TROUBLESHOOTING HINTS Mitsubishi Lancer Evolution VIII

Anti-Lock Braking System (ABS) - Except Evolution & Sportback 5 illustrations ~303 words

TROUBLESHOOTING HINTS

The most likely causes for DTC is to set are

  1. Malfunction of battery
  2. Damaged wiring harness and connector
  3. Malfunction of hydraulic unit and ABS-ECU

Required Special Tools

  1. MB991223: Harness Set
  2. MB991958: Scan Tool (MUT-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: MUT-III USB Cable MB991911: MUT-III Main Harness B (Vehicles without CAN communication system)
  3. MB991529: Diagnostic Trouble Code Check Harness

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155
  1. STEP 1. Check the battery. Refer to «BATTERY - EXCEPT EVOLUTION & SPORTBACK»(/mitsubishi/lancer-evolution/viii-2003-2005/remont/charging-system/#battery-except-evolution-sportback) . Q: Is the battery damaged? YES: Charge or replace the battery and then go to Step 4 . NO: Go to Step 2.
  2. STEP 2. Check the charging system. Refer to «GENERATORS & REGULATORS - EXCEPT EVOLUTION & SPORTBACK»(/mitsubishi/lancer-evolution/viii-2003-2005/remont/charging-system/#generators-regulators-except-evolution-sportback) . Q: Is the charging system damaged? YES: Repair the Charging System and then go to Step 4 . NO: Go to Step 3.
  3. STEP 3. Check the harness wires between junction block connector C-211 terminal 2 and ABS-ECU connector B-118 terminal 20. NOTE: After inspecting intermediate connector C-210 and C-122, inspect the wire. If intermediate connector C-210 and C-122 is damaged, repair or replace it. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/viii-2003-2005/remont/oem-general-information/#general-electrical-except-evolution-sportback) . If the connector has been repaired or replaced, go to Step 4. Q: Is the harness wire between junction block connector C-211 terminal 2 and ABS-ECU connector B-118 terminal 20 damaged? YES: Repair it and go to Step 4. NO: Repair the hydraulic unit (integrated with ABS-ECU) and then go to Step 4.
  4. STEP 4 Recheck for diagnostic trouble code. Q: Does DTC 16 reset? YES: Start over at Step 1 . NO: The procedure is complete.

Scheme 156

Scheme 156: Stoplight Switch Circuit
Scheme 156: Stoplight Switch Circuit

Scheme 157

Scheme 157
Scheme 157

The "ON" signal when the brake pedal is pressed or the "OFF" signal when the brake pedal is released is input to the ABS-ECU (terminal 3).
