 8.0 ± 0.5 N.m (71 ± 4 in-lb)

Scheme 52

Scheme 52: >> B << TIRE BEAD MOUNTING
Scheme 52: >> B << TIRE BEAD MOUNTING

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Prepare the tire and fix the rim as usual.
  2. Put the tire on the rim, so that the cross point of the belt with the rim is approximately 20 cm (7.9 inch) away from the valve.
  3. Engage the shoe and make sure that 20 cm (7.9 inch) is maintained between the cross point and the valve. The arrow shows the direction of rotation of the wheel.
  4. Turn the wheel in order to engage all the first side of the tire. NOTE: The standard shoes can pass over the sensor without damaging it.
  5. Put the second side of the tire in position, so that the cross point of the belt with the rim is approximately 20 cm (7.9 inch) away from the valve. The curved arrow shows the direction of rotation of the wheel.
  6. Turn the wheel in order to engage all of the second side of the tire. NOTE: The standard shoes can pass over the sensor without damaging it.

>> C << TIRE PRESSURE INFLATION/NUT RETIGHTENING

CAUTIONAfter tire inflation, retighten the valve nut to 8.0 ± 0.5 N.m (71 ± 4 in-lb). This is necessary, because the TPMS transmitter is secured to the wheel with the valve nut and rubber grommet. The rubber grommet will be depressed by tire pressure or deteriorate over a period of time, which requires the valve nut to be retightened.

Inflate tire to required pressure, then retorque the valve nut to 8.0 ± 0.5 N.m (71 ± 4 in-lb).

See also:
• TROUBLESHOOTING CONTENTS
• HOW TO COPE WITH INTERMITTENT MALFUNCTIONS
• HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING
• C1900
• C1901
• C1912
• C1915
• U1412
• DIAGNOSIS
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• HARNESS CONNECTOR INSPECTION
• DIAGNOSIS
• DIAGNOSTIC TROUBLE CODE DIAGNOSIS
• CAN COMMUNICATION-RELATED DTC (U-CODE) TABLE
• CAN BUS DIAGNOSTICS TABLE
• DIAGNOSTIC TROUBLE CODE CHART
• HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)
• DIAGNOSTIC TROUBLE CODE CHART < SRS-ECU >
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSTIC TROUBLE CODE CHART
• DIAGNOSIS
• DIAGNOSTIC TROUBLE CODE CHART
• BATTERY TEST
• MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT
• TROUBLE SYMPTOM CHART
• INSPECTION PROCEDURE 1: THE HAZARD WARNING LIGHT DO NOT ILLUMINATE
• INSPECTION PROCEDURE 1: THE FRONT DOME LIGHT DOES NOT ILLUMINATE NORMALLY
• INSPECTION PROCEDURE 2: THE REAR DOME LIGHT DOES NOT ILLUMINATE NORMALLY
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• ID CODES REGISTRATION PROCEDURE
• ID CODES REGISTRATION PROCEDURE
• B1731
• B1761
• B1A08
• B1A10
• B1A24
• B1A25
• B1A28
• B1A35
• B2204
• B2401
• C1608
• C1900
• C1901
• C1912
• C1910
• C1913
• C1915
• U0019
• U0141
• U0151
• U0154
• U0155
• U0164
• U0184
• U0195
• U0245
• U1412
• U1415
• U1417
• ID CODES REGISTRATION JUDGMENT TABLE
• DATA LIST REFERENCE TABLE
• REGISTRATION USING SCAN TOOL MB991958 (M.U.T.-III SUB ASSEMBLY)
• HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)
• INSPECTION PROCEDURE 1: SCAN TOOL CANNOT COMMUNICATE WITH WCM.
• INSPECTION PROCEDURE 4: ABNORMALITY IN WCM POWER SUPPLY AND GROUND CIRCUITS.
• INSPECTION PROCEDURE 5: KEYLESS ENTRY SYSTEM DOES NOT WORK.
• INSPECTION PROCEDURE 6: KEYLESS ENTRY HAZARD LIGHT ANSWERBACK FUNCTION, THE DOME LIGHT ANSWERBACK FUNCTION OR THE HORN ANSWERBACK FUNCTION DOES NOT WORK NORMALLY.
• INSPECTION PROCEDURE 7: THE TIMER LOCK FUNCTION DOES NOT WORK AFTER THE DOORS HAVE BEEN UNLOCKED BY THE KEYLESS ENTRY SYSTEM.
• INSPECTION PROCEDURE 8: THE TRUNK IS NOT OPENED WHEN THE KEYLESS ENTRY TRANSMITTER "TRUNK" BUTTON IS OPERATED < LANCER >.
• INSPECTION PROCEDURE 9: POWER DOOR LOCKS WITH SELECTIVE UNLOCKING DOES NOT WORK.
• STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING
• DIAGNOSTIC TROUBLE CODE CHART
• CUSTOMIZATION FUNCTION
• TROUBLE SYMPTOM CHART

More articles — Accessories & Equipment
