Keyless Entry System - Evolution Mitsubishi Lancer Evolution VIII

GENERAL DESCRIPTION

The keyless entry system is equipped to GSR as standard and optionally equipped to RS.

The main features are

1. Antenna and receiver are incorporated in the ETACS-ECU.
2. ID code can be registered by using the scan tool MB991958 (MUT-III sub assembly).
3. Transmitter is a key holder type, which incorporates lock button and unlock button.

KEYLESS ENTRY SYSTEM DIAGNOSIS

The keyless entry system is controlled by the Simplified Wiring System (SWS). For troubleshooting, refer to GENERAL DESCRIPTION .

1. The locking is answered back by two times' flashing of the doom light, two times' flashing of the turn signal lights and one time sounding of the horn answerback.

Scheme 95

HOW TO REPLACE THE TRANSMITTER BATTERY

1. Remove the set screw to remove the battery from the transmitter.
2. Install a battery with its (+) side face-down. Battery required for replacement: Coin type battery CR2032
3. Insert the claw first, and assemble the transmitter.
4. Verify that the keyless entry system operates.

Scheme 96

KEYLESS ENTRY SYSTEM TIMER LOCK FUNCTION INSPECTION

Press the "UNLOCK" button on the transmitter and do not open any doors. The doors should relock within 30 seconds. If not, troubleshoot. Refer to SWS DIAGNOSIS .

ENABLING/DISABLING THE ANSWERBACK FUNCTION

Required Special Tools

1. MB991529: Diagnostic trouble code check harness
2. MB991958: Scan Tool (MUT-III Sub Assembly)

1. MB991824: Vehicle Communication Interface (V.C.I.)
2. MB991911: MUT-III Main Harness B

If the keyless entry system locks or unlocks the doors, the dome light flashes or illuminates, the hazard warning light flashes (hazard answerback function) and the horn sounds (horn answerback function). The hazard and horn answerback functions can be enabled or disabled according to the following procedure

ENABLING/DISABLING THE HAZARD ANSWERBACK FUNCTION

The hazard answerback function can be enabled or disabled by one of the two procedures, refer to < WHEN THE TRANSMITTER IS USED AFTER GROUNDING DATA LINK CONNECTOR TERMINAL 1> or < WHEN THE TRANSMITTER IS USED AFTER CONNECTING THE SPECIAL TOOL MB991824 (V.C.I.) TO THE DATA LINK CONNECTOR> .

< WHEN THE TRANSMITTER IS USED AFTER GROUNDING DATA LINK CONNECTOR TERMINAL 1>

1. Enter the hazard answerback customize mode by observing one of the following steps. If the ETACS-ECU enters the customize mode, its tone alarm will sound once. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then connect data link connector terminal 1 to ground. Connect the data link connector terminal 1 to ground. Close the driver's side door. Leave the windshield washer switch on for at least ten seconds. Then the ETACS-ECU tone alarm will sound once.
2. If the transmitter "LOCK" button is pushed consecutively twice within two seconds, the ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the doors are locked. Enable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound once. Disable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound twice.
3. If the transmitter "UNLOCK" button is pushed consecutively twice within two seconds, the ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the doors are unlocked. Enable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound once. Disable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound twice.
4. Exit the hazard answerback customize mode by observing one of the following steps.

1. Disconnect data link connector terminal 1 from ground.
2. Turn the ignition switch to position other then "LOCK" (OFF), or remove the ignition key.
3. Open the driver's side door

Note. If any operation is not done for at least three minutes after the ETACS-ECU has entered the customize mode, the hazard answerback customize mode will be canceled automatically.

Scheme 97

< WHEN THE TRANSMITTER IS USED AFTER CONNECTING THE SPECIAL TOOL MB991824 (V.C.I.) TO THE DATA LINK CONNECTOR>

1. Enter the hazard answerback customize mode by observing one of the following steps. If the ETACS-ECU enters the customize mode, its tone alarm will sound once. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then connect special tool MB991824 (V.C.I.) to the data link connector. Connect the special tool MB991824 (V.C.I.) to the data link connector. Close the driver's side door. Leave the windshield washer switch on for at least ten seconds. Then the ETACS-ECU tone alarm will sound once.
2. If the transmitter "LOCK" button is pushed consecutively twice within two seconds, the ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the doors are locked. Enable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound once. Disable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound twice.
3. If the transmitter "UNLOCK" button is pushed consecutively twice (within two seconds), the ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the doors are unlocked. Enable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound once. Disable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound twice.
4. Exit the hazard answerback customize mode by observing one of the following steps.

1. Disconnect special tool MB991824 (V.C.I.) from the data link connector.
2. Turn the ignition switch to position other then "LOCK" (OFF), or remove the ignition key.
3. Open the driver's side door

Note. If any operation is not done for at least three minutes after the ETACS-ECU has entered the customize mode, the hazard answerback customize mode will be canceled automatically.

Scheme 98

< HOW TO ADJUST HAZARD ANSWERBACK WHEN THE TRANSMITTER IS USED TO LOCK DOORS>

1. Remove the ignition key.
2. Push the "UNLOCK" button and then push the "LOCK" button within 4 seconds to 10 seconds.
3. Release the "LOCK" button within 10 seconds after Step 2 and then release the "UNLOCK" button. The ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the doors are unlocked.

1. Enable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound once.
2. Disable the hazard answerback function when the doors are locked: The ETACS-ECU tone alarm will sound twice.

< HOW TO ADJUST HAZARD ANSWERBACK WHEN THE TRANSMITTER IS USED TO UNLOCK DOORS>

1. Remove the ignition key.
2. Push the "UNLOCK" button and then push the "LOCK" button within 4 seconds to 10 seconds.
3. Release the "LOCK" button within 10 seconds after Step 2 and then release the "UNLOCK" button. The ETACS-ECU tone alarm will sound, indicating that the hazard answerback function can be enabled or disabled when the door are unlocked.

1. Enable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound once.
2. Disable the hazard answerback function when the doors are unlocked: The ETACS-ECU tone alarm will sound twice.

ENABLING/DISABLING THE HORN ANSWERBACK FUNCTION

1. Remove the ignition key.
2. Push the "UNLOCK" button and then push the "LOCK" button within 4 seconds to 10 seconds.
3. Release the "LOCK" button within 10 seconds after Step 2 and then release the "UNLOCK" button. The ETACS-ECU tone alarm will sound, indicating that the horn answerback function can be enabled or disabled.

1. Enable the horn answerback function*: The ETACS-ECU tone alarm will sound once.
2. Disable the horn answerback function: The ETACS-ECU tone alarm will sound twice.
3. Enable the horn answerback function**: The ETACS-ECU tone alarm will sound three times.

Note. *: The horn will sound if "LOCK" button is pressed with the doors locked. The horn will sound if the doors are locked with the keyless entry system.

HOW TO REGISTER SECRET CODE

Required Special Tools

1. MB991529: Diagnostic trouble code check harness
2. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991911: MUT-III Main Harness B Each individual secret code is registered inside the transmitter, and so it is necessary to register these codes with the EEPROM inside the receiver in the following cases.
3. When the transmitter or ETACS-ECU is replaced
4. If more transmitters are to be used
5. If it appears that a problem is occurring because of faulty registration of a code.

A maximum of four different codes can be stored in the EEPROM memory (four different transmitters can be used). When the code for the first transmitter is registered, the previously registered codes for all transmitters are cleared. Therefore, if you are using four transmitters or are adding more transmitters, the codes for all transmitters must be registered at the same time.

Scheme 99

1. Insert the ignition key into the key cylinder and check that the doors have been locked normally when the ignition key is turned.
2. Insert the ignition key into the key cylinder. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then connect data link connector terminal 1 to ground.
3. Connect the data link connector terminal 1 to ground. NOTE: Connecting terminal 1 of the data link connector to ground will put the system in secret code registration standby mode.
4. Push the hazard warning light switch six times within 10 seconds. NOTE: At this time the code registration monitor request is out- ) put and becomes registration mode (all doors locked and then all doors unlocked). The hazard warning light switch is turned on and off alternately whenever it is pushed.
5. Press the transmitter button, and then press it two times within 10 seconds of the first press. This will register the code.
6. When registration is completed, the code registration monitor request is output (all doors locked and then all doors unlocked).
7. If you are using two or more transmitters or have added a second transmitter, the same registration procedure should be carried out within one minute after registering the code for the first transmitter. After the second registration is completed, the code registration monitor request is output (all doors locked and then all doors unlocked).
8. Registration mode will be canceled under the following conditions: When the secret code for four transmitters has been registered; When one minute has passed after registration mode started; When the data link connector terminal 1 to ground is disconnected; When the ignition key is removed from the ignition key cylinder
9. After the registration is completed, carry out the following. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then disconnect data link connector terminal 1 from ground.
10. Disconnect data link connector terminal 1 from ground.
11. Remove the ignition key from ignition key cylinder.
12. Close all of the doors.
13. Verify the keyless entry system operates normally.

Scheme 100

Scheme 101

Scheme 102

1. Insert the ignition key into the key cylinder and check that the doors have been locked normally when the ignition key is turned.
2. Insert the ignition key into the key cylinder. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then connect special tool MB991824 (V.C.I.) to the data link connector.
3. Connect special tool MB991824 (V.C.I.) to the data link connector.
4. Within 10 seconds after turning the V.C.I, power supply switch to the "ON" position, push the hazard warning light switch six times. NOTE: At this time the code registration monitor request is sent and becomes registration mode (all doors locked and then all doors unlocked). The hazard warning light switch is turned ON and OFF alternately whenever the hazard warning light switch is pushed.
5. Press the transmitter button, and then press it two times within 10 seconds of the first press. This will register the code.
6. When registration is completed, the code registration monitor request is sent (all doors locked and unlocked).
7. If you are using two or more transmitters or have added a second transmitter, the same registration procedure should be carried out within one minute after registering the code for the first transmitter. After the second registration is completed, the code registration monitor request is sent (all doors locked and unlocked).
8. Registration mode will be canceled under the following conditions: When the secret code for four transmitters has been registered; When one minute has passed after registration mode started; When special tool MB991824 (V.C.I.) is disconnected from the data link connector When the ignition key is removed from the ignition key cylinder
9. After the registration is completed, carry out the following work. CAUTION: Turn the ignition switch to the "LOCK" (OFF) position and then disconnect special tool MB991824 (V.C.I.) from the data link connector.
10. Disconnect special tool MB991824 (V.C.I.) from the data link connector.
11. Remove the ignition key from ignition key cylinder.
12. Close all of the doors.
13. Verify the keyless entry system operates normally.
