REMOVAL SERVICE POINT
- Disengage claw A and lower the cover in the arrow 1 direction.
- Push claw B in the arrow 2 direction to unlock, and pull out the mirror in the arrow 3 direction.
Scheme 78
FASTENER TIGHTENING SPECIFICATION
| ITEM | SPECIFICATION |
|---|---|
| TRIMS | |
| Child restraint fitting bolt | 22 ± 4 N.m (16 ± 3 ft-lb) |
| FRONT SEAT ASSEMBLY | |
| Seatback assembly bolt | 22 ± 3 N.m (16 ± 2 ft-lb) |
| Front seat assembly bolt | 45 ± 10 N.m (34 ± 7 ft-lb) |
| Front seat assembly nut | 30 ± 5 N.m (22 ± 4 ft-lb) |
| Slide adjuster inner bolt | 22 ± 3 N.m (16 ± 2 ft-lb) |
| Slide adjuster outer bolt | 22 ± 3 N.m (16 ± 2 ft-lb) |
| REAR SEAT ASSEMBLY | |
| Rear seatback assembly bolt | 22 ± 4 N.m (16 ± 3 ft-lb) |
| FRONT SEAT BELT | |
| Adjustable seat belt anchor bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Inner seat belt bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Outer seat belt bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| REAR SEAT BELT | |
| Center seat blet, inner bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Center seat belt, outer bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Inner seat belt bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
| Outer seat belt bolt | 44 ± 10 N.m (33 ± 7 ft-lb) |
