Front Seat Assembly - Evolution Mitsubishi Lancer Evolution VIII

Seats 3 illustrations

Scheme 30

Scheme 30: REMOVAL AND INSTALLATION

Scheme 30: REMOVAL AND INSTALLATION

>> A << FRONT SEAT ASSEMBLY INSTALLATION

Temporarily tighten the nuts and bolts in all mounting locations shown in the illustration with no load applied to the front seat cushion, and check the operation of the seat slide.
Tighten the nuts and bolts in all mounting locations to the specified torque.

Scheme 31

Scheme 31

Scheme 31

Scheme 32

Scheme 32: DISASSEMBLY AND ASSEMBLY

Scheme 32: DISASSEMBLY AND ASSEMBLY

FASTENER TIGHTENING SPECIFICATION

ITEM	SPECIFICATION
TRIMS
Child restraint fitting bolt	22 ± 4 N.m (16 ± 3 ft-lb)
FRONT SEAT ASSEMBLY
Seatback assembly bolt	22 ± 3 N.m (16 ± 2 ft-lb)
Front seat assembly bolt	45 ± 10 N.m (34 ± 7 ft-lb)
Front seat assembly nut	30 ± 5 N.m (22 ± 4 ft-lb)
Slide adjuster inner bolt	22 ± 3 N.m (16 ± 2 ft-lb)
Slide adjuster outer bolt	22 ± 3 N.m (16 ± 2 ft-lb)
REAR SEAT ASSEMBLY
Rear seatback assembly bolt	22 ± 4 N.m (16 ± 3 ft-lb)
FRONT SEAT BELT
Adjustable seat belt anchor bolt	44 ± 10 N.m (33 ± 7 ft-lb)
Inner seat belt bolt	44 ± 10 N.m (33 ± 7 ft-lb)
Outer seat belt bolt	44 ± 10 N.m (33 ± 7 ft-lb)
REAR SEAT BELT
Center seat blet, inner bolt	44 ± 10 N.m (33 ± 7 ft-lb)
Center seat belt, outer bolt	44 ± 10 N.m (33 ± 7 ft-lb)
Inner seat belt bolt	44 ± 10 N.m (33 ± 7 ft-lb)
Outer seat belt bolt	44 ± 10 N.m (33 ± 7 ft-lb)

Fastener Tightening Torque Specification
