IGNITION KEY REMINDER TONE ALARM
The ignition key reminder tone alarm will sound under the following condition, and warm the driver to remove the ignition key.
IGNITION SWITCH DIAGNOSIS
The ignition key reminder torn alarm is controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to SWS DIAGNOSIS .
- The driver's door is opened when the ignition switch is at "LOCK" (OFF) or "ACC" position with out removing the ignition key.
However, the light reminder tone alarm will take precedence over this function.
Scheme 1
REMOVAL AND INSTALLATION
| WARNING | Before removal of the air bag module, refer to AIR BAG SAFETY PRECAUTIONS . When removing and installing the steering wheel, do not let it bump against the air bag module. |
Scheme 2
Scheme 3
- Insert the key into steering lock cylinder to turn the ignition key to the "ACC" position.
- Insert the locking pin with a small crosstipped screwdriver, etc., and remove the steering lock cylinder.
IGNITION SWITCH CONTINUITY CHECK
Disconnect ignition switch connector C-201 without removing the ignition switch and steering lock cylinder. Then check the continuity.
Scheme 4
Scheme 5
KEY REMINDER SWITCH CONTINUITY CHECK
Ignition key reminder switch continuity check.
Disconnect key reminder switch connector C-202 without removing the ignition switch and steering lock cylinder. Then check the continuity.
Scheme 6
Scheme 7
