REMOTE CONTROLLED MIRROR OPERATION
The mirror on the door mirror moves up/down and left/right by operating the remote controlled door mirror switch when the ignition switch is in the "ON" or "ACC" position.
Scheme 70
Scheme 71
Required Special Tool
- MB990784: Ornament Remover
<< A>> MIRROR REMOVAL
Push the top of the mirror with your hand to tilt it and attach the protective tape as shown in the illustration. Then insert a flat-tipped screwdriver in between the notch at the rear of the mirror and the pivot plate, and disengage the bottom of the mirror.
Scheme 72
>> A<< MIRROR INSTALLATION
While supporting the clip position on the underside of the pivot plate with a flat-tipped screwdriver, press the clip at the front of the mirror to engage the bottom of the mirror.
Scheme 73
ELECTRIC REMOTE CONTROLLED MIRROR OPERATION CHECK
Check that the mirror moves as described in the table when each terminal is connected to the battery.
Scheme 74
| BATTERY CONNECTION | DIRECTION OPERATION |
|---|---|
| Connect terminal 1 to the negative battery terminal. Connect terminal 3 to the positive battery terminal. | Up |
| Connect terminal 3 to the negative battery terminal. Connect terminal 1 to the positive battery terminal. | Down |
| Connect terminal 1 to the negative battery terminal. Connect terminal 2 to the positive battery terminal. | Right |
| Connect terminal 2 to the negative battery terminal. Connect terminal 1 to the positive battery terminal. | Left |
BATTERY CONNECTION SPECIFICATIONS
DOOR MIRROR CONTROL SWITCH CONTINUITY CHECK
| SWITCH POSITION | TESTER CONNECTION | SPECIFIED CONDITION | |
|---|---|---|---|
| OFF | 9 - 2, 9 - 3, 9 - 6, 9 - 10, 9 - 11, 1 - 2, 1 - 3, 1 - 6, 1 - 10, 1 - 11 | Open circuit | |
| Left side | OFF | 9 - 6, 9 - 10, 9 - 11, 1 - 6, 1 - 10, 1 - 11 | Open circuit |
| Up | 1 - 6, 9 - 11 | Less than 2 ohms | |
| Down | 1 - 11, 6 - 9 | ||
| Right | 1 - 6, 9- 10 | ||
| Left | 1 - 10, 6 - 9 | ||
| Right side | OFF | 9 - 2, 9 - 3, 9 - 6, 1 - 2, 1 - 3, 1 - 6 | Open circuit |
| Up | 1 - 6, 3 - 9 | Less than 2 ohms | |
| Down | 1 - 3, 6 - 9 | ||
| Right | 1 - 6, 2 - 9 | ||
| Left | 1 - 2, 6 - 9 | ||
SWITCH SPECIFICATIONS
Scheme 75
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Rear spoiler | |
| Rear spoiler assembly bolt and nut | 5.2 +/- 0.2 N.m (46 +/- 2 in-lb) |
| Windshield wiper and washer | |
| Wiper arm and blade assembly nut | 27 +/- 3 N.m (20 +/- 2 ft-lb) |
| Wiper link assembly bolt | 7.4 +/- 1.4 N.m(65 +/- 13 in-lb) |
| Wiper motor bolt | 8.9 +/- 1.9 N.m (79 +/- 17 in-lb) |
| Washer tank assembly bolt | 5.0 +/- 1.0 N.m (44 +/- 9 in-lb) |
| Rear wiper and washer | |
| Nozzle and collar assembly nut | 9.8 +/-2.0 N.m (87 +/- 17 in-lb) |
| Wiper arm and blade assembly nut | 7.4 +/-1.4 N.m (65 +/- 13 in-lb) |
| Wiper motor bolt | 7.4 +/- 1.4 N.m (65 +/- 13 in-lb) |
FASTENER TIGHTENING SPECIFICATIONS
SERVICE SPECIFICATIONS
| ITEM | STANDARD VALUE |
|---|---|
| Windshield wiper blade park position mm (in) | 34 +/- 5 (1.3 +/- 0.20) |
| Rear wiper blade park position mm (in) | 38 +/- 5 (1.5 +/- 0.20) |
SERVICE SPECIFICATIONS
ADHESIVES
| ITEM | SPECIFICATION |
|---|---|
| Front three-diamond mark | Adhesive tape: Double-sided tape 20 mm (0.79 in) width and 0.8 mm (0.03 in) thickness |
| Side air dam assembly | Adhesive tape: Double-sided tape 5 mm (0.20 in) width and 1.2 mm (0.05 in) thickness |
| Rear spoiler assembly | Adhesive tape: Double-sided tape 5 mm (0.2 in) width and 0.8 mm (0.03 in) thickness and 5 mm (0.2 in) width and 1.6 mm (0.06 in) thickness |
ADHESIVE SPECIFICATIONS
COMPONENT IDENTIFICATIONS
| APPLICABLE LOCATION | IDENTIFICATION COLOR |
|---|---|
| Drip molding clip A | Yellow |
| Drip molding clip B | Blue |
| Drip molding clip C | Milky white |
| Front drip molding clip A | Orange |
| Front drip molding clip B | Purple |
| Front drip molding clip C | Blue |
| Rear drip molding clip | Gray |
COMPONENT IDENTIFICATION
