WHEN USING THE ABS WARNING LIGHT Mitsubishi Lancer Evolution VIII

Anti-Lock Braking System (ABS) - Except Evolution & Sportback 4 illustrations ~196 words

WHEN USING THE ABS WARNING LIGHT

Required Special Tool

  1. MB991529: Diagnostic Trouble Code Check Harness

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126

Scheme 127

Scheme 127
Scheme 127
  1. Turn the ignition switch to the "LOCK" (OFF) position.
  2. Use special tool MB991529 to ground terminal number 1 (diagnostic control terminal) of the data link connector.
  3. Turn the ignition switch to the "ON" position.
  4. Read out a diagnostic trouble code by observing how the ABS warning light flashes.
  5. Turn the ignition switch to the "LOCK" (OFF) position.
  6. Disconnect special tool MB991529.

Required Special Tools

  1. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicle Communication interface (V.C.I.) MB991827: MUT-III USB Cable MB991911: MUT-III Main Harness B (Vehicles without CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

Scheme 128

Scheme 128
Scheme 128
  1. Connect scan tool MB991958 to the data link connector.
  2. Turn the ignition switch to the "ON" position.
  3. Select "Interactive Diagnosis" from the start-up screen.
  4. Select "System select."
  5. Choose "ABS" from the "CHASSIS" tab.
  6. Select "MITSUBISHI."
  7. Select "Diagnostic Trouble Code."
  8. If a DTC is set, it is shown.
  9. Choose "DTC erase" to erase the DTC.
